Optex Accurance-3D A3001CB Manual

Anti-Tailgate & Anti-Piggyback Sensor System
Model : Control Box A3001CB
: TOF Sensor A3001S
Instruction guide
(Version 0.01)

i
Before your operation
Read this instruction guide carefully prior to installation and operation.
After reading, store this guide carefully in an easily accessible place for reference.
 Pictorial indication
This guide uses the following warning indications for correct use of the project, harm to you or other people
and damage to your assets, which are described below. Be sure to understand the description before
reading the rest of this guide.
Failure to follow the instruction guide provided with this indication and improper
handling may cause death or serious injury.
Failure to follow the instruction guide provided with this indication and improper
handling may cause injury and/or property damage.
This symbol represents important notes
This symbol indicates prohibition.
This symbol indicates mandatory actions.
Document disclaimer
Please read carefully the following instructions for installation, wiring and setting.
Follow the instructions below to reduce the risk of fire or electrical shock.
Do not turn on the power during installation.
Connect wires into the terminal blocks firmly. If the connection is not firm
or comes off, it may cause a fire.
Do not use the products beyond the specifications on power or power
consumption. If the product is in use under such irregular environment, it
may cause a fire or electric shock.
Stop using the product when there is smoke or a strange smell coming
from it or when it fell down or damaged.
Do not use the products beyond the specifications; otherwise, it may
cause a fire or electric shock by a short circuit or heat.
Do not wash or insert anything into the product.
Do not put anything over the product in use. It may generate heat and
burn the inside; therefore, it may cause a fire or electric shock.
Never attempt to disassemble or repair the product.
It may cause fire or damage to the devices.
To reduce the risk of injury
Check if the products (detection unit and control box) are mounted firmly
and periodically. If the mounting plate or screws rust, those may fall of and
injure a person(s).
Do not touch the unit base or power terminals of the product with a wet
hand (do not touch when the product is wet with rain, etc.).
It may cause electric shock.
CAUTION
WARNING
WARNING

ii
To reduce the risk of injury
Be careful with your fingers when closing the cover of the control box.
To reduce the risk of failure.
Do not use the products under environments with extreme humidity, oil,
smoke, dust and any severe vibration.
Do not stand or put any heavy objects on the products.
To reduce the risk of performance degradation.
Use the specified wires.
Make sure there are no objects next to the product, which may interfere to
the performance, such as an emergency light.
The product is designed only for interior usage; inside building, so do not
use it outside.
Do not install the product in height beyond the specification. This may
decrease the performance.
Do not touch the window of detection unit. This may reduce the detection
performance.
Do not spray any chemical products on the products, such as thinner,
benzine, an air freshner or insect spray.
Inform a building owner or facility manager
Inform a building owner or facility manager of the following instruction, [Warning], [Caution] for proper
operation and ask them to follow.
Follow the instructions below to reduce the risk of fire or electric shock
Stop using the product when there is smoke or a strange smell coming
from it.
Do not wash or insert any objects in the products.
Do not break down and modify, and repair the products.
To reduce the risk of performance degradation.
Please contact the installing company when the detection units are moved
or the installed location is changed after the delivery. Otherwise, the
product does not work properly. (However, the control box may be
moved.)
If the window of detection unit is dirty, it may reduce the detection
performance. Use a neutral detergent and clean the unit.
Do not use alkaline, acid detergent, or thinner.
Do not paint the products.
CAUTION
WARNING
CAUTION

iii
Precautions
This product can only be incorporated with certain specific conditions in case that outward opening
interlock door and door opening width 1,000mm max.
TOF Sensor is celling mount and please install the front of TOF Sensor horizontally downward
Note that the product does not prevent unauthorized entry physically. It must be used under restrictions of
the product as mentioned in the instruction guide.
Install the product properly according to required local regulations or guidelines.
Do not connect a fire alarm or smoke detector to this product.
The product is designed to register only and therefore not to prevent property loss and casualty, or physical
damage.
Please note that the manufacturer and distributors are not liable for any densification by any damages.
This product may not detect properly an object(s) under certain specific conditions in case that
definitely at the place where the ground such as slopes is not level and the place with the unevenness
by unusual behavior of a person or persons
with a cart or trolley, or large baggage or an umbrella
a poster or an sign paper on the door or on the wall
Copyright
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Software licensed based on GNU General Public License (GPL) is included in this product. We obtain
a source code of the software concerned and, according to GPL reproduce it and distribute it and can
modify the visitor. Please contact us for the open source code using with this product.
Copyrighted (C) 2015 OPTEX.CO,.LTD

iv
Definition of terms
The following terms are important to know in order that the product works properly.
Secured area
Area with entry limitation by an authorization device.
Interlock area
Area in interlock.
Non-secured area
Area with no entry restrictions
Tailgating
Unauthorized person is following an authorized person into the Interlock area.
Piggybacking
Unauthorized person is hugging an authorized person or actually on authorized person’s back into the
Interlock area.
Inward opening
Door opening into the interlock area
Outward opening
Door opening into out of the interlock area
Door open
Status that the door is open, or a signal of the status “Door open”
Door close
Status that the door is close, or a signal of the status “Door close”

v
Table of contents
Before your operation.................................................................................................................................i
Pictorial indication...............................................................................................................................i
Document disclaimer..................................................................................................................................i
Inform a building owner or facility manager...............................................................................................ii
Precautions .............................................................................................................................................. iii
Copyright........................................................................................................................................... iii
Definition of terms ....................................................................................................................................iv
1Introduction...........................................................................................................................................7
1-1 Features..............................................................................................................................................7
1-2 Contents..............................................................................................................................................7
Control Box A3001CB........................................................................................................................7
TOF Sensor A3001S..........................................................................................................................8
1-3 System example for A3001 .................................................................................................................8
1-4 Part Names.........................................................................................................................................9
Control box.........................................................................................................................................9
TOF sensor......................................................................................................................................10
2Mounting and wiring ...........................................................................................................................11
2-1 Mounting TOF sensor........................................................................................................................11
Mounting position of TOF Sensor.....................................................................................................11
How to mount TOF Sensor...............................................................................................................15
2-2 Mounting Control Box........................................................................................................................17
Disassembling top case...................................................................................................................17
Assembling front case......................................................................................................................18
How to mount Control Box ...............................................................................................................19
2-3 Wiring................................................................................................................................................20
Wiring example of A3001.................................................................................................................20
Input/output terminals.......................................................................................................................21
Wire specification.............................................................................................................................21
Wiring between Control Box and TOF Sensor .................................................................................23
2-4 LED indications.................................................................................................................................24
LED indications of Control Box.........................................................................................................24
LED indications of TOF Sensor........................................................................................................25
3Setting detection area and sensitivity .................................................................................................26
3-1 Connection to PC..............................................................................................................................26
Before initial setting..........................................................................................................................26
LAN connection................................................................................................................................26
3-2 PC setting..........................................................................................................................................27
TCP/IP .............................................................................................................................................27
PC network setting...........................................................................................................................28
Start-up Remote Desktop Connection..............................................................................................29
Automatic log on of Remote Desktop Connection............................................................................31
Remove of Remote Desktop Connection.........................................................................................32
3-3 Initial setting of ACCURACE-3D application......................................................................................33
Date & Time adjustment...................................................................................................................33
Installer setting.................................................................................................................................34
Setting detection area......................................................................................................................36
Security settings...............................................................................................................................37

vi
Output status....................................................................................................................................39
Installer logout..................................................................................................................................40
3-4 Operation checking ...........................................................................................................................40
3-5 Event log recording function..............................................................................................................41
Output log / delete log......................................................................................................................42
3-6 Sound function..................................................................................................................................43
4Appendix.............................................................................................................................................44
4-1 Outer dimensions..............................................................................................................................44
4-2 Specifications....................................................................................................................................45
Control box.......................................................................................................................................45
TOF sensor......................................................................................................................................47
4-3 Signal diagram..................................................................................................................................48
4-4 Troubleshooting.................................................................................................................................50
4-5 How to remove battery safely............................................................................................................52

7
1 Introduction
1-1 Features
A3001 is Anti-Tailgate & Anti-Piggyback Sensor System that uses Time Of Flight technology.
This product can only be incorporated with the size limited outward opening Interlock door.
Note that the product does not prevent unauthorized entry physically.
Control Box is accessible to up to two TOF Sensor, it can be used for both direction One way (only entry)
and Two way (entry and exit)
The product is designed to register only and therefore not to prevent property loss and casualty, or physical
damage.
Please note that the manufacturer and distributors are not liable for any densification by any damages.
1-2 Contents
Make sure that all parts are available and without any damage before use.
<Note>
Detection unit and control box are supplied separately.
Control Box A3001CB
Fig 1-1
Control Box A3001CB Installation manual

8
 TOF Sensor A3001S
Fig 1-2
1-3 System example for A3001
Fig 1-3
<Note>
Authorization device means ID reader or Biometric reader etc…
TOF Sensor A3001S Mounting screws
(2pcs)
Sensor power cable
Ferrite core
(2pcs)
Wire connector (4pcs)
Control
Box
TOF
Sensor
Magnet
contact
LAN1
A
uthorization in Primary
Shutdown
Zero
One
More
Suspicious
A
IR
Heartbeat
Door1 control
Door2 control
Authorization
device for exit
TOF
Sensor
Access
Control
System
Or
Interlock
Controller
Magnet
contact
I
/O
I/O
A
uthorization
in Secondary
Authorization
device for
entr
y
TWO way
LAN2

9
1-4 Part Names
Control box
Fig 1-4
Fig 1-5
Scre
w
Top Case
Front Case
Power Switch
SSD
Power Indicato
r
Power Input
terminals
Power Supply sockets
for TOF Sensor (2) USB 2.0
(4)
LAN Connector
(2)
Sound jack
24 VDC GND
Power input
Output
Primary
Operation indicator
Primary
Secondary
12345678910111213141516
Secondary
Activation Activation
Zero
One
More
Sus- picious
AIR
Heart- beat
N/A N/A
Zero
One
More
Sus- picious
AIR
Heart- beat
N/A N/A
N/A
Autho- rization
N/A N/A
Autho- rization
N/A
Other Sensor
Input
Primary
12345678910
Secondary Common
Power Switch
Power Indicato
r
O
p
eration Indicato
r
Power Input
terminals
Power Supply sockets
for TOF Sensor (2)
Input
terminals / indicators
(
10
)
Output
terminals / indicators
(16)

10
TOF sensor
Front side Back side
Fig 1-6
Operation indicator
(3 colors)
Powe
r
indicato
r
(Green)
Powe
r
input socket LAN connecto
r

11
2 Mounting and wiring
2-1 Mounting TOF sensor
Mounting position of TOF Sensor
The mounting position of TOF Sensor changes by a use (One way or Two way) and size of interlock area as
shown as below;
For One way
Interlock area within 1.5 m×1.0 m (W×D)
Fig 2-1
Table 2-1
Mounting height
2.3 m 2.6 m 2.9 m
A 1.0 m max.
B 1.5 m max. 1.9 m max. 2.3 m max.
C 0.3 to 0.5 m 0.4 to 0.6 m 0.5 to 0.7 m
D C + 0.5 m max. C + 0.6 m max. C + 0.7 m max.
[Secured area]
[Public area]
A
Entry
B
D
C
Authorizati
on device
for entr
y
Center ±0.1 m
TOF Sensor
direction

12
Interlock area over 1.5 m×1.0 m (W×D)
Presence sensor (AIR input) is necessary
Fig 2-2
Note: Detection area need to be overlapped each other
Table 2-2
Mounting height
2.3 m 2.6 m 2.9 m
A 1.0 m max.
B 1.5 m max. 1.9 m max. 2.3 m max.
C 0.3 to 0.5 m 0.4 to 0.6 m 0.5 to 0.7 m
D C + 0.5 m max. C + 0.6 m max. C + 0.7 m max.
[Secured area]
[Non-secured area]
A
Entry
B
D
C
Center ±0.1 m
Presence
sensor area
TOF Sensor
direction

13
For Two way
Interlock area within 1.5 m×1.5 m (W×D)
Fig 2-3
Table 2-3
Mounting height
2.3 m 2.6 m 2.9 m
A 1.0 m max.
B 1.5 m max 1.9 m max 2.3 m max
C 0.3 to 0.5 m 0.4 to 0.6 m 0.5 to 0.7 m
D 0.3 to 0.5 m 0.4 to 0.6 m 0.5 to 0.7 m
E C + D + 0.5 m max. C + D + 0.6 m max. C + D + 0.7 m max.
[Secured area]
[Non-secured area]
A
Entry
B
E
C
Authorization
device for
entr
y
Center ±0.1 m
Exit
D
Authorization
device for
exit
Detection area
overlap length
= 0.5 m
TOF Sensor
direction

14
Interlock area over 1.5 m×1.5 m (W×D)
Presence sensors(AIR input) are necessary
Fig 2-4
Table 2-4
Mounting height
2.3 m 2.6 m 2.9 m
A 1.0 m max.
B 1.5 m max 1.9 m max. 2.3 m max.
C 0.3 to 0.5 m 0.4 to 0.6 m 0.5 to 0.7 m
D C + 0.5 m max. C + 0.6 m max. C + 0.7 m max.
E 0.3 to 0.5 m 0.4 to 0.6 m 0.5 to 0.7 m
F E + 0.5 m max. E + 0.6 m max. E + 0.7 m max.
A
B
F
C
Center ±0.1 m
[Secured area]
[Non-secured area]
Entry Exit
E
Presence
sensor area
D
TOF Sensor
direction

15
How to mount TOF Sensor
TOF Sensor must be mounted on a ceiling with no dealing facing the floor downward.
(90 degree vertically to the floor)
<Note>
TOF sensor must be oriented as Fig 2-1, Fig 2-2, Fig 2-3 and Fig 2-4.
The allow mark on TOF Sensor is indicated in the figures.
This system has the direction sensing function. Wrong orientation may cause false detections,
”One“ person may result in “More” person.
Remove the arrow mark sticker on the front of TOF Sensor after mounting TOF Sensor.
The sticker blocks the field of view of the TOF Sensor.
Fig 2-5
Fix TOF Sensor with screws (provided).
<Note>
Make sure that the direction of the arrow of TOF Sensor is same with the arrow of figures of mounting
position.
When mount TOF Sensor, ensure that there is no obstacle in the Sensing Area (139 mm×50 mm) as shown
in the figure below, and keep 30 mm space in the back of TOF Sensor.
*Keep TOF Sensor not free from static electricity to prevent the dust adhesion to a Sensing area.
[mm]
Fig 2-6
139
50

16
Fig 2-7
If mounting height is lower than 2.3 m, make mounting jig as shown in Fig 2-8.
[mm]
Fig 2-8
<Note>
Please mount TOF Sensor under the local law and the local regulations.
Screw hole
30
Do not put anything
Sensing area
139 50
70° 50°
Screw hole
30
Do not put anything
Sensing area
139 50
70° 50°
<Note>
This figure is only for reference.

17
2-2 Mounting Control Box
Disassembling top case
Fig 2-9
1 Turning the screw on the upper side of body.
※The screw does not come off.
Fig 2-10
2 Remove top case as shown in Fig 2-10

18
Assembling front case
Front Case can be used in 2 ways by assembly direction.
Fig 2-11
1 For front wiring.
Fig 2-12
2 For back wiring.

19
 How to mount Control Box
[mm]
Fig 2-13
1 Drill a hook hole and two mounting
holes as shown in Fig 2-13.
(mounting template)
Please prepare three screws or three
anchors depending on the mounting
wall.
Fig 2-14
2 Making a hook.
*Make 3mm distance between the
screwhead and the wall. (see Fig 2-14)
Fig 2-15
3 Hook the control box on the screw,
which was made on step 2.
4 Align the control box and fasten it with
two screws (see Fig 2-15)
230
175
Hook hole
Mountin
g
holes
Screw size
5 mm dia. max.
Approx.3 mm
