Optex HX-40/40AM Quick start guide

-1-
N219
INSTALLATION INSTRUCTIONS
No.59-1501-0
High Mount
Outdoor Detector
High Mount
Outdoor Detector
CONTENTS
By utilising the OPTEX’s unique pyro-element,
HX series achieves high reliable detection
performance against false and missed alarms.
HX series provides stable and accurate
detection in outdoor severe environmental
conditions.
•HX-40 : standard model with two PIRs
•HX-40AM : HX-40 with IR anti-masking
feature
HX -40/40AM
HX -40/40AM
Warning Warning Caution
INSTALLATION HINTS
1
(1) INSTALLATION HINTS 1
(2) PARTS IDENTIFICATION 2
(3) KNOCKOUTS 2
(4) DETECTION AREA SETTING 3
(5) INSTALLATION 3
(6)
BRACKET INSTALLATION AND ADJUSTMENT 4
(7) WIRING 6
(8) FUNCTION SETTING 7
(9) OPERATION TEST 9
(10) LED FUNCTIONS 10
(11) SPECIFICATIONS 11
Parallel
2.5 - 3.0 m
(8.3 - 10 ft.)
Tilt
Never repair or modify product Do not pour water over the
product Mount securely
Mount the detector so that a majority of traffic flow is across the detection pattern.

-2-
䎃
䎃
䎃
䎃
䎃
䎃䎃
PARTS IDENTIFICATION
2
Hood
Screw (3×10 mm)
Screw (4×20 mm)
Bracket
Shaft cover
Lock screw (M4×35 mm)
Base
Bracket base
Main unitTerminals
Cover
Lock screw
Lens
LED indicator
Area
masking seal
PIR sensor
(Don not touch)
Anti-masking infrared LED
(HX-40AM only)
For wall
fastening
Wiring Hole
Wiring Hole
(Off-the-shelf) magnet switch
installation position
Adjustment screw
For switch
box fastening
For main unit fastening
Up-down
lock screw
Don’t touch
3-B Bracket
KNOCKOUTS
3
3-A Main unit
For wall fastening/bracket fastening
(installation pitch 83.5 mm (3.3 inch))
For bracket
up-down lock screw
For hood fastening
Wiring
knockout
Wiring sponge pad

-3-
Side view of detection area
(Installation height 3.0 m (1 ft.) )
(Installation height 2.5 m)
To limit the detection distance, apply the appropriate masking seal. Note that there are three
different types of seal.
DETECTION AREA SETTING
4
4-B Detection Length Adjustment
4-A Detection Area
Top view of detection area
90°
40°
30°
20°
10°
0
8 m
(26.7ft.)
8 m
(26.7ft.)
12 m (40 ft.)
12 m
(40 ft.)
3.0 m (10 ft.)
12 m (40 ft.)
2.5 m (8.3 ft.)
9.0 m (30 ft.)
3.0 m (10 ft.)
5.5 m (18.3 ft.)
3.0 m (10 ft.)
4.0 m (13.3 ft.)
3.0 m (10 ft.)
1
3
2
11
2
In
Out
Pass the wire through the base knockout. Fasten the base to the wall.
INSTALLATION
5
12
Wiring sponge pad

-4-
In
In
Out
Out
Wiring sponge pad
1
2
3
4
Push the shaft cover clip outwards to
remove the cover.
Loosen the adjustment screw, tilt the
bracket about 45° and pass through the
wire.
Fasten the bracket to the wall.
Change the bracket direction according
to whether the Main unit is to face left
or right.
Pass the wire through the base
knockout and install the base on the
bracket.
Adjustment
screw
BRACKET INSTALLATION AND ADJUSTMENT
6
20°
20°
90° 90°
6-A Bracket installation
Shaft cover
Push
Using the bracket makes it possible to adjust the unit through 180° degree.
In cases where the ground is uneven and therefore not parallel with the base of the unit, it is
possible to adjust the unit vertically by +/- 20 degree (see section 6-B)
Do not change the detection
distance with bracket.
Use the masking seal to
adjust the detection distance.
Caution>>

-5-
12 m (40 ft.)
3.0 m (10 ft.)
If the base of the unit is already parallel to the ground,
• Do not change the detection distance by tilting the unit up or down.
•Always use the Masking seals.
•Walk test the unit to ensure that the disired detection distance is achieved.
Tighten the adjustment screw.
Wire to the terminal and install the
Main unit and lens on the base.
On the Main unit, make the settings
and check operation.
Using 6-B as reference, adjust the up-
down orientation, then tighten the lock
screw.
Fit the shaft cover into place.
Caution>>
85
6
7Once the operation checks are
complete, fit the shaft cover into place.
When the Main unit is fastened to the
bracket, you can not remove the shaft
cover.
Caution>>
9
6-B Detection distance check and up-down angle adjustment
Adjustment
screw
The LED lights when you
come closer within
9 m (30 ft.).
Adjust the angle upward.
Carry out the walk test again.
The LED lights at
12 m (40 ft.).
There is no need to adjust
the up-down angle.
The LED lights at a
point farther than
13 - 14 m (43 - 47 ft.).
Adjust the angle downward.
Carry out the walk test again.
In cases where he ground is not parallel with the base of the unit the correct detection
distance will not be obtained. In such cases, a walk test will be required. To ensure that the
required area of detection is achieved.
Complete walk test from outside the walking area
to inside. Check that at a distance of 12 to 13m
(40 to 43ft.) from the Main unit, the sensor detects
the person and the LED lights.

-6-
9.5-18VDC
+
–
NC
COM
NO
SPSP
T.O.(NC)
AUX
(NC) (NC)
TAMPER
(NC) (NC)
TAMPER
INPUT
TROUBLE
OUTPUT ALARM POWER
+
–
NC
COM
NO
SPSP
AUX
INPUT ALARM POWER
9.5-18VDC
WIRING
7
*1: TAMPER terminals to be connected to a 24 hour supervisory loop.
HX-40AM
HX-40
SPARE (Non short)
ALARM OUTPUT (N.O.) ALARM OUTPUT (COM) ALARM OUTPUT (N.C.) POWER INPUT (–) (9.5 - 18VDC) POWER INPUT (+) (9.5 - 18VDC)
TAMPER OUTPUT
(N.C.) *1
AUX INPUT (N.C.) TROUBLE OUTPUT
(N.C.)

-7-
Dip switch 2
8-B PULSE COUNT
ON
(factory default)
POSITION FUNCTION
OFF
The LED lights when someone is detected.
The LED does not light even if someone is
detected
ON
OFF
2 times
(factory default)
POSITION FUNCTION
3 times
Suitable for standard applications.
Set this when used in a location with drastic
temperature fluctuation or hostile environment.
3 times
2 times
Dip switch 1
8-A LED ON/OFF HX-40
HX-40AM
HX-40
HX-40AM
FUNCTION SETTING
8
Dip SW
1 LED ON/OFF SELECTOR
2 PULSE COUNT SELECTOR
3 EXTERNAL SENSOR INPUT SELECTOR
4 TROUBLE OUTPUT SELECTOR
ANTI-MASKING
SENSITIVITY
SELECTOR (8-F)
PIR SENSITIVITY SELECTOR
(8-A)
(8-B)
(8-C)
(8-D)
(8-E)
Do not touch
NOTE: For the walk test, move more than 1 m (0.3 ft.) away from
the detector.
AND
(factory default)
POSITION FUNCTION
OR
When both the Main unit and the satellite detect
someone, the alarm is output.
Set to this when not connecting a satellite unit.
Note: The alarm is not output unless both the Main
unit and the satellite detect someone within
60 seconds.
When either the Main unit or the satellite detects
someone, the alarm is output.
OR
AND
By connecting a satellite unit (another warning sensor), you can
expand the detection area and correct false alarms.
As a satellite unit, you can use any general no-voltage contact
output (NC) warning sensor, including the following.
<Infrared (AIR) sensors, thermal line (PIR) sensors, magnet
switches, etc.>
Dip switch 3
8-C EXTERNAL SENSOR INPUT HX-40
HX-40AM

-8-
HX-40
HX-40AM
PIR SENSITIVITY
SELECTOR
8-E PIR SENSITIVITY
POSITION
HIGH
MIDDLE
(factory default)
LOW Suitable for hostile and narrow area
FUNCTION
Suitable for sites requiring greater sensitivity
applications
Suitable for standard applications
LOW
MIDDLE
HIGH
ON
(factory default)
POSITION OUTPUT TERMINAL
OFF
TROUBLE
TROUBLE and ALARM
Use this when not wiring a dedicated trouble input
terminal on the control panel.
ON
OFF
Dip switch 4
8-D TROUBLE OUTPUT HX-40
HX-40AM
Red
Red
Trouble output is used for anti-masking signal.
When an object is placed close to the lens surface, for a period of
more than 180 seconds, the IR Anti-Masking circuit will activate and
generate a trouble signal.
LED Operation>>
DETECTOR STATUS
Anti-Masking booting
(Anti-Masking start up)
Anti-Masking
LED Indication
Red blinks 2 times and goes
off for 5 sec.
This movement is repeated.
Red blinks 3 times and goes
off for 3 sec.
This movement is repeated.
LED operation
ANTI-MASKING
SENSITIVITY SELECTOR
POSITION
HIGH
STD
(factory default)
OFF
FUNCTION
Suitable for site requires greater sensitivity
applications.
Suitable for standard applications.
Suitable for site requires no anti-masking function.
OFF
STD
HIGH
8-F ANTI-MASKING HX-40
HX-40AM

-9-
b a
OPERATION TEST
9
9-A Example of adjustment for false alarms
1
2
If there is a road where people or vehicles can pass in front of the detection area, and
can trigger false alarms, adjust the area as follows.
Delete the unneccesory detection area (a)
using the appropriate masking seal(s) 1 2 or 3.
(Reduce the distance fromo 12m, 9m, 5.5m ,4m (40ft., 30ft.,
18.3ft., 13.3ft.) as determined by the walk testing.
Actually move and check that the system does
not detect movement on the road (a) but does
detect when you enter the detection area (b).
The detection area might increase when there
is a big temperature difference between the
moving object and the background.
For example, when the detection distance is
set to 12 m (40 ft.), sometimes vehicles 13 m
(43 ft.) away may be detected.
In this case, set the detection distance to 9 m
(3 ft.). This shortens the alarm area but it can
reduce false alarms due to vehicles.
Caution>>
Approx. 9 m
(30 ft.)
Position B
Approx. 13 m (43 ft.)
A heat source beyond the detection area may
cause the detector to cause a false alarm by
reflecting off the ground.
Examples of reflective ground is water
(puddle), wet road, smooth surface concrete
and asphalt road.
The heat source is strong and / or reflection
rate is high, detectors detection distance will
be longer than required and may detect
unwanted objects beyond. According to the
ground condition of the installation site, select
the detection range position.
Caution>>

-10-
To limit the detection range, apply the area masking seal to the section you want to hide on the
lens inside. Configure the area in such a way as to avoid having anything cut across the area.
9-B Area Masking
Pasting on example for
masking No. 5 and No. 6
Area masking seal
1
2
3
4
5
6
7
8
9
0
1
9
2
8
3
7
4
6
556
HX-40AM
HX-40
LED FUNCTIONS
10
DETECTOR STATUS
Alarm
Warm-up period
LED Indication
Red light
Red blinks
LED operation
Light BlinkOFF
Red
DETECTOR STATUS
Alarm
Warm-up period
Trouble
output
Anti-Masking booting
(Anti-Masking start up)
Anti-Masking
LED Indication
Red light
Red blinks
Red blinks 2 times and goes off for 5 sec.
This movement is repeated.
Red blinks 3 times and goes off for 3 sec.
This movement is repeated.
LED operation

-11-
SPECIFICATIONS
11
* Specifications and design are subject to change without prior notice.
Model
Detection method
PIR Coverange
Distance limit
Detectable speed
Sensitivity
Power input
Current draw
Alarm period
Warm-up period
Alarm output
Tamper output
Trouble output
Aux input
LED indicator
RF Interference
Operating temperature
Environment humidity
Weatherproof
Mounting
Mounting height
Bracket adjust angle
Weight
Accessories
HX-40 HX-40 AM
Passive infrared
12 m (40 ft.) 85° wide / 94 zones
4 m, 5.5 m, 9 m, 12 m (13 ft, 18 ft, 30 ft, 40 ft.)
0.3 – 1.5 m/s (1 – 5 ft/s)
2.0°C (3.6°F) at 0.6 m/s
9.5 – 18VDC
35 mA (max) at 12VDC 40 mA (max) at 12VDC
2.0 ± 1 sec
Approx. 60 sec(LED blinks)
Form C 28VDC 0.2A max
N.C. 28V DC, 0.1A max
–N.C. 28V DC, 0.1A max
N.C. 28V DC, 0.1A max
Red:Warm-up, Alarm Red:Warm-up, Alarm, Trouble
No alarm 10 V/m
-20 – +60°C (-4 – +140°F)
95% max
IP55
Wall (Outdoor, Indoor)
2.5 - 3.0 m (8.3 - 10 ft.)
Vertical: ± 20° Horizon: ± 95°
600 g (21.2 oz)
Bracket, Hood, Area masking seal, Screw kit (3×10-2, 4×20-4)

-12-
WARRANTY
5 year replacement warranty
The HX-40 series is designed to detect movement of an intruder and activate an alarm control
panel.
Being only a part of a complete system, we cannot accept complete responsibility for any
damages or other consequences resulting from an intrusion. Due to our policy of continuous
improvement Optex reserves the right to change specification without prior notice.
The Warranty period is from the date of purchase.
OPTEX INCORPORATED (USA)
TEL:[phone]
Tech:[phone]
URL:http://www.optexamerica.com
OPTEX KOREA CO., LTD. (KOREA)
TEL:[phone]
URL:http://www.optexkorea.com
OPTEX SECURITY Sp.z o.o. (POLAND)
TEL:[phone]
URL:http://www.optex.com.pl
OPTEX (DONGGUAN) CO., LTD.
SHENZHEN OFFICE (CHINA)
TEL:[phone]
URL:http://www.optexchina.com
OPTEX CO., LTD. (JAPAN)
(ISO 9001 Certified by LRQA) (ISO 14001 Certified by JET)
5-8-12 Ogoto Otsu Shiga 520-0101 JAPAN
TEL:[phone] FAX:[phone] URL:http://www.optex.co.jp/e/
OPTEX (EUROPE) LTD. (UK)
TEL:[phone]
URL:http://www.optex-europe.com
OPTEX SECURITY SAS (FRANCE)
TEL:[phone]
URL:http://www.optex-security.com
Unit:mm (inch) Unit:mm (inch)
99(3.9)
205(8.1)
266(10.5)
148(5.8)
197.5(7.8)
92(3.6)
Using bracket and hood
DIMENSIONS
Without bracket and hood
