Organized Living freedomRail Garage 3 Drawer GOBox User manual

Backing
2 Small
Draw er
left sides
b
a
a
b
a
freedomRail Garage Assembly Instructions
3 Drawer GOBox
Contents of Package
Right Side
Left Side
(1) Large Drawer Back
(2) Small Drawer Backs
(3) Drawer Bottoms
(1) Large
Drawer
Left Side
(1) Large
Drawer
Right Side
(2)
Small
Drawers
Left
Sides
(2)
Small
Drawers
Right
Sides
(2) Small Drawer Fronts
(1) Large Drawer Front
Proper Care for an OBox: Use Goo Gone™ or Simple Green® with a rag or putty knife to remove any excess glue or marring that was caused by shipping or assembly.
Step 1: Attach Hanging Brackets
Assembling the 3 Drawer GOBox
Step 2: Install Connector Bolts
Left Side Right Side
Back Edge Back Edge
Top and Bottom
Smaller Holes for
Connector Bolts
Install (4) Connector Bolts into small holes on Top and Bottom Panels.
Step 3: Attach Sides
Cam
Lock
Open
(a) Attach Sides to Bottom. (b) Tighten Cams by turning clockwise until snug. (a) Attach Top. (b) Tighten Cams by turning clockwise until snug.
Step 4: Attach Top
Attach Hanging Brackets to Sides using Euroscrews. (If using power drill, set torque to low setting.)
Top
1
Over
Bottom
Top
(6)
(3) Handles
Machine Screws
(For Handles)
(6) Full Extension Drawer Glides
Tools Required
#2 Phillips
Screwdriver
#2 Phillips Driver
(34) Euroscrews
(6) 1 /" Wood Screws
(14) Connector Bolts
(16) Backing Nails
Hanging
Brackets
(2)
Hammer
Power Drill
AlignArrowWithHole.

(a) Lock cam by turning clockwise / turn. Turn until snug.
(b) Attach Inner Glides to Drawer with Euroscrews. Notched End should be at back.
(c) Attach Handle with Machine Screws.
a
c
b
b
a
c
a
freedomRail Garage Assembly Instructions
3 Drawer GOBox
Installing Glides
Step 5: Separate Glides Black Tab
Outer Glide
Inner Glide
Attaches to Drawer
Attaches to GOBox
Notched
End
Step 6: Attach Outer Glides to GOBox
Step 8: Mount GOBox onto Uprights
Step 9: Attach Drawer Panels and Drawer Bottom Step 10: Attach Front Panel Connectors
Step 11: Attach Drawer Glides and Handle Step 12: Insert Drawers
(a) Pull out Inner Glide to expose Black Tab.
Install Backing with Nails provided into Top and Bottom Panels only.
(a) Attach Sides to Back. (b) Secure with 1 /" Wood Screws. (c) Slide in Bottom.
(a) Position Drawer on Glides and push in Drawer completely. Repeat Steps 9, 10, 11, and 12 for
two Small Drawers. NOTE: To remove Drawers, push the Black Tab while pulling out the Drawer.
OrganizedLiving.com
1-800-669-3225
June 2018
7315-2006
©2018 Organized Living
Bloomington, IN 47403
Screw in Connector Bolts and attach Front.
Mount GOBox onto Uprights by inserting Hanging Brackets into the innermost track of each Upright.
Two people recommended for installation.
Turn GOBox on its side. Attach Outer Glides with Euroscrews.
Install Outer Glides in holes 1, 2, and 3. Repeat for other sides.
Step 7: Install Backing
Assembling/Inserting Drawers
1
2
3
GOBox Front
Bumper
