oticon Oticon Opn 1 BTE13 PP User manual

Instructions for use BTE13 PP
BTE - BTE PP
Oticon Opn
Oticon Siya

Model overview
This booklet is valid for Oticon Opn™ and Oticon Siya families, in
the following hearing aid models:
Oticon Opn 1 BTE13 PP
Oticon Opn 2 BTE13 PP
Oticon Opn 3 BTE13 PP
Oticon Siya 1 BTE
Oticon Siya 2 BTE
Oticon Siya 1 BTE PP
Oticon Siya 2 BTE PP
 LED light (Oticon Opn) for visual indication
The LED light is used to help users, caregivers, parents, and
teachers to operate the hearing aid and to give instructions on
relevant functions and modes (see relevant information
throughout the booklet).
Introduction to this booklet
This booklet gives you guidance on how to use and maintain your
new hearing aid. Please read the booklet carefully, including the
Warning section. This will help you to get the most out of your new
hearing aid.
Your hearing care professional has adjusted the hearing aid to meet
your needs. If you have additional questions, please contact your
hearing care professional.
About Startup Handling Options Tinnitus Warnings More info
For your convenience, this booklet contains a navigation bar to help
you easily navigate through the different sections.

Intended use
The hearing aid is intended to amplify and transmit sound to the
ear, and thereby compensate for impaired hearing within mild
to severe-to-profound hearing loss. This power hearing aid is
intended for use by adults and children older than 36 months.
IMPORTANT NOTICE
The hearing aid amplification is uniquely adjusted and optimised
to your personal hearing capabilities during the hearing aid fitting
performed by your hearing care professional.
Table of contents 1/2
About
Identify your hearing aid and earpiece 8
Identify left and right hearing aid 12
MultiTool for handling batteries and cleaning 13
Start up
Turn the hearing aid on and off 14
When to replace the battery 15
How to replace the battery (size 13) 16
Handling
Caring for your hearing aid 18
Put on the hearing aid with sound hook 19
Clean the mould 20
Put on hearing aid with thin tube (Corda miniFit) 22
Clean the thin tube 23
Standard earpieces: Replace dome or Grip Tip 24
Customised earpieces: Clean Micro mould/LiteTip 26
Replace ProWax filter 27
Continues on next page

Options
Optional features and accessories 28
Flight mode 29
Change programs 30
Change volume 32
Mute 34
Use hearing aids with iPhone, iPad, and iPod touch 35
Pair hearing aids with iPhone 36
Wireless accessories 38
Tamper-resistant battery drawer 40
Other options 42
Tinnitus
Tinnitus SoundSupport™ (optional) 44
Guidelines for tinnitus sound generator users 45
Sound options and volume adjustment 46
Limitation on use time 49
Warnings related to Tinnitus 52
Warnings
General warnings 54
More info
Troubleshooting guide 58
Water and dust resistant (IP68) 60
Conditions of use 61
Warranty 62
Technical information 64
Your individual hearing aid settings 70
Table of contents 2/2

8 9
About Startup Handling Options Tinnitus Warnings More info
Identify your hearing aid and earpiece
There are two different attachments and several different
earpieces available for the hearing aid.
Mould
Tube
Sound
hook
About
With sound hook and
mould earpiece
With thin tube
(Corda miniFit)
Ear grip (optional)
Thin
tube
(0.9 mm
0.13 mm)
Standard earpieces: Customised earpieces:
Please see details for replacing the dome
in chapter “Replace dome or GripTip”
Power dome
Grip Tip
Available in small and large, left and
right, with or without vent.
Bass dome, single vent
Bass dome, double vent
The thin tube uses one of the following earpieces:
LiteTip
VarioTherm® LiteTip
Micro mould
VarioTherm® micro mould
® VarioTherm is a registered trademark
of Dreve
Open dome
* only as open dome for speaker 60
6 mm5 mm* 8 mm 10 mm 12 mm
Dome sizes

Push button
Mute, change
volume and
programs
LED light
(only optional
for Opn)
Program,
volume, and
battery status
Microphone
openings
Sound in
10 11
About Startup Handling Options Tinnitus Warnings More info
With sound hook and mould
What it is and does
Push button
Mute, change
volume and
programs
LED light
(only optional
for Opn)
Program,
volume, and
battery status
Nail grip
Open the
battery drawer
Battery drawer
Contains the battery.
Functions as an on/off switch
Sound hook
Tube
Brings sound
into the ear
Mould
Hold the
hearing aid
in the ear
Microphone
openings
Sound in
With thin tube (Corda miniFit)
What it is and does
Battery drawer
Contains the battery.
Functions as an on/off switch
Thin tube
Brings sound
into the ear
Nail grip
Open the
battery drawer

12 13
About Startup Handling Options Tinnitus Warnings More info
Identify left and right hearing aid
It is important to distinguish between the left and the right
hearing aid as they may be programmed differently.
You can find left/right colour indicators in the battery drawer.
Indicators can also be found on Micro moulds (optional).
A RED indicator marks
the RIGHT hearing aid
A BLUE indicator marks
the LEFT hearing aid
IMPORTANT NOTICE
Your MultiTool has a built-in magnet. Keep the MultiTool at least 30 cm
away from credit cards and other magnetically sensitive devices.
MultiTool for handling batteries and cleaning
The MultiTool contains a magnet that makes it easier to replace
the battery in the hearing aid. It also contains a brush and wire loop
for cleaning and removing earwax. If you need a new MultiTool,
please contact your hearing care professional.
Brush
Wire loopMagnet

14 15
About Startup Handling Options Tinnitus Warnings More info
Turn the hearing aid on and o
The battery drawer is also used to switch the hearing aid on and
off. To save battery life, make sure your hearing aid is switched off
when you are not wearing it. If you wish to return to the standard
settings of the hearing aid, simply open and close the battery
drawer (quick reset).
Turn ON
Close the
battery
drawer with
the battery
in place.
Turn OFF
Open the
battery drawer.
Start up
When to replace the battery
When it is time to replace the battery, you will hear three beeps
repeated in moderate intervals until the battery runs out.
Three beeps**
= The battery is running low
Four beeps
= The battery has run out
Warning Visual* - Continuously repeated
Battery running low Red, short blink
Battery tip
To make sure the hearing aid is always working, bring spare
batteries with you, or replace the battery before you leave home.
* Only optional for Opn
** Bluetooth® will be turned off and it will not be possible to use wireless accessories.
Note: Batteries need to be replaced more often if you are streaming to your hearing aids.
State Visual* - One sequence only
Quick reset Green, long blink

16 17
About Startup Handling Options Tinnitus Warnings More info
How to replace the battery (size 13)
2. Uncover 3. Insert
Fully open the
battery drawer.
Remove the battery.
Remove the sticky
label from the +side
of the new battery.
Tip:
Wait 2 minutes so that
the battery can draw
air, to ensure optimal
functioning.
Insert the new
battery into the
battery drawer.
Insert it from above,
NOT from the side.
Make sure the +side
is facing up.
1. Remove
MultiTool
Close the battery drawer. The
hearing aid will play a jingle
through the earpiece.
Hold the earpiece close to
your ear to hear the jingle.
The MultiTool can be used to
change the battery. Use the
magnetic end to remove and insert
batteries.
The MultiTool is provided by
your hearing care professional.
4. Close Tip

18 19
About Startup Handling Options Tinnitus Warnings More info
Handling
Put on the hearing aid with sound hook
Read the following pages if you have a hearing aid with a sound
hook and mould.
The mould is
customised for you
and fits your ear
shape. The moulds
are unique for the
left or the right ear.
Gently pull your
ear outwards and
press the mould in
the direction of the
ear canal, twisting
slightly.
Place the hearing aid
behind your ear.
Step 1 Step 2
Caring for your hearing aid
When handling your hearing aid, hold it over a soft surface to avoid
damage in case you drop it.
Clean the microphone openings
Carefully brush any debris away
from the openings. Gently brush
the surface. Make sure the brush
is not pressed into the openings.
IMPORTANT NOTICE
Use a soft, dry cloth to clean the hearing aid. The hearing aid must
never be washed or immersed in water or other liquids.
Microphone
openings

20 21
About Startup Handling Options Tinnitus Warnings More info
Clean the mould
The mould should be cleaned
regularly. Use a soft cloth to
clean the surface of the mould.
Use the MultiTool wire loop
to clean the opening.
Replace the tube
The tubing between the mould
and the hearing aid should be
replaced if it becomes yellow or
stiff. Consult your hearing care
professional about this.
Wash the mould
Make sure you are
able to identify
which mould is for
which hearing aid
before disconnect-
ing them from the
hearing aid.
Disconnect the tube
and mould from
the hook. Hold the
hook firmly when
pulling it off the
tube. Otherwise the
hearing aid may be
damaged.
Wash the mould
and tube using mild
soap. Rinse and dry
completely before
reconnecting to the
hearing aid.
Step 1 Step 2 Step 3

22 23
About Startup Handling Options Tinnitus Warnings More info
Put on hearing aid with thin tube (Corda miniFit)
Read the following pages if your hearing aid has a thin tube.
Place the hearing aid
behind your ear.
The thin tube should
only be used with
an attached ear-
piece. Use only parts
designed for your
hearing aid.
Hold the bend of
the tube between
your thumb and
index finger. The
earpiece should
point towards the
ear canal opening.
Gently push the
earpiece into your
ear canal until the
thin tube sits close to
your head. If the thin
tube has an ear grip,
place it in the ear so it
follows the contour of
the ear.
Step 1 Step 2 Step 3
Clean the thin tube
The thin tube should be cleaned to keep it clear of moisture and
wax. If not cleaned, it may become blocked with wax, which stops
sound from coming out.
Pull the thin tube
out of the hearing
aid.
Push the cleaning
tool all the way
through the thin
tube.
Reconnect the thin
tube to the hearing
aid.
Step 1 Step 2 Step 3

24 25
About Startup Handling Options Tinnitus Warnings More info
Standard earpieces: Replace dome or Grip Tip
The standard earpiece should not be cleaned. If the earpiece
is filled with wax, replace it with a new one. Grip Tips should be
replaced at least once a month.
Hold on to the end
of the thin tube and
then pull off the
earpiece.
Insert the thin tube
exactly into the
middle of the
earpiece to obtain a
secure attachment.
Push firmly to ensure
that the earpiece is
fastened securely.
Step 1 Step 2 Step 3
IMPORTANT NOTICE
If the earpiece is not on the thin tube when removed from the ear,
the earpiece may still be in the ear canal. Consult your hearing care
professional for further instructions.

26 27
About Startup Handling Options Tinnitus Warnings More info
Wax filter
Customised earpieces: Clean Micro mould/LiteTip
The earpiece should be cleaned
regularly. The earpiece has a
white wax filter*that keeps
wax and debris from damaging
the hearing aid.
Replace the filter when
clogged, or if the sound is not
normal, or contact your hearing
care professional.
Clean the vent by pressing
the brush through the
hole, twisting it slightly.
Vent
New
filter
Replace ProWax lter
2. Remove 3. Insert
Remove the tool
from the shell. The
tool has two pins,
one empty for
removal and one
with the new wax
filter.
Push the empty pin
into the wax filter
in the earpiece and
pull it out.
Insert the new wax
filter using the other
pin, remove the tool,
and throw it out.
1. Tool
New
filter
Old filter
IMPORTANT NOTICE
Always use the same type of wax filter as was originally supplied with
the hearing aid. If you are in any doubt about the use or replacement of
wax filters, contact your hearing care professional.
* VarioTherm Micro mould and LiteTip do not have a wax filter

28 29
About Startup Handling Options Tinnitus Warnings More info
Options
Optional features and accessories
The features and accessories described in the following pages are
optional. Please contact your hearing care professional to find out
how your hearing aid is programmed.
If you experience difficult listening situations, a special program
may be helpful. These are programmed by your hearing care
professional.
Write down any hearing situations in which you may need help.
Flight mode
When boarding an airplane or
entering an area in which it
is prohibited to radiate radio
signals, flight mode must be
activated. The hearing aid
will still be working. It is only
necessary to activate flight
mode on one hearing aid; this
will turn off Bluetooth® on both
hearing aids.
To activate and
deactivate Press
the push button for
at least 7 seconds.
A jingle confirms
your action.
Opening and closing
the battery drawer
will also deactivate
flight mode.
Listening state Visual* - Continuously repeated
Flight mode active
Green, short blink Red, short blink Pause
* Only optional for Opn

30 31
About Startup Handling Options Tinnitus Warnings More info
Press up or down
between programs.
Note that you can change continuously
between programs - both up and down
in the program order. For example, if you
want to go from program 1 to 4, you can
press the down button once instead of
pressing the up button 3 times.
Change programs
Your hearing aid can have up to 4 different programs. These are
programmed by your hearing care professional.
To be filled out by the hearing care professional
Program Sound
when activated
When to use Visual*
Continuously repeated
11 beep
22 beeps
33 beeps
44 beeps
Green, short blink Pause
Program change: LEFT RIGHT Short press Long press
* Only optional for Opn

32 33
About Startup Handling Options Tinnitus Warnings More info
Press button
to turn volume up You will hear
2 beeps at
start-up level
Press button
to turn volume down
Change volume
The push button allows you to adjust the volume. You will hear a
click when you turn the volume up or down.
MAXIMUM
START-UP
LEVEL
MINIMUM
To be filled out by the hearing care professional
Volume state Visual* - One sequence only
Start-up level
Minimum / maximum volume
Volume up / down
Green, short blink Green, long blink Red, short blink
Volume change LEFT RIGHT Short press
* Only optional for Opn

34 35
About Startup Handling Options Tinnitus Warnings More info
Mute
Use the mute function if you
need to silence the hearing aid.
IMPORTANT NOTICE
Do not use the mute function as an off switch, as the hearing aid still
draws current from the battery in this mode.
Apply a very long
press (4 seconds)
to either end of
the button to mute
the hearing aid.
To reactivate the
hearing aid, push
the button briefly.
NOTE: the mute function only mutes the
microphone(s) on the hearing aids.
Listening state Visual* - Continuously repeated
Mute
Green, short blink Red, short blink Pause
Use hearing aids with iPhone, iPad, and iPod touch
Your hearing aids are Made for
iPhone® and allow for direct
communication and control with
iPhone, iPad® or iPod touch®.
For assistance in using these
products with your hearing aids,
please contact your hearing care
professional or visit:
www.oticon.global/connectivity
For information on compatibility,
please visit www.oticon.global/connectivity
Use of the Made for Apple badge means that an accessory has been designed to connect
specifically to the Apple product(s) identified in the badge, and has been certified by the
developer to meet Apple performance standards. Apple is not responsible for the operation
of this device or its compliance with safety and regulatory standards.
Apple, the Apple logo, iPhone, iPad, and iPod touch are trademarks of Apple Inc., registered
in the U.S. and other countries.
* Only optional for Opn

36 37
About Startup Handling Options Tinnitus Warnings More info
Pair hearing aids with iPhone
2. General 3. Accessibility1. Settings
Open your iPhone
and go to “Settings”.
Make sure Bluetooth
is on. Then choose
“General”.
On the “General”
screen, choose
“Accessibility”.
On the “Accessibility”
screen, choose
“MFi Hearing Devices”.
6. Confirm pairing5. Select
Open and close the
battery drawer on
both hearing aids,
and place them
close to your iPhone.
The hearing aids
remain in pairing
mode for 3 minutes.
Your iPhone will
detect the hearing
aids for pairing.
Detected devices
will appear in your
iPhone list. Choose
your hearing aids.
Confirm pairing. If
you have two hearing
aids, pairing confir-
mation is needed for
each hearing aid.
4. Prepare
Bluetooth
General
Accessibility
MFi Hearing Devices
William’s Hearing Aids
Oticon Opn
Bluetooth Pairing
Request
“William’s Hearing Aids” would
like to pair with your iPhone
Cancel Pair
On
✓
When you turn o your hearing aids or Apple® device, they will no longer be connected. To connect them again, turn on your hearing
aids by opening and closing the battery door. The hearing aids will then automatically reconnect to your Apple device.

38 39
About Startup Handling Options Tinnitus Warnings More info
Wireless accessories
As an enhancement to your wireless hearing aids, a range of
accessories is available. These can enable you to hear and
communicate better in many everyday situations.
ConnectClip
When paired with your mobile
phone, you can use the hearing
aids as a hands-free headset or
as remote microphone.
TV Adapter 3.0
Wireless transmitter of sound
from TV and electronic audio
devices. TV Adapter streams
sound directly to your hearing
aids.
FM
Your hearing aids supports
the option of attaching an
FM system. The FM system
allows you to receive speech or
audio signals directly to your
hearing aids from a dedicated
transmitter.
For more information contact
your hearing care professional.
Remote Control 3.0
Offers the ability to change
program, adjust volume, or
mute your hearing aids.
Oticon ON App
Offers an intuitive and discreet
way to control your hearing
aids. For iPhone, iPad, iPod
touch, and Android™ devices.
Listening state Visual* - Continuously repeated
Wireless accessories incl. hearing aid
microphone
Wireless accessories
Green, short blink Green, long blink Pause
For more information visit: www.oticon.global/connectivity
* Only optional for Opn
