oventrop Hydrocontrol MTR User manual

Valves, controls + systems
Installation and Operating Instructions
EN
"Hydrocontrol MTR" Balancing Valve (lead-free)
lead-free (LF)
≤0,25%Pb
for wetted parts
DN 15 (lowow)
 (mediumow)
 (highow)
DN 20
DN 25
DN 32
DN 40
DN 50
Do not install this valve in drinking water systems!
Pleasereadtheseinstructionscompletelybefore
installation and operation!
Installationandbalancingshouldbecarriedoutby
qualiedpersonnelonly!
Leavetheseinstructionswiththebuildingowner!

General Specications "Hydrocontrol MTR" (lead-free)
2
1. Table of Contents
2. GeneralSpecications .....2
2.1
Scope of Delivery & Contact . 2
2.2 InstructionNotes.................2
2.2.1 PictographsUsed...................3
2.3 Copyright&Proprietary
Rights..................................3
2.4
General Terms and Conditions
for Sales and Delivery ..........4
2.5 Storage................................4
3. Safety Notices ...................4
3.1 IntendedUse.......................4
3.1.1 ChangestotheProduct.........4
3.2 DenitionofWarningNotices
.............................................4
3.3 Product-SpecicRisks.......5
3.4 PersonnelQualications.....6
3.4.1 SafetyEquipment...................6
4. Technical Description ...... 7
4.1 Setup&Functions...............7
4.2 TechnicalData...................10
4.3 Accessories&SpareParts12
5. Installation
& Initial Operation............13
5.1 BasicInformation..............13
5.2 InstallationoftheValve.....15
5.3 InitialOperation.................17
6. Maintenance & Repairs ..22
7. Decommissioning
& Disposal ........................22
8. Appendix(owcharts).... 73
2. General
 Specications
2.1 Scope of Delivery &
Contact
Congratulations on purchasing
thisbalancingvalve!Pleasecheck
your delivery for any transport
damage. If any defects are evi-
dent,reportimmediately.
Contact Address
OVENTROPCorp
P.O.Box789
29KripesRoad
EastGranby,CT06026
Phone (860)4139173
Fax  (860)4139436
Website:www.oventrop-us.com
2.2 Instruction Notes
These installation and operating
instructionsarefor the Oventrop
"Hydrocontrol MTR" balancing
valve(lead-free≤0.25%Pb).

"Hydrocontrol MTR" (lead-free) General Specications
3
Warningsymbolfor
personal injuries
Danger from hot
orcoldliquid
Danger from hot
or cold surfaces
Mandatory action
Notice, information,
recommendation
Wearsafetygloves
Wearsafetyglasses
Wearsafetyboots
Do not use
fordrinkingwater
Riskduetoheavyvalve
housings
Non-compliance with the spe-
cicationsinthismanualwillre-
sult the voiding of the warranty
onthisproduct.
Thefollowingprinciplesapply:
Assembly, initial operation, and
repairs may only be carried out
by qualied personnel (see sec.
3.4).
Installation must be carried
out according to all applicable
building codes.
Read these instructions all the
way through before carrying
out any work.
Leave these instructions with
the building owner.
The instructions should be
kept on hand at the place of
installation for later reference.
2.2.1PictographsUsed
The following pictographs are
usedintheseinstructions:
2.3 Copyright&Proprietary
Rights
These instructions are copyright
protected.Theyareintendedexclu-
sively for people who handle the
product.Itisnotpermissibletosha-
retheinstructionswiththirdparties.

Safety Notices "Hydrocontrol MTR" (lead-free)
4
2.4 General Terms and
Conditions for Sale
and Delivery
The general terms and conditions
applicableatthetime of delivery
apply for the sale and delivery of
Oventrop.
2.5 Storage
The valve may only be stored
underthefollowingconditions:
- Storagetemperature:-4to
+140°F(-20°Cto+60°C)
- Keepdryandprotectedfrom
dust.
- PreventUVradiationand
directsunlight.
- The valve (including accesso-
ries and spare parts) must not
bestoredtogetherinthesame
room with solvents, chemi-
cals,acids,fuels,orthelike.
3. Safety Notices
3.1 IntendedUse
The Oventrop "Hydrocontrol
MTR" valve (lead-free ≤ 0.25%
Pb) is intended for installation
in heating and cooling system
pipework.
Anyuseofthevalvebeyondthis
or other than this, particularly
in drinking water systems, is
not the use it is intended for.
In addition, the valve is not suit-
able for gases or media that
contain oil or are aggressive.
The manufacturer will not be
liableforthesekindsofnon-in-
tended use. The risk will be
bornebytheuseralone.
Theeventofanexternalrewas
not taken into consideration
whendesigningthevalve.
3.1.1ChangestotheProduct
Modifying the valve is not per-
missible.
3.2 Denitionof
Warning Notices
Warning notices in these instruc-
tions are marked by a warning
symbol, followed by a signal
word ineachinstance.Thesignal
wordsdenetheseverity of the
risk thatarisesfromasituation.
Pay attention to the warning
notices in order to avoid acci-
dents, personal injuries, and ma-
terialdamages.

"Hydrocontrol MTR" (lead-free) Safety Notices
5
NOTE
Signal word (without a
warningsymbol)marking
potential material
damages.
WARNING
Warningsymboland
signalwordmarkinga
medium-riskhazardthat
couldpossiblyresultin
deathorseverebodily
injuryifitisnotavoided.
CAUTION
Warningsymboland
signalwordmarkinga
low-riskhazardthatcould
possiblyresultinmildor
moderatebodilyinjuries
or material damages if it
isnotavoided.
WARNING
Fittings under pressure
– hot/cold liquid!
Risk of burns
from surfaces!
Onlyperformworkwhenthe
system is depressurized.
  Shut down the system
section and allow it to cool
beforecarryingoutallwork.
  Allowliquids to drain in a
 controlledfashion.
Checkfor leaks before
 startingupthesystem.
Maintain permissible
operating pressure during
 initialsystemoperation.

Wearsafety glasses and
gloves.

 Avoidunprotectedcontact
 withhot/coldsystemparts.
Beforeperforminganywork,
 waituntilsurfacescanbe
 touchedwithoutriskof
 injury.
Danger of injury due to
inadequate qualifications!

 Have installation, maintenance
andrepairscarriedoutby
 qualiedpersonnelonly.
3.3 Product-SpecicRisks
Theremayberesidual risks to
people and material property
from assembling and using the
product.Forthisreason,obser-
vethefollowingsafetynotices:

Safety Notices "Hydrocontrol MTR" (lead-free)
6
Risk of injury due to
heavy valve bodies!
WARNING
  Whenassemblingheavy
valves, only use suitable
lifting equipment and
slings.Useprotective
 equipment.

 Attachslingsforliftingthe
fittings to the housing body
only.
 Do not use attached parts
such as handwheels and
metering valves as
connection points for
lifting equipment.
  Wearpersonalsafety
 equipment(e.g.safety
 boots).
CAUTION
  Whereapplicable,wear
safety gloves when
 assemblingand
 disassemblingthevalve.
Risk of injury
on sharp edges!
3.4 Personnel
 Qualications
The heating, gas, and water
technician must be capable of
workingonheatingandaircon-
ditioningsystemsbasedonspe-
cialist training, experience, and
knowledgeofthecorresponding
standards.Theymustbeableto
recognizepotentialrisksontheir
own.
3.4.1 Safety Equipment
Personalsafetyequipment(e.g.
safety glasses, gloves, safety
boots) should be used for all
work.

"Hydrocontrol MTR" (lead-free) Technical Description
7
Fig. 1: MTR with NPT connections
Fig. 2: MTR with soldered connections
4. Technical
Description
4.1 Setup & Functions
The"Hydrocontrol MTR" balan-
cingvalve(lead-free≤0.25%Pb)
isintended forshutoffandba-
lancing in hydronic heating and
cooling systems. The Y-pattern
globe valve has a multi-turn
hand wheel and two measuring
ports. It is available with NPT
threaded connections or solde-
redconnections.
Legend
1 Handwheel
2 Settingadjustmentscale
3 NPTthreadedconnections
4 Soldered connections
5 Cvvalue
 identicationplate
6 Measuring connection (+)
7 Measuring connection (-)
Housingspecications
(bothmodels):
OV:Oventrop
DN:NominalDiameter
PN:Nominalpressure
LF:lead-free

Technical Description "Hydrocontrol MTR" (lead-free)
8
Dimensions (inches) according to nominal Diameter:
DN D t L H SP*
15 NPT½ 0.54 3.43 4.49 1.06
20 NPT¾ 0.56 3.78 4.57 1.26
25 NPT1 0.66 4.02 4.69 1.61
32 NPT1¼ 0.68 4.69 5.35 1.97
40 NPT1½ 0.68 5.20 5.51 2.17
50 NPT2 0.70 6.42 5.94 2.76
*SpannerSize
Fig. 3: Scale drawing of design with NPT threaded connections

"Hydrocontrol MTR" (lead-free) Technical Description
9
Fig. 4: Scale drawing of design with soldered connections
Dimensions (inches) according to nominal Diameter:
DN D t L H
15 0.627 0.51 4.21 4.49
20 0.877 0.75 4.80 4.57
25 1.128 0.91 5.04 4.69
32 1.378 0.98 5.79 5.35
40 1.628 1.10 6.38 5.51
50 2.128 1.34 7.56 5.94

Technical Description "Hydrocontrol MTR" (lead-free)
10
4.2 Technical Data
Nominal Diameter (DN) 15 20 25 32 40 50
Operating medium
Waterandwater-glycolmixtures
(max.50%)
Operating temperature
min/max -4°F(-20°C)bis+302°F(+150°C)*
Maximum operating
pressure
NPTconnections:
362psi(2500kPa)
Solderedconnections:
232psi(1600kPa)**
Material
Valvehousing/bonnet Castbrass,lead-free≤0.25%Pb
Spindle/valvedisk/
wetted parts Brass,lead-free≤0.25%Pb
Valvediskseal PTFE
O-ringspindleseal EPDM
* Themin/max.operatingtemperaturecanbesignicantly
 limitedbytheselectedsolderingalloyandsolderingprocess.
**Themax.operatingpressurecanbesignicantlylimited
 bytheselectedsolderingalloyandsolderingprocess.

"Hydrocontrol MTR" (lead-free) Technical Description
11
Flow volumes(ingallonsperminute,GPM)
Nominal
Diameter (DN)
Cv values min.
rateofow*
Measuring
orice Whole Valve
15 (lowow) 0.64 0.64 0.24
15 (mediumow) 1.39 1.33 0.53
15 (highow) 2.54 2.43 0.97
20 4.91 4.28 1.87
25 9.94 7.05 3.79
32 18.38 14.45 7.00
40 27.05 20.92 10.30
50 54.34 35.26 20.69
* MinimumrateofowinGPMatapressurelossof0.145psi
 (1kPa)overthemeasuringorice

Technical Description "Hydrocontrol MTR" (lead-free)
12
4.3 Accessories &
 SpareParts
WARNING
Incorrect or defective
spare parts and accesso-
ries may lead to damage,
malfunctionsandinjuries.

 Onlyuseoriginal
manufacturer spare
partsandaccessories.
Electronic measuring equipment
"OV-DMC2"(1069177)
"OV-DMPC"(1069277
not illustrated)
"OV-Connect"(1069180
not illustrated)
Lead seal kit (1089091)
(not shown)
Blocking kit(1060180)
(not shown)
Colored rings
blue(1069650)
red(1069651)
Fig. 5: OV-DMC 2
Fig. 6: colored rings

"Hydrocontrol MTR" (lead-free) Installation & Initial Operation
13
5. Installation
& Initial Operation
5.1 Basic Information
Do not use the valve
indrinkingwaterlines.
Thevalvecanbeinstalledinany
orientation in either the supply
orreturnpipe.
WARNING
Risk of injury from
hot / cold surfaces!
Thereisariskofburns
from coming into contact
withthesystem.
  Beforeallwork,allow
the system section to
cool down until
surfacescanbetouched
withoutriskofinjury.
CAUTION
Risk of cuts from
sharp edges!
Threads,bores,andpipe
edgesmaycausecuts.
  Wearsafetygloves.
WARNING
Dangerfromttings
under pressure!
Workingon an operating
HVAC system is danger-
ous.Liquidwhenunder
pressurecanbeveryhot,
and its uncontrolled release
canresultinsevereinjuries.
  Performallworkona
depressurizedand
cooled-offsystemonly.
  Shut down the system
sectionandallowliquid
to drain in a controlled
fashion.
  Wearsafetyglasses
andgloves.

Installation & Initial Operation "Hydrocontrol MTR" (lead-free)
14
Fig. 7: Straight pipe section before valve
Alengthofstraight
pipe at least ve(5)
pipe diameters must
beinstalledbeforethe
inletofthevalve.
When installed after a pump,
there must be at least ten (10)
pipediameterslength of straight
pipebeforethevalve.
Fig. 8:
Minimum distance from valve to pump
The handwheel
and measuring
connections should
beeasilyaccessible
followingassembly.

"Hydrocontrol MTR" (lead-free) Installation & Initial Operation
15
5.2 Installation of the Valve
WARNING
Thereisariskofbeing
burnedbyhot liquid
if you install the valve
in a system when it is
running. Shut down the
system section, allow
it to cool off, and drain
theliquidinacontrolled
fashion.
1. In a new installation,
 itmaybenecessaryto
 ushthepipelinesof
the system before
 installingthevalve.
 Avoidcontaminating
the valve with metal
 debris,sealants,etc.
2.
Observetheowarrow on
 thehousing(Fig.9).
Fig. 9:
Installation position of valve in pipeline

Installation & Initial Operation "Hydrocontrol MTR" (lead-free)
16
NOTE
Information on the installation of valves with
a soldered connection:
Material damage due to improper soldering!
Danger from the uncontrolled escape of media!
Incorrect soldering can cause damage to the valve
components(e.g.,valveseals).Thiscanleadtothe
uncontrolledescapingofmediaandariskofburns.
 Duringsolderingthemaximumtemperatureof150°C
(300degreesFahrenheit)onthehousingconnection
nozzle(measuringvalvesandtoppart)mustnotbe
exceeded.Topreventthiseithercooldownthe
housingconnectionnozzle(e.g.,withadampcloth).
Or,ifthisisnotsufficient,unscrewthemeasuring
valvesandthetoppartduringsoldering.
 Thevalvemustbefullyopen.
 The soldering agent and method must comply with the
state-of-the-art.

"Hydrocontrol MTR" (lead-free) Installation & Initial Operation
17
5.3 Initial Operation
Settingtheowvolume
using calculated preset values
Turn the handwheel to a preset
value toregulatetheowvolume
requiredfortheline.
Fig. 10: Handwheel details
Legend
1 Slidingindicator
2 Longitudinalscale
 (basicsetting)
3 Marking
4 Peripheralscale(nesetting)
5 Boresforleadsealingortag
6 Cover plug
The preset values depend on the parameters of the sys-
teminwhichthevalveisinstalled.Ifthevolumeowand
pressure loss areknown,youcandeterminethepreset
valuesbyusingtheowratediagramsintheappendixto
theseinstructions.
Before initial operation, the sys-
temmustbelledanddeaera-
ted.
WARNING
Danger from overpressure
and leaking medium!
Overpressureinthesystem
can result in injuries from
parts suddenly coming
loose and media escaping
inanuncontrolledfashion.
  Maintaintheadmissible
operatingpressures.
  Performaleakagetest.
{
1
2
4
5
6
3

Installation & Initial Operation "Hydrocontrol MTR" (lead-free)
18
Fig. 11:
Limiting the adjusting spindle
LimitingthePresetting
Even with a limited
presetting, the valve
canstillbesettozero
orshutoff.
Thepresetvaluecanbelimited
orxed(seeFig. 11).Thisme-
ans that after shut off (hand-
wheel set to zero) the previ-
ousvaluecanbequicklyfound
againandreset.
1. Insertthelongendofan
 Allenwrench(3mm)into
the center hole on the
 handwheelface(Fig.11).
2. Turnthekeyclockwiseas
far as it will go in order to
limit the adjusting spindle
 within.

"Hydrocontrol MTR" (lead-free) Installation & Initial Operation
19
Fig. 12:
Marking valve with colored ring
Fig. 13:
Pulling off and repositioning handwheel
1
23
4
5
Marking Feed/Return
Usea colored ring tomark the
valveashavingbeeninstalledin
a feed line (red) or a return line
(blue).Thetwotabsofthecolo-
red ring are used to attach it to
thehandwheel(Fig.12).
If peripheral scale is hard to
read: Reposition handwheel
Depending on the installation po-
sitionofthevalve,itmaynotbe
possible to read the peripheral
scaleforthenesetting.Ifthisis
the case, you can reposition the
handwheel to bring the display
intothelineofsight.
1. Setbothscalesto"0"
(valveclosed).
2. Removecoverplug(5).
3. Undoscrew(4)withsocket
wrench(12mm).
4. Pullhandwheel(2) off of valve
spindle (1) withslighttug.
5. Turnhandwheel (2) so that
window of peripheral scale
(3)iseasilyvisible.Do not
change "0"setting when
doing so.
6. Sethandwheelontovalve
spindleandreplacescrew.
7. Pressoncoverplug.

Installation & Initial Operation "Hydrocontrol MTR" (lead-free)
20
Settingtheowvolume
The tting has two measuring
ports for connecting it to a dif-
ferential pressure meter. As
suchitispossibletosetthevalve
toaspeciedowvolumevalue.
The measuring computer (e.g.
"OV-DMC2")measuresthepre-
vailing differential pressure be-
fore (+) and after (-) the measur-
ingoriceintegratedinthevalve,
thereby calculating the current
volumeow.Thismakesitpos-
sible to balance between target
and actual values. Any devia-
tionscanbereadjustedusingthe
handwheel.
When using a measuring com-
puter, insert its measuring
needles into the two open-
ings of the measuring ports.
Connect the measuring tube
marked in blue to the valve
labeled with "-"and the tube
marked in red to the "+"valve,
accordingly.
Should you use a
differential pressure
meter, please also note
the relevant
instructionsforuse.
