Palmgren 80110A User manual

operating manual & parts list 80110A
10″
BENCH MODEL DRILL PRESS
Read carefully and follow all safety rules and operating instructions before
first use of this product.
30796.00-0509

DESCRIPTION
Palmgren Drill Presses feature a heavy cast iron base, column collar,
work table and head.Work table height is adjustable using rack
and pinion.Table can be tilted 45° both right and left, and rotates
360° on a vertical axis.Work table surface is precision ground
which features T-slots for secure, accurate mounting of workpiece.
Battery-powered laser attachment provides a beam that helps
operator precisely position the drill bit. Other features of the
Palmgren drill press are an enclosed ball bearing quill assembly,
quick belt change and tension mechanism, positive quick-adjust
feed depth stop and a 1/3 HP, 1725 RPM motor. Chuck is included.
Palmgren drill presses are ideal for use in home shops, mainte-
nance shops and light industrial applications. Spindle speeds are
adjustable for drilling steel, cast iron, aluminum, wood and plastic.
UNPACKING
Refer to Figures 4 and 5.
Crates should be handled with care to avoid damage from drop-
ping, bumping, etc. Store and unpack crates with correct side up.
After uncrating drill press, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing or dam-
aged parts. If any damage or loss has occurred, claim must be filed
with carrier immediately. Check for completeness. Immediately
report missing parts to dealer.
Drill press is shipped unassembled.Locate and identify the follow-
ing assemblies and loose parts: head assembly, base, column
assembly, table assembly, table crank handle, handle bars with grip
and batteries.
Contents of hardware bag includes: Drill chuck with key, four M8 x
20 hex head bolts and one 4mm hex wrench.
IMPORTANT: The tool has been coated with a protective coating.
In order to ensure proper fit and operation the coating must be
removed. Remove coating with mild solvents such as mineral spir-
its and a soft cloth. Nonflammable solvents are recommended.
After cleaning, cover all exposed surfaces with a light coating of oil.
Paste wax is recommended for table top.
CAUTION: Never use highly volatile solvents. Avoid getting clean-
ing solution on paint as it may tend to deteriorate these finishes.
Use soap and water on painted components.
SPECIFICATIONS
Chuck size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5-13mm, (1⁄16-1⁄2”)
Spindle taper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . JT33
Spindle travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5”
Quill diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.57”
Quill collar diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.05”
Column diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.28”
Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 620-3100
Swing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10”
Table size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.8 x 7.8”
Table Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9/16”
Base size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.2” x 13.5”
Base working surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 x 6.3”
Drilling capacity (cast iron) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2”
Max. distance, spindle to table: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.7”
Distance, spindle to base: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15.8”
Overall height: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27.5”
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 lbs
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/3 HP, 115V, 1725 RPM, 3.5 A
SAFETY RULES
Before any work is done, carefully read the cautions listed.Working
safely prevents accidents.
WARNING: Some dust created by power sanding, sawing, grind-
ing, drilling and other construction activities contains chemicals
known to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
•Lead from lead-based paints.
•Crystalline silica from bricks and cement and other masonry
products.
•Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures vary, depending on how often you
do this type of work.To reduce your exposure to these chemicals:
work in a well ventilated area and work with approved safety
equipment. Always wear OSHA/NIOSH approved, properly fitting
fase mask or respirator when using such tools.
BE PREPARED FOR JOB
•Wear proper apparel. Do not wear loose clothing, gloves, neck-
ties, rings, bracelets or other jewelry which may get caught in
moving parts of machine.
•Wear protective hair covering to contain long hair.
•Wear safety shoes with non-slip soles.
•Wear safety glasses which comply with United States ANSI
Z87.1. Everyday glasses have only impact resistant lenses.They
are NOT safety glasses.
•Wear face mask or dust mask if cutting operation is dusty.
•Be alert and think clearly.Never operate power tools when
tired, intoxicated or when taking medications that cause
drowsiness.
WORK AREA SHOULD BE READY FOR JOB
•Keep work area clean. Cluttered work areas and work benches
invite accidents.
•Do not use power tools in dangerous environments. Do not use
power tools in damp or wet locations. Do not expose power
tools to rain.
•Work area should be properly lighted.
•Proper electrical outlet should be available for tool.
Three-prong plug should be plugged directly into properly
grounded, three-prong receptacle.
•Extension cords should have a grounding prong, and the three
wires of the extension cord should be of the correct gauge.
•Keep visitors at a safe distance from work area.
•Keep children out of workplace. Make workshop childproof. Use
padlocks, master switches or remove switch keys to prevent
any unintentional use of power tools.
TOOL SHOULD BE MAINTAINED
•Always unplug tool prior to inspection.
•Read operating instructions manual for specific maintaining
and adjusting procedures.
•Keep tool lubricated.
•Use sharp cutters and keep the tool clean for safest operation.
•Remove adjusting tools. Form the habit of checking that adjust-
ing tools are removed before turning on the machine.
•Keep all parts in working order. Check to determine that the
guard or other parts will operate properly and perform their
intended function.
2
Palmgren Operating Manual & Parts List 80110A

3
SAFETY RULES (CONTINUED)
•Check for damaged parts. Check for alignment of moving parts,
binding, breakage, mounting and any other condition that may
affect a tool’s operation.
•Damaged parts should be properly repaired or replaced.Do not
perform makeshift repairs. (Use the parts list provided to order
replacement parts.)
KNOW HOW TO USE TOOL
•Use the right tool for the job. Do not force tool or attachment
to do a job for which it was not designed.
•Disconnect tool when changing accessories such as bits, cut-
ters and the like.
•Avoid accidental start-up. Make sure switch is in OFF position
before plugging in.
•Do not force tool. It will work most efficiently at the rate for
which it was designed.
•Handle workpiece correctly. Secure work with clamps or vise.
Leave hands free to operate machine, Protect hands from
possible injury.
•Never leave a tool running unattended.Turn the power off and
do not leave tool until it comes to a complete stop.
•Do not overreach. Keep proper footing and balance.
•Never stand on tool. Serious injury could occur if tool is tipped
or if cutter is unintentionally contacted.
•Keep hands away from moving parts and cutting surfaces.
•Know your tool. Learn its operation, application and specific
limitations.
•Feed work into a bit or cutter against the direction of rotation
of bit or cutter.
•Turn the machine off if it jams. A cutter jams when it digs too
deeply into the workpiece. (The motor force keeps it stuck in
workpiece.)
•Use recommended accessories. Refer to page 9.Use of improp-
er accessories may cause risk of injury to persons.
•Clamp workpiece or brace against column to prevent rotation.
•Use recommended speed for drill accessory and workpiece
material.
WARNING: Think Safety! Safety is a combination of operator com-
mon sense and alertness at all times when drill press is being used.
ASSEMBLY
MOUNT COLUMN ASSEMBLY TO BASE
Refer to Figure 6.
•Place base (Ref. No. 1) on flat level surface.
•Mount column assembly (Ref. No. 2) to base using four hex
head bolts. (Ref. No. 3).
MOUNT TABLE
Refer to Figure 6.
•Loosen set screw (Ref. No. 8) Remove rack and rack retaining
ring (Ref. Nos. 9 and 10) from column (Ref. No.2).
•Place rack inside table assembly bracket with large, unma-
chined portion of rack to the top. Slide rack into slot in bracket
so that teeth of rack engage pinion gear in bracket.
•Slide table assembly with rack over column. Place bottom end
of rack inside beveled edge of column flange.
•Slide rack retaining ring over column with beveled edge down.
Position ring against top of rack so that rack is in beveled edge
of ring. Secure ring with set screw (Ref. No. 8).
•Rotate table assembly around column. Adjust rack retaining
ring as necessary to prevent binding of rack.
•Attach crank handle (Ref. No. 7) to shaft on worm gear, rotate
worm gear to remove slack, and shoulder crank handle against
table bracket. Secure handle with set screw (Ref. No. 11).
•Tighten table bracket locking handle (Ref. No. 12) to secure
table assembly.
MOUNT HEAD ASSEMBLY
Refer to Figure 7.
•Slide drill press head assembly onto top of column.
•Position head so that it is centered over base.
•Secure head by tightening set screws (Ref. No. 3) on side of
head.
MOUNT QUILL FEED HANDLES
Refer to Figure 7.
•Thread the (3) handle bars with grips (Ref. No. 12) securely into
quill feed assembly (Ref. No. 10).
MOUNT DRILL CHUCK AND ARBOR
Refer to Figure 7.
•Be sure spindle and chuck tapers are clean and dry. Make sure
quill is in the UP position.
•Use the provided chuck key (Ref. No. 40) to adjust the jaws of
the chuck (Ref. No. 31) until they are recessed inside the drill
chuck body.
•Slide chuck over spindle taper and push chuck onto spindle.
•Tap the end of drill chuck with a rubber or wooden mallet to
seat it onto the spindle.
INSTALLING BATTERY FOR LASER GUIDE
Refer to Figure 1.
•Open the cover of battery compartment by sliding latch
upward.
•Install 2 pieces of 1.5V batteries into the battery compartment
according to the polarity indicated on the cover.
•Close the cover.
•Turn on the switch to check the laser guide operation.
NOTE: Replace the batteries with batteries that have a rating of 1.5
volts (Number 4 series and AAA size or equivalent).When replacing
the batteries, the laser guide should be thoroughly cleansed. Use a
soft paintbrush or similar device, to remove all sawdust and debris.
INSTALLATION
Refer to Figures 2 and 3.
MOUNT DRILL PRESS
•Drill press must be mounted to flat level surface. Use shims or
machine mounts if necessary. Do not mount drill press in direct
sunlight.
Palmgren Operating Manual & Parts List 80110A
Figure 1 – Laser Guide Assembly
Cover
Latch
Switch

4
INSTALLATION (CONTINUED)
•Be sure to bolt drill press to bench securely to prevent tipping
and minimize vibration.
•Tighten all nuts and bolts that may have loosened during
shipment.
POWER SOURCE
The motor is designed for operation on the voltage an frequency
specified. Normal loads will be handled safely on voltages not
more than 10% above or below the specified voltage.
Running the unit on voltages which are not within the range may
cause overheating and motor burn out.Heavy loads require that the
voltage at motor terminals be no less than the voltage specified.
GROUNDING INSTRUCTIONS
WARNING: Improper connection of equipment grounding con-
ductor can result in the risk of electrical shock. Equipment should
be grounded while in use to protect operator from electrical shock.
Check with a qualified electrician if grounding instructions are not
understood or if in doubt as to whether the tool is properly
grounded.
This tool is equipped with an approved 3-conductor cord rated up
to 150V and a 3-prong grounding type plug rated at 115V (See
Figure 2) for your protection against shock hazards.
Grounding plug should be plugged directly into a properly
installed and grounded 3-prong grounding-type receptacle, as
shown (Figure 2).
Do not remove or alter grounding prong in any manner. In the
event of a malfunction or breakdown, grounding provides a path
of least resistance for electrical shock.
WARNING: Do not permit fingers to touch the terminals of plug
when installing or removing from outlet.
Plug must be plugged into matching outlet that is properly
installed and grounded in accordance with all local codes and
ordinances. Do not modify plug provided. If it will not fit in outlet,
have proper outlet installed by a qualified electrician.
Inspect tool cords periodically, and if damaged, have repaired by
an authorized service facility.
Green (or green and yellow) conductor in cord is the grounding
wire. If repair or replacement of the electric cord or plug is neces-
sary, do not connect the green (or green and yellow) wire to a live
terminal.
Where a 2-prong wall receptacle is encountered, it must be
replaced with a properly grounded 3-prong receptacle installed in
accordance with National Electric Code and local codes and ordi-
nances.
WARNING: This work should be performed by a qualified electrician.
A temporary 3-prong to 2-prong grounding adapter (See Figure 3)
is available for connecting plugs to a two pole outlet if it is
properly grounded.
Do not use a 3-prong to 2-prong grounding adapter unless permit-
ted by local and national codes and ordinances.
(A 3-prong to 2-prong grounding adapter is not permitted in
Canada.) Where permitted, the rigid green tab or terminal on the
side of the adapter must be securely connected to a permanent
electrical ground such as a properly grounded water pipe, a prop-
erly grounded outlet box or a properly grounded wire system.
Many cover plate screws, water pipes and outlet boxes are not
properly grounded.To ensure proper ground, grounding means
must be tested by a qualified electrician.
EXTENSION CORDS
•The use of any extension cord will cause some drop in voltage
and loss of power.
•Wires of the extension cord must be of sufficient size to carry
the current and maintain adequate voltage.
•Use the table to determine the minimum wire size (A.W.G.)
extension cord.
•Use only 3-wire extension cords having 3-prong grounding
type plugs and 3-pole receptacles which accept the tool plug.
•If the extension cord is worn, cut, or damaged in any way,
replace it immediately.
EXTENSION CORD LENGTH
Wire Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A.W.G.
Up to 25 ft.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
25-50 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
NOTE: Using extension cords over 50 ft. long is not recommended.
OPERATION
Refer to Figures 4, 5, 6 and 7.
WARNING: Read and understand operating instructions and
parts manual before operating this machine.
CAUTION: The operation of any power tool can result in foreign
objects being thrown into the eyes, which can result in severe eye
damage. Always wear safety glasses complying with United States
ANSI Z87.1 (shown on package) before commencing power tool
operation.
THE LASER GUIDE
Your tool is equipped with a laser guide, a battery powered device
using Class IIIa laser beams.The laser beams will enable you to pre-
view the drill bit path on the workpiece to be drilled before you
begin your operation.
Laser Radiation: Avoid direct eye contact. A
Laser light is radiated when the laser guide is
turned on. Avoid direct eye contact. Always turn off the laser and
unplug the drill press from the power source before making any
adjustments.
•A laser pointer is not a toy and should not come into hands of
children. Misuse of this appliance can lead to irreparable eye
injuries.
•Any adjustments to increase the laser power is forbidden.
•When using the laser pointer, do not point the laser beam
towards people and / or reflecting surfaces. Even a laser beam
of lower intensity may cause eye damage.Therefore, do not
look directly into the laser beam.
•If the laser pointer is stored for more than three months with-
out use, please remove the batteries to avoid damage from
possibly leaking batteries.
•The laser pointer includes no user serviceable components.
Never open the housing for repair or adjustments.
Palmgren Operating Manual & Parts List 80110A
Figure 3 – 2-Prong Receptacle with adapter
Grounding Lug
Adapter
3-Prong Plug
2-Prong Receptacle
Make sure this is
Connected to a known
Grounded Receptacle
Figure 2 – 3-Prong Receptacle
Properly Grounded Outlet
Grounding Prong
3-Prong Plug

5
Palmgren Operating Manual & Parts List 80110A
OPERATION (CONTINUED)
•On units equipped with the Laser-Guide attachment, repairs
shall only be carried out by the laser manufacturer or autho-
rized agent.
•Laser Warning label: Max output <5mW DIODE LASER: 630-
660nm, Complies with 21CFR 1040.10 and 1040. 11.
ADUSTING THE LASER LINES
Refer to Figure 4.
Check the laser beam alignment to ensure the intersection of the
laser lines precisely at the spot where the drill bit meets the work-
piece. If it is not, the laser lines should be adjusted using the laser
adjustment knobs located on the opposite sides of the head
assembly.
•Mark an “X” on a piece of scrap wood.
•Insert a small drill bit into the chuck and align its tip to the
intersection of the lines of the “X”.
•Secure the board to the table.
•Turn on the laser and verify the laser lines align with the “X” on
the workpiece.
•If the laser lines do not align, loosen knobs on each side of the
laser module and rotate the lasers until the lines meet in the
center of the“X”. Retighten the knobs to secure.
NOTE: Check and adjust the laser beam alignment every time the
drill press table is raised or lowered to a new position.
SPEED ADJUSTMENTS
Refer to Figures 5 and 7.
WARNING: Be sure drill press is turned off and is disconnected
from power source before adjusting speeds.
•To change spindle speed, loosen motor lock bolt (Ref. No. 5), on
the right side of the head and push the motor toward front of
drill press.This will loosen the belt and permit relocating the
belt to the desired pulley groove for the required spindle speed
(See Figure 5).
•After belt has been repositioned, push motor mount plate (Ref.
No.6) to move motor toward rear of drill press and tighten
motor lock bolt.
•Check belt for proper tension and make any final adjustment. A
belt is properly tensioned when light pressure applied to mid-
point of the belt produces about 1/2”deflection.
TABLE ADJUSTMENTS
Refer to Figure 6.
•Height adjustments:To adjust table, loosen locking handle (Ref.
No.12) and turn crank handle (Ref. No. 7) to desired height.
Immediately retighten table bracket locking handle.
•Rotation of work table : Loosen table locking handle (Ref. No.
12) and rotate table to desired position and retighten handle.
•Tilting work table: Loosen hex head bolt (Ref. No. 13).Tilt table
to desired angle up to 45° and retighten hex head bolt.
•To obtain more distance between chuck and table, the work
table can be rotated 180° and base can be used as a work sur-
face.This permits drilling of larger objects.
•Clamp table securely after adjustments have been made.
DEPTH STOP ADJUSTMENT
Refer to Figure 7.
•To control drilling depth, loosen locking bolt (Ref. No. 11) on
quill feed assembly (Ref. No. 10). Rotate scale so desired depth
is indicated on scale next to the pointer.Tighten locking bolt.
Use this feature to drill more than one hole to the same depth.
•Spindle can be locked in either fully or partially down position.
Loosen locking bolt (Ref. No.11). Lower chuck to desired depth,
rotate scale fully clockwise and tighten locking bolt. Use this
feature to set up and align work.
MOUNT DRILL BIT
WARNING: Be sure drill press is turned off and is disconnected
from power source before adjusting speeds.
•Place drill bit in jaws of drill chuck.
•Tighten chuck with drill chuck key. Be sure to tighten the chuck
using all three key positions on the chuck body and remove
chuck key.
•Use only the self-ejecting chuck key (Ref. No. 40) supplied with
this drill press, or a duplicate key. Use of any other key might
allow start up with the key still in the chuck. An airborne key
could strike the operator and cause injury.
Spindle
Rotation
Spindle Motor
Figure 5 – Spindle Speed Adjustment
Recommended Drill Size per Material for 5 Speeds
5
4
3
2
1
5
4
3
2
1
5-5
4-4
3-3
2-2
1-1
3100
2340
1720
1100
620
in/mm
5/16 7.9
3/8 9.5
5/8 15.9
7/8 22.2
11⁄431.8
in/mm
3/16 4.8
1/4 6.4
3/8 9.5
1/2 12.7
3/4 19.0
in/mm
11/64 4.4
7/32 5.6
11/32 8.7
15/32 11.9
11/16 17.5
in/mm
5/32 4.0
3/16 4.8
5/16 7.9
7/16 11.1
5/8 15.9
in/mm
7/64 2.8
1/8 3.2
1/4 6.4
11/32 8.7
1/2 12.7
in/mm
3/32 2.4
3/32 2.4
5/32 4.0
1/4 6.4
3/8 9.5
in/mm
1/16 1.6
1/16 1.6
1/8 3.2
3/16 4.8
5/16 7.9
in/mm
1/32 0.8
3/64 1.2
1/16 1.6
1/8 3.2
1/4 6.4
Belt
Location RPM Wood Zinc Diecast Alum. &
Brass Plastic Cast Iron & Bronze
Steel
Mild &
Malleable
Steel Cast &
Med.
Carbon
Steel Stainless & Tool
Figure 4 – Laser Guide Assembly
Laser
Knob
Switch

6
Palmgren Operating Manual & Parts List 80110A
MAINTENANCE
WARNING: Turn switch off and remove plug from power source
outlet before maintaining or lubricating your drill press
V-BELT
Replace V-belt when worn.
LUBRICATION
Refer to Figures 6 and 7.
The ball bearings are lubricated at the factory and need no further
lubrication. Using 20wt. non detergent oil, periodically lubricate
the splines (grooves) in the spindle and the rack (teeth on the
quill) as follows:
•Lower quill assembly (Figure 7, Ref. No. 54) all the way down.
•Apply lubricant around the inside of the hole in the spindle
pulley (Figure 7, Ref. No. 29).
•Apply lubricant to rack (teeth) on quill (Figure 7, Ref. No. 27)
while extended below drill press head.
•Apply lubricant to rack and pinion gear (Figure 6, Ref. Nos. 9
and 15) on column and table assembly.
CLEAN MOTOR
Frequently blow out any dust that may accumulate inside motor. If
power cord is worn, cut or damaged in any way, have it replaced
immediately.

7
SYMPTOM
Spindle does not turn
Noisy spindle
Noisy operation
Bit burns or smokes
Excessive drill runout or wobble
Drill bit binds in workpiece
The laser guide will not turn on
POSSIBLE CAUSES
1. No power to drill press
2. Defective switch
3. Defective motor
Defective bearings
1. Incorrect bet tension
2. Dry spindle
3. Loose spindle
4. Loose motor pulley
1. Incorrect speed
2. Chips not coming out of hole
3. Dull bit
4. Feeding too slow
5. Bit not lubricated
6. Bit running backwards
1. Bent bit
2. Bit not properly installed in chuck
3. Chuck not properly installed
4. Worn spindle bearings
1. Workpiece pinching bit or excessive feed
2. Improper belt tension
3. Workpiece not supported or clamped
properly
The batteries have become uncharged
CORRECTIVE ACTION
1. Check wiring, fuse or circuit breaker
2. Replace switch
3. Replace motor
Replace bearings
1. Adjust tension
2. Lubricate spindle, See Lubrication, page 5
3. Tighten pulley nut
4. Tighten set screw in pulley
1. Change speed
2. Retract bit frequently to clear chips
3. Sharpen or replace bit
4. Feed faster; enough to allow drill to cut
5. Lubricate bit
6. Check motor rotation to be sure it is
clockwise facing shaft end
1. Replace bit
2. Install bit properly
3. Install chuck properly
4. Replace bearings
1. Support or clamp work, decrease feed
pressure
2. Adjust tension
3. Support or clamp workpiece securely
See Assembly section,“Installing Battery for
Laser Guide”
TROUBLESHOOTING
Palmgren Operating Manual & Parts List 80110A

8
Figure 6 - Replacement Parts Illustration for Base
Palmgren Operating Manual & Parts List 80110A
11
12
10
8
5
4
15
6
7
13
14
2
39
1

9
Palmgren Operating Manual & Parts List 80110A
REPLACEMENT PARTS LIST FOR BASE
ΔNot Shown.
* Standard hardware item available locally.
Ref. Part
No. Description Number Qty.
1 Base 21811.00 1
2 Column and collar assembly 21812.00 1
3 8-1.25 x 20mm Hex head bolt * 4
4 Table and bracket assembly (Including Ref. Nos. 13 and 15) 21813.00 1
5 Worm and pinion gear set, (Ref. Nos. 6 and 15) 21814.00 1
6 Worm gear 21815.00 1
7 Crank handle 21816.00 1
8 6-1.0 x 14mm Pan head screw * 1
9 Rack 21817.00 1
10 Rack retaining ring 21818.00 1
11 6-1.0 x 12mm Hex head bolt 21819.00 1
12 Table bracket locking handle 00311.00 1
13 12-1.75 x 25mm Hex head bolt * 1
14 3AMI-14 Retaining ring 05989.00 1
15 Pinion gear and shaft 21820.00 1
Recommended Accessories
Δ4”Angle vise 11351 1
Δ4”Drill press vise 12352 1
Δ4”Standard vise 12403 1

10
Palmgren Operating Manual & Parts List 80110A
Figure 7 - Replacement Parts Illustration for Head
18
47
47
15
36
16
3
3
3
19
45
43
44 46
20
41
51
57
4
42
53
2
1
52
5
8
8
9
9
6
11
22
23
27
26
26
21
31
40
50
7
55
28
24
24
25
25
14
28
35
39
37
34
29
30
49
38
32
56
59
58
33
13
17
12
10
54
48
48 48
48

Ref.
No. Description Part No. Qty.
1 Drill press head † 1
2 Stop pin 21778.00 1
3 8-1.25 x 8mm Set screw * 4
4 Tension adjustment bar 21779.00 1
5 Motor lock bolt 21780.00 1
6 Motor mount plate 21781.00 1
7 6-1.0 x 12mm Hex head bolt * 4
8 6mm Flat washer * 8
9 8mm Flat washer * 4
10 Quill feed assembly 21782.00 1
11 Knob 21783.00 1
12 Handle bar and grip 21784.00 3
13 Upper spindle assembly 21785.00 1
(Ref. Nos. 14, 25, 28 and 49)
14 3AMI-22 Retaining ring 01861.00 1
15 Cap cover with spring 21786.00 1
16 Pointer 21787.00 1
17 Rivet 21788.00 1
18 10-1.5mm Hex nut (set) 21789.00 1
19 Screw and nut 21790.00 1
20 5-0.8 x 10mm Pan head screw * 3
21 Spindle 21791.00 1
22 Rubber bumper 21792.00 1
23 3AMI-12 Retaining ring 00519.00 1
24 5-0.8mm Hex nut * 2
25 6203ZZ Bearing 01901.00 2
26 6201ZZ Bearing 00520.00 2
27 Quill † 1
28 3BMI-40 Retaining ring 03838.00 2
29 Spindle pulley 21794.00 1
30 Cord clamp 07752.00 1
31 JT-33 Chuck with key (Ref.No.40) 21795.00 1
Ref.
No. Description Part No. Qty.
32 Motor pulley 21796.00 1
33 V-belt 21797.00 1
34 Pulley housing 21798.00 1
35 6-1.0 x 8mm Pan head screw * 4
36 5mm Serrated washer * 1
37 Line cord 21799.00 1
38 5mm Lock washer * 1
39 6mm Lock washer * 4
40 Chuck key 21800.00 1
41 Grommet 04076.00 2
42 8-1.25mm Hex nut * 2
43 Switch with key 16080.00 1
44 Switch plate 21801.00 1
45 4-1.60 x 12mm Thread forming screw 10372.00 3
46 Face cover 21802.00 1
47 5-0.8 x 15mm Pan head screw * 3
48 5mm Flat washer * 6
49 Upper spindle sleeve 21803.00 1
50 1/3 HP Motor 21804.00 1
51 Spring 21805.00 1
52 Capacitor 25MFD 250 VAC 21806.00 2
53 8-1.25 x 25mm Hex head bolt * 2
54 Lower spindle assembly 21807.00 1
(Ref. Nos. 21-23, 26 and 27)
55 Knob 21808.00 1
56 Line cord clamp 21809.00 2
57 Spacer 21810.00 4
58 4-0.7 x 8mm Pan head screw * 1
59 4mm Serrated washer * 1
ΔLaser Guide Assembly 25153.00 1
ΔOperator’s Manual 30796.00 1
11
Palmgren Operating Manual & Parts List 80110A
REPLACEMENT PARTS LIST FOR HEAD
ΔNot Shown.
* Standard hardware item available locally.
† Not available as repair part.

Palmgren warrants their products to be free of deficiency in material or workmanship.The duration of this warranty is
expressively limited to one year parts and labor unless otherwise noted beginning from the date of delivery to the original
user.The following Palmgren products carry the following warranties on parts with a 1 year warranty on labor:
•USA Machine vises – Lifetime
•Imported Machine vises – 2 years
•Bench vises – 2 years
•Positioning tables – 2 years
•Bench grinders & buffers – 3 years
•Tapping machines – 2 years
•Drilling machines – 2 years
•Finishing machines – 2 years
•Band saws – 2 years
•Work stands – 2 years
The obligation of Palmgren is limited solely to the repair or replacement, at our option, at its factory or authorized repair
agent of any part that should prove deficient. The warranty does not cover expendable and/or wear parts (i.e. v-belts, coated
abrasives), damage to tools arising from alteration, abuse or use other than their intended purpose, packing and freight.
Purchaser must lubricate and maintain the product under normal operating conditions at all times. Proper use and care
instructions are provided in the operator’s manual. Failure to follow these instructions will void the warranty.
This warranty is the purchaser’s exclusive remedy against Palmgren for any deficiency in its products. Under no circumstances
is Palmgren liable for any direct, indirect, incidental, special or consequential damages including lost profits in any way related
to the use or inability to use our products. This warranty gives you specific legal rights which may vary from state to state.
SERVICE & REPAIR
1. If a Palmgren product requires a repair or warranty service DO NOT return the product to the place of purchase.
2. All warranty related work must be evaluated and approved by Palmgren.
3. Prior to returning any item the user must obtain factory approval and a valid RGA number.
4. For instructions and RGA number call toll free [phone].
Palmgren Operating Manual & Parts List 80110A
TWO YEAR LIMITED WARRANTY
