Palmgren Operating Manual & Parts List 80177
operating manual & parts list 80177
17" FLOOR MODEL DRILL PRESS
WITH SINGLE / THREE PHASE
Read carefully and follow all safety rules and operating instructions before
rst use of this product.

2
Palmgren Operating Manual & Parts List 80177
DESCRIPTION
Palmgren Drill Presses feature a heavy cast iron base, column collar,
work table and head. Work table height is adjustable using rack and
pinion. Table can be tilted 45° both right and left, and rotates 360°
on a vertical axis. Work table surface is precision ground and features
T-slots for secure, accurate mounting of workpiece and also a coolant
trough. Digital readout displays spindle RPM. Other features of the
Palmgren drill press are an enclosed ball bearing quill assembly,
quick belt change and tension mechanism, positive quick-adjust
feed depth stop and a 1 HP, 16 speeds motor. Chuck and chuck arbor
are included.
Palmgren drill presses are ideal for use in home shops, maintenance
shops and light industrial applications. Spindle speeds are adjustable
for drilling steel, cast iron, aluminum, wood and plastic.
UNPACKING
Refer to Figure 1.
WARNING: Be careful not to touch overhead power lines, piping,
lighting, etc., if lifting equipment is used. Drill press weighs up to
183 lbs, proper tools, equipment and qualied personnel should be
employed in all phases of unpacking and installation.
Crates should be handled with care to avoid damage from dropping,
bumping, etc. Store and unpack crates with correct side up. After
uncrating drill press, inspect carefully for any damage that may have
occurred during transit. Check for loose, missing or damaged parts.
If any damage or loss has occurred, claim must be led with carrier
immediately. Check for completeness. Immediately report missing
parts to dealer.
Drill press is shipped unassembled. Locate and identify the following
assemblies and loose parts:
A Head Assembly (~) G Quill Feed Handle
B Head Assembly (3~) H Feed Handle Bar
C Table I Table Crank Handle
D Table Bracket J Table Bracket Locking Handle
E Base K Table Locking Handle
F Column Assembly L Chuck & Spindle Arbor
IMPORTANT: The tool has been coated with a protective coating.
In order to ensure proper t and operation the coating must be
removed. Remove coating with mild solvents such as mineral spirits
and a soft cloth. Nonammable solvents are recommended. After
cleaning, cover all exposed surfaces with a light coating of oil. Paste
wax is recommended for table top.
CAUTION: Never use highly volatile solvents. Avoid getting
cleaning solution on paint as it may tend to deteriorate these
nishes. Use soap and water on painted components.
SPECIFICATIONS
Chuck size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 mm, JT3
Spindle taper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MT2 x JT3
Spindle travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5”
Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 - 3476
Table size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-1/3 x 14-1/3”
Base size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-2/5 x 11-1/9”
Overall height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68”
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183 lbs
Motor:
Single phase . . . . . . . . . . . . . . . . . . . . . . 1 HP, 120/240 V, 10.2/5.1 A, 60 Hz
(Tool Prewired 120 V)
Three phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 HP, 240 V, 5 A, 60 Hz
PROPOSITION 65 WARNING: Some dust created by power
sanding, sawing, grinding, drilling and other construction activities
contains chemicals known to the state of California to cause cancer,
birth defects or other reproductive harm.
Some examples of these chemicals are:
● Lead from lead-based paints.
● Crystalline silica from bricks and cement and other
masonry products.
● Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures vary, depending on how often you do
this type of work. To reduce your exposure to these chemicals: work
in a well ventilated area and work with approved safety equipment.
Always wear OSHA/NIOSH approved, properly tting face mask or
respirator when using such tools.
Before any work is done, carefully read the cautions listed. Working
safely prevents accidents.
BE PREPARED FOR JOB
● Wear proper apparel. Do not wear loose clothing, gloves, neckties,
rings, bracelets or other jewelry which may get caught in moving
parts of machine.
● Wear protective hair covering to contain long hair.
● Wear safety shoes with non-slip soles.
● Wear safety glasses which comply with United States ANSI Z87.1.
Everyday glasses have only impact resistant lenses. They are NOT
safety glasses.
● Wear face mask or dust mask if cutting operation is dusty.
● Be alert and think clearly. Never operate power tools when tired,
intoxicated or when taking medications that cause drowsiness.
SAFETY RULES
AB
C
D
E
F
Figure 1 - Unpacking
G H I
JK
L
Not Shown: Worm Gear, four M10*1.5-40 Hex Bolts, Wedge,
3 and 5 mm Hex Wrenches, Chuck Key, Belt Tesion Handle,
Hardware Bag For Quill Feed Handle.

3
Palmgren Operating Manual & Parts List 80177
WORK AREA SHOULD BE READY FOR JOB
● Keep work area clean. Cluttered work areas and work benches
invite accidents.
● Do not use power tools in dangerous environments. Do not use
power tools in damp or wet locations. Do not expose power tools
to rain.
● Work area should be properly lighted.
● Proper electrical outlet should be available for tool. Three-prong
plug should be plugged directly into properly grounded, three-
prong receptacle.
● Extension cords should have a grounding prong, and the three
wires of the extension cord should be of the correct gauge.
● Keep visitors at a safe distance from work area.
● Keep children out of workplace. Make workshop childproof. Use
padlocks, master switches or remove switch keys to prevent any
unintentional use of power tools.
TOOL SHOULD BE MAINTAINED
● Always unplug tool prior to inspection.
● Read operating instructions manual for specic maintaining and
adjusting procedures.
● Keep tool lubricated.
● Use sharp cutters and keep the tool clean for safest operation.
● Remove adjusting tools. Form the habit of checking that
adjusting tools are removed before turning on the machine.
● Keep all parts in working order. Check to determine that the
guard or other parts will operate properly and perform their
intended function.
● Check for damaged parts. Check for alignment of moving parts,
binding, breakage, mounting and any other condition that may
aect a tool’s operation.
● Damaged parts should be properly repaired or replaced. Do not
perform makeshift repairs. (Use the parts list provided to order
replacement parts.)
KNOW HOW TO USE TOOL
● Use the right tool for the job. Do not force tool or attachment to
do a job for which it was not designed.
● Disconnect tool when changing accessories such as bits, cutters
and the like.
● Avoid accidental start-up. Make sure switch is in OFF position
before plugging in.
● Do not force tool. It will work most eciently at the rate for which
it was designed.
● Handle workpiece correctly. Secure work with clamps or vise.
Leave hands free to operate machine. Protect hands from possible
injury.
● Never leave a tool running unattended. Turn the power o and
do not leave tool until it comes to a complete stop.
● Do not overreach. Keep proper footing and balance.
● Never stand on tool. Serious injury could occur if tool is tipped or
if cutter is unintentionally contacted.
● Keep hands away from moving parts and cutting surfaces.
● Know your tool. Learn its operation, application and specic
limitations.
● Feed work into a bit or cutter against the direction of rotation of
bit or cutter.
● Turn the machine o if it jams. A cutter jams when it digs too
deeply into the workpiece. (The motor force keeps it stuck in
workpiece.)
● Use recommended accessories.
● Clamp workpiece or brace against column to prevent rotation.
● Use recommended speed for drill accessory and workpiece
material.
WARNING: Think Safety! Safety is a combination of operator common
sense and alertness at all times when drill press is being used.
INSTALL COLUMN TO BASE
Refer to Figure 7.
● Place base (Ref. No. 3) on at level surface.
● Mount column assembly (Ref. No. 7) to base using four hex bolts
(Ref. No. 10).
INSTALL TABLE TO COLUMN ASSEMBLY
Refer to Figure 7.
● Insert the worm gear (Ref. No. 34) into the table crank handle
hole from inside the table bracket (Ref. No. 25). Make sure the
worm gear (Ref. No. 34) meshes with the inside raising/lowing
gear.
● Install the table bracket locking handle (Ref. No. 33) into the hole
at the rear of the table bracket (Ref. No. 25).
NOTE: Install the handle from left to right, so it enters the
non-threaded side of the table bracket rst.
● Place the rack (Ref. No. 13) inside the table bracket (Ref. No. 25),
making sure the worm gear (Ref. No. 34) on the inside of the
table bracket is engaged with the teeth of the rack and the arrow
stamped on the rack is pointing up.
● Slide the table bracket with the rack onto the column.
● Engage the bottom of the rack with the lip of the column
support. Tighten the table bracket lock handle to lock the table
bracket to the column.
● Install the rack ring (Ref. No. 36) on the column so the top lip of
the rack sits into the rack ring.
IMPORTANT: The bottom of the collar MUST NOT be pushed
all the way down onto the top of the rack. MAKE SURE the top
of the rack is under the bottom of the collar and that there is
enough clearance to allow the rack to freely rotate around the
column. Tighten the set screw of the rack ring.
NOTE: To avoid column or collar damage, DO NOT OVERTIGHTEN
the set screw.
● Install the table crank handle (Ref. No. 31) onto the worm gear
shaft on the side of the table bracket.
● Line up the at side of the worm gear shaft with the set screw
(Ref. No. 28) in the table crank handle (Ref. No. 31) and tighten the
screw with the 3 mm hex wrench provided.
● Attach table (Ref. No. 24) to table bracket (Ref. No. 25) using the
table locking handle (Ref. No. 22).
ASSEMBLY

4
Palmgren Operating Manual & Parts List 80177
INSTALL THE HEAD
Refer to Figure 9/10.
WARNING: Although compact, the drill press head assembly
is heavy. Two people are required to mount the drill press head
assembly onto the column.
● Carefully lift the head above the column and slide it onto the
column. Make sure the head slides down over the column as far
as possible. Align the head with the base.
● Using the 5 mm hex wrench, tighten the two head lock set
screws (Ref. No. 70) on the right side of the head.
ATTACH BELT TENSION HANDLE
Refer to Figure 8.
● Thread handle (Ref. No. 183) into motor mount plate (Ref. No.
184).
MOUNT QUILL FEED HANDLE ASSEMBLY
Refer to Figure 8.
● Place key (Ref. No. 146) into feed shaft assembly (Ref. No. 61).
● Place quill feed handle assembly (Ref. No. 147) to the feed shaft
assembly.
● Secure quill feed handle assembly with a at head screw (Ref. No.
150) and a washer (Ref. No. 149).
●
Thread handle bar (Ref. No. 151) into quill feed handle assembly
(Ref. No. 147) .
INSTALL THE CHUCK
Refer to Figure 8.
WARNING: Before any assembly of the chuck and arbor to the drill
press head, clean all mating surfaces with a nonpetroleum based
product, such as alcohol or lacquer thinner. Any oil or grease used
in the packing of these parts must be removed otherwise the chuck
may come loose during operation.
● Place the chuck (Ref. No. 131) onto the spindle arbor (Ref. No.
134) while lowering the spindle by turning the feed handles (Ref.
No. 147) counterclockwise, until the slot appears on the quill.
● Push the chuck and spindle arbor up into the spindle, making sure
the tang is engaged and locked in the inner slot of the spindle.
Once tang is oriented correctly, drill duck will not rotate without
turning the spindle.
● Open the jaws of the chuck (Ref. No. 131) by rotating the chuck
sleeve clockwise. To prevent damage, make sure the jaws are
completely receded into the chuck.
NOTE: Clean the taper with a non-alcohol based cleaner before
inserting it into the arbor.
● Using a rubber mallet, plastic-tipped hammer, or a block of wood
and a hammer, rmly tap the chuck upward into position on the
spindle shaft.
CHUCK KEY STORAGE
Refer to Figure 8, 9/10.
● Storage holder (Figure 9/10, Ref. No. 68) for the chuck key (Figure
8, Ref. No. 132) is located on the right side of the head.
MOUNT DRILL PRESS
● Drill press must be mounted to at level surface. Use shims or
machine mounts if necessary. Do not mount drill press in
direct sunlight.
● Be sure to bolt drill press to oor or bench securely to prevent
tipping and minimize vibration.
● Tighten all nuts and bolts that may have loosened during
shipment.
POWER SOURCE
The motor is designed for operation on the voltage an frequency
specied. Normal loads will be handled safely on voltages not more
than 10% above or below the specied voltage.
Running the unit on voltages which are not within the range may
cause overheating and motor burn out. Heavy loads require that the
voltage at motor terminals be no less than the voltage specied.
GROUNDING INSTRUCTIONS
Refer to Figure 2, 3 and 4.
WARNING: Improper connection of equipment grounding
conductor can result in the risk of electrical shock. Equipment
should be grounded while in use to protect operator from electrical
shock. Check with a qualied electrician if grounding instructions
are not understood or if in doubt as to whether the tool is properly
grounded.
This tool is equipped with an approved 3-conductor cord rated
up to 300 V and a 3-prong grounding type plug rated at 115 V for
your protection against shock hazards.
Grounding plug should be plugged directly into a properly
installed and grounded 3-prong grounding-type receptacle, as
shown (Figure 2).
Do not remove or alter grounding prong in any manner. In the event
of a malfunction or breakdown, grounding provides a path of least
resistance for electrical shock.
WARNING: Do not permit ngers to touch the terminals of plug
when installing or removing from outlet.
Plug must be plugged into matching outlet that is properly installed
and grounded in accordance with all local codes and ordinances.
Do not modify plug provided. If it will not t in outlet, have proper
outlet installed by a qualied electrician.
Inspect tool cords periodically, and if damaged, have repaired by an
authorized service facility.
INSTALLATION
3-Prong Plug
Grounding Prong
Properly Grounded Outlet
Figure 2 – 3-Prong Receptacle

5
Palmgren Operating Manual & Parts List 80177
Green (or green and yellow) conductor in cord is the grounding wire.
If repair or replacement of the electric cord or plug is necessary, do
not connect the green (or green and yellow) wire to a live terminal.
Where a 2-prong wall receptacle is encountered, it must be replaced
with a properly grounded 3-prong receptacle installed in accordance
with National Electric Code and local codes and ordinances.
WARNING:
This work should be performed by a qualied electrician.
A temporary 3-prong to 2-prong grounding adapter (See Figure 3)
is available for connecting plugs to a two pole outlet if it is properly
grounded.
Do not use a 3-prong to 2-prong grounding adapter unless
permitted by local and national codes and ordinances.
(A 3-prong to 2-prong grounding adapter is not permitted in
Canada.) Where permitted, the rigid green tab or terminal on the
side of the adapter must be securely connected to a permanent
electrical ground such as a properly grounded water pipe, a properly
grounded outlet box or a properly grounded wire system.
Many cover plate screws, water pipes and outlet boxes are not
properly grounded. To ensure proper ground, grounding means
must be tested by a qualied electrician.
EXTENSION CORDS
● The use of any extension cord will cause some drop in voltage
and loss of power.
● Wires of the extension cord must be of sucient size to carry the
current and maintain adequate voltage.
● Use the table to determine the minimum wire size (A.W.G.)
extension cord.
● Use only 3-wire extension cords having 3-prong grounding type
plugs and 3-pole receptacles which accept the tool plug.
● If the extension cord is worn, cut, or damaged in any way, replace
it immediately.
EXTENSION CORD LENGTH (120 VOLTS)
Wire Size A.W.G.
Up to 25 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
25-50 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
NOTE: Using extension cords over 50 ft. long is not recommended.
EXTENSION CORD LENGTH (240 VOLTS)
Wire Size A.W.G.
Up to 50 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
50-100 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
100-200 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
200-300 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
NOTE: Using extension cords over 300 ft. long is not recommended.
POWER SOURCE
For single phase: Drill press requires a 120/240 volt, 60 Hz power
source. To use the drill press with a 240 V power supply, have a
qualied electrician attach a 240 volt, 20/30 A three-prong plug onto
drill press line cord.
For three phase: Drill press requires a 120 volt, 60 Hz power source.
ELECTRICAL CONNECTIONS
Refer to Figure 4
WARNING: All electrical connections must be performed by a
qualied electrician. Make sure unit is o and disconnected from
power source while motor is mounted, connected, reconnected or
anytime wiring is inspected.
● The motor should be wired for 120 volts and clockwise rotation
as viewed from shaft end of motor.
● A label on the motor describes the possible wiring
congurations. There are many dierent possible combinations,
so only the diagram provided with the motor should be used.
● The power supply to motor is controlled by a push button
switch. Power lines are connected to the quick connect terminals
of the switch.
● The green ground line must remain securely fastened to the
motor ground terminal to provide proper grounding.
● To operate drill press at 240 volts, rewire motor as shown in
Figure 4 and replace line cord plug with a 240 volt, 15 A, 3-prong
plug. If motor label has a dierent wiring conguration, use the
motor label diagram to rewire motor.
NOTE: Only for the drill press with single phase use.
WARNING: Read and understand operating instructions and parts
manual before operating this machine.
CAUTION: The operation of any power tool can result in foreign
objects being thrown into the eyes, which can result in severe
eye damage. Always wear safety glasses complying with United
States ANSI Z87.1 (shown on package) before commencing power
tool operation.
START AND STOP THE DRILL PRESS
Refer to Figure 9/10.
WARNING: Be sure drill bit is not in contact with workpiece when
motor is started. Start motor and allow bit to come up to full speed
before drilling.
● The ON/OFF siwtch (Ref. No. 47/48) is located on the front of the
head casting.
● To turn the drill press on, push START button. Always allow drill
bit to come up to speed before drilling.
● To turn the drill press o, press the large red OFF paddle or lift
the paddle and press directly on the red OFF button. Do not
leave drill press until the bit has come to a complete stop.
Figure 3 – 2-Prong Receptacle with adapter
3-Prong Plug
Adapter
Grounding Lug Make sure this is
Connected to a
known Grounded
Receptacle
2-Prong Receptacle
120 Volts
1313 4242
240 Volts
Figure 4 – Wiring Schematic for Motor
OPERATION

6
Palmgren Operating Manual & Parts List 80177
SPEED ADJUSTMENTS
Refer to Figures 5 and 8.
WARNING: Be sure drill press is turned o and is disconnected from power source before adjusting speeds.
● To change spindle speed, loosen motor lock handle (Ref. No. 187), pivot the motor toward front of drill press. This will loosen the belt and
permit relocating the belt to the desired pulley groove for the required spindle speed (See Figure 5).
● After belt has been repositioned, pull the handle (Ref. No. 183) to move motor toward rear of drill press and tighten motor lock handle.
● Check belt for proper tension and make any nal adjustment. A belt is properly tensioned when light pressure applied to midpoint of the
belt produces about 1/2”deection.
E
D
C
B
A
Z
Y
X
W
5
4
3
2
1
Motor
Spindle
RPM Wood Zinc Diecast Alum. & Brass Plastic Cast Iron &
Bronze
Steel - Mild &
Malleable
Steel - Cast &
Med. Carbon
Steel - Stainless
& Tool
in/mm in/mm in/mm in/mm in/mm in/mm in/mm in/mm
3476 5/16 7.9 3/16 4.8 11/64 4.4 5/32 4.0 7/64 2.8 3/32 2.4 1/16 1.6 1/32 0.8
2362 5/8 15.9 3/8 9.5 11/32 8.7 5/16 7.9 1/4 6.4 5/32 4.0 1/8 3.2 1/16 1.6
1660 7/8 22.2 1/2 12.7 15/32 11.9 7/16 11.1 11/32 8.7 1/4 6.4 3/16 4.8 1/8 3.2
566 1/ 31.8 3/4 19.0 11/16 17.5 5/8 15.9 1/2 12.7 3/8 9.5 5/16 7.9 1/4 6.4
497 1/ 31.8 3/4 19.0 11/16 17.5 5/8 15.9 1/2 12.7 3/8 9.5 5/16 7.9 1/4 6.4
344 1/ 41.3 7/8 22.2 3/4 19.0 13/16 20.6 5/8 15.9 1/2 12.7 7/16 11.1 3/8 9.5
257 2 50.8 1 25.4         9/16 14.3 1/2 12.7
Figure 5 – Spindle Speed Adjustment
RPM Belt Locaiton
138 A1-5Z
257 B2-5Z
304 A1-4Y
344 C3-5Z
461 D4-5Z
497 A1-3X
566 B2-4Y
708 A1-2W
755 C3-4Y
927 B2-3X
1491 E5-4Y
1660 D4-3X
1761 C3-2W
2362 D4-2W
2444 E5-3X
3476 E5-2W
TABLE ADJUSTMENTS
Refer to Figure 7.
● Height adjustments: To adjust table, loosen locking handle (Ref.
No. 33) and turn crank handle (Ref. No. 31) to desired height.
Immediately retighten table bracket locking handle.
● Rotation of work table : Loosen table locking handle (Ref. No. 22)
and rotate table (Ref. No. 24) to desired position and retighten
handle.
● Tilting work table: Loosen hex bolt (Ref. No. 20). Remove pin (Ref.
No. 16) by loosening hex nut (Ref. No. 17). Tilt table to desired
angle up to 45° and retighten table bolt. Reinsert pin and nut
when returning the table to 0° position.
● To obtain more distance between chuck and table, the work
table can be rotated 180° and base can be used as a work
surface. This permits drilling of larger objects.
● Clamp table securely after adjustments have been made.
DEPTH STOP ADJUSTMENT
Refer to Figure 8.
To control drilling depth, use scale (Ref. No. 128) to adjust to desired
depth. Depress and hold pin, slide depth stop nut (Ref. No. 130)
along lead screw until bottom edge of nut coincides with the desired
depth on the scale, then release pin. Use this feature to drill more
than one hole to the same depth.
MOUNT DRILL BIT
Refer to Figure 8.
WARNING: To avoid injury or accident by the chuck key ejecting
forcibly from the chuck when the power is turned on, use only the
self-ejecting chuck key supplied with this drill press. ALWAYS recheck
and remove the chuck key before turning the power on. Be sure drill
press is turned o and is disconnected from power source before
adjusting speeds.
● Place drill bit in jaws of drill chuck.
● Tighten chuck with drill chuck key. Be sure to tighten the chuck
using all three key positions on the chuck body and remove
chuck key.
● Use only the self-ejecting chuck key (Ref. No. 132) supplied with
this drill press, or a duplicate key. Use of any other key might
allow start up with the key still in the chuck. An airborne key
could strike the operator and cause injury.

7
Palmgren Operating Manual & Parts List 80177
●Apply lubricant to rack and pinion gear (Figure 7, Ref. Nos. 13 &
34) on column and table assembly.
CLEAN MOTOR
Frequently blow out any dust that may accumulate inside motor.
If power cord is worn, cut or damaged in any way, have it replaced
immediately.
IMPORTANT: To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustment (other than those listed in this manual)
should be performed by authorized service centers or other qualied
service organizations, always sing identical replacement parts.
WARNING: To avoid shock or re hazard, if the power lead is worn
or cut in any way, replace it immediately.
REMOVE THE CHUCK
Refer to Figure 8.
● With the switch“OFF”and the unit unplugged, adjust the depth
stop nut (Ref. No. 130) to hold the drill at a depth of 3 in. (7.6 cm).
● Align the key holes in the spindle and quill by rotating the chuck
by hand.
● Insert the key wedge (Ref. No. 142) into the key holes. Tap the key
wedge lightly with a plastic tipped hammer, until the chuck and
arbor fall out of the spindle.
NOTE: Place one hand below the chuck to catch it when it falls
out.
DIGITAL DISPLAY PANEL
Refer to Figure 6.
● Display panel (A) shows the spindle RPM.
● Button (B) turns power on and o to LED light.
REVERSING SWITCH
Refer to Figure 10.
NOTE: Only the drill press with the three-phase electric power
system has the reversible function.
● The direction of the chuck rotation is controlled by the rocker
switch located at the left side of the ON/OFF switch base (Ref.
No. 51).
WARNING: The design of the switch will not permit changing the
direction of rotation while the drill press is running.
WARNING: Turn switch o and remove plug from power source
outlet before maintaining or lubricating your drill press.
DRIVE BELT
Replace drive belt when worn.
LUBRICATION
Refer to Figures 7 and 8.
The ball bearings are lubricated at the factory and need no further
lubrication. Using 20wt. non detergent oil, periodically lubricate the
splines (grooves) in the spindle and the rack (teeth on the quill)
as follows:
●Lower quill assembly (Figure 8, Ref. No. 147) all the way down.
●Apply lubricant around the inside of the hole in the spindle
pulley (Figure 8, Ref. No. 158 & 172).
●Apply lubricant to rack (teeth) on quill (Figure 8, Ref. No. 144)
while extended below drill press head.
Figure 6 – Digital Display Panel
A
B
MAINTENANCE

8
Palmgren Operating Manual & Parts List 80177
TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION
Spindle does not turn 1. No power to drill press 1. Check wiring, fuse or circuit breaker
2. Defective switch 2. Replace switch
3. Defective motor 3. Replace motor
Noisy spindle Defective bearings Replace bearings
Noisy operation 1. Incorrect belt tension 1. Adjust tension
2. Dry spindle 2. Lubricate spindle, See Lubrication, page 7
3. Loose spindle 3. Tighten pulley nut
4. Loose motor pulley 4. Tighten set screw in pulley
Bit burns or smokes 1. Incorrect speed 1. Change speed
2. Chips not coming out of table 2. Retract bit frequently to clear chips
3. Dull bit 3. Sharpen or replace bit
4. Feeding too slow 4. Feed faster; enough to allow drill to cut
5. Bit not lubricated 5. Lubricate bit
6. Bit running backwards 6. Check motor rotation to be sure it is clockwise facing
shaft end
Excessive drill runout or wobble 1. Bent bit 1. Replace bit
2. Bit not properly installed in chuck 2. Install bit properly
3. Chuck not properly installed 3. Install chuck properly
4. Worn spindle bearings 4. Replace bearings
Drill bit binds in workpiece 1. Workpiece pinching bit or excessive feed 1. Support or clamp work, decrease feed pressure
2. Improper belt tension 2. Adjust tension
3. Workpiece not supported or clamped properly 3. Support or clamp workpiece securely

9
Palmgren Operating Manual & Parts List 80177
Service Record
Palmgren 17" Floor Modle Drill Press
DATE MAINTENANCE PERFORMED REPLACEMENT PARTS REQUIRED

10
Palmgren Operating Manual & Parts List 80177
NOTES

11
Palmgren Operating Manual & Parts List 80177
NOTES

12
Palmgren Operating Manual & Parts List 80177
Figure 7 - Replacement Parts Illustration for Base (Single & Three Phase)
41
16 17
20
22
10
13 39
38
7
3
33
25
24
28
29
31
36
34

13
Palmgren Operating Manual & Parts List 80177
Ref.
No. Description
Part No.
Qty.
3 Base 9632113.05 1
7 Columm holder ass'y 9632114.05 1
10 M10*1.5-40 Hex. hd. bolt * 4
13 Rack 9632179.05 1
16 Location pin 9631972.05 1
17 1/4*20UNC T=4.7 Hex. nut * 1
20 5/8-11UNC-1 Hex. hd. bolt * 1
22 Table lock handle 9632117.05 1
24 Table 9632119.10 1
25 Table bracket ass'y 9632118.05 1
28 M6*1.0-10 Hex. soc. set screw * 1
29 Handle bar 9631982.05 1
31 Crank handle 9632125.05 1
33 Column lock handle 9631976.05 1
34 Worm 9632123.05 1
36 Rack ring ass'y 9632120.05 1
38 Tilting scale 9631974.05 1
39 φ2.3-5 Drive screw * 2
41 Instruction manual * 1
* Standard hardware item available locally.
REPLACEMENT PARTS LIST FOR BASE

14
Palmgren Operating Manual & Parts List 80177
Figure 8 - Replacement Parts Illustration for Spindle and Drive (Single & Three Phase)
189 (~)
190 (3~)
118 (~)
119 (3~)
193
194
105 (~)
106 (3~)
131
132
134
63
137
139
141
126
124
125
128
130
123
122
195
61
146
147
149
150
151
156
153
158
160
163
168
166
165
172
170
174
137
182 176
66
180
174
184 183
185
177
187
186
176
144
142
178

15
Palmgren Operating Manual & Parts List 80177
REPLACEMENT PARTS LIST FOR SPINDLE AND DRIVE
Ref.
No. Description Part No. Qty.
Ref.
No. Description Part No. Qty.
61 Feed shaft ass'y 9632140.10 1 160 φ22.5 Pulley set nut 9632126.05 1
63 M10*1.5 T=8 Hex. nut * 1 163 V-ribbed belt (poiyourethane) 9632180.10 1
66
M6*1.0-12 Cr. re. round washer hd. screw * 4 165 Parallel key 9607885.05 1
105 Head for single phase * 1 166 Motor pulley 9632151.05 1
106 Head for three phase * 1 168 M6*1.0-16 Hex. soc. Set screw * 1
118 Power cable for single phase 9632146.05 1 170 V-ribbed belt (poiyourethane) 9632182.10 1
119 Power cable for three phase 9632146.10 1 172 Pulley ass'y 9632132.10 1
122 5 mm Hex. wrench 9600150.05 1 174 M10*1.5-20 Hex. soc. hd. cap bolt * 8
123 3 mm Hex. wrench 9600149.05 1 176 M10*1.5 T=10 Chuck nut * 2
124 Circular nut 9632066.05 1 177 φ10*20-2 Nylon washer * 2
125 M6*1.0-40 Hex. soc. hd. cap screw * 2 178 Collar 9600533.05 1
126 Plunger housing 9632067.05 1 180 Motor retaining clip 9632184.05 1
128 Set bolt ass'y 9632026.10 1 182 M10*1.5-25 Hex. soc. hd. cap bolt * 1
130 Depth stop nut 9632029.05 1 183 Handle shifter 9632148.05 1
131 Chuck & key 9632138.05 1 184 Motor bracket 9632149.05 1
132 Chuck key 9632139.05 1 185 M10*1.5 T=8 Hex. nut * 1
134 MT2*JT3 Drilling arbor 9627926.05 1 186 φ12 Spring washer * 1
137 Spring washer * 5 187 Locking handle ass'y 9632145.05 1
139 Set ring 9632136.10 1 189 Motor ass'y for single phase 9632181.10 1
141 M8*1.25-20 Hex. soc. hd. cap bolt * 1 190 Motor ass'y for three phase 9632181.15 1
142 Wedge shifter 9618909.05 1 193 1/2*20UNF T=6.5 Hex. nut * 1
144 Spindle ass'y 9632137.10 1 194 1/2*20UNF T=10 Hex. nut * 1
146 Parallel key 9632020.05 1 195 Plate spring ass'y 9632133.05 1
147 Handle ass'y 9632141.05 1
149 Washer 9632017.05 1
150 M5*0.8-12 Cr. re. count hd. screw 9632004.05 1
151 Handle bar ass'y 9632018.05 1
153 Driving sleeve ass'y 9609624.10 1
156 Retaining ring 9632129.10 2
158 Pulley & magnet ass'y 9632127.05 1
* Standard hardware item available locally.

16
Palmgren Operating Manual & Parts List 80177
Figure 9 - Replacement Parts Illustration for Head (Single Phase)
43 44
50
57
58
56 55
47
49
54
59
105
61
64
65
66
68
70
71
77
76
83
39
74
81
86
85
79
87
88
89
91
93
94
95
96
45
99
101
100
102

17
Palmgren Operating Manual & Parts List 80177
REPLACEMENT PARTS LIST FOR HEAD (Single Phase)
Ref.
No. Description Part No. Qty.
Ref.
No. Description Part No. Qty.
39 φ2.3-5 Drive screw * 4 83 Label * 1
43 Lead wire ass'y 9600068.00 1 85 Hall sensor ass'y 9632042.05 1
44 Lead wire ass'y 9600069.00 1 86 M3*0.5-8 Cr. re. pan hd. screw * 2
45 Lead wire ass'y 9600070.00 1 87 M8*1.25 T=5 Hex. nut * 1
47 Switch ass'y 9632157.05 1 88 Captive screw 9632037.05 1
49 M5*0.8-35 Cr. re. pan hd. screw * 2 89 Caution label * 1
50 Switch box ass'y 9632159.05 1 91 Label * 1
54 Controller ass'y 9632160.05 1 93 Warning label * 1
55 M3*24-6 Cr. re. pan hd. tapping screw * 4 94 M5*0.8-10 Cr. re. pan hd. screw * 1
56 M5*0.8-16 Cr. re. round washer hd. screw * 2 95 Cord clamp 9632156.05 1
57 M5*0.8-8 Cr. re. pan hd. screw * 2 96 Spring pin 9604092.05 2
58 φ5 External tooth lock washer * 2 99 Lamp socket 9632058.05 1
59 Sticker * 2 100 M5*0.8-16 Hex. soc. hd. cap screw * 3
61 Feed shaft ass'y 9632140.10 1 101 Lamp ass'y 9632064.05 1
64 M10*1.5 T=8 Hex. nut * 1 102 Cover 9632065.05 1
65 Quill set screw 9632135.05 1 105 Head * 1
66 M6*1.0-12 Cr. re. round washer hd. screw * 1
68 Chuck key holder 9632158.05 1
70 M10*1.5-12 Hex. soc. set screw * 2
71 φ8.5*22-3 Flat washer * 4
74 Motor label * 1
76 M4*0.7-6 Cr. re. pan hd. screw * 1
77 Sacle plate 9632043.05 1
79 Pulley cover ass'y 9632153.05 1
81 Strain relief 9632041.05 1
* Standard hardware item available locally.

18
Palmgren Operating Manual & Parts List 80177
Figure 10 - Replacement Parts Illustration for Head (Three Phase)
51
43
44
46
48
49
54
55
56
58
57
59
70
71
66
68
64
65
61
39
199
83
81
77
76
86
85
79
87
88
89
91
93
94
95
96
45
99
100
101 109
110 113
112
111
114
98
102
106

19
Palmgren Operating Manual & Parts List 80177
REPLACEMENT PARTS LIST FOR HEAD (Three Phase)
Ref.
No. Description Part No. Qty.
Ref.
No. Description Part No. Qty.
39 φ2.3-5 Drive screw * 4 83 Label * 1
43 Lead wire ass'y 9600068.00 2 85 Hall sensor ass'y 9632042.05 1
44 Lead wire ass'y 9600069.00 2 86 M3*0.5-8 Cr. re. pan hd. screw * 2
45 Lead wire ass'y 9600070.00 1 87 M8*1.25 T=5 Hex. nut * 1
46 Lead wire ass'y 9600071.00 2 88 Captive screw 9632037.05 1
48 Switch ass'y 9632044.05 1 89 Caution label * 1
49 M5*0.8-35 Cr. re. pan hd. screw * 2 91 Label * 1
51 Switch box ass'y 9632159.10 1 93 Warning label * 1
54 Controller ass'y 9632160.05 1 94 M5*0.8-10 Cr. re. pan hd. screw * 1
55 M3*24-6 Cr. re. pan hd. tapping screw * 4 95 Cord clamp 9632156.05 1
56 M5*0.8-16 Cr. re. round washer hd. screw * 2 96 Spring pin 9604092.05 2
57 M5*0.8-8 Cr. re. pan hd. screw * 2 98 Strain relief 9632044.05 2
58 φ5 External tooth lock washer * 2 99 Lamp socket 9632058.05 1
59 Sticker * 2 100 M5*0.8-16 Hex. soc. hd. cap screw * 3
61 Feed shaft ass'y 9632140.10 1 101 Lamp ass'y 9632064.05 1
64 M10*1.5 T=8 Hex. nut * 1 102 Cover 9632065.05 1
65 Quill set screw 9632135.05 1 106 Head * 1
66 M6*1.0-12 Cr. re. round washer hd. screw * 1 109 M5*12-16 Cr. re. truss hd. tapping screw * 4
68 Chuck key holder 9632158.05 1 110 Switch cover 9632048.05 1
70 M10*1.5-12 Hex. soc. set screw * 2 111 M5*0.8-12 Cr. re. pan hd. screw * 2
71 φ8.5*22-3 Flat washer * 4 112 Wire connector 9632047.05 1
76 M4*0.7-6 Cr. re. pan hd. screw * 1 113 M4*16-10 Cr. re. pan hd. tapping screw * 2
77 Sacle plate 9632043.05 1 114 Connector box 9631089.05 1
79 Pulley cover ass'y 9632153.05 1 199 Motor label * 1
81 Strain relief 9632041.05 1
* Standard hardware item available locally.

20
Palmgren Operating Manual & Parts List 80177
WARRANTY
Palmgren warrants their products to be free of defects in material or workmanship. This warranty does not cover defects due directly or
indirectly to misuse, abuse, normal wear and tear, failure to properly maintain the product, heated, ground or otherwise altered, or used for a
purpose other than that for which it was intended. The warranty does not cover expendable and/or wear parts (i.e. v-belts, coated
screws, abrasives), damage to tools arising from alteration, abuse or use other than their intended purpose, packing and freight. The duration
of this warranty is expressly limited to one year parts and labor, unless otherwise noted below beginning from the date of delivery to the
original user. The Palmgren products carry the following warranties on parts with a 1 year warranty on labor:
● USA Machine vises – Lifetime
● IQ Machine vises – Lifetime
● Bench vises – Lifetime
● Positioning tables – Lifetime
● Bench grinders & buers – 3 years
● Tapping machines – 2 years
● Drilling machines – 2 years
● Finishing machines – 2 years
● Band saws – 2 years
● Work stands – 2 years
● Arbor presses – 2 years
● Metal framing equipment – 2 years
● Accessories – 1 year
The obligation of Palmgren is limited solely to the repair or replacement, at our option, at its factory or authorized repair agent of any
part that should prove decient. Purchaser must lubricate and maintain the product under normal operating conditions at all times.
Prior to operation become familiar with product and the included materials, i.e. warnings, cautions and manuals. Failure to follow these
instructions will void the warranty.
This warranty is the purchaser’s exclusive remedy against Palmgren for any deciency in its products. Under no circumstances is Palmgren
liable for any direct, indirect, incidental, special or consequential damages including lost prots in any way related to the use or inability to
use our products. This warranty gives you specic legal rights which may vary from state to state.
SERVICE & REPAIR
1. If a Palmgren product requires a repair or warranty service DO NOT return the product to the place of purchase.
2. All warranty related work must be evaluated and approved by Palmgren.
3. Prior to returning any item the user must obtain factory approval and a valid RGA number.
4. For instructions and RGA number call toll free [phone].
