KX-NS700G Quick Reference Guide
1. Introduction
Thank you for purchasing this Panasonic product.
Please read this guide before using this product.
See the KX-NS700 manuals for the full KX-NS700 details other than the KX-NS700G
content written in this guide. For more information, refer to
http://www.panasonicpartnerportal.com/
2. Overview
LAN Port
PFT Port
DPT Port
LCOT6 Port
DLC16 Port
SLT Port
16
116
KX-NS700G: Front Side
Model No. Model Name
KX-NS5180 (Pre-installed) 6-port Analogue Trunk Card (LCOT6)
KX-NS5172 (Pre-installed) 16-port Digital Extension Card (DLC16)
1

Note
Refer to the KX-NS700 Installation manual for the description of optional cards other than
the pre-installed cards.
KX-NS700G has pre-installed ports (CO lines, extensions, UM) and mailboxes as follows:
Pre-installed Number
CO Line 6 ports
Extension DPT 18 ports
SLT 4 ports
IPPT 4 ports
Unified Message 2 ports
Mailbox 500 mailboxes
Pin assignment of KX-NS700G as below:
LAN Port (10BASE-T/100BASE-T)
No. Signal Name Input (I)/Output (O) Function
81
1 TPO+ O Transmit data +
2 TPO- O Transmit data -
3 TPI+ I Receive data +
4-5 Reserved – –
6 TPI- I Receive data -
7-8 Reserved – –
User supplied (not included): CAT 5 or higher Cable.
2

DPT Port
No. Signal Name Function
81
1 D1 A Data port 1 (Low)
2 D2 A Data port 1 (High)
3 D1 B Data port 2 (Low)
4 Reserved –
5 Reserved –
6 D2 B Data port 2 (High)
7 Reserved –
8 Reserved –
User supplied (not included): RJ45 connector, Twisted pair cable.
SLT Port
No. Signal Name Function
81
1 TA Tip port 1
2 RA Ring port 1
3 Reserved –
4 Reserved –
5 Reserved –
6 Reserved –
7 TB Tip port 2
8 RB Ring port 2
User supplied (not included): RJ45 connector, Twisted pair cable.
3

DLC16 PORT
No. Signal Name Function
81
1 D1A Data port 1 (Low)
2 D2A Data port 1 (High)
3 D1B Data port 2 (Low)
4 D1C Data port 3 (Low)
5 D2C Data port 3 (High)
6 D2B Data port 2 (High)
7 D1D Data port 4 (Low)
8 D2D Data port 4 (High)
User supplied (not included): RJ45 connector, Twisted pair cable.
4

PFT PORT/LCOT6 PORT
Optional card KX-NS5180
No. Signal Name
81
1TA
2RA
3
4Reserved
5Reserved CO1 Tip
6Reserved
7TB
8RB
PFT1-2
Reserved
No. Signal Name
81
1TA
2RA
3
4Reserved
5Reserved
6Reserved
7TB
8RB
Reserved
CO1 Ring
CO2 Tip
CO2 Ring
Note
The connector consists of multiple lines for the extensions/CO lines. Therefore, each RJ45
cable needs to be connected to the necessary port and divided for the appropriate
extensions/CO lines. For more information, consult your Dealer.
5

3. System Components
The following cards and activation keys are installed:
Model No. Model Name
KX-NS5110 VoIP DSP Card (S Type) (DSP S)
KX-NS7134 SD Memory Card (XS Type) (SD Memory XS)
The SD card is sealed to at the factory so that it does not fall off during transportation. If
you need to exchange the SD card, remove the seal before exchanging.
SD Card Mother Board
SD Card Slot
Remove it when
the SD card exchange.
Model No. Activation Key Type Description
KX-NSM501W 1 (x4) IP PT/SIP-MLT/
P-SIP
Allows the use of 1 (x4)
IP-PT/KX-UT series SIP
phone/P-SIP Extension.
This activation key is
preinstalled for 4 IP
channels.
Other equipment and activation keys are available as the options:
Model No. Model Name
KX-NS5162 DOOR PHONE INTERFACE CARD (DPH2)
KX-NS5290 PRI23 TRUNK CARD (PRI23)
KX-A247X WALL MOUNT KIT
KX-NS0154 DECT 4-CHANNEL IP CELL STATION UNIT
KX-NSE201W ACTIVATE 1 IP-CS FOR EXPANSION TO 8-CHANNEL
6

Model No. Model Name
KX-NSE205W ACTIVATE 5 IP-CS FOR EXPANSION TO 8-CHANNEL
KX-NSE210W ACTIVATE 10 IP-CS FOR EXPANSION TO 8-CHANNEL
KX-NSE220W ACTIVATE 20 IP-CS FOR EXPANSION TO 8-CHANNEL
KX-NCP0158 8-CHANNEL DECT CELL STATION AND INTERFACE CARD
(IP)
KX-A421 OPTIONAL POWER SUPPLY (PSLP1662) FOR THE
KX-NCP0158 CELL STATION
KX-NSA010W COMMUNICATION ASSISTANT—THIN CLIENT LICENSE
KX-NSA020W CTI—CSTA MULTIPLEXOR LICENSE
KX-NSA2XXW COMMUNICATION ASSISTANT PRO
KX-NSA301W COMMUNICATION ASSISTANT ICD SUPERVISOR
KX-NSA401W COMMUNICATION ASSISTANT OPERATOR CONSOLE
KX-NSA9XXW COMMUNICATION ASSISTANT QSIG NETWORK PLUG-IN
KX-NSE1XXW ACTIVATION KEY FOR MOBILE EXTENSION
KX-NSF101W CTI—3RD PARTY CTI
KX-NSM1XXW IP TRUNK ACTIVATION KEY
KX-NSN002W Q-SIG NETWORKING (PER SYSTEM)
KX-NSF201W CALL CENTER FEATURE ENHANCEMENT
KX-NSU002W AUTOMATIC 2-WAY RECORDING CONTROL—MANAGER
KX-NSU003W BACK-UP RECORDING DATA
KX-NSU3XXW MANUAL 2-WAY RECORDING
Refer to the Installation manual for the details. Other KX-NS700 equipment and activation
keys not listed here will not operate with the KX-NS700G even if they are successfully
installed.
4. The specification differences between KX-NS700G
and KX-NS700
4.1 System Capacity
• KX-NS700G limits number of extensions from original NS700 and other resources, such
as trunks, are not limited.
Maximum number of extensions is as follows,
7

Extension type Maximum number
DPTs 18
SLTs 4
IP-PTs 4
• The KX-NS700G capacities can be expanded to the same as the KX-NS700 by installing
“Activation Key to release KX-NS700G capacity limitation” (KX-NSF999W).
Note
• KX-NSF999W is a new activation key and a dedicated activation key for the KX-NS700G.
• The KX-NSF999W has to be preinstalled before activating any KX-NS700 optional
equipment or activation keys other than those listed above.
8

Following table shows system capacity
Pre Install Max. without
KX-NSF999W
Max. with
KX-NSF999W
CO line (ch) 6 102
Legacy 6 38 (30+8)
LCOT 6 12
PRI23 0 23
IP 0 64
SIP 0 64
H.323 0 32
Extension (ch) 22 26 166
Legacy 22 22 38
SLT 4 4 36 (32+4)
DPT 18 18 34 (32+2)
APT 0 0 8
IP 0 (4 IP-PT AK) 4 32/128*2
IP-PT 0 (4 IP-PT AK) 4 32/128*2
SIP 0 (4 IP-PT AK) 4 32/128*2
P-SIP *1 0 (4 IP-PT AK) 4 32/128*2
SIP Phone [phone]*2
KX-UT series 0 (4 IP-PT AK) 4 32/128*2
CS (pcs) 0 24
DPT-CS (2ch) 0 8
DPT-CS (8ch) 0 4
IP-CS (8ch) 0 16
New IP-CS (4ch/8ch) 0 32
SIP-CS 0 16
9

Pre Install Max. without
KX-NSF999W
Max. with
KX-NSF999W
PS (DECT) (pcs) 128 128
VM
ESVM (ch) 2 2
Built-in UM (ch) 2 24
TVM unit 2 2
Door phone 0 2
Door phone 0 2
Door opener 0 2
Sensor 0 2
PFT 2 2
(2) 2
MOH / BGM (2) 2
EPG (2) 2
*1 KX-HDV series, KX-NTV series, KX-TGP600
*2 In case that IP extensions are over 32 or connecting to KX-NS720, "Expansion
Capacity Activation key" (KX-NSF991W) is required.
10

4.2 System Resource Capacity
The System Resource Capacity is the same as KX-NS700 even if “Activation Key to
release NS700G capacity limitation” (KX-NSF999W) is not installed. See the KX-NS700
manuals for System Resource Capacity details.
4.3 Programming
• The KX-NS700G does not support the database conversion from legacy PBX (ex.
KX-TDA50, KX-TDE series, and KX-NCP series).
