Panasonic AK-HRP1000G User manual

DVQP1358YA
W0317MN1107 -PS
ENGLISH
For details of operating Remote Operation Panel AK-HRP1000G, please
visit the Panasonic website (http://pro-av.panasonic.net/en/manual/index.
html), and refer to the Operating Instruction (HTML or PDF).
Read this document when using the AK-HRP1000G Remote Operation Panel in
conjunction with AK-UB300G Series Multi-Purpose Cameras.
Operating Guide
Remote Operation Panel
Model No. AK-HRP1000G

Connecting the Unit to AK-UB300G Series Cameras 3
System block diagram 3
Connections 4
Compatible Functions List 5
ROP Menu (when AK-UB300G is connected) 10
ROP menu list 10
01 PAINT SWITCH 17
02 SHUTTER SPEED 18
03 PEDESTAL 19
04 CHROMA 20
05 RB GAIN 21
06 COLOR TEMP 22
07 FLARE 23
08 GAMMA 24
09 BLACK GAMMA 25
10 KNEE 26
11 DETAIL 27
12 SKIN TONE DTL 28
13 MATRIX 29
14 COLOR CORRECTION 31
15 SKIN CORRECTION 33
16 DNR 34
17 HAZE REDUCTION 35
18 LENS CONTROL 36
19 SYSTEM CAM 37
20 CAMERA MENU CONTROL 38
21 ROP SETTING 39
22 CONNECT SETTING 40
23 ROP IP SETTING 41
24 CAMERA IP SETTING 41
25 AUTO IRIS SETTING 42
26 HDR-PAINT 43
- 2 -
Table of Contents

Connecting the Unit to AK-UB300G Series Cameras
NOTE
The descriptions in this document assume that the system version of the unit is V4.40-00-0.00 or later. Make sure that the system
version of the AK-UB300G used in conjunction with the unit is V7.52-000-00.00 or later.
System block diagram
This is the configuration for connecting one AK-UB300G and one remote operation panel.
A
B
C
IRIS
E
ZOOM/FOCUS
D
F
(AK-UB300G)
A. Remote control lens
B. HD monitor (for HD main line)
C. HD monitor (for HD monitor)
D. External DC power supply
E. UHD/HD monitor (for UHD/HD main line)
F. AK-HRP1000G
Video output
For UHD mode
For UHD main line: Use the output from the <UHD/HD SDI OUT 1> to <UHD/HD SDI OUT 4> terminals.
For HD main line: Use the output from the <HD SDI OUT 1> terminal.
For HD monitor: Use the output from the <HD SDI OUT 2> terminal.
For UHD CROP mode/HD mode
For HD main line: Use the output from the <HD SDI OUT 1> terminal, or the output from the <UHD/HD SDI OUT
1>/<UHD/HD SDI OUT 2> terminal.
For HD monitor: Use the output from the <HD SDI OUT 2> terminal.
Remote operation panel
Connect AK-HRP1000G to the <I/F> terminal or the <LAN> terminal of the AK-UB300G.
- 3 -
Connecting the Unit to AK-UB300G Series Cameras

Connections
Set the connection setting to [Serial(AW)] or [LAN(AW)] in the [CONNECT SETTING] menu.
ヤヰワワユヤヵチヴユヵヵリワヨ
ヒチバチヒヒ
ヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナ
ワヰワワヰワ
ヤモヮベヤモヮペ
ヴㄆㄓㄊ㄂ㄍドモヸナロモワドモヸナワヰワワヰワワヰワワヰワ
ヤモヮフ
ワヰワ
ヤモヮヘヤモヮビヤモヮピヤモヮヒヤモヮブヤモヮプ
When connecting, observe the following points.
Serial connection
Use a dedicated cable to connect the [CCU] connector of this unit to the <I/F> terminal of the AK-UB300G.
Use a PoE injector for the power supply.
LAN connection
Connect the [LAN] connector on this unit to the <LAN> connector on the AK-UB300G using a LAN cable (sold
separately).
This unit can be powered using PoE. Use a switching hub with PoE support.
Use a straight cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).
For details on switching hubs and PoE injectors that have been verified to support PoE, consult with your dealer.
- 4 -
Connecting the Unit to AK-UB300G Series Cameras

Compatible Functions List
When the unit is used in conjunction with an AK-UB300G Series Multi-Purpose Camera, some of the unit's button, dial, and other control
functions will be limited or disabled. Be sure to refer to the following table.
NOTE
The descriptions in this document assume that the system version of the unit is V4.40-00-0.00 or later. Make sure that the system
version of the AK-UB300G used in conjunction with the unit is V7.52-000-00.00 or later.
Front panel 1
Front panel 2
Front panel 3
Front panel 4
Front panel 5
Front panel 6
Front panel 7
Front panel 8
Front panel 9
- 5 -
Connecting the Unit to AK-UB300G Series Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 1
[POWER HEAD] button ×
[POWER VF] button ×
[BARS/TEST] button ✓Only the ON/OFF for the color bar signal
output will function.
[REF. RECALL] button ×
[AUTO WHITE] button ✓
[AUTO BLACK] button ✓
[AUTO SET UP] button ×
[CHARA] button ×
[MATRIX] button ✓
[SKIN DTL] button ✓
[DRS] button ✓Enabled starting with the following system
version.
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
[B.GAMMA] button ✓Enabled starting with the following system
version.
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
[ASSIGN] button ✓
Front panel 2
[ASSIGN STATUS] button ✓If a function that is not available on the
camera side is assigned, it will be displayed
in red in the top button display of the status
screen.
Buttons [1] to [5] (CONTROL/MODE) ✓If a function that is not available on the
camera side is assigned, it will be displayed
in red in the [ASSIGN] button display area of
the ASSIGN status screen.
[CONTROL/MODE] button ✓
Front panel 3
LCD panel ✓
[MENU] dial ✓
[EXIT] button ✓
[UNDO] button ✓
[MENU] button ✓
Front panel 4
[ON] indicator (SCENE FILE) ✓This indicator is off when a scene file is not
selected.
Scene file page switching button ✓
[1/6], [2/7], [3/8], [4/EXT1], and [5/EXT2]
buttons (SCENE FILE)
✓[EXT1] and [EXT2] are disabled.
[STORE] button ×
- 6 -
Connecting the Unit to AK-UB300G Series Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 5
[ND] indicator ✓
[ND] setting buttons ✓
[ND] display ✓
[CC] indicator ×
[CC] setting buttons ×
[CC] display ×
[HEAD] button ×
[ECC] button ×
[M.GAIN] indicator ✓
[M.GAIN] setting buttons ✓Display and operation will vary depending on
whether the [VAR] button is ON or OFF.
When the [VAR] button is ON:
Switches the GAIN value of the current
[GAIN SELECT].
When the [VAR] button is OFF: Switches
[GAIN SELECT].
[1] (LOW) < > [2] (MID) < > [3] (HIGH) < > [ 1]
(S.GAIN1) < > [ 2] (S.GAIN2) < > [ 3]
(S.GAIN3)
[M.GAIN] display ✓Display and operation will vary depending on
whether the [VAR] button is ON or OFF.
When the [VAR] button is ON:
Displays the GAIN value of the current [GAIN
SELECT].
When the [VAR] button is OFF:
Displays the [GAIN SELECT] value.
[VAR] button ✓Enabled starting with the following system
version.
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
Front panel 6
[SHUTTER] display ✓Displays as “----” when synchro shutter is
selected.
[ON] button (SHUTTER) ✓
[SYNC] button (SHUTTER) ✓
[SHUTTER] setting buttons ✓
- 7 -
Connecting the Unit to AK-UB300G Series Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 7
[GAIN R], [GAIN G], and [GAIN B] dials ✓
[BLACK R], [BLACK G], and [BLACK B] dials ✓Only pedestal (R, B) adjustment is possible,
but starting with the following system version,
flare adjustment will also be possible.
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
[FLARE] button ✓Fixed at pedestal adjustment, but starting
with the following system version, flare
adjustment will also be possible.
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
[PAINT LOCK] button ✓
[DTL] dial ✓
[CAM SEL] indicator ✓
[SELECT] dial ✓
[TEMP] indicator ✓
[SYNC] indicator ×
[MFLR] indicator ✓Enabled starting with the following system
version.
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
[USER] indicator ✓
Front panel 8
[EXT] indicator ×
[D.EXT] indicator ×
[IRIS] lever ✓
[M.PED] dial ✓
[RELATIVE] button ✓
[SENSE] dial ✓
[COARSE] dial ✓
[IRIS] display ✓
[AUTO] button ✓When the auto iris function is enabled, the
iris gauge that appears at the bottom of the
LCD panel (status screen) will not operate.
[CLOSE] button ×
[M.PED] display ✓
[IRIS LOCK] button ✓
[M.PED LOCK] button ×
- 8 -
Connecting the Unit to AK-UB300G Series Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 9
Camera number/tally display ✓Only camera numbers are displayed, but
starting with the following system version,
tally (red, green) display will also be possible
(only during LAN connection).
AK-UB300G: V7.52-000-00.00
This unit: V4.40-00-0.00
[ALM] indicator ✓
[OPT] indicator ×
[PANEL ACTIVE] button ✓
[CALL] button ×
[PREVIEW] button ✓
Memory card slot ✓
Memory card access indicator ✓
Torque adjustment screw ✓
- 9 -
Connecting the Unit to AK-UB300G Series Cameras

ROP Menu (when AK-UB300G is connected)
ROP menu list
When an AK-UB300G Multi-Purpose Camera is connected, the ROP menu will be as follows. The setting values will vary depending on the
connected model. Depending on the model, unsupported functions will be displayed as [-].
NOTE
The descriptions in this document assume that the system version of the unit is V4.40-00-0.00 or later. Make sure that the system
version of the AK-UB300G used in conjunction with the unit is V7.52-000-00.00 or later.
For details on menu operations, refer to the following sections in the operating instructions.
“Displaying menus”
“Basic menu operations”
01 PAINT SWITCH
MATRIX “MATRIX” (see page 17)
LINEAR MATRIX “LINEAR MATRIX” (see page 17)
COLOR CORRECT “COLOR CORRECT” (see page 17)
SKIN DTL “SKIN DTL” (see page 17)
DTL “DTL” (see page 17)
DNR “DNR” (see page 17)
D. HAZE CLEAR “D. HAZE CLEAR” (see page 17)
DRS “DRS” (see page 17)
FLARE “FLARE” (see page 17)
GAMMA “GAMMA” (see page 17)
BLACK GAMMA “BLACK GAMMA” (see page 17)
KNEE “KNEE” (see page 17)
02 SHUTTER SPEED
SHUTTER SPEED “SHUTTER SPEED” (see page 18)
SHUTTER SYNCHRO “SHUTTER SYNCHRO” (see page 18)
SHUTTER SW “SHUTTER SW” (see page 18)
SHUTTER MODE “SHUTTER MODE” (see page 18)
03 PEDESTAL
PED R “PED R” (see page 19)
PED B “PED B” (see page 19)
M. PED “M. PED” (see page 19)
04 CHROMA
CHROMA LEVEL “CHROMA LEVEL” (see page 20)
CHROMA LEVEL SW “CHROMA LEVEL SW” (see page 20)
05 RB GAIN
GAIN AWB R “GAIN AWB R” (see page 21)
GAIN AWB B “GAIN AWB B” (see page 21)
06 COLOR TEMP COLOR TEMP “COLOR TEMP” (see page 22)
07 FLARE
FLARE R “FLARE R” (see page 23)
FLARE G “FLARE G” (see page 23)
FLARE B “FLARE B” (see page 23)
M.FLARE “M.FLARE” (see page 23)
FLARE “FLARE” (see page 23)
- 10 -
ROP Menu (when AK-UB300G is connected)

08 GAMMA
GAMMA R “GAMMA R” (see page 24)
GAMMA MASTER “GAMMA MASTER” (see page 24)
GAMMA B “GAMMA B” (see page 24)
GAMMA MODE “GAMMA MODE” (see page 24)
BLACK STRETCH “BLACK STRETCH” (see page 24)
DYNAMIC LEVEL “DYNAMIC LEVEL” (see page 24)
KNEE POINT “KNEE POINT” (see page 24)
KNEE SLOPE “KNEE SLOPE” (see page 24)
GAMMA “GAMMA” (see page 24)
09 BLACK GAMMA
BLACK GAMMA R “BLACK GAMMA R” (see page 25)
BLACK GAMMA MASTER “BLACK GAMMA MASTER” (see page 25)
BLACK GAMMA B “BLACK GAMMA B” (see page 25)
B.GAMMA “B.GAMMA” (see page 25)
10 KNEE
POINT (%) R “POINT (%) R” (see page 26)
POINT (%) MASTER “POINT (%) MASTER” (see page 26)
POINT (%) B “POINT (%) B” (see page 26)
SLOPE R “SLOPE R” (see page 26)
SLOPE MASTER “SLOPE MASTER” (see page 26)
SLOPE B “SLOPE B” (see page 26)
AUTO KNEE POINT % “AUTO KNEE POINT %” (see page 26)
AUTO KNEE LEVEL “AUTO KNEE LEVEL” (see page 26)
AUTO KNEE RESPONSE “AUTO KNEE RESPONSE” (see page 26)
KNEE “KNEE” (see page 26)
11 DETAIL
MASTER DETAIL “MASTER DETAIL” (see page 27)
DETAIL LV H “DETAIL LV H” (see page 27)
DETAIL LV V “DETAIL LV V” (see page 27)
PEAK FRQ “PEAK FRQ” (see page 27)
V DETAIL FRQ “V DETAIL FRQ” (see page 27)
CRISP “CRISP” (see page 27)
LEVEL DEPENDENT “LEVEL DEPENDENT” (see page 27)
DETAIL SOURCE “DETAIL SOURCE” (see page 27)
DETAIL GAIN (+) “DETAIL GAIN (+)” (see page 27)
DETAIL GAIN (-) “DETAIL GAIN (-)” (see page 27)
DETAIL CLIP+ “DETAIL CLIP+” (see page 27)
DETAIL CLIP- “DETAIL CLIP-” (see page 27)
KNEE APERTURE “KNEE APERTURE” (see page 27)
DETAIL “DETAIL” (see page 27)
LV DPN SW “LV DPN SW” (see page 27)
- 11 -
ROP Menu (when AK-UB300G is connected)

12 SKIN TONE DTL
MEMORY SELECT “MEMORY SELECT” (see page 28)
CURSOR “CURSOR” (see page 28)
POS H “POS H” (see page 28)
POS V “POS V” (see page 28)
SKIN GET “SKIN GET” (see page 28)
ZEBRA SWITCH “ZEBRA SWITCH” (see page 28)
ZEBRA EFFECT “ZEBRA EFFECT” (see page 28)
EFFECT MEMORY “EFFECT MEMORY” (see page 28)
SKIN TONE CRISP “SKIN TONE CRISP” (see page 28)
I CENTER “I CENTER” (see page 28)
I WIDTH “I WIDTH” (see page 28)
Q WIDTH “Q WIDTH” (see page 28)
Q PHASE “Q PHASE” (see page 28)
SKIN TONE DETAIL “SKIN TONE DETAIL” (see page 28)
13 MATRIX
LINEAR TABLE “LINEAR TABLE” (see page 29)
COLOR CORRECT “COLOR CORRECT” (see page 29)
MATRIX (R-G) P “MATRIX (R-G) P” (see page 29)
MATRIX (R-G) N “MATRIX (R-G) N” (see page 29)
MATRIX (R-B) P “MATRIX (R-B) P” (see page 29)
MATRIX (R-B) N “MATRIX (R-B) N” (see page 29)
MATRIX (G-R) P “MATRIX (G-R) P” (see page 29)
MATRIX (G-R) N “MATRIX (G-R) N” (see page 29)
MATRIX (G-B) P “MATRIX (G-B) P” (see page 29)
MATRIX (G-B) N “MATRIX (G-B) N” (see page 29)
MATRIX (B-R) P “MATRIX (B-R) P” (see page 30)
MATRIX (B-R) N “MATRIX (B-R) N” (see page 30)
MATRIX (B-G) P “MATRIX (B-G) P” (see page 30)
MATRIX (B-G) N “MATRIX (B-G) N” (see page 30)
MATRIX “MATRIX” (see page 30)
COLOR CORRECT “COLOR CORRECT” (see page 30)
LINEAR MATRIX “LINEAR MATRIX” (see page 30)
- 12 -
ROP Menu (when AK-UB300G is connected)

14 COLOR CORRECTION
LINEAR TABLE “LINEAR TABLE” (see page 32)
COLOR CORRECT “COLOR CORRECT” (see page 32)
COLOR CORRECT “COLOR CORRECT” (see page 32)
SAT “SAT” (see page 32)
PHASE “PHASE” (see page 32)
SAT G “SAT G” (see page 32)
PHASE G “PHASE G” (see page 32)
SAT CY_G “SAT CY_G” (see page 32)
PHASE CY_G “PHASE CY_G” (see page 32)
SAT CY “SAT CY” (see page 32)
PHASE CY “PHASE CY” (see page 32)
SAT B_CY “SAT B_CY” (see page 32)
PHASE B_CY “PHASE B_CY” (see page 32)
SAT B “SAT B” (see page 32)
PHASE B “PHASE B” (see page 32)
SAT MG_B “SAT MG_B” (see page 32)
PHASE MG_B “PHASE MG_B” (see page 32)
SAT MG “SAT MG” (see page 32)
PHASE MG “PHASE MG” (see page 32)
SAT R_MG “SAT R_MG” (see page 32)
PHASE R_MG “PHASE R_MG” (see page 32)
SAT R “SAT R” (see page 32)
PHASE R “PHASE R” (see page 32)
SAT YL_R “SAT YL_R” (see page 32)
PHASE YL_R “PHASE YL_R” (see page 32)
SAT YL “SAT YL” (see page 32)
PHASE YL “PHASE YL” (see page 32)
SAT G_YL “SAT G_YL” (see page 32)
PHASE G_YL “PHASE G_YL” (see page 32)
MATRIX “MATRIX” (see page 32)
COLOR CORRECT “COLOR CORRECT” (see page 32)
LINEAR MATRIX “LINEAR MATRIX” (see page 32)
15 SKIN CORRECTION
SKIN AREA HUE “SKIN AREA HUE” (see page 33)
SKIN AREA TONE “SKIN AREA TONE” (see page 33)
SKIN AREA SW “SKIN AREA SW” (see page 33)
SKIN AREA TABLE “SKIN AREA TABLE” (see page 33)
16 DNR
DNR LEVEL “DNR LEVEL” (see page 34)
DNR SW “DNR SW” (see page 34)
17 HAZE REDUCTION
LEVEL “LEVEL” (see page 35)
SW “SW” (see page 35)
18 LENS CONTROL
FOCUS MODE “FOCUS MODE” (see page 36)
FOCUS SPEED “FOCUS SPEED” (see page 36)
FOCUS “FOCUS” (see page 36)
ZOOM WIDE “ZOOM WIDE” (see page 36)
ZOOM SPEED “ZOOM SPEED” (see page 36)
ZOOM TELE “ZOOM TELE” (see page 36)
- 13 -
ROP Menu (when AK-UB300G is connected)

19 SYSTEM CAM
FORMAT “FORMAT” (see page 37)
CROP OUT “CROP OUT” (see page 37)
CROP MARKER “CROP MARKER” (see page 37)
CROP ADJ “CROP ADJ” (see page 37)
CROP H POS (%) “CROP H POS (%)” (see page 37)
CROP V POS (%) “CROP V POS (%)” (see page 37)
GEN LOCK INPUT “GEN LOCK INPUT” (see page 37)
GEN LOCK COARSE “GEN LOCK COARSE” (see page 37)
GEN LOCK FINE “GEN LOCK FINE” (see page 37)
SHOOTING MODE “SHOOTING MODE” (see page 37)
20 CAMERA MENU CONTROL
MENU ON/OFF “MENU ON/OFF” (see page 38)
CURSOR/PARAMETER “CURSOR/PARAMETER” (see page 38)
EXECUTE “EXECUTE” (see page 38)
- 14 -
ROP Menu (when AK-UB300G is connected)

21 ROP SETTING
CONTROL(MENU)1 Refer to the following section in the operating instructions.
“34 ROP SETTING”
CONTROL(MENU)2
CONTROL(MENU)3
CONTROL(MENU)4
CONTROL(MENU)5
B.GAMMA SW
MODE(ON/OFF)1
MODE(ON/OFF)2
MODE(ON/OFF)3
MODE(ON/OFF)4
MODE(ON/OFF)5
ECC BTN CTRL
ASSIGN BUTTON
USER ASSIGN
IRIS LEV MODE
CAM SEL
DTL VOL
SKIN DTL SW
LCD BRIGHT
PANEL LED BRIGHT
7SEG BRIGHT GROUP1
7SEG BRIGHT GROUP2
BUZZER
PERIOD
CYCLE
STD POSITION M.PED
STD POSITION VAR
STD POSITION ND
STD POSITION CC
IRIS PRIORITY
ROP DATA SAVE
ROP DATA LOAD
SD CARD FORMAT
INITIAL with NW
INITIAL
POWER BUTTON
IRIS CALIBRATION TOP
IRIS CALIBRATION BOTTOM
UPGRADE
PAINT VOL CO
SYSTEM VERSION
SOFT VERSION
FPGA VERSION
22 CONNECT SETTING
CONNECT MODE CAM1 “CONNECT MODE CAM1” (see page 40)
CONNECT MODE CAM2 to
CAM99 “CONNECT MODE CAM2 to CAM99” (see page 40)
- 15 -
ROP Menu (when AK-UB300G is connected)

23 ROP IP SETTING
ROP IP ADDRESS Refer to the following section in the operating instructions.
“36 ROP IP SETTING”
ROP PORT
UPLOAD
ROP SUBNET MASK
UPLOAD
ROP DEFAULT GATEWAY
UPLOAD
MAC ADDRESS
24 CAMERA IP SETTING
CAM1 to CAM99 IP ADDRESS Refer to the following section in the operating instructions.
“37 CAMERA IP SETTING”
CAM1 to CAM99 PORT
CAM1 to CAM99 INF UPLOAD
25 AUTO IRIS SETTING LEVEL “LEVEL” (see page 42)
26 HDR-PAINT
HLG BLACK GAMMA R “HLG BLACK GAMMA R” (see page 43)
HLG BLACK GAMMA MASTER “HLG BLACK GAMMA MASTER” (see page 43)
HLG BLACK GAMMA B “HLG BLACK GAMMA B” (see page 43)
HLG KNEE POINT “HLG KNEE POINT” (see page 43)
HLG KNEE SLOPE “HLG KNEE SLOPE” (see page 43)
HLG B.GAMMA “HLG B.GAMMA” (see page 43)
HLG KNEE “HLG KNEE” (see page 43)
HLG TYPE “HLG TYPE” (see page 43)
HLG MODE “HLG MODE” (see page 43)
SDR CNVRT MD “SDR CNVRT MD” (see page 43)
SHOOTING MODE “SHOOTING MODE” (see page 43)
DNR LEVEL “DNR LEVEL” (see page 43)
DNR SW “DNR SW” (see page 43)
SDR CONVERT GAIN “SDR CONVERT GAIN” (see page 43)
SDR CONVERT CLIP “SDR CONVERT CLIP” (see page 43)
- 16 -
ROP Menu (when AK-UB300G is connected)

01 PAINT SWITCH
ヱモリワヵチヴヸリヵヤラ
ヒチバチビ
ヮモヵンリヹロリワユモンヮモヵンリヹヤヰロヰンヤヰンンユヤヵ
ヰョョ
ュワンュヵロュンヴヴレリワュヵロュハチラモ・ユヤロユモン
ヰョョヰワヰョョヰョョヰョョ
ョロモンユ
ヰョョヰワヰワ
ヱモリワヵチヴヸリヵヤラ
ビチバチビ
ヨモヮヮモャロモヤレヨモヮヮモレワユユ
ヰョョヰョョ ヮモワヶモロ
Item Setting details
MATRIX Enables/disables the matrix (linear matrix / 12-axis color correction).
LINEAR MATRIX Enables/disables linear matrix.
COLOR CORRECT Enables/disables 12-axis color correction.
SKIN DTL Enables/disables the skin tone detail function.
DTL Enables/disables the detail.
DNR Enables/disables the noise reduction function.
D. HAZE CLEAR Enables/disables the haze elimination function.
DRS Enables or disables the dynamic range stretcher.
[---] is displayed during UHD mode or UHD CROP mode.
FLARE Enables or disables the flare.
GAMMA Enables or disables the gamma.
BLACK GAMMA Enables or disables the black gamma.
This setting is not available when [DRS] of [PAINT SWITCH] is set to [ON].
KNEE Enables or disables the knee.
- 17 -
ROP Menu (when AK-UB300G is connected)

02 SHUTTER SPEED
ヴラヶヵヵユンチヴヱユユュ
ヒチバチヒ
ヴラヶヵヵユンヴラヶヵヵユン
ノ
ヴヱユユュヴヺワヤランヰ
ヰョョ
ヴヸヮヰュユ
ヰョョヴラヶヵヒパパ
Item Setting details
SHUTTER SPEED Sets the shutter speed for when [SHUTTER MODE] is set to [SHUT].
SHUTTER SYNCHRO The setting cannot be set.
SHUTTER SW Enables/disables the shutter function.
SHUTTER MODE Selects the operation mode of the shutter.
SHUT
The shutter speed set in [SHUTTER SPEED] is used.
SYNC
The shutter speed set in [SHUTTER SYNCHRO] is used.
- 18 -
ROP Menu (when AK-UB300G is connected)

03 PEDESTAL
ンャヱユュユヴヵモロ
ヒチバチヒ
パパ
ヮハチヱユュ
ヱユュ
ヌヒ
Item Setting details
PED R Sets the correction level of red to the master pedestal.
PED B Sets the correction level of blue to the master pedestal.
M. PED Adjusts the black level of the master pedestal.
- 19 -
ROP Menu (when AK-UB300G is connected)

04 CHROMA
ヤランヰヮモ
ヒチバチヒ
パ
ヤランヰヮモロユヷユロヤランヰヮモロユヷユロチチヴヸ
ヰョョ
ヰョョ
Item Setting details
CHROMA LEVEL Adjusts the chroma gain when [CHROMA SW] is set to [ON].
CHROMA LEVEL SW Enables/disables the gain adjustment of chroma.
- 20 -
ROP Menu (when AK-UB300G is connected)
