Panasonic AK-HRP1010G User manual

Operating Instructions
Remote Operation Panel
Model No.AK-HRP1010G
Please carefully read this manual, and save this manual for future use.
Before using this product, be sure to read “Read this first!” (pages 2 to 4) .
W1021AM0 -PS DVQP2583ZA
ENGLISH

Read this first!
indicates safety information.
WARNING:
• To reduce the risk of fire, do not expose this equipment to
rain or moisture.
• To reduce the risk of fire, keep this equipment away from
all liquids. Use and store only in locations which are not
exposed to the risk of dripping or splashing liquids, and do
not place any liquid containers on top of the equipment.
WARNING:
Always keep memory cards (optional accessory) out of the
reach of babies and small children.
WARNING:
This equipment is compliant with Class A of CISPR 32.
In a residential environment this equipment may cause radio
interference.
CAUTION:
Do not remove panel covers by unscrewing.
To reduce the risk of electric shock, do not remove the covers.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION:
To reduce the risk of fire or electric shock and annoying
interference, use the recommended accessories only.
FCC NOTICE(USA)
Supplier’s Declaration of Conformity
Trade Name: Panasonic
Model Number: AK-HRP1010G
Responsible Party: Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102
Support contact: 1-800-524-1448
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Warning:
To assure continued FCC emission limit compliance, follow the attached installation instructions and the user must use only shielded
interface cables when connecting to host computer or peripheral devices.
Also, any unauthorized changes or modifications to this equipment could void the user’s authority to operate this device.
FCC CAUTION:
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
NOTIFICATION(Canada)
CAN ICES-003(A)/NMB-003(A)
indicates safety information.
- 2 -
Read this first!

EMC NOTICE FOR THE PURCHASER/USER OF THE APPARATUS
1. Pre-requisite conditions to achieving compliance with the above standards
<1> Peripheral equipment to be connected to the apparatus and special connecting cables
• The purchaser/user is urged to use only equipment which has been recommended by us as peripheral equipment to be
connected to the apparatus.
• The purchaser/user is urged to use only the connecting cables described below.
<2> For the connecting cables, use shielded cables which suit the intended purpose of the apparatus.
• Video signal connecting cables
Use double shielded coaxial cables, which are designed for 75-ohm type high-frequency applications, for SDI (Serial Digital
Interface).
Coaxial cables, which are designed for 75-ohm type high-frequency applications, are recommended for analog video signals.
• Audio signal connecting cables
If your apparatus supports AES/EBU serial digital audio signals, use cables designed for AES/EBU.
Use shielded cables, which provide quality performance for high-frequency transmission applications, for analog audio
signals.
• Other connecting cables (LAN, RS-422)
Use shielded cables, which provide quality performance for high-frequency applications, as connecting cables.
• When connecting to the DVI signal terminal, use a cable with a ferrite core.
• If your apparatus is supplied with ferrite core(s), they must be attached on cable(s) following instructions in this manual.
2. Performance level
The performance level of the apparatus is equivalent to or better than the performance level required by these standards.
However, the apparatus may be adversely affected by interference if it is being used in an EMC environment, such as an area
where strong electromagnetic fields are generated (by the presence of signal transmission towers, cellular phones, etc.). In order to
minimize the adverse effects of the interference on the apparatus in cases like this, it is recommended that the following steps be
taken with the apparatus being affected and with its operating environment:
1. Place the apparatus at a distance from the source of the interference.
2. Change the direction of the apparatus.
3. Change the connection method used for the apparatus.
4. Connect the apparatus to another power outlet where the power is not shared by any other appliances.
Turkey Only
AEEE Yönetmeliğine Uygundur.
AEEE Complies with Directive of Turkey.
Note:
The rating plate (serial number plate) is on the bottom of the unit.
Manufactured by: Panasonic Corporation, Osaka, Japan
Importer’s name and address of pursuant to EU rules:
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Disposal of Old Equipment
Only for European Union and countries with recycling systems
This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic
products must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable collection points in
accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any potential negative effects
on human health and the environment. For more information about collection and recycling, please contact your local
authority, dealer or supplier.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
- 3 -
Read this first!

< Предупреждение >
Следуй е нижеприведённым правилам, если иное не указано в других докумен ах.
1.
Ус анавливай е прибор на вёрдой плоской поверхнос и, за исключением о соединяемых или несъёмных час ей.
2. Храни ь в сухом, закры ом помещении.
3. Во время ранспор ировки не броса ь, не подверга ь излишней вибрации или ударам о другие предме ы.
4. У илизирова ь в соо ве с вии с национальным и/или мес ным законода ельс вом.
Правила и условия реализации не ус ановлены изго ови елем и должны соо ве с вова ь национальному и/или мес ному
законода ельс ву с раны реализации овара.
ІНФОРМАЦІЯ ПРО ПІДТВЕРДЖЕННЯ ВІДПОВІДНОСТІ ПРОДУКТУ
Виробник: Panasonic Corporation Панасонік Корпорейшн
Адреса виробника: Kadoma, Osaka, Japan Кадома, Осака, Японія
Країна походження: Japan Японія
Імпор ер: ТОВ “ПАНАСОНІК УКРАЇНА ЛТД”
Адреса Імпор ера: вул. Васильківська, буд. 30, м. Київ, 03022, Україна
Примі ки:
Термін служби виробу 7 років
Да у виго овлення можна визначи и за комбінацією букв і цифр серійного номера, що роз ашований на маркувальній абличці виробу.
Приклад: X X XXXXXXX
Рік: ос ання цифра року (6 – 2016, 7 – 2017,…0 – 2020)
Місяць: А – Січень, В – Лю ий… L – Грудень
The symbols on this product (including the accessories) represent the following. (Some symbols are not
displayed on this unit.)
ON
Standby (OFF)
AC
DC
Class II equipment (The construction of the product is double-insulated.)
- 4 -
Read this first!

Read this first! 2
Introduction 7
How to View This Manual 7
About trademarks and registered trademarks 7
About copyright 7
Illustrations and screen displays featured in the manual 7
Abbreviations 7
Overview 8
Notice 9
Personal computer requirements 9
Disclaimer of warranty 9
Network security 9
User authentication 9
Restrictions on use 10
Memory cards 10
Upgrade software 10
Software for peripheral equipment 10
File types handled by the unit 10
Features 11
Precautions for Use 12
Precautions for Installation 13
Installing and removing rack mount brackets 14
Rack installation (rack mounting) 14
Connection 15
Operation Modes 15
Operation mode setting procedure 15
Switching between serial connection and IP con-
nection 15
System Connection Configuration 17
CCU connections 17
Parts and their functions 19
Front panel 1 19
Front panel 2 22
Front panel 3 23
Front panel 4 24
Front panel 5 25
Front panel 6 27
Front panel 7 28
Front panel 8 30
Front panel 9 33
Connectors 35
Adjustment and settings 36
Auto Setup 36
Starting auto setup 36
Scene file 37
Storing and opening scene files 37
PAINT LOCK 38
Using the PAINT LOCK 38
ND filter 39
Displaying and setting the ND filter 39
CC filter 40
Displaying and setting the CC filter 40
Color temperature (ECC) 41
Setting the color temperature (ECC) 41
Master gain (M.GAIN) 42
Displaying and setting the master gain (M.GAIN) 42
Shutter (SHUTTER) 43
Displaying and setting the shutter (SHUTTER) 43
Master pedestal (M.PED) 44
Displaying and setting the master pedestal (M.PED) 44
Iris (IRIS) 45
Displaying and setting the iris (IRIS) 45
[SELECT] dial 47
Using the select dial 47
Camera selection 48
Status screen 49
Displaying and operating the status screen 49
Items displayed on the status screen 50
OPT LEVEL 50
CAM INFO 50
SCENE 51
ASSIGN 51
ASSIGN status screen 52
ROP menu 53
Displaying menus 53
Basic menu operations 54
Other menu operations 55
ROP menu list 56
PAINT 69
PAINT SW 69
SHUTTER 70
BLACK SHADING 71
PEDESTAL 72
UHD CHROMA 73
HD CHROMA 74
RGB GAIN 75
COLOR TEMP 76
ECC 77
CAM USER SW TEMP 78
WHITE SHADING 79
FLARE 80
GAMMA 81
BLACK GAMMA 82
KNEE 83
WHITE CLIP 84
DRS 85
UHD DTL 86
HD DTL 87
SD DTL 88
UHD SKIN TONE DTL 89
HD SKIN TONE DTL 90
LINEAR MATRIX 91
COLOR CORRECTION 92
SKIN CORRECTION 94
DNR 95
HDR-PAINT 96
NON LINEAR MATRIX 98
COLOR ADJUSTMENT 99
FUNCTION 102
SYSTEM CAM INFO 102
SYSTEM CCU INFO 104
AUTO IRIS SETTING 106
LENS CONTROL 107
SHUTTER SELECT 108
LENS FILE EDIT 109
MONITOR 111
- 5 -
Table of Contents

REFERENCE 112
MAINTENANCE 113
CAMERA/CCU MENU CONTROL 113
ROP VOL/BUTTON 114
IRIS LEVER SETTING 117
ROP SETTING 118
ROP INITIALIZE 119
ROP VERSION 120
SD CARD DATA SAVE 121
SD CARD DATA LOAD 122
SYSTEM 124
ROP IP SETTING 124
CAM IP SEARCH 126
MANUAL IP SETTING 127
CONNECT SETTING 128
CAMERA AUTH SETTING 129
ROP AUTH SETTING 130
Software 131
IP connection 131
IP connection procedure 131
Installing the software 131
Connecting and setting the personal computer 132
Setting the IP addresses of the devices 132
ROP Setup Software 133
Notice about using ROP Setup Software 134
Firewall 134
Reference 135
Connector pin assignment table 135
1 <CCU> connector 135
2 <LAN> connector 135
3 <PREVIEW> connector 136
Appearance 137
Specifications 138
General 138
Monitor 138
Input/output section 138
Index 139
- 6 -

Introduction
How to View This Manual
About trademarks and registered trademarks
Microsoft®, Windows® 10, Microsoft Edge and Internet Explorer® are either registered trademarks or trademarks of Microsoft Cor-
poration in the United States and other countries.
Intel® Core™ is a trademark or registered trademark of Intel Corporation and its subsidiaries in the United States and/or other
countries.
SDXC logo is a trademark of SD-3C and LLC.
Other names of companies or products in this manual are either registered trademarks or trademarks of their respective owners.
About copyright
Distributing, copying, disassembling, reverse compiling, reverse engineering and also exporting in violation of export laws of the software
provided with this unit are expressly prohibited.
Illustrations and screen displays featured in the manual
What is shown in the manual’s illustrations and screen displays may differ from how it actually appears.
The screenshots are used in accordance with the guidelines of Microsoft Corporation.
Abbreviations
The following abbreviations are used in this manual.
The term memory card will be used below as a generic term for both SD, SDHC and SDXC memory cards. SD, SDHC or SDXC will
be used in descriptions that refer to only one of the two card types.
A studio handy camera is referred to as a camera in this manual.
A camera control unit is referred to as a CCU in this manual.
A remote operation panel is referred to as an ROP in this manual.
For the purposes of this manual, the model numbers of the units are given as listed in the table below.
Model number of unit Model number given in manual
AK-HC5000G
AK-HC5000
AK-HC5000GS
AK-UC3300G
AK-UC3300
AK-UC3300GS
AK-UC4000G
AK-UC4000
AK-UC4000GS
AK-HRP1010G AK-HRP1010
AK-UCU500P
AK-UCU500
AK-UCU500PS
AK-UCU500E
AK-UCU500ES
AK-UCU600P
AK-UCU600
AK-UCU600PS
AK-UCU600E
AK-UCU600ES
- 7 -
Introduction

Overview
This unit is a remote operation panel for controlling a studio handy camera (AK-HC5000/AK-UC3300/AK-UC4000; sold separately) and a
camera control unit (AK-UCU500/AK-UCU600; sold separately).
Use a dedicated optical fiber multi cable to connect a studio handy camera to a camera control unit and use an ROP cable or IP connection
to connect this unit to the camera control unit.
When IP connections are used, up to 99 camera control units can be controlled.
- 8 -
Introduction

Notice
Personal computer requirements
For the software supplied with the unit, use a personal computer specified on the following website.
https://pro-av.panasonic.net/
Disclaimer of warranty
IN NO EVENT SHALL Panasonic Corporation BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR
REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:
ANY DAMAGE AND LOSS, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT, SPECIAL, CONSEQUENTIAL OR
EXEMPLARY, ARISING OUT OF OR RELATING TO THE PRODUCT;
PERSONAL INJURY OR ANY DAMAGE CAUSED BY INAPPROPRIATE USE OR NEGLIGENT OPERATION OF THE USER;
UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT BY THE USER;
INCONVENIENCE OR ANY LOSS ARISING WHEN IMAGES ARE NOT DISPLAYED, DUE TO ANY REASON OR CAUSE
INCLUDING ANY FAILURE OR PROBLEM OF THE PRODUCT;
ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE, ARISING OUT OF THE SYSTEM COMBINED
BY THE DEVICES OF THIRD PARTY;
ANY INCONVENIENCE, DAMAGES OR LOSSES RESULTING FROM ACCIDENTS CAUSED BY AN INADEQUATE
INSTALLATION METHOD OR ANY FACTORS OTHER THAN A DEFECT IN THE PRODUCT ITSELF;
LOSS OF REGISTERED DATA CAUSED BY ANY FAILURE;
ANY DAMAGE OR CLAIMS DUE TO LOSS OR LEAKAGE OF IMAGE DATA OR SETTING DATA SAVED ON THIS UNIT OR ON A
MEMORY CARD OR PERSONAL COMPUTER.
Network security
This unit also has functions which are used when it is connected to a network.
Using the unit when it is connected to a network may possibly give rise to the following.
Leakage or disclosure of information transmitted via this unit
Unauthorized use of this unit by a third person with malicious intent
Interference or stoppage of this unit by a third person with malicious intent
It is your responsibility to take sufficient network security measures such as those described below to protect yourself against the above
risks.
Use this unit in a network secured by a firewall, etc.
If this unit is used in a system with a personal computer connected, make sure that checks for and removal of computer viruses
and malicious programs are implemented regularly.
Also observe the following points.
Do not install the unit in a location where the unit, cables, and other parts may be easily damaged.
User authentication
In order to protect device settings from exposure on the network, when connecting to a network, please enable user authentication to
restrict access as appropriate.
- 9 -
Introduction

Restrictions on use
It is recommended that the remote operation panel and all devices to be used with the remote operation panel be connected to the same
network segment.
Events related to settings of network devices may occur if devices are connected to different segments, so verify operation carefully before
placing devices into service.
Memory cards
Memory cards used with the unit should conform to SDHC or SDXC standards.
Be sure to use the unit to format memory cards.
Memory cards with the following capacity can be used with the unit.
SDHC: 4 GB to 32 GB
SDXC: 64 GB
For the latest information not described in the Operating Instructions, refer to the following website.
https://pro-av.panasonic.net/
Observe the following points when using and storing this unit.
Avoid high temperature and humidity.
Avoid water droplets.
Avoid static electricity.
Upgrade software
You can obtain the upgrade software from Service and Support on the following website.
https://pro-av.panasonic.net/
For the upgrade procedure, refer to the instructions included with the download file.
Software for peripheral equipment
Software updates will also become necessary for the peripheral equipment that is connected to this unit (cameras or CCUs).
For details, consult your dealer.
File types handled by the unit
Scene file Data for creating the required image characteristics.
Reference file The term reference file is a generic term for user files and factory files.
User file A user file is system setting data composed of scene files and operation data. The user can record user files.
Factory file A file that contains camera settings that were stored at the factory.
Lens file Data for correcting specific lens characteristics.
ROP configuration file ROP specific setting data.
- 10 -
Introduction

Features
This unit is a remote operation panel for controlling a studio handy camera (AK-HC5000/AK-UC3300/AK-UC4000) and a camera
control unit (AK-UCU500/AK-UCU600).
Scene files, user files, and lens files can be saved to a memory card.
The unit can be connected to one CCU (AK-UCU500/AK-UCU600) via a serial connection.
Eliminate the need for individual ROP cables by connecting up to 99 CCUs via a network hub (100base-TX switching hub).
The unit is equipped with PoE*1, allowing connection to a network device that supports the PoE standard (IEEE802.3af com-
pliant)*2.
The ROP Setup Software can be used to set the camera connections.
*1: Power over Ethernet. Referred to as "PoE" in this manual.
*2: For details on PoE power supply devices for which operation has been verified, consult your dealer or Panasonic representative.
- 11 -
Introduction

Precautions for Use
In addition to the safety precautions given in “Read this first!”, also observe the following instructions.
Handle carefully
Do not drop the unit or expose it to strong impacts or vibrations. Do not carry the unit by the [IRIS] lever. Doing so may cause a fail-
ure or accident.
Use the product in an ambient temperature of 0 °C to 40 °C (32 °F to 104 °F)
Exposure to temperatures below 0 °C (32 °F) or above 40 °C (104 °F) could adversely affect Internal components.
Power off before connecting or disconnecting cables
Connect and disconnect cables when the unit is turned off.
Avoid humidity and dust
Avoid using the product in a very humid or dusty place because a lot of humidity and dust will cause damage to the internal com-
ponents.
Cleaning
Turn the power off and wipe the product with a dry cloth.
To remove stubborn dirt, dip a cloth into a diluted solution of kitchen detergent (neutral detergent), wring it out well, and wipe the
product gently. Then, wipe the product with a cloth dampened with water. Finally, wipe the product with a dry cloth.
NOTE
Avoid using benzine, paint thinners and other volatile fluids.
If a chemical cleaning cloth is to be used, carefully read through the precautions for its use.
Avoid open flames
Do not place candles and other sources open flame near the unit.
Avoid exposure to water
Make sure that the unit is not directly exposed to water. Exposure to water could damage it.
Disposal of the unit
When the unit has reached the end of its service life and is to be disposed of, ask a qualified contractor to dispose of the unit prop-
erly in order to protect the environment.
LCD panels
The pixels of the LCD panel are controlled to obtain high precision with 99.99% of the effective pixels. This leaves less than
0.01% of pixels that may not light or may remain on all the time.
This is normal and will have no effect on the images you shoot.
There may be some unevenness on the screen depending on the image displayed.
Wiping or rubbing the LCD screen with a rough cloth may damage it.
LCD response time and brightness vary with operating temperature.
When the unit is left in a high-temperature and high-humidity location for prolonged periods, the LCD panel characteristics may
change and result in uneven image quality.
Due to the characteristics of LCD panels, prolonged display of bright still images or prolonged operation in high-temperature or
high-humidity environments may result in residual images, luminance reduction, burn-in, banding, or panel defects and degrad-
ation that result in areas of permanently changed brightness.
In addition, avoid prolonged continuous use in the following types of environments.
Confined areas with high temperature and humidity
Near the exhaust vent of air conditioning equipment, etc.
Prolonged use involving the images and environments described above will accelerate deterioration of the LCD panel over time.
To prevent deterioration over time and its related phenomena, we recommend the following.
Do not display bright still images for prolonged periods.
Lower the brightness.
Turn off the power of the unit (and the power of the CCU and hub) when the unit is not in use.
Residual images will gradually disappear as different images are displayed.
- 12 -
Introduction

Precautions for Installation
In addition to the safety precautions given in “Read this first!”, also observe the following instructions.
Be sure to ask your dealer to perform the installation and connection work for the unit.
Cable connections
Be sure to use dedicated ROP cables (Hirakawa Hewtech Corp. 20379-FG-SV-10 cables or equivalent).
If the unit will not be used for an extended period of time, disconnect the ROP cables to save electricity.
Concerning PoE power supply
The unit complies with the IEEE802.3af standard. Use a compatible Ethernet hub and PoE injector to use a PoE power supply.
For details on Ethernet hubs and PoE injectors for which operations have been verified, consult your dealer.
Grounding
Ground the system via the <SIGNAL GND> terminal on the unit.
A
A. <SIGNAL GND> terminal
Handle carefully
Dropping the unit or subjecting it to a strong impact or vibration may cause a failure or accident.
Do not allow any foreign objects to enter inside the unit.
Allowing water, metal items, food or drink, or other foreign objects to enter inside the unit may cause a fire or electric shock.
Installation location
This unit is designed for indoor use only.
Use the unit on a stable and horizontal surface that is sufficiently capable of supporting its weight.
When the unit will be recessed into a panel or table, make sure that enough space is provided for ventilation and cables.
Do not install the unit in a location where it and the cables can be easily damaged.
Do not install the unit in a cold place where the temperature drops below 0 °C (32 °F) or in a hot place where the temperature rises
above 40 °C (104 °F).
Avoid installing the unit where it will be exposed to direct sunlight or near an outlet from which hot air is blown out.
Installing the unit in a location with a lot of humidity, dust, or vibration may result in a failure.
- 13 -
Introduction

Installing and removing rack mount brackets
The unit is shipped from the factory with the rack mount brackets installed.
The customer can remove the four screws that hold the rack mount brackets in place using a Phillips screwdriver.
A
A
B
B
A. Rack mount bracket
B. Securing screws
After detaching, store the rack mount brackets and the screws in a location easily accessible when required.
The next time you use the rack mount brackets to secure the unit, tighten the four screws to a torque of 50 N•cm or more.
Rack installation (rack mounting)
Secure the unit to the rack using two securing screws.
The securing screws are not supplied with the unit. Purchase screws that will fit the φ5 mm (3/16 inch) in diameter holes before
rack mounting.
The temperature in the rack must be between 0 °C (32 °F) and 40 °C (104 °F).
A
A. Securing screws (commercially available)
- 14 -
Introduction

Connection
Operation Modes
Operation mode setting procedure
In the factory default state, connect the CCU to the unit and then set the operation mode.
Connect with serial
1. Set the setting of “CONNECT
MODE” to “Serial” under
[SYSTEM] > [CONNECT
SETTING] in the ROP menu.
2. Connect the CCU, and start
operations.
Connect the CCU to the unit in the factory default state.
Operate with IP
1. Set the IP address of the unit under [SYSTEM] > [ROP IP SETTING].
Connect with the CCU via an IP connection and start operation.
When setting the IP address of the
connection destination manually
When setting the IP address of the
connection destination by searching
2. Set the IP address of the CCU to
be connected under [SYSTEM] >
[MANUAL IP SETTING].
3. Set the setting of “CONNECT
MODE” to assign for each
camera control number to “LAN”
under [SYSTEM] > [CONNECT
SETTING] in the ROP menu.
2. Search for the IP addresses of
devices and then set the camera
to assign to each camera control
number under [SYSTEM] >
[CAM IP SEARCH].
3. Set the account information of
the connection destination
device under [SYSTEM] >
[CAMERA AUTH SETTING].
4. Set the account information of the
connection destination device
under [SYSTEM] > [CAMERA
AUTH SETTING].
Switching between serial connection and IP connection
Switch between serial connection and IP connection via the [CONNECT SETTING] settings of the ROP menu or via the serial/LAN settings
of the ROP Setup Software.
“CONNECT SETTING” (see page 128)
“ROP Setup Software” (see page 133)
When the settings are initialized, the operation mode returns to serial connection (factory default state).
“ALL” (see page 119)
Serial connection
Serial connection with the CCU is
possible.
・IP connection is not possible.
IP connection
IP connection with the CCU is possible.
・A serial connection can be used in
combination with IP connections.
Switch to IP connection *1
Switch back to serial connection *2
Factory default state
Power ON
When the settings are initialized, the operation mode returns
to serial connection (factory default state).
- 15 -
Connection

*1: If an ROP configuration file that was saved to a memory card in IP connection is loaded in serial connection, the operation mode
becomes IP connection.
*2: If an ROP configuration file that was saved to a memory card in serial connection is loaded in IP connection, the operation mode
becomes serial connection.
- 16 -
Connection

System Connection Configuration
The unit can be connected to a CCU via a serial connection or IP connection.
Up to 99 CCUs can be controlled.
Only one CCU can be connected via a serial connection.
A configuration with one serial connection and 98 IP connections is possible.
CCU connections
Serial connection
ROP cable
Connection example:
AK-UCU600
AK-HRP1010
1. Connect the <CCU> connector on this unit to the <ROP> connector on the CCU using a dedicated ROP
cable (sold separately).
2. When you have finished connecting the equipment, turn on the main power of the CCU.
If a camera is not connected, some of the control functions from the unit to the CCU will be limited.
Turn off the CCU before disconnecting the ROP cable.
- 17 -
Connection

IP connection
Personal computer
LAN cable (straight cable)
LAN cable (straight cable)
Max.100 m (328.1 ft)
AK-HRP1010
AK-UCU600
AK-UCU600
PoE-compatible switching hub*1
(100base-TX)
*1: The CCU does not support PoE.
1. Connect the <LAN> connector on this unit to the <LAN> connector on the CCU rear panel using a LAN
cable (sold separately).
The unit can be powered with PoE. Use a switching hub with PoE support.
Use a straight cable (category 5e or higher) for the LAN cable*2 (Max. 100 m (328.1 ft))
*2: STP (shielded twisted pair)
2. When you have finished connecting the equipment, turn on the power of the CCU.
If a camera is not connected, some of the control functions from the unit to the CCU will be limited.
Up to 99 CCUs (AK-UCU500/AK-UCU600) can be controlled from the unit.
To operate CCUs via an IP connection, you need to configure the [CONNECT SETTING] settings of the ROP menu or
the ROP Setup Software settings. Before using ROP Setup Software, connect the unit to the personal computer with a
LAN cable.
“CONNECT SETTING” (see page 128)
“ROP Setup Software” (see page 133)
- 18 -
Connection

Parts and their functions
Front panel 1
1 2 3 4 5 6 7
8910 11 12 13
1 [POWER HEAD] button Use this button to control camera power remotely. However, it will not function unless the CCU
and the camera are turned on.
Each press of the button turns the power of the camera on or off.
Status displays
On (green): The camera is turned on.
On (red): The camera is turned off.
Flashing (red): The camera has been turned off from the unit.
Off: When the camera is not connected
nWhen the camera is powered from an external DC power supply, the button lights green
and the camera power supply cannot be remotely controlled from this unit.
2 [POWER VF] button Use this button to control the viewfinder power remotely.
When the camera is turned on by the unit, the viewfinder is also turned on.
Each press of the button turns the power On (power on) and Off (power off).
Status displays
On: Both the camera and viewfinder are On.
Off: The viewfinder has been turned off from the unit
nOn/off operation for the viewfinder cannot be performed if the power on the viewfinder is
turned off.
3 [BARS/TEST] button Use this button to output the CCU color bar signal from the camera video output on the CCU
rear panel.
To select a CCU color bar type, select [FUNCTION] > [SYSTEM CCU INFO] > [BARS HD]
or [BARS SD] in the ROP menu.
“BARS HD” (see page 104)
“BARS SD” (see page 104)
When the video signal is a camera signal or a color bar signal, press and hold the
[BARS/TEST] button to select the TEST signal. To switch from TEST signal output, press
the [BARS/TEST] button to select camera video output.
Status displays
On (yellow): CCU color bar On
On (green): TEST signal On
Off: Camera video
4 [REF. RECALL] button Press and hold this button to recall the reference setting information (reference file) of the
camera.
Assign the user file and factory file under [FUNCTION] > [SYSTEM CAM INFO] >
[REF.RECALL] of the ROP menu.
“ASU RECALL” (see page 103)
Status displays
On: Recalling
Off: Recall complete
- 19 -
Parts and their functions

5 [AUTO WHITE] button Use this button to perform auto white balance adjustment.
Status displays
On: Indicates that the auto white balance adjustment has started.
Flashing: Warns that the automatic white balance adjustment ended without being
completed.
When highlights and lowlights are lost, white balance is returned to its pre-
vious value. When correct white balance cannot be obtained, adjustment
stops at the last obtained value.
Off: Indicates that the auto white balance has been adjusted correctly.
nPress and hold the [AUTO WHITE] button during white balance adjustment (lamp on)
cancels adjustment and turns the lamp off. (“BREAK” appears on the picture monitor
(PM) of the CCU.) Then the white balance value returns to the value it had prior to auto
white balance adjustment.
6 [AUTO BLACK] button Use this button to perform auto black balance adjustment.
Status displays
On: Indicates that the auto black balance adjustment has started.
Flashing: Warns that the automatic black balance adjustment ended without being
completed. Auto black balance returns to the value it had prior to adjust-
ment.
Off: Indicates that the auto black balance has been adjusted correctly.
nPress and hold the [AUTO BLACK] button during white balance adjustment (lamp on)
cancels adjustment and turns the lamp off. (“BREAK” appears on the picture monitor
(PM) of the CCU.) Then the black balance value returns to the value it had prior to auto
black balance adjustment.
7 [AUTO SET UP] button Use this button to start auto setup.
The setup status is output to the picture monitor (PM).
“Auto Setup” (see page 36)
8 [CHARA] button Use this button to switch on and off the character display of the status screen on the CCU pic-
ture monitor (PM).
Status displays (button press method)
On (short press): Displays characters on the picture monitor (PM). Each short press
changes the display data.
Off (long press): Turns off the picture monitor (PM) character display.
9 [MATRIX] button Use this button to enable the function to correct saturation and color phase according to the
gain setting of each color component in matrix memory.
Each press of the button turns the function on or off.
Status displays
On: ON
Off: OFF
10 [SKIN DTL] button Use this button to apply coring to the detail enhancement of the skin tone areas in the video
output to soften or increase the enhancement of skin tone details.
Each press of the button turns the function on or off.
You can select “UHD” or “HD” as the target for skin tone detail control under [MAINTENANCE]
> [ROP VOL/BUTTON] > [SKIN DTL SW] in the ROP menu.
“SKIN DTL SW” (see page 116)
Status displays
On: ON
Off: OFF
11 [DRS] button Use this button to enable or disable the dynamic range stretcher.
Status displays
On: ON
Off: OFF
12 [B.GAMMA] button Use this button to enable or disable the black gamma correction.
You can select “HDR” (HLG B.GAMMA) or “SDR” (B.GAMMA) as the target for enabling or dis-
abling under [MAINTENANCE] > [ROP VOL/BUTTON] > [B.GAMMA SW] of the ROP menu.
“B. GAMMA SW” (see page 116)
Status displays
On: ON
Off: OFF
- 20 -
