Panasonic AK-HRP1005G User manual

DVQP2496ZAW0321AM0 -PS
ENGLISH
For details of operating Remote Operation Panel AK-HRP1005G, please
visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.
html), and refer to the Operating Instructions (HTML or PDF).
Read this document when using the AK-HRP1005G Remote Operation Panel in
conjunction with AW-UE100 4K Integrated Camera.
Operating Guide
Remote Operation Panel
Model No. AK-HRP1005G

Connecting the Unit to AW-UE100 Cameras 3
Connection Example 3
Connections 4
Compatible Functions List 5
ROP Menu (during AW-UE100 connection) 8
ROP Menu List 8
01 SCENE 14
02 SHUTTER SPEED 15
03 FILTER 16
04 PEDESTAL 17
05 CHROMA 18
06 GAIN 19
07 WHITE BALANCE 20
08 GAMMA 21
09 BLACK GAMMA 22
10 KNEE 23
11 WHITE CLIP 24
12 DRS 25
13 DETAIL 26
14 MATRIX 27
15 COLOR CORRECTION 28
16 DNR 31
17 BRIGHTNESS 32
18 LENS CONTROL 33
19 IRIS RELATIVE 34
20 SYSTEM CAM 35
21 CAMERA MENU CONTROL 37
22 ROP SETTING 38
23 CONNECT SETTING 39
24 ROP IP SETTING 40
25 CAMERA IP SETTING 40
26 AUTO IRIS SETTING 41
27 SWITCHER LINK 42
28 AW CONTROLLER LINK 42
- 2 -
Table of Contents

Connecting the Unit to AW-UE100 Cameras
Connection Example
Serial connection with AW-UE100
DC IN 12 V
IR ID
AUDIO IN
RS-422
SERVICE
12G SDI OUT3G SDI OUT
G/L IN
LAN
LINK ACT
PoE injector
* Prepare a cable that is in accordance
with the following serial connection
cable specifications.
Supplied AC adapter
4K Integrated Camera
AW-UE100
<RS-422> connector
IP connection with AW-UE100
DC IN 12 V
IR ID
AUDIO IN
RS-422
SERVICE
12G SDI OUT3G SDI OUT
G/L IN
LAN
LINK ACT
<LAN LINK/ACT> connector
Switching hub
with PoE support
LAN cable (straight cable)
LAN cable (straight cable)
4K Integrated Camera
AW-UE100
Supplied AC adapter
Serial connection cable specifications
ヒヤモヮチチュモヵユドラナ⾺⾺⾼⾼ヱㄊㄏチワㄐハョㄖㄏ㄄ㄕㄊㄐㄏヱㄐㄍ㄂ㄓㄊㄕㄚョㄍㄐㄘチㄐㄇチㄔㄊㄈㄏ㄂ㄍビヤモヮチチュモヵユドロナピヤモヮチチヤヰワヵドラナフヤモヮチチヤヰワヵドロナヤモヮēチンヰヱヤモヮēチンヰヱンヰヱチēチヤモヮンヰヱチēチヤモヮブヤモヮチチワㄐハチモプヤモヮチチワㄐハチャヘヤモヮチチワㄐハチヤベヤモヮチチワㄐハチュペ
ヒビチヷ
ヒパヨワュヒヨワュン㄀ヵモロロヺ㄀リワンヹュノヵヹュノヵヹュヌンヹュヌヰヱヵリヰワ㄀ヰヶヵヒヰヱヵリヰワ㄀ヰヶヵビビピフブプヘベラㄊㄓㄐㄔㄆチホチランヒパモノヒパンノヒパヱチドヘヒナ
AW-UE100
<RS-422> connector side (RJ-45)
AK-HRP1005G
<CCU> connector side
- 3 -
Connecting the Unit to AW-UE100 Cameras

Connections
Set the connection setting to “Serial(AW5)” or “LAN(AW5)” in the [CONNECT SETTING] menu.
ヒチバチヒヘ
ヤヰワワユヤヵチヴユヵヵリワヨヴㄆㄓㄊ㄂ㄍ⾷モヸブ⾸ロモワ⾷モヸブ⾸ワヰワワヰワワヰワワヰワヤモヮヒヤモヮピヤモヮプヤモヮフヤモヮブヤモヮビヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナ
When connecting, observe the following points.
Serial connection
Use a dedicated cable to connect the <CCU> connector of this unit to the <RS-422> connector of the AW-UE100.
Use a PoE injector for the power supply.
LAN connection
Connect the <LAN> connector on this unit to the <LAN LINK/ACT> connector on the AW-UE100 using a LAN cable (sold
separately).
Configure the camera IP address and port number settings of the connection destinations in [CAMERA IP SETTING] as
well.
This unit can be powered using PoE. Use a switching hub with PoE support.
Use a straight cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).
For details on switching hubs and PoE injectors that have been verified to support PoE, consult with your dealer.
- 4 -
Connecting the Unit to AW-UE100 Cameras

Compatible Functions List
When the unit is used in conjunction with an AW-UE100 4K Integrated Camera, there will be functions that are limited or disabled for some
of the unit's buttons, dials, and other controls. Be sure to refer to the following table.
Front panel 1
Front panel 2
Front panel 3
Front panel 4
Front panel 5
Front panel 6
Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 1
[PANEL LOCK] button ✓
[AUTO] button ✓If auto setup has been assigned, this will not
operate.
[BARS] button ✓Only the ON/OFF for the color bar signal output
will function.
[TALLY/CALL] lamp/button ×
[REF. RECALL] button ×
[FILES] button ✓This is always lit.
[SETUP] button ✓
[AUTO IRIS] button ✓
Front panel 2
Function buttons ✓
LCD panel ✓
Menu operation dials ✓
- 5 -
Connecting the Unit to AW-UE100 Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 3
[GAIN] button ✓When this button is pressed, the gain menu
appears on the LCD panel. The button is lit dur-
ing menu display.
[SHT] button ✓When this button is pressed, the shutter menu
appears on the LCD panel. The button is lit dur-
ing menu display.
[COLOR] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[WHITE BALANCE] > [CHROMA] > [MATRIX] >
[COLOR CORRECTION] > Menu off (status
screen)
[FILTER] button ✓Only the ND filter can be configured.
[GAMMA] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[GAMMA] > [BLACK GAMMA] > Menu off (status
screen)
[FLARE] button ×
[KNEE] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[KNEE] > [WHITE CLIP] > Menu off (status
screen)
[DTL] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[DETAIL] > [DNR] > Menu off (status screen)
Front panel 4
[GAIN], [TEMP], [GAMMA], [SKIN] adjust-
ment block
✓When [GAIN] is lit,
adjust [GAIN R] with the red (R) adjustment dial,
and adjust [GAIN B] with the blue (B) adjustment
dial.
When [TEMP] is lit,
[COLOR TEMP] is adjusted with the green (G)
adjustment dial.
When [GAMMA] is lit,
“MASTER GAMMA” is adjusted using the green
(G) adjustment dial.
[SKIN] adjustment is disabled.
[PED], [FLARE], [B.GAM] adjustment block ✓When [PED] is lit,
adjust [PED R] with the red (R) adjustment dial,
adjust [M.PED] with the green (G) adjustment
dial,
and adjust [PED B] with the blue (B) adjustment
dial.
[FLARE] adjustment is disabled.
When [B.GAM] is lit,
[BLACK GAMMA] is adjusted using the green (G)
adjustment dial.
- 6 -
Connecting the Unit to AW-UE100 Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 5
[ALM] indicator ✓
[OPT] indicator ×
[EXT] indicator ×
[D.EXT] indicator ✓
Adjustment value display ✓The adjustment value of the CC filter is not dis-
played.
[ND] indicator ✓
[CC] indicator ×
[IRIS] indicator ✓
[GAIN] indicator ✓
[PED] indicator ✓
[SHT] indicator ✓
[SYNC] indicator ✓
[DISP] button ✓
[UP (FREE)] button ✓
[DOWN (CHARA)] button ✓
[LOCK] indicator ✓
[SEL] dial ✓
Front panel 6
Memory card slot ✓
Memory card access indicator ✓
Camera number/tally display ✓
[IRIS RELATIVE] button ✓
Torque adjustment screw ✓
IRIS lever ✓
Master pedestal dial ✓
[PREVIEW] button ✓
- 7 -
Connecting the Unit to AW-UE100 Cameras

ROP Menu (during AW-UE100 connection)
ROP Menu List
When an AW-UE100 4K Integrated Camera is connected, the ROP menu will be as follows.
NOTE
To perform menu operations, upgrade the system version of the unit to V5.00-00-0.00 or later.
For details on menu operations, refer to the following sections in the Operating Instructions.
“Displaying menus”
“Basic menu operations”
01 SCENE
SCENE1(push) “SCENE1(push)” (see page 14)
SCENE2(push) “SCENE2(push)” (see page 14)
SCENE3(push) “SCENE3(push)” (see page 14)
SCENE4(push) “SCENE4(push)” (see page 14)
02 SHUTTER SPEED
MODE “MODE” (see page 15)
SPEED “SPEED” (see page 15)
ELC “ELC” (see page 15)
03 FILTER ND “ND” (see page 16)
04 PEDESTAL
M.PED “M.PED” (see page 17)
OFFSET “OFFSET” (see page 17)
PED R “PED R” (see page 17)
PED G “PED G” (see page 17)
PED B “PED B” (see page 17)
05 CHROMA
LEVEL “LEVEL” (see page 18)
PHASE “PHASE” (see page 18)
06 GAIN
SUPER GAIN “SUPER GAIN” (see page 19)
GAIN “GAIN” (see page 19)
AGC MAX GAIN “AGC MAX GAIN” (see page 19)
07 WHITE BALANCE
MODE “MODE” (see page 20)
COLOR TEMP “COLOR TEMP” (see page 20)
GAIN OFFSET “GAIN OFFSET” (see page 20)
GAIN R “GAIN R” (see page 20)
GAIN B “GAIN B” (see page 20)
ATW SPEED “ATW SPEED” (see page 20)
ATW TRGT R “ATW TRGT R” (see page 20)
ATW TRGT B “ATW TRGT B” (see page 20)
08 GAMMA
MODE “MODE” (see page 21)
GAMMA “GAMMA” (see page 21)
09 BLACK GAMMA
BLACK GAMMA “BLACK GAMMA” (see page 22)
RANGE “RANGE” (see page 22)
10 KNEE
MODE “MODE” (see page 23)
A.KNEE RESPONSE “A.KNEE RESPONSE” (see page 23)
POINT “POINT” (see page 23)
SLOPE “SLOPE” (see page 23)
11 WHITE CLIP
WHITE CLIP “WHITE CLIP” (see page 24)
WHITE CLP LV “WHITE CLP LV” (see page 24)
- 8 -
ROP Menu (during AW-UE100 connection)

12 DRS DRS “DRS” (see page 25)
13 DETAIL
MASTER DTL “MASTER DTL” (see page 26)
CORING “CORING” (see page 26)
V DTL LEVEL “V DTL LEVEL” (see page 26)
FREQ “FREQ” (see page 26)
LEVEL DEPEND. “LEVEL DEPEND.” (see page 26)
KNEE APE.LEVEL “KNEE APE.LEVEL” (see page 26)
GAIN(+) “GAIN (+)” (see page 26)
GAIN(-) “GAIN (-)” (see page 26)
SKIN DTL “SKIN DTL” (see page 26)
SKIN DTL EFFECT “SKIN DTL EFFECT” (see page 26)
DTL SW “DTL SW” (see page 26)
14 MATRIX
TYPE “TYPE” (see page 27)
ADAPTIVE MATRIX “ADAPTIVE MATRIX” (see page 27)
R-G “R-G” (see page 27)
R-B “R-B” (see page 27)
G-R “G-R” (see page 27)
G-B “G-B” (see page 27)
B-R “B-R” (see page 27)
B-G “B-G” (see page 27)
- 9 -
ROP Menu (during AW-UE100 connection)

15 COLOR CORRECTION
TYPE “TYPE” (see page 29)
ADAPTIVE MATRIX “ADAPTIVE MATRIX” (see page 29)
COLOR CORRECT “COLOR CORRECT” (see page 29)
SAT “SAT” (see page 29)
PHASE “PHASE” (see page 29)
SAT B_Mg “SAT B_Mg” (see page 29)
PHASE B_Mg “PHASE B_Mg” (see page 29)
SAT Mg “SAT Mg” (see page 29)
PHASE Mg “PHASE Mg” (see page 29)
SAT Mg_R “SAT Mg_R” (see page 29)
PHASE Mg_R “PHASE Mg_R” (see page 29)
SAT Mg_R_R “SAT Mg_R_R” (see page 29)
PHASE Mg_R_R “PHASE Mg_R_R” (see page 30)
SAT R “SAT R” (see page 30)
PHASE R “PHASE R” (see page 30)
SAT R_R_Yl “SAT R_R_Yl” (see page 30)
PHASE R_R_Yl “PHASE R_R_Yl” (see page 30)
SAT R_Yl “SAT R_Yl” (see page 30)
PHASE R_Yl “PHASE R_Yl” (see page 30)
SAT R_Yl_Yl “SAT R_Yl_Yl” (see page 30)
PHASE R_Yl_Yl “PHASE R_Yl_Yl” (see page 30)
SAT Yl “SAT Yl” (see page 30)
PHASE Yl “PHASE Yl” (see page 30)
SAT Yl_Yl_G “SAT Yl_Yl_G” (see page 30)
PHASE Yl_Yl_G “PHASE Yl_Yl_G” (see page 30)
SAT Yl_G “SAT Yl_G” (see page 30)
PHASE Yl_G “PHASE Yl_G” (see page 30)
SAT G “SAT G” (see page 30)
PHASE G “PHASE G” (see page 30)
SAT G_CY “SAT G_CY” (see page 30)
PHASE G_CY “PHASE G_CY” (see page 30)
SAT CY “SAT CY” (see page 30)
PHASE CY “PHASE CY” (see page 30)
SAT CY_B “SAT CY_B” (see page 30)
PHASE CY_B “PHASE CY_B” (see page 30)
SAT B “SAT B” (see page 30)
PHASE B “PHASE B” (see page 30)
16 DNR DNR “DNR” (see page 31)
17 BRIGHTNESS
PICTURE LEVEL “PICTURE LEVEL” (see page 32)
FRAME MIX “FRAME MIX” (see page 32)
DAY/NIGHT “DAY/NIGHT” (see page 32)
A.F.MIX GAIN “A.F.MIX GAIN” (see page 32)
- 10 -
ROP Menu (during AW-UE100 connection)

18 LENS CONTROL
FOCUS MODE “FOCUS MODE” (see page 33)
FOCUS SPEED “FOCUS SPEED” (see page 33)
FOCUS “FOCUS” (see page 33)
ZOOM WIDE “ZOOM WIDE” (see page 33)
ZOOM SPEED “ZOOM SPEED” (see page 33)
ZOOM TELE “ZOOM TELE” (see page 33)
DIGITAL ZOOM SW “DIGITAL ZOOM SW” (see page 33)
DIGITAL ZOOM MAX “DIGITAL ZOOM MAX” (see page 33)
DIGITAL ZOOM D.EXT “DIGITAL ZOOM D.EXT” (see page 33)
19 IRIS RELATIVE
SENSE “SENSE” (see page 34)
COARSE “COARSE” (see page 34)
RELATIVE “RELATIVE” (see page 34)
20 SYSTEM CAM
FORMAT “FORMAT” (see page 35)
FREQUENCY “FREQUENCY” (see page 35)
12G 3G SDI “12G 3G SDI” (see page 35)
3G 3G SDI “3G 3G SDI” (see page 35)
I.S. “I.S.” (see page 35)
OSD 12G “OSD 12G” (see page 35)
OSD 3G “OSD 3G” (see page 35)
OSD MONI “OSD MONI” (see page 35)
OSD HDMI “OSD HDMI” (see page 36)
OSD IP “OSD IP” (see page 36)
OSD STATUS “OSD STATUS” (see page 36)
AUDIO “AUDIO” (see page 36)
GENLOCK PHASE “GENLOCK PHASE” (see page 36)
HEAD PW(push) “HEAD PW(push)” (see page 36)
TALLY CONTROL “TALLY CONTROL” (see page 36)
TALLY INPUT “TALLY INPUT” (see page 36)
TALLY SIGNAL “TALLY SIGNAL” (see page 36)
TALLY CONT MD “TALLY CONT MD” (see page 36)
21 CAMERA MENU CONTROL
MENU ON/OFF “MENU ON/OFF” (see page 37)
CURSOR/PARAMETER “CURSOR/PARAMETER” (see page 37)
EXECUTE “EXECUTE” (see page 37)
- 11 -
ROP Menu (during AW-UE100 connection)

22 ROP SETTING
IRIS LEV MODE Refer to the following section in the Operating Instructions.
“37 ROP SETTING”
M.PED CONT
LOCK SELECT
AUTO BUTTON
G/M PED VOL
FREE+LOCK
CAM SEL
DTL BUTTON
SKIN VOL
LCD BRIGHT
PANEL BRIGHT
B.GAMMA VOL
BUZZER
PERIOD
CYCLE
STD POSITION M.GAIN
STD POSITION VAR
STD POSITION ND
STD POSITION CC
IRIS PRIORITY
ROP DATA SAVE
ROP DATA LOAD
SD CARD FORMAT
INITIAL with NW
INITIAL
UPGRADE
IRIS CALIBRATION TOP
IRIS CALIBRATION BOTTOM
SYSTEM VERSION
SOFT VERSION
FPGA VERSION
23 CONNECT SETTING
CONNECT MODE(push) CAM1 “CONNECT MODE(push) CAM1” (see page 39)
CONNECT MODE(push) CAM2
to CAM99 “CONNECT MODE(push) CAM2 to CAM99” (see page 39)
- 12 -
ROP Menu (during AW-UE100 connection)

24 ROP IP SETTING
IP ADDRESS 1 Refer to the following section in the Operating Instructions.
“39 ROP IP SETTING”
IP ADDRESS 2
IP ADDRESS 3
IP ADDRESS 4
IP ADDRESS PORT
IP ADDRESS UPLOAD
SUBNET MASK 1
SUBNET MASK 2
SUBNET MASK 3
SUBNET MASK 4
SUBNET MASK UPLOAD
DEFAULT GATEWAY
DEFAULT GATEWAY
UPLOAD
MAC ADDRESS
25 CAMERA IP SETTING
CAM1 to CAM99 IP ADDRESS Refer to the following section in the Operating Instructions.
“40 CAMERA IP SETTING”
CAM1 to CAM99 PORT
CAM1 to CAM99 INF UPLOAD
26 AUTO IRIS SETTING
IRIS SPEED “IRIS SPEED” (see page 41)
IRIS WINDOW “IRIS WINDOW” (see page 41)
27 SWITCHER LINK
SW' IP Refer to the following sections in “Functions Added by Version
Updates”.
“Functions linking with AV-HS6000”
RECEIVE UDP PORT
UPLOAD
SWITCHER LINK
TALLY RECEIVE
PREVIEW
TALLY ACTION MATERIAL
TALLY ACTION CAM No.
28 AW CONTROLLER LINK
RECEIVE PORT Refer to the following sections in “Functions Added by Version
Updates”.
“Function linking with AW-RP150”
INFO UPLOAD
AW CONT LINK
- 13 -
ROP Menu (during AW-UE100 connection)

01 SCENE
ヒチバチヒ
ヴヤユワユヰワヰョョヰョョヰョョヴヤユワユヒドㄑㄖㄔㄉナヴヤユワユピドㄑㄖㄔㄉナヴヤユワユフドㄑㄖㄔㄉナヴヤユワユビドㄑㄖㄔㄉナ
Item Setting details
SCENE1(push) Switches the scene file.
Switches to the scene set to ON.
SCENE2(push)
SCENE3(push)
SCENE4(push)
- 14 -
ROP Menu (during AW-UE100 connection)

02 SHUTTER SPEED
ヒチバチヒ
ヴラヶヵヵユンチヴヱユユュヰョョ
ノノ
ヮヰュユユロヤヴヱユユュ
Item Setting details
MODE Selects the operation mode of the shutter.
SPEED Sets the shutter speed.
ELC Sets the maximum shutter value for ELC operation.
- 15 -
ROP Menu (during AW-UE100 connection)

03 FILTER
ヒチバチヒ
ョリロヵユンヒワュ
Item Setting details
ND Sets the transmittance of the lens’ built-in ND (neutral density) filter.
- 16 -
ROP Menu (during AW-UE100 connection)

04 PEDESTAL
ヒチバチヒ
ヱユュユヴヵモロパヰョョヮハヱユュヰョョヴユヵンヨャパパパヱユュ
Item Setting details
M.PED Adjusts the black level of the master pedestal.
OFFSET Sets the [PED R], [PED G], and [PED B] pedestal levels when the auto black balance is adjusted.
PED R Sets the correction level of red to the master pedestal.
PED G Sets the correction level of green to the master pedestal.
PED B Sets the correction level of blue to the master pedestal.
- 17 -
ROP Menu (during AW-UE100 connection)

05 CHROMA
ヒチバチヒ
ヤランヰヮモパパロユヷユロヱラモヴユ
Item Setting details
LEVEL Sets the color intensity of images.
PHASE Finely adjusts the color phase of images.
- 18 -
ROP Menu (during AW-UE100 connection)

06 GAIN
ヒチバチヒ
ヨモリワヰョョフヒベヴヶヱユンヨモリワモヨヤヮモヹチヨモリワヨモリワ
Item Setting details
SUPER GAIN Sets the super gain (increased sensitivity) to ON/OFF.
GAIN Adjusts the gain of images.
AGC MAX GAIN When “AUTO” is selected as the [GAIN] setting, the maximum gain-up amount can be set.
- 19 -
ROP Menu (during AW-UE100 connection)

07 WHITE BALANCE
ヒチバチビ
ヸラリヵユチャモロモワヤユモヸャチモピビパパレヰョョヮヰュユヨモリワヰョョヴユヵヤヰロヰンヵユヮヱンャパパヨモリワ
ビチバチビ
ヸラリヵユチャモロモワヤユワヰンヮモロパパヴヱユユュヵンヨヵチャヵンヨヵチンモヵヸ
Item Setting details
MODE Sets the white balance mode.
COLOR TEMP Sets color temperature settings.
GAIN OFFSET Sets the [GAIN R] and [GAIN B] values when the [MODE] is set to “AWB A” or “AWB B”.
GAIN R Adjusts the R gain.
GAIN B Adjusts the B gain.
ATW SPEED Sets the control speed of the ATW function.
ATW TRGT R Finely adjusts the [GAIN R] output when converged in the auto tracking white balance operation.
ATW TRGT B Finely adjusts the [GAIN B] output when converged in the auto tracking white balance operation.
- 20 -
ROP Menu (during AW-UE100 connection)
