Panasonic AWRP655N - MULTI FUNCTION CONTROLLER User manual

Panasonic Broadcast
AW-RP655N Mechanical Parts
CONTENTS
CHASSIS FRAME ASSEMBLY .......................................................................................................PRT-1
PANEL PARTS ASSEMBLY ............................................................................................................PRT-3
PACKAGING PARTS ASSEMBLY ..................................................................................................PRT-5

PRT-1
CHASSIS FRAME ASSEMBLY
103
13
11
6
5
12
4
6
10
104
12
3
7 8
204
205
102
14
9
PANELPARTSASSEMBLY
(See PRT-3)

PRT-2
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
CHASSIS FRAME ASSEMBLY
3 VMAB0129 BASE PLATE 1
4 VGL0965 PANEL(LED) 3
5 VGL0966 PANEL(LCD) 1
6 TD447MR07B BUTTON GUARD 7
7 N2JZA0000003 JOYSTICK(LEFT) 1
8 N2JZA0000004 JOYSTICK(RIGHT) 1
9 VGP5658-1 JOYSTICK PANEL 2
10 VMG1440 RUBBER CAP 8
11 V5RA0279D3 VOLUME DIAL 1
12 VGU9018 ENCORDER DIAL 3
13 K1AA104H0015 INCOMCONNECTOR 1
14 SJ-5003 RUBBER FOOT 4
102 XSB3+6FN SCREW 12
103 XSN26+6FN SCREW 2
104 XYN3+C12FJK SCREW 8
108 VMX3213 WASHER 4
204 VGNB0106 LABEL(MAIN) 1
205 VQLB0077 LABEL(SETTING) 1
301 RP655A01 CABLE 1 SEE PAGE BLK-1
302 RP655A02 CABLE 1 SEE PAGE BLK-1
303 RP655A03 CABLE 1 SEE PAGE BLK-1
304 RP655A04 CABLE 2 SEE PAGE BLK-1
305 RP655A05 CABLE 2 SEE PAGE BLK-1

PRT-3
PANEL PARTS ASSEMBLY
17 23
22
22
22
22
E2
107
201
21
1
107
107
20
107
19
106
105
18
203
103
E1
16 15
202
2
102 100
201

PRT-4
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
PANEL PARTS ASSEMBLY
1 VGPB0058 SWITCH PANEL 1
2 VGPB0059 REAR PANEL 1
15 K1AA104H0015 DCCONNECTOR 1
16 2G1A001B EARTH TERMINAL 1
17 VMGB0031 SWITCH CUSHION 1
18 VMX3146 LED GUIDE 1
19 VMA0M67 P.C.BOARD MOUNT ANGLE(A) 3
20 VMAB0130 P.C.BOARD MOUNT ANGLE(B) 1
21 VMXB0049 SPACER 3
22 K9ZZ00000595 LED SPACER(A) 11
23 K9ZZ00000653 LED SPACER(B) 36
101 XSB26+6FN SCREW 3
102 XSB3+6FN SCREW 6
103 XSN26+6FN SCREW 2
105 XYN3+F6FN SCREW 2
106 XYN26+J6FN SCREW 3
107 XYN3+J8FN SCREW 12
E1 VEAB0317A MAIN P.C.BOARD 1
E2 VEAB0318A PANEL P.C.BOARD 1
201 V7MA0270A4 LABEL(FUSE) 3
202 V7MA0099B4 LABEL(CAUTION) 1
203 V7MA0338A4 LABEL(SEE MANUAL) 1

PRT-5
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
PACKAGING PARTS ASSEMBLY
6
85 101
2
3
1
9
4
7
MULTI FUNCTION CONTROL
1 VPGB0039 PACKAGING CASE 1
2 VPNB0052 PAD(LEFT) 1
3 VPN5685 PAD(RIGHT) 1
4 VPN5689 PAD(TOP) 1
5 A5PB0002A4 RACK ANGLE 2
6 VQFB0044-1 PRINTED MATTERS BAG 1
6-1 VQTB0101-1 OPERATING INSTRUCTIONS 1
6-2 XZG89X190KG2 ENVELOPE 1
6-3 VQA0866 WARRANTY SHEET 1
6-4 VQC4626 SAFTY INSTRUCTION CARD 1
6-5 VPF0681 POLYETHYLENE BAG 1
7 YWT050803 POLYETHYLENE BAG 1 (SCREW)
8 PE20X35C05B POLYETHYLENE BAG 1 (RACK ANGLE)
9 PE55X71C1B POLYETHYLENE BAG 1
101 XSB4+8FN SCREW 4

PRT-6
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
ELECTRICAL REPLACEMENT PARTS LIST
E1 VEAB0317A REAR P.C.BOARD 1 (RTL)
E2 VEAB0318A PANEL P.C.BOARD 1 (RTL)
E1 VEAB0317A REAR P.C.BOARD 1 (RTL)
B100 CR2032L/B BATTERY 1
C1 F2D1D1010001 E.CAPACITOR CH 20V 100U 1
C2 F2D1D1010001 E.CAPACITOR CH 20V 100U 1
C4 F1H1H511A650 C.CAPACITOR CH 50V 510P 1
C6 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C7 F3H1V156A037 T.CAPACITOR CH 35V 15U 1
C9 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C10 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C12 F1H1H4730002 C.CAPACITOR CH 50V 0.047U 1
C14 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C15 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C18 F1H1H222A789 C.CAPACITOR CH 50V 2200P 1
C19 EEFUD0J101ER E.CAPACITOR CH 6.3V 100U 1
C21 F2G1A471A026 E.CAPACITOR CH 10V 470U 1
C23 F2G1A471A026 E.CAPACITOR CH 10V 470U 1
C24 F1H1H511A650 C.CAPACITOR CH 50V 510P 1
C100 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C101 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C102 F3F1C475A037 T.CAPACITOR CH 16V 4.7U 1
C103 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C103 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C104 F1H1H220A650 C.CAPACITOR CH 50V 22P 1
C105 F1H1H220A650 C.CAPACITOR CH 50V 22P 1
C106 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C107 F3G1A476A029 T.CAPACITOR CH 10V 47U 1
C108 F3G1A476A029 T.CAPACITOR CH 10V 47U 1
C109 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C111 F3G1A476A029 T.CAPACITOR CH 10V 47U 1
C112 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C113 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C114 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C115 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C116 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C117 F1H1H223A789 C.CAPACITOR CH 50V 0.022U 1
C118 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C119 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C120 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C121 F1H1H103A789 C.CAPACITOR CH 50V 0.01U 1
C122 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C123 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C124 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C125 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C126 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C127 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C128 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C129 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C200 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C201 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C202 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C203 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C204 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C205 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C206 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C207 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C208 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C209 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C210 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C211 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C213 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C217 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C219 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C220 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C221 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C222 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C223 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C224 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C225 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C226 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C227 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C228 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C229 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C230 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C231 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C232 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C233 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C234 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C235 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C236 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C237 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C238 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C239 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C240 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C241 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C242 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C300 F1H1H102A793 C.CAPACITOR CH 50V 1000P 1
C301 F1H1H102A793 C.CAPACITOR CH 50V 1000P 1
C302 F1H1H102A793 C.CAPACITOR CH 50V 1000P 1
C303 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C304 F1H1A105A019 C.CAPACITOR CH 10V 1U 1
C400 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C401 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C402 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C403 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C406 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C407 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C408 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C409 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C411 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C412 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C413 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C415 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C416 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C417 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C419 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C420 F3H1V156A037 T.CAPACITOR CH 35V 15U 1
C421 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C422 F1H1H102A793 C.CAPACITOR CH 50V 1000P 1
C423 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C424 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C425 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C426 F3F1V105A028 T.CAPACITOR CH 35V 1U 1
C427 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C428 F1L1C2260007 C.CAPACITOR CH 16V 22U 1
C429 F1L1C2260007 C.CAPACITOR CH 16V 22U 1
C430 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C431 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
D1 MAZ30620ML DIODE 1
D3 B0JCME000014 DIODE 1
D4 B0JCME000014 DIODE 1
D100 MA3J142K0L DIODE 1
D101 MA3J142K0L DIODE 1
D102 MA3J142K0L DIODE 1
D300 MA3J143A0L DIODE 1
D301 MA3J143A0L DIODE 1
D302 MA3J143A0L DIODE 1
F1 K5H162300003 FUSE 1
F3 K5H102300011 FUSE 1
F4 K5H501300008 FUSE 1
F5 K5H501300008 FUSE 1
F6 K5H501300008 FUSE 1
F7 K5H102300011 FUSE 1
F8 K5H501300008 FUSE 1
FL1 F1Z1H4720003 FILTER 1
FL2 F1Z1H4720003 FILTER 1
FL3 F1Z1H4720003 FILTER 1

PRT-7
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
FL4 F1Z1H4720003 FILTER 1
IC1 C0CBBFG00001 IC 1
IC2 C0BBBA000024 IC 1
IC3 C0DBAZZ00110 IC 1
IC4 C0ABBA000025 IC 1
IC100 C0EBB0000169 IC 1
IC101 C0JBAZ002192 IC 1
IC102 C2CBJG000674 IC 1
IC103 C0JBAA000157 IC 1
IC104 C3BBJC000037 IC 1
IC105 C0JBAN000139 IC 1
IC106 C0JBAS000249 IC 1
IC107 C0JBAA000387 IC 1
IC108 C0EBB0000169 IC 1
IC109 C0JBAZ002331 IC 1
IC110 C0JBAB000632 IC 1
IC111 C0JBAZ002331 IC 1
IC112 C0ZBZ0001064 IC 1
IC200 C0JBAS000134 IC 1
IC201 C0JBAN000139 IC 1
IC202 C0JBAE000321 IC 1
IC203 C0JBAA000157 IC 1
IC204 C0JBAE000321 IC 1
IC205 C0JBAB000436 IC 1
IC206 B1HBGFG00014 IC 1
IC207 C1DB00000145 IC 1
IC208 C1DB00000146 IC 1
IC209 C1DB00000146 IC 1
IC210 C1DB00000146 IC 1
IC211 C1DB00000146 IC 1
IC212 C1DB00000146 IC 1
IC300 C0JBAA000157 IC 1
IC301 C0JBAA000157 IC 1
IC400 C0ABCA000088 IC 1
IC401 C0ABCA000088 IC 1
IC403 C0ABCA000088 IC 1
IC404 C0ABCA000017 IC 1
IC405 C0ABBB000324 IC 1
IC406 C0ABBA000168 IC 1
L1 G1A330HA0037 COIL 1
L3 G1A330HA0016 COIL 1
L100 J0JCC0000089 COIL 1
L101 J0JCC0000089 COIL 1
L102 J0JCC0000089 COIL 1
L103 J0JCC0000089 COIL 1
L104 J0JCC0000089 COIL 1
L200 J0JCC0000089 COIL 1
L201 J0JCC0000089 COIL 1
L202 J0JCC0000089 COIL 1
L203 J0JCC0000089 COIL 1
L204 J0JCC0000089 COIL 1
L205 J0JCC0000089 COIL 1
L206 J0JCC0000089 COIL 1
L207 J0JCC0000089 COIL 1
L208 J0JCC0000089 COIL 1
L209 J0JCC0000089 COIL 1
L210 J0JCC0000089 COIL 1
L211 J0JCC0000089 COIL 1
L212 J0JCC0000089 COIL 1
L213 J0JCC0000089 COIL 1
L214 J0JCC0000089 COIL 1
L215 J0JCC0000089 COIL 1
L216 J0JCC0000089 COIL 1
L217 J0JCC0000089 COIL 1
L218 J0JCC0000089 COIL 1
L219 J0JCC0000089 COIL 1
L220 J0JCC0000089 COIL 1
L221 J0JCC0000089 COIL 1
L222 J0JCC0000089 COIL 1
L223 J0JCC0000089 COIL 1
L224 J0JCC0000089 COIL 1
L225 J0JCC0000089 COIL 1
L226 J0JCC0000089 COIL 1
L227 J0JCC0000089 COIL 1
L228 J0JCC0000089 COIL 1
L229 J0JCC0000089 COIL 1
L230 J0JCC0000089 COIL 1
L231 J0JCC0000089 COIL 1
L232 J0JCC0000089 COIL 1
L233 J0JCC0000089 COIL 1
L234 J0JCC0000089 COIL 1
L235 J0JCC0000089 COIL 1
L236 J0JCC0000089 COIL 1
L237 J0JCC0000089 COIL 1
L238 J0JCC0000089 COIL 1
L239 J0JCC0000089 COIL 1
L240 J0JCC0000089 COIL 1
L241 J0JCC0000089 COIL 1
L242 J0JCC0000089 COIL 1
L243 J0JCC0000089 COIL 1
L244 J0JCC0000089 COIL 1
L245 J0JCC0000089 COIL 1
L246 J0JCC0000089 COIL 1
L247 J0JCC0000089 COIL 1
L248 J0JCC0000089 COIL 1
L249 J0JCC0000089 COIL 1
L250 J0JCC0000089 COIL 1
L251 J0JCC0000089 COIL 1
L252 J0JCC0000089 COIL 1
L253 J0JCC0000089 COIL 1
L254 J0JCC0000089 COIL 1
L259 J0JCC0000089 COIL 1
L260 J0JCC0000089 COIL 1
L261 J0JCC0000089 COIL 1
L262 J0JCC0000089 COIL 1
L263 J0JCC0000089 COIL 1
L264 J0JCC0000089 COIL 1
L265 J0JCC0000089 COIL 1
L266 J0JCC0000089 COIL 1
L300 J0JCC0000089 COIL 1
L301 J0JCC0000089 COIL 1
L302 J0JCC0000089 COIL 1
L303 J0JCC0000089 COIL 1
L304 J0JCC0000089 COIL 1
L305 J0JCC0000089 COIL 1
L402 J0JCC0000160 COIL 1
L403 J0JCC0000160 COIL 1
L404 J0JCC0000160 COIL 1
L406 J0JCC0000160 COIL 1
L407 J0JCC0000160 COIL 1
P1 K1KA06A00485 CONNECTOR 1
P2 K1KA05BA0031 CONNECTOR 1
P100 K1FA109B0068 CONNECTOR 1
P200 K1FB115B0108 CONNECTOR 1
P201 K2LC108B0059 CONNECTOR 1
P202 K2LC108B0059 CONNECTOR 1
P203 K2LC108B0059 CONNECTOR 1
P204 K2LC108B0059 CONNECTOR 1
P205 K2LC108B0059 CONNECTOR 1
P206 K2LC108B0059 CONNECTOR 1
P207 K2LC108B0059 CONNECTOR 1
P208 K1KA15B00072 CONNECTOR 1
P300 K2LC108B0059 CONNECTOR 1
P400 K1KA10AA0310 CONNECTOR 1
Q1 2SB1218QRTX TRANSISTOR 1
Q2 2SD1819QRTX TRANSISTOR 1
Q3 2SD1819QRTX TRANSISTOR 1
Q4 2SB1218QRTX TRANSISTOR 1
Q7 B1DHCD000029 FET 1
Q9 B1DHCD000029 FET 1
Q11 B1DHCD000029 FET 1
Q12 2SB0766QRTX TRANSISTOR 1
Q100 2SD1819QRTX TRANSISTOR 1
Q101 2SB1218QRTX TRANSISTOR 1
Q400 2SD0874QRTX TRANSISTOR 1
Q401 2SB1218QRTX TRANSISTOR 1
Q402 B1BDGD000001 TRANSISTOR 1
Q403 2SD1819QRTX TRANSISTOR 1

PRT-8
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
R3 ERJ3RBD203V M.RESISTOR CH 1/16W 20K 1
R6 D0GB912JA041 M.RESISTOR CH 1/10W 9.1K 1
R8 D0GB203JA041 M.RESISTOR CH 1/10W 20K 1
R9 D0GB623JA041 M.RESISTOR CH 1/10W 62K 1
R10 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R11 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R12 D0GB623JA041 M.RESISTOR CH 1/10W 62K 1
R14 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R15 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R16 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R17 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R18 D0GB681JA041 M.RESISTOR CH 1/10W 680 1
R19 D0GB681JA041 M.RESISTOR CH 1/10W 680 1
R20 D0GB681JA041 M.RESISTOR CH 1/10W 680 1
R21 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R23 D0GB683JA041 M.RESISTOR CH 1/10W 68K 1
R26 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R29 ERJ3RBD362V M.RESISTOR CH 1/16W 3.6K 1
R30 ERJ3RBD822V M.RESISTOR CH 1/16W 8.2K 1
R31 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R33 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R35 D0GB100JA041 M.RESISTOR CH 1/10W 10 1
R37 D0GB100JA041 M.RESISTOR CH 1/10W 10 1
R39 D0GB100JA041 M.RESISTOR CH 1/10W 10 1
R43 ERJ3RBD201V M.RESISTOR CH 1/16W 200 1
R44 ERJ3RBD333V M.RESISTOR CH 1/16W 33K 1
R45 ERJ3RBD103V M.RESISTOR CH 1/16W 10K 1
R46 ERJ3RBD203V M.RESISTOR CH 1/16W 20K 1
R47 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R48 D0GB100JA041 M.RESISTOR CH 1/10W 10 1
R49 D0GB100JA041 M.RESISTOR CH 1/10W 10 1
R50 D0GB100JA041 M.RESISTOR CH 1/10W 10 1
R51 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R52 ERJ3RBD202V M.RESISTOR CH 1/16W 2K 1
R53 ERJ3RBD103V M.RESISTOR CH 1/16W 10K 1
R100 ERJ3RBD183V M.RESISTOR CH 1/16W 18K 1
R101 ERJ3RBD153V M.RESISTOR CH 1/16W 15K 1
R102 D1H847340001 BLOCK RESISTOR 47K 1
R103 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R104 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R105 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R106 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R107 D1H81514A013 BLOCK RESISTOR 150 1
R108 D1H81514A013 BLOCK RESISTOR 150 1
R109 D1H81514A013 BLOCK RESISTOR 150 1
R110 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R111 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R112 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R113 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R114 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R116 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R117 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R118 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R119 D1H81514A013 BLOCK RESISTOR 150 1
R120 D1H81514A013 BLOCK RESISTOR 150 1
R121 D1H81514A013 BLOCK RESISTOR 150 1
R125 D1H81514A013 BLOCK RESISTOR 150 1
R128 D1H81514A013 BLOCK RESISTOR 150 1
R129 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R131 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R133 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R134 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R135 D1H81514A013 BLOCK RESISTOR 150 1
R143 D1H81514A013 BLOCK RESISTOR 150 1
R144 D1H81514A013 BLOCK RESISTOR 150 1
R145 D1H81514A013 BLOCK RESISTOR 150 1
R146 D1H81514A013 BLOCK RESISTOR 150 1
R147 D1H81514A013 BLOCK RESISTOR 150 1
R148 D1H81514A013 BLOCK RESISTOR 150 1
R149 D1H81514A013 BLOCK RESISTOR 150 1
R152 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R153 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R154 D0GB162JA041 M.RESISTOR CH 1/10W 1.6K 1
R155 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R156 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R157 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R158 D0GB472JA041 M.RESISTOR CH 1/10W 4.7K 1
R159 D1BB1202A087 M.RESISTOR CH 1/10W 12K 1
R160 ERJ3RBD153V RESISTOR CH 1/16W 15K 1
R161 D0GB223JA041 M.RESISTOR CH 1/10W 22K 1
R162 D0GB472JA041 M.RESISTOR CH 1/10W 4.7K 1
R163 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R164 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R165 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R166 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R167 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R168 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R169 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R200 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R201 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R202 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R203 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R204 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R205 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R206 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R207 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R208 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R209 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R210 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R211 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R212 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R215 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R216 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R217 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R218 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R219 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R220 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R221 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R222 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R223 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R224 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R225 D0GF201JA026 M.RESISTOR CH 1/4W 200 1
R300 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R301 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R302 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R303 D0GB470JA041 M.RESISTOR CH 1/10W 47 1
R304 D0GB470JA041 M.RESISTOR CH 1/10W 47 1
R305 D0GB470JA041 M.RESISTOR CH 1/10W 47 1
R306 D0GB470JA041 M.RESISTOR CH 1/10W 47 1
R307 D0GB470JA041 M.RESISTOR CH 1/10W 47 1
R308 D0GB470JA041 M.RESISTOR CH 1/10W 47 1
R309 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R310 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R311 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R400 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R401 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R402 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R403 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R406 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R407 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R408 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R409 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R410 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R411 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R414 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R415 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R416 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R417 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R418 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R419 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R422 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R423 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R424 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R425 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R427 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R428 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R429 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R431 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R432 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R433 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R434 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1

PRT-9
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
R435 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R438 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R439 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R440 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R441 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R443 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R444 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R445 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R447 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R448 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R449 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R451 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R452 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R453 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R455 D0GB621JA041 M.RESISTOR CH 1/10W 620 1
R456 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R457 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R458 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R459 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R462 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R463 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R464 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R465 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R467 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R468 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R469 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R471 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R472 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R474 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R475 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R476 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R478 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R479 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R484 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R485 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R487 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R488 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R489 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R491 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R492 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R493 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R494 D0GB223JA041 M.RESISTOR CH 1/10W 22K 1
R495 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R496 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R497 D0GB152JA041 M.RESISTOR CH 1/10W 1.5K 1
R498 ERJ3RBD202V M.RESISTOR CH 1/16W 2K 1
R499 ERJ3RBD203V M.RESISTOR CH 1/16W 20K 1
R500 ERJ3RBD103V M.RESISTOR CH 1/16W 10K 1
R501 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R502 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R503 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R504 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R505 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R506 D0GB393JA041 M.RESISTOR CH 1/10W 39K 1
R507 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R508 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R509 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R510 D0GB202JA041 M.RESISTOR CH 1/10W 2K 1
R511 ERJ3RBD302V M.RESISTOR CH 1/16W 3K 1
R512 ERJ3RBD302V M.RESISTOR CH 1/16W 3K 1
R513 ERJ3RBD103V M.RESISTOR CH 1/16W 10K 1
R514 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R515 D0GB303JA041 M.RESISTOR CH 1/10W 30K 1
R516 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R517 D0GB331JA041 M.RESISTOR CH 1/10W 330 1
R518 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R519 D0GB332JA041 M.RESISTOR CH 1/10W 3.3K 1
R520 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R521 ERJ3RBD103V M.RESISTOR CH 1/16W 10K 1
R522 ERJ3RBD103V M.RESISTOR CH 1/16W 10K 1
R526 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R527 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R528 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R532 D0GDR00Z0002 M.RESISTOR CH 1/4W 0 1
R533 D0GDR00Z0002 M.RESISTOR CH 1/4W 0 1
SW100 K0D141A00002 SWITCH 1
SW101 K0D123B00024 SWITCH 1
SW102 K0D113B00043 SWITCH 1
SW200 K0D123B00024 SWITCH 1
TP1 D0YDR0000029 TEST POINT TERMINAL 1
TP2 D0YDR0000029 TEST POINT TERMINAL 1
TP3 D0YDR0000029 TEST POINT TERMINAL 1
TP4 D0YDR0000029 TEST POINT TERMINAL 1
TP100 D0YDR0000029 TEST POINT TERMINAL 1
TP101 D0YDR0000029 TEST POINT TERMINAL 1
TP102 D0YDR0000029 TEST POINT TERMINAL 1
TP201 D0YDR0000029 TEST POINT TERMINAL 1
TP202 D0YDR0000029 TEST POINT TERMINAL 1
TP203 D0YDR0000029 TEST POINT TERMINAL 1
TP400 D0YDR0000029 TEST POINT TERMINAL 1
TP401 D0YDR0000029 TEST POINT TERMINAL 1
X100 H0J120500026 CRYSTAL OSCILLATOR 1
MISCELLANEOUS
B100 BCR20H4 BATTERY HOLDER 1
E2 VEAB0318A PANEL P.C.BOARD 1 (RTL)
BZ400 L0DCDA000016 BUZZER 1
C1 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C2 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C3 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C4 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C5 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C6 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C7 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C8 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C9 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C10 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C11 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C12 F3F1C106A039 T.CAPACITOR CH 16V 10U 1
C13 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C14 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C401 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C402 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C403 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C404 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C405 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C408 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C409 F3F1V104A026 T.CAPACITOR CH 35V 0.1U 1
C410 F1H1H101A650 C.CAPACITOR CH 50V 100P 1
C411 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C412 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C413 F1H1H220A650 C.CAPACITOR CH 50V 22P 1
C414 F1H1H220A650 C.CAPACITOR CH 50V 22P 1
C415 F3G1C226A022 T.CAPACITOR CH 16V 22U 1
C416 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C417 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C418 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C419 F3G1C226A022 T.CAPACITOR CH 16V 22U 1
C420 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C421 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C422 F1H1H103A789 C.CAPACITOR CH 50V 0.01U 1
C423 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C424 F3G1C226A022 T.CAPACITOR CH 16V 22U 1
C425 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C432 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C433 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C434 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C435 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C436 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C437 F1H1H471A650 C.CAPACITOR CH 50V 470P 1

PRT-10
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
C438 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C439 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C440 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C441 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C448 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C449 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C711 F2G1A471A026 E.CAPACITOR CH 10V 470U 1
C712 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C713 F1H1H471A650 C.CAPACITOR CH 50V 470P 1
C714 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C715 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C716 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C717 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C718 F3H1C107A048 T.CAPACITOR CH 16V 100U 1
C719 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C720 F1H1E1040006 C.CAPACITOR CH 25V 0.1U 1
C721 F1H1H103A789 C.CAPACITOR CH 50V 0.01U 1
D1 LN417YPH LED 1
D2 LN417YPH LED 1
D3 LN317GPH LED 1
D4 LN317GPH LED 1
D5 LN317GPH LED 1
D6 LN317GPH LED 1
D7 LN317GPH LED 1
D8 LN317GPH LED 1
D9 LN317GPH LED 1
D10 LN317GPH LED 1
D11 LN417YPH LED 1
D12 LN417YPH LED 1
D13 LN417YPH LED 1
D14 LN417YPH LED 1
D15 LN317GPH LED 1
D16 LN317GPH LED 1
D17 LN317GPH LED 1
D18 LN317GPH LED 1
D19 LN317GPH LED 1
D20 LN317GPH LED 1
D21 LN317GPH LED 1
D22 LN317GPH LED 1
D23 LN417YPH LED 1
D24 LN417YPH LED 1
D25 LN417YPH LED 1
D26 LN417YPH LED 1
D27 LN317GPH LED 1
D28 LN317GPH LED 1
D29 LN317GPH LED 1
D30 LN317GPH LED 1
D31 LN317GPH LED 1
D32 LN317GPH LED 1
D33 LN317GPH LED 1
D34 LN317GPH LED 1
D35 LN417YPH LED 1
D36 LN417YPH LED 1
D37 LN28RPX LED 1
D38 LN28RPX LED 1
D39 LN28RPX LED 1
D40 LN28RPX LED 1
D41 LN28RPX LED 1
D42 LN38GPX LED 1
D43 LN38GPX LED 1
D44 LN38GPX LED 1
D45 LN48YPX LED 1
D46 LN48YPX LED 1
D47 LN38GPX LED 1
D48 MA6X12100L DIODE 1
D49 MA6X12100L DIODE 1
D50 MA6X12100L DIODE 1
D400 MA3J142K0L DIODE 1
D703 MA3J142K0L DIODE 1
F701 K5H102300011 FUSE 1
F702 K5H501300008 FUSE 1
FL701 F1Z1H4720003 FILTER 1
FL702 F1Z1H4720003 FILTER 1
IC1 C1ZBZ0002770 IC 1
IC2 C1ZBZ0002770 IC 1
IC3 C1ZBZ0002770 IC 1
IC4 C1ZBZ0002770 IC 1
IC401 C0EBB0000169 IC 1
IC402 C0JBAZ002192 IC 1
IC403 C1DB00000145 IC 1
IC404 C2CBJG000674 IC 1
IC405 C0JBAC000366 IC 1
IC406 C0JBAN000139 IC 1
IC407 C0JBAS000134 IC 1
IC703 C0JBAB000713 IC 1
IC704 C0JBAB000713 IC 1
IC705 C0JBAB000713 IC 1
IC706 C0JBAB000713 IC 1
IC708 C0JBAZ002505 IC 1
IC709 C0JBAA000345 IC 1
IC710 C0JBAA000345 IC 1
L405 J0JCC0000089 COIL 1
L406 J0JCC0000089 COIL 1
L407 J0JCC0000089 COIL 1
L408 J0JCC0000089 COIL 1
L409 J0JCC0000089 COIL 1
L410 J0JCC0000089 COIL 1
L411 J0JCC0000089 COIL 1
L412 J0JCC0000089 COIL 1
L413 J0JCC0000089 COIL 1
L602 J0JCC0000089 COIL 1
L604 J0JCC0000089 COIL 1
L605 J0JCC0000089 COIL 1
L606 J0JCC0000089 COIL 1
P1 K1KA16A00213 CONNECTOR 1
P2 K1KY02AA0045 CONNECTOR 1
P3 K1KY02AA0045 CONNECTOR 1
P4 K1KA08BA0081 CONNECTOR 1
P400 K1KA15B00072 CONNECTOR 1
P402 K1KA10BA0087 CONNECTOR 1
P403 K1KA10BA0087 CONNECTOR 1
P600 K1KA04BA0086 CONNECTOR 1
P701 K1KA05AA0061 CONNECTOR 1
Q1 UNR521400L TRANSISTOR 1
Q2 UNR521400L TRANSISTOR 1
Q3 UNR521400L TRANSISTOR 1
Q4 UNR521400L TRANSISTOR 1
Q5 UNR521400L TRANSISTOR 1
Q6 UNR521400L TRANSISTOR 1
Q7 UNR521400L TRANSISTOR 1
Q8 UNR521400L TRANSISTOR 1
Q9 UNR521400L TRANSISTOR 1
Q10 UNR521400L TRANSISTOR 1
Q11 UNR521400L TRANSISTOR 1
Q12 UNR521400L TRANSISTOR 1
Q13 UNR521400L TRANSISTOR 1
Q14 UNR521400L TRANSISTOR 1
Q15 UNR521400L TRANSISTOR 1
Q16 UNR521400L TRANSISTOR 1
Q17 UNR521400L TRANSISTOR 1
Q18 UNR521400L TRANSISTOR 1
Q19 UNR521400L TRANSISTOR 1
Q20 UNR521400L TRANSISTOR 1
Q21 UNR521400L TRANSISTOR 1
Q22 UNR521400L TRANSISTOR 1
Q23 UNR521400L TRANSISTOR 1
Q24 UNR521400L TRANSISTOR 1
Q25 UNR521400L TRANSISTOR 1
Q26 UNR521400L TRANSISTOR 1
Q27 UNR521400L TRANSISTOR 1
Q28 UNR521400L TRANSISTOR 1
Q29 UNR521400L TRANSISTOR 1
Q30 UNR521400L TRANSISTOR 1
Q31 UNR521400L TRANSISTOR 1
Q32 UNR521400L TRANSISTOR 1

PRT-11
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
Q33 UNR521400L TRANSISTOR 1
Q34 UNR521400L TRANSISTOR 1
Q35 UNR521400L TRANSISTOR 1
Q36 UNR521400L TRANSISTOR 1
Q37 UNR521400L TRANSISTOR 1
Q38 UNR521400L TRANSISTOR 1
Q39 UNR521400L TRANSISTOR 1
Q40 UNR521400L TRANSISTOR 1
Q41 UNR521400L TRANSISTOR 1
Q42 UNR521400L TRANSISTOR 1
Q43 UNR521400L TRANSISTOR 1
Q44 UNR521400L TRANSISTOR 1
Q45 UNR521400L TRANSISTOR 1
Q46 UNR521400L TRANSISTOR 1
Q47 UNR521400L TRANSISTOR 1
Q48 UNR521400L TRANSISTOR 1
Q49 UNR521400L TRANSISTOR 1
Q50 UNR521400L TRANSISTOR 1
Q51 UNR521400L TRANSISTOR 1
Q52 UNR521400L TRANSISTOR 1
Q53 UNR521400L TRANSISTOR 1
Q54 UNR521400L TRANSISTOR 1
Q55 UNR521400L TRANSISTOR 1
Q56 UNR521400L TRANSISTOR 1
Q57 UNR521400L TRANSISTOR 1
Q58 UNR521400L TRANSISTOR 1
Q59 UNR521400L TRANSISTOR 1
Q60 UNR521400L TRANSISTOR 1
Q61 UNR521400L TRANSISTOR 1
Q62 UNR521400L TRANSISTOR 1
Q63 UNR521400L TRANSISTOR 1
Q64 UNR521400L TRANSISTOR 1
Q65 UNR521400L TRANSISTOR 1
Q66 UNR521400L TRANSISTOR 1
Q67 UNR521400L TRANSISTOR 1
Q68 UNR521400L TRANSISTOR 1
Q69 UNR521400L TRANSISTOR 1
Q70 UNR521400L TRANSISTOR 1
Q71 UNR521400L TRANSISTOR 1
Q72 UNR521400L TRANSISTOR 1
Q73 UNR521400L TRANSISTOR 1
Q74 UNR521400L TRANSISTOR 1
Q75 UNR521400L TRANSISTOR 1
Q76 UNR521400L TRANSISTOR 1
Q77 UNR521400L TRANSISTOR 1
Q78 UNR521400L TRANSISTOR 1
Q79 UNR521400L TRANSISTOR 1
Q80 UNR521400L TRANSISTOR 1
Q81 UNR521400L TRANSISTOR 1
Q82 UNR521400L TRANSISTOR 1
Q83 UNR521400L TRANSISTOR 1
Q84 UNR521400L TRANSISTOR 1
Q85 UNR521400L TRANSISTOR 1
Q86 UNR521400L TRANSISTOR 1
Q87 UNR521400L TRANSISTOR 1
Q88 UNR521400L TRANSISTOR 1
Q89 UNR521400L TRANSISTOR 1
Q90 UNR521400L TRANSISTOR 1
Q91 UNR521400L TRANSISTOR 1
Q92 UNR521400L TRANSISTOR 1
Q93 UNR521400L TRANSISTOR 1
Q94 UNR521400L TRANSISTOR 1
Q95 UNR521400L TRANSISTOR 1
Q96 UNR521400L TRANSISTOR 1
Q97 UNR521400L TRANSISTOR 1
Q98 UNR521400L TRANSISTOR 1
Q99 UNR521400L TRANSISTOR 1
Q100 UNR521400L TRANSISTOR 1
Q101 UNR521400L TRANSISTOR 1
Q102 UNR521400L TRANSISTOR 1
Q103 UNR521400L TRANSISTOR 1
Q104 UNR521400L TRANSISTOR 1
Q105 UNR521400L TRANSISTOR 1
Q106 UNR521400L TRANSISTOR 1
Q107 UNR521400L TRANSISTOR 1
Q108 UNR521400L TRANSISTOR 1
Q109 UNR521400L TRANSISTOR 1
Q110 UNR521400L TRANSISTOR 1
Q111 UNR521400L TRANSISTOR 1
Q112 UNR521400L TRANSISTOR 1
Q113 UNR521400L TRANSISTOR 1
Q114 UNR521400L TRANSISTOR 1
Q115 UNR521400L TRANSISTOR 1
Q116 UNR521400L TRANSISTOR 1
Q117 UNR521400L TRANSISTOR 1
Q118 UNR521400L TRANSISTOR 1
Q119 UNR521400L TRANSISTOR 1
Q120 UNR521400L TRANSISTOR 1
Q121 UNR521400L TRANSISTOR 1
Q122 UNR521400L TRANSISTOR 1
Q123 UNR521400L TRANSISTOR 1
Q124 UNR521400L TRANSISTOR 1
Q125 UNR521400L TRANSISTOR 1
Q126 UNR521400L TRANSISTOR 1
Q127 UNR521400L TRANSISTOR 1
Q128 UNR521400L TRANSISTOR 1
Q129 UNR521400L TRANSISTOR 1
Q130 UNR521400L TRANSISTOR 1
Q131 UNR521400L TRANSISTOR 1
Q132 UNR521400L TRANSISTOR 1
Q133 2SB0766QRTX TRANSISTOR 1
Q134 UNR521400L TRANSISTOR 1
Q400 2SD1819QRTX TRANSISTOR 1
Q402 UNR521400L TRANSISTOR 1
Q403 UNR521400L TRANSISTOR 1
Q404 UNR521400L TRANSISTOR 1
R2 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R3 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R5 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R6 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R8 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R9 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R11 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R12 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R14 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R15 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R17 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R18 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R20 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R21 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R23 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R24 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R26 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R27 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R29 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R30 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R32 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R34 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R35 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R36 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R38 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R39 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R41 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R42 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R44 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R45 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R47 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R48 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R50 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R51 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R53 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R55 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R56 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R58 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R59 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R60 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R63 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R64 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R65 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R66 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R68 D0GB910JA041 M.RESISTOR CH 1/10W 91 1

PRT-12
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
R69 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R71 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R72 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R74 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R75 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R77 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R78 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R80 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R81 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R84 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R85 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R87 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R88 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R89 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R90 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R92 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R93 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R95 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R96 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R98 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R99 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R101 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R102 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R104 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R105 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R107 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R108 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R110 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R111 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R113 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R114 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R116 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R117 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R119 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R120 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R122 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R124 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R125 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R126 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R128 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R129 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R131 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R132 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R134 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R135 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R137 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R138 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R140 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R141 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R143 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R145 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R146 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R148 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R149 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R150 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R153 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R154 D0GB910JA041 M.RESISTOR CH 1/10W 91 1
R155 D0GB151JA041 M.RESISTOR CH 1/10W 150 1
R156 D0GB151JA041 M.RESISTOR CH 1/10W 150 1
R158 D0GB151JA041 M.RESISTOR CH 1/10W 150 1
R159 D0GB151JA041 M.RESISTOR CH 1/10W 150 1
R161 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R162 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R164 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R165 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R167 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R168 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R170 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R171 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R173 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R174 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R176 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R177 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R179 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R180 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R182 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R183 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R185 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R186 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R188 D0GB271JA041 M.RESISTOR CH 1/10W 270 1
R189 D0GB271JA041 M.RESISTOR CH 1/10W 270 1
R191 D0GB561JA041 M.RESISTOR CH 1/10W 560 1
R192 D0GB561JA041 M.RESISTOR CH 1/10W 560 1
R194 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R195 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R197 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R199 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R200 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R202 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R203 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R205 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R206 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R207 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R209 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R210 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R212 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R213 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R215 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R216 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R218 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R219 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R221 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R222 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R224 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R225 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R228 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R229 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R231 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R232 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R234 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R235 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R236 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R237 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R239 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R240 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R242 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R243 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R245 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R246 D0GB391JA041 M.RESISTOR CH 1/10W 390 1
R248 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R249 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R251 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R252 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R254 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R255 D0GB471JA041 M.RESISTOR CH 1/10W 470 1
R257 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R259 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R261 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R263 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R265 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R267 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R269 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R271 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R273 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R275 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R277 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R279 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R281 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R283 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R285 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R287 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R289 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R291 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R293 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R295 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R297 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R299 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R301 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R303 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R305 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R307 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R309 D0GB911JA041 M.RESISTOR CH 1/10W 910 1

PRT-13
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
R311 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R313 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R315 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R317 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R319 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R321 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R323 D0GB911JA041 M.RESISTOR CH 1/10W 910 1
R325 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R327 D0GB751JA041 M.RESISTOR CH 1/10W 750 1
R345 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R347 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R350 D0GB472JA041 M.RESISTOR CH 1/10W 4.7K 1
R351 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R352 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R353 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R354 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R355 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R356 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R357 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R358 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R359 D0GB472JA041 M.RESISTOR CH 1/10W 4.7K 1
R361 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R362 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R363 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R364 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R365 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R366 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R367 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R368 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R370 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R371 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R372 D0GB821JA041 M.RESISTOR CH 1/10W 820 1
R373 D0GD1R6JA035 M.RESISTOR CH 1/4W 1M 1
R374 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R375 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R376 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R377 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R378 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R379 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R380 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R381 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R382 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R383 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R384 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R385 D0GB104JA041 M.RESISTOR CH 1/10W 100K 1
R386 D0GD1R6JA035 M.RESISTOR CH 1/4W 1M 1
R387 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R388 D1H81514A013 BLOCK RESISTOR 150 1
R389 D1H81514A013 BLOCK RESISTOR 150 1
R390 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R391 D1H81514A013 BLOCK RESISTOR 150 1
R392 D1H81514A013 BLOCK RESISTOR 150 1
R393 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R394 D1H81514A013 BLOCK RESISTOR 150 1
R395 D1H81514A013 BLOCK RESISTOR 150 1
R396 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R397 D1H81514A013 BLOCK RESISTOR 150 1
R398 D1H81514A013 BLOCK RESISTOR 150 1
R400 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R401 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R403 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R404 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R405 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R406 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R407 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R410 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R411 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R412 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R413 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R414 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R415 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R416 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R418 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R419 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R420 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R421 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R422 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R424 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R425 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R426 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R427 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R428 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R429 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R430 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R432 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R433 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R434 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R437 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R438 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R439 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R440 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R441 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R444 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R445 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R446 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R447 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R451 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R452 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R453 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R454 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R455 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R456 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R457 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R458 D0GB105JA041 M.RESISTOR CH 1/10W 1M 1
R459 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R460 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R461 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R462 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R463 D0GB124JA041 M.RESISTOR CH 1/10W 120K 1
R464 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R465 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R466 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R469 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R470 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R471 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R472 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R473 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R477 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R478 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R479 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R489 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R490 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R491 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R492 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R493 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R494 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R495 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R496 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R497 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R498 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R499 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R500 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R501 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R502 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R503 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R504 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R505 D0GBR00Z0002 M.RESISTOR CH 1/10W 0 1
R506 D0GB103JA041 M.RESISTOR CH 1/10W 10K 1
R507 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R508 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R509 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R510 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R511 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R512 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R514 D0GB473JA041 M.RESISTOR CH 1/10W 47K 1
R517 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R725 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R726 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R727 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R728 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R729 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R730 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1

PRT-14
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
R731 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R732 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R733 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R734 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R735 D0GB512JA041 M.RESISTOR CH 1/10W 5.1K 1
R736 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
R737 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R738 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R739 D0GB101JA041 M.RESISTOR CH 1/10W 100 1
R741 D0GB102JA041 M.RESISTOR CH 1/10W 1K 1
SW1 K0F111A00526 SWITCH 1
SW2 K0F111A00526 SWITCH 1
SW3 K0F111A00526 SWITCH 1
SW4 K0F111A00526 SWITCH 1
SW5 K0F111A00526 SWITCH 1
SW6 K0F111A00526 SWITCH 1
SW7 K0F111A00526 SWITCH 1
SW8 K0F111A00526 SWITCH 1
SW9 K0F111A00526 SWITCH 1
SW10 K0F111A00526 SWITCH 1
SW11 K0F111A00523 SWITCH 1
SW12 K0F111A00523 SWITCH 1
SW13 K0F111A00523 SWITCH 1
SW14 K0F111A00523 SWITCH 1
SW15 K0F111A00523 SWITCH 1
SW16 K0F111A00523 SWITCH 1
SW17 K0F111A00523 SWITCH 1
SW18 K0F111A00523 SWITCH 1
SW19 K0F111A00523 SWITCH 1
SW20 K0F111A00523 SWITCH 1
SW21 K0F111A00523 SWITCH 1
SW22 K0F111A00523 SWITCH 1
SW23 K0F111A00523 SWITCH 1
SW24 K0F111A00523 SWITCH 1
SW25 K0F111A00523 SWITCH 1
SW26 K0F111A00523 SWITCH 1
SW27 K0F111A00523 SWITCH 1
SW28 K0F111A00523 SWITCH 1
SW29 K0F111A00523 SWITCH 1
SW30 K0F111A00523 SWITCH 1
SW31 K0F111A00523 SWITCH 1
SW32 K0F111A00523 SWITCH 1
SW33 K0F111A00523 SWITCH 1
SW34 K0F111A00523 SWITCH 1
SW35 K0F111A00523 SWITCH 1
SW36 K0F111A00523 SWITCH 1
SW37 K0F111A00523 SWITCH 1
SW38 K0F111A00523 SWITCH 1
SW39 K0F111A00523 SWITCH 1
SW40 K0F111A00523 SWITCH 1
SW41 K0F111A00523 SWITCH 1
SW42 K0F111A00523 SWITCH 1
SW43 K0F111A00523 SWITCH 1
SW44 K0F111A00523 SWITCH 1
SW45 K0F111A00523 SWITCH 1
SW46 K0F111A00523 SWITCH 1
SW47 K0F111A00523 SWITCH 1
SW48 K0F111A00523 SWITCH 1
SW49 K0F111A00523 SWITCH 1
SW50 K0F111A00523 SWITCH 1
SW51 K0F111A00526 SWITCH 1
SW52 K0F111A00524 SWITCH 1
SW53 K0F111A00524 SWITCH 1
SW54 K0F111A00487 SWITCH 1
SW55 K0F111A00487 SWITCH 1
SW56 K0F111A00487 SWITCH 1
SW57 K0F111A00487 SWITCH 1
SW58 K0F111A00487 SWITCH 1
SW59 K0F111A00487 SWITCH 1
SW60 K0F111A00487 SWITCH 1
SW61 K0F111A00487 SWITCH 1
SW62 K0F111A00491 SWITCH 1
SW63 K0F111A00489 SWITCH 1
SW64 K0F111A00488 SWITCH 1
SW65 K0F111A00490 SWITCH 1
SW66 K0F111A00491 SWITCH 1
SW67 K0F111A00491 SWITCH 1
SW68 K0F111A00490 SWITCH 1
SW69 K0F111A00491 SWITCH 1
SW70 K0F111A00490 SWITCH 1
SW71 K0F111A00490 SWITCH 1
SW72 K0F111A00491 SWITCH 1
SW73 K0F111A00487 SWITCH 1
SW74 K0F111A00487 SWITCH 1
SW75 K0F111A00487 SWITCH 1
SW76 K0F111A00490 SWITCH 1
SW77 K0F111A00487 SWITCH 1
SW78 K0F111A00487 SWITCH 1
SW79 K0F111A00487 SWITCH 1
SW80 K0F111A00487 SWITCH 1
SW81 K0F111A00487 SWITCH 1
SW82 K0F111A00487 SWITCH 1
SW83 K0F111A00490 SWITCH 1
SW84 K0F111A00490 SWITCH 1
SW85 K0F111A00490 SWITCH 1
SW86 K0D122A00067 SWITCH 1
SW100 K0D141A00002 SWITCH 1
SW401 K9AA01800001 SWITCH 1
SW402 K9AA01800001 SWITCH 1
SW403 K9AA01800001 SWITCH 1
TP701 D0YDR0000029 TEST POINT TERMINAL 1
TP702 D0YDR0000029 TEST POINT TERMINAL 1
TP703 D0YDR0000029 TEST POINT TERMINAL 1
VR1 D2BEA13B0005 V.RESISTOR 1
VR600 D2AAA13B0001 V.RESISTOR 1
VR601 D2BEA13B0005 V.RESISTOR 1
X400 H0J120500026 CRYSTAL OSCILLATOR 1
MISCELLANEOUS
K9ZZ00000595 LED SPACER(A) 11
K9ZZ00000653 LED SPACER(B) 36
L5DBBYY00006 LCD PANEL 1
