Panasonic KX-TGA750B User manual

Thank you for purchasing a Panasonic product.
Please read this installation manual before using the unit and
save it for future reference.
For assistance, visit our Web site:
http://www.panasonic.com/help
for customers in the U.S.A. or
Puerto Rico.
This unit is an additional handset compatible with the following
series of Panasonic Digital Cordless Phone:
KX-TG4011/KX-TG4021/KX-TG4031/KX-TG4051/
KX-TG6511/KX-TG6521/KX-TG6531/KX-TG6541/
KX-TG7531
Youmustregisterthishandset with yourbaseunit beforeitcan
be used. This installation manual describes only the steps
needed to register and begin using the handset. Please read
the base unit’s operating instructions for further details.
Charge the batteries for about 7 hours before initial use.
Additional Digital Cordless Handset
Model No. KX-TGA750
Installation Manual
PNQX2420ZA DC0110DY0 (A)
Printed in China
TGA750(e).fm Page 1 Thursday, January 7, 2010 3:48 PM

2For assistance, please visit http://www.panasonic.com/help
Accessory information
Supplied accessories
*1 The handset cover comes attached to the handset.
Note:
LPlease read the base unit’s operating instructions for additional/
replacement accessories.
– Optional headsets: KX-TCA60, KX-TCA93, KX-TCA94,
KX-TCA400, KX-TCA430
Setting up
Connections/Wall mounting
Accessory item/Order number Quantity
Charger/PNLC1012ZB 1
AC adaptor/PQLV219Y 1
Rechargeable batteries/HHR-4DPA
(Part No. HHR-55AAABU or N4DHYYY00004) 2
Handset cover*1/PNYNTGA652BR 1
Belt clip/PNKE1054Z1 1
Hooks
25.4 mm
(1 inch)
(120 V AC, 60 Hz)
Screws
(Not supplied)
TGA750(e).fm Page 2 Thursday, January 7, 2010 3:48 PM

For assistance, please visit http://www.panasonic.com/help 3
Note:
LUse only the supplied Panasonic AC adaptor PQLV219.
LThe AC adaptor must remain connected at all times. (It is normal for
the adaptor to feel warm during use.)
Battery installation/Battery charge
Important:
LUse the supplied rechargeable batteries. For replacement, we
recommend using the Panasonic rechargeable batteries noted on
page 2.
LWipe the battery ends (S, T) with a dry cloth.
LAvoid touching the battery ends (S, T) or the unit contacts.
LConfirm correct polarities (S, T).
LUSE ONLY Ni-MH batteries AAA (R03) size.
LDo NOT use Alkaline/Manganese/Ni-Cd batteries.
Charge for about 7 hours.
LWhen the batteries are fully charged, the charge indicator goes off and
“Fully charged”is displayed.
Note:
LIf the batteries are fully charged, but the operating time seems to be
shorter, clean the battery ends (S, T) and the charge contacts with a
dry cloth and charge again.
Charge indicator
Confirm
“Charging”
is displayed.
Rechargeable
Ni-MH ONLY
TGA750(e).fm Page 3 Thursday, January 7, 2010 3:48 PM

4For assistance, please visit http://www.panasonic.com/help
Panasonic Ni-MH battery performance (supplied batteries)
Controls
NControl type
ASoft keys
The handset features 2 soft keys and the center of the navigator
key. By pressing a soft key, or the center of the navigator key, you
can select the feature shown directly above it on the display.
Operation Operating time
In continuous use 13 hours max. (If Eco mode is on.)
Not in use (standby) 6 days max. (If Eco mode is on.)
ACharge indicator
Ringer indicator
Message indicator
BNonslip pad
LNonslip pad offers support
when you cradle the
handset between your
shoulder and ear.
CSpeaker
D{C} (TALK)
E{s} (SP-PHONE:
Speakerphone)
FHeadset jack
GDial keypad ({*}: TONE)
HReceiver
IDisplay
J{OFF}
K{FLASH}{CALL WAIT}
LMicrophone
MCharge contacts
B C
M
A
G
F
D
E
J
K
I
H
L
A
B
A
TGA750(e).fm Page 4 Thursday, January 7, 2010 3:48 PM

For assistance, please visit http://www.panasonic.com/help 5
BNavigator key
–{^}, {V}, {<}, or {>}: Scroll through various lists and items.
– VOL. (Volume: {^} or {V}): Adjust the receiver or speaker
volume while talking.
–{<}CID (Caller ID): View the caller list.
–{>}REDIAL: View the redial list.
Note:
LThe preset melodies used for the ringer tone in this product are used
with permission of © 2007 Copyrights Vision Inc.
For KX-TG4011/KX-TG4021 series users
NUsing the soft keys (operational differences between handsets)
KX-TGA750 features 3 soft keys, different to your original handset
which features keys with printed function names.
Press the soft key corresponding to the desired operation
(page 4: A).
Example: When selecting/setting the desired item in programming
LSome KX-TGA750 soft key names are different to the button names
described in your base unit’s operating instructions.
Registering a handset to a base unit
1Base unit:
NKX-TG4011/KX-TG6511 series
Press and hold {LOCATOR}for about 5 seconds. (No registration
tone)
NKX-TG4021/KX-TG4031/KX-TG4051/KX-TG6521/KX-TG6531/
KX-TG6541/KX-TG7531 series
Press and hold {LOCATOR}for about 5 seconds until the
registration tone sounds.
LIf all registered handsets start ringing, press the same button to
stop. Then repeat this step.
Original handset (printed key name) KX-TGA750 soft keys
{OK}{SELECT}{SAVE}
TGA750(e).fm Page 5 Thursday, January 7, 2010 3:48 PM

6For assistance, please visit http://www.panasonic.com/help
2Handset:
Place the handset on the base unit or charger, then wait until a long
beep sounds and wis displayed.
Note:
LIf an error tone sounds, or if _is displayed, register the handset
according to the base unit’s operating instructions.
Display language
1{MENU}i{#}{1}{1}{0}
2{V}/{^}: Select the desired setting.
3{SAVE}i{OFF}
Date and time
1{MENU}i{#}{1}{0}{1}iEnter the current month, date, and
year by selecting 2 digits for each. i{OK}
Example: For July 15, 2010, enter {0}{7}{1}{5}{1}{0}.:
2Enter the current hour and minute (12-hour clock format) by selecting
2 digits for each.
Example: For 9:30, enter {0}{9}{3}{0}.
3{AM/PM}: Select “AM”or “PM”. i{SAVE}i{OFF}
Belt clip
NTo attach NTo remove
TGA750(e).fm Page 6 Thursday, January 7, 2010 3:48 PM

For assistance, please visit http://www.panasonic.com/help 7
For KX-TG4031/KX-TG4051/KX-TG6511/
KX-TG6521/KX-TG6531/KX-TG6541
series users
There are some differences in the specification of your original handset
and the KX-TGA750. The feature differences are described in the chart
below.
Main feature differences
*1 KX-TG4031/KX-TG4051/KX-TG6521/KX-TG6531/KX-TG6541
series only
Operational differences in other features
NChanging group names in the shared phonebook
See “Changing group names” (page 11).
NEditing entries in the shared phonebook
See “Editing entries” (page 12).
Feature KX-TGA750 KX-TG4031/
KX-TG4051
series handset
KX-TG6511/
KX-TG6521/
KX-TG6531/
KX-TG6541
series handset
Display size 2.1 inches 1.8 inches 1.8 inches
Button size Large Extra large Large
Display mode
(page 8) r——
Message list
(page 9) r*1 ——
TGA750(e).fm Page 7 Thursday, January 7, 2010 3:48 PM

8For assistance, please visit http://www.panasonic.com/help
Features only available for KX-TGA750
Display mode
You can select to display either a single item or multiple items on one
screen at a time for the following features:
– handset main menu icons in function menu
– menu list, recorded message list, phonebook list, caller list, and redial
list
Select the desired setting:
–{MULTI}/“Multi items”: Multiple entries/all menu icons are shown
on one screen at a time.
–{SINGLE}/“Single item”: An entry/a menu icon is shown on one
screen in large characters at a time.
The default setting is “Multi items”.
NUsing soft key (Temporarily switching the display mode)
You can temporarily switch the display mode by pressing the right soft
key shown when viewing the lists or selecting menu icons.
NProgramming the display mode beforehand
1{MENU}i{#}{1}{9}{2}
2{V}/{^}: Select the desired setting. i{SAVE}i{OFF}
Note:
LWhen in multiple items display mode, you can move screens by
pressing {>}or {<}, without scrolling down or up through the list:
– Press {>}to go to the next screen.
– Press {<}to return to the previous screen.
LWhen in multiple items display mode, you can switch the screen to
confirm the detailed information by pressing {SINGLE}.
TGA750(e).fm Page 8 Thursday, January 7, 2010 3:48 PM

For assistance, please visit http://www.panasonic.com/help 9
Differences in the answering system operations
(KX-TG4021/KX-TG4031/KX-TG4051KX-TG6521/
KX-TG6531/KX-TG6541 series only)
Message list: Listening to messages from the message list
You can select the item to play back.
1{MENU}i{#}{3}{2}{9}
2{V}/{^}: Select the desired item from the message list. i{PLAY}
LYou can erase the selected message as follows: {ERASE}i
{V}/{^}: “Yes”i{SELECT}
3When finished, press {OFF}.
Note:
LIf the item has already been heard, “Q”is displayed, even if it was
heard using another handset.
LIf the unit cannot receive callerinformation, “Message”is displayed in
the message list.
LWhen you play a message from the message list, the playback
operations are as shown below:
– Ifyoupress {1}or{<},thecurrentlyplayingmessageisplayed back
from the beginning.
– If you press {2}or {>}, the unit stops message playback and the
display goes back to the message list.
TGA750(e).fm Page 9 Thursday, January 7, 2010 3:48 PM

10 For assistance, please visit http://www.panasonic.com/help
For KX-TG4011/KX-TG4021 series users
There are some differences in the specification of your original handset
and the KX-TGA750. The feature differences are described in the
following chart.
Main feature differences
*1 KX-TG4021 series only
Operational differences in other features
– Date and time (page 6)
– Chain dial (page 12)
– Voice guidance language (page 13)
– Selecting “Greeting only” (page 13)
– Calling back during playback (Caller ID subscribers only) (page 13)
Feature KX-TGA750 KX-TG4011/
KX-TG4021
series handset Page
Display size 2.1 inches 1.4 inches —
Phonebook settings
– Group
– All erase r— 11, 12
Message list r*1 —9
Message alert r— 13, 17
Display mode r—8
Alarm r—15
Silent mode r—15
Voice mail settings
– Voice mail access no.
– VM tone detection r—16
Time adjustment setting r—17
TGA750(e).fm Page 10 Thursday, January 7, 2010 3:48 PM
