Panasonic KX-HGT100-B User manual

Document Version 2008-08
Thank you for purchasing a SIP Telephone. Please read this
manual carefully before using this product and save this manual for
future use.
For more details, please refer to the manuals of the PBX.
Accessories (included)
*1 For AC adaptor (not included).
This model supports the following PBX version and CODEC
types:
KX-NCP500/KX-NCP1000: PBMPR Software File Version 1.0000 or later
KX-TDE600: PGMPR Software File Version 2.0000 or later
KX-TDE100/KX-TDE200: PMMPR Software File Version 2.0100 or later
CODEC: G.729A, G.711
Handset Handset Cord Ferrite Core*1
One One One
Quick Reference Guide
Model No. KX-HGT100
SIP Telephone

Location of Controls
2Document Version 2008-08
Location ofControls
I
K
L
M
A
GH
E
F
B
D
C
O
N
J

Location of Controls
Document Version 2008-08 3
ALCD (Liquid Crystal
Display)
BHeadset Jack
CPROGRAM/EXIT: Used to
enter and exit the personal
programming mode.
DCLEAR: Used to erase some
or all call logs, or clear digits
or characters.
EAUTO: Used for Speed
Dialing.
FHOLD*1: Used to place a call
on hold.
GREDIAL: Used to redial the
last 10 dialed numbers.
HMUTE: Used to mute the
microphone/handset/headset
during a conversation.
IMIC (Microphone):
Used for
hands-free conversations.
J SP-PHONE (Speakerphone) /
HEADSET
*1
: Used for
performing hands-free
operations. Also used to
make or answer calls if a
headset is connected.
KMESSAGE*1: Used to
access the Voice Mail
feature*2 or to call back the
party who left the message
waiting indication. The
indicator turns red in both
cases.
LTRANSFER: Used to
transfer a call to another
party.
MNavigator Key*3:Used to
adjust the volume and
display contrast, select
desired items, or view call
logs.
NINFORMATION: Used to
display your extension
number, the status of the
unit, and the network settings
on the LCD display.
OOK: Used to select the items.
Also used as end of dialing.
*1 These 3 indicators simultaneously flash red when you cannot make or
receive calls due to an error.
*2 Availability of this feature depends on your PBX. Consult your dealer.
*3 Press up or down while the unit is idle to access the outgoing, incoming,
and missing call logs.

Settings
4Document Version 2008-08
Settings
Initial Settings
You can program the following functions using the LCD display.
Note: = Confirmation Tone
*1 The date and time will be set automatically when the unit is connected to
a PBX that can update the time setting.
*2 You can configure the default setting to show or prevent showing your
telephone number when making an outside call. See page 6 to show or
prevent on a per call basis.
*3 The default language is English.
Program Settings
Save speed dial? See page 6.
Set date & time*1
While on-hook
My Caller ID*2
LCD contrast?
Ringer tone?
Ringer volume?
Set hold music?
Keytone volume?
Time AM/PM 24H
Change language?*3
While on-hook
C. Tone
year (2 digits)
Month.Day
(4 digits)
hour
(01-12)
hour
(13-00)
minute
(00-59)
minute
(00-59)
select
"AM/PM/
24H"
C. Tone
C. Tone

Settings
Document Version 2008-08 5
Speaker/Handset/Headset/Ringer Volume
*1 If you hear your own voice through the handset or headset, decrease the
volume.
Program Settings
Set network
For DHCP Setting
While on-hook
For STATIC IP Setting
While on-hook
Speaker volume
While in a hands-free
conversation
Press Up to
increase or Down to
decrease the
volume.
Handset/Headset
volume*1
While using the handset or
headset
Ringer volume While receiving a call
C. Tone
IP address
(12 digits)
subnet mask
(12 digits)
default gateway
(12 d
igits)
C. Tone

Features List
6Document Version 2008-08
Features List
Icon Meanings
= Off-hook = On-hook = Feature number
= Talk = Confirmation Tone
Making Calls
Calling
To an extension To an outside party
To temporarily change the default "My Caller ID" setting
To call back using the incoming call log
Redial
To redial the last number dialed
To redial using the outgoing call log
Speed Dialing
To store
To dial
C. Tone
extension no. outside phone no.
outside
phone no.
To show
To prevent (not show)
desired no.* (max. 32 digits)
*Enter CO line access number
before outside phone number.
speed dial no. (0-9)
C. Tone
speed dial no. (0-9)

Features List
Document Version 2008-08 7
During a Conversation
System Speed Dialing
To dial
Doorphone Call
Call Hold
To hold To retrieve a call at the holding extension
Call Transfer
system speed dial no. (3 digits)
doorphone no. (2 digits)
outside
phone no.
To an extension
To an outside
party
extension no.

Features List
8Document Version 2008-08
Making Use of the Voice Mail Service
Note: VPS = Voice Processing System
Listening to a message
While the MESSAGE indicator is red
* When the MESSAGE button is pressed, the latest recorded message may be
heard, or a call back may be performed directly, depending on the type of message.
From your own extension
* If you have no password, you can skip the
last step.
From someone else’s extension
* If you have no password, you can skip the
last step.
Mailbox Password*
VPS extension no.
End Call
KX-TVA series
KX-TVS series
Listen to Message
Deliver Message
Mailbox Management
Automated Attendant
Message Notification
Other Features
End Call
Listen to Message
Deliver Message
Check Mailbox Distribution
Automated Attendant
Mailbox Management
Other Features
mailbox no.
VPS extension no.
Mailbox Password*

Features List
Document Version 2008-08 9
•Consult your dealer or the network administrator for more details
regarding feature numbers.
•Control panel/button names and descriptions can be found in "Location
of Controls" on page 2.
Leaving a message
During playback
Repeat Voice Guidance
Exit
mailbox no.
From your own extension
From someone else’s extension
* If you have no password, you can skip the last step.
Enter the desired mailbox number Leave
a message
To send the message immediately
To set the delivery time
(KX-TVA series)
(KX-TVS series) Follow the guidance
VPS extension no.
Mailbox Password*
Mailbox Password*

Connection
10 Document Version 2008-08
Connection
7 cm
2- 3/4 in
AC adaptor
PC
LAN
To a Switching Hub.
To a PC.
AC adaptor (not included)
<Back view>
Headset (not included)
Recommended:
KX-TCA86, KX-TCA91, KX-TCA92
Do not use a KX-T7090 headset.
• For extra orders for the accessories,
call toll-free: 1-800-332-5368
Attach the ferrite core to the AC adaptor cord.
