Panasonic KX-TVP100E User manual

Voice Processing System
MODEL
KX-TVP100E
I
M
NSTALLATION
Please read this manual before connecting
the Voice Processing System.
ANUAL
Panasonic
TVP100
VOICE PROCESSING SYSTEM KX-TVP100

APPROVED for connection to
telecommunication systems
specified in the instructions for
use subject to the conditions set
out in them.
606168
i
Precaution
WARNING
THIS UNIT MAY ONLY BE INSTALLED AND SERVICED BY QUALIFIED
SERVICE PERSONNEL.
WHEN A FAILURE OCCURS WHICH RESULTS IN THE INTERNAL PARTS
BECOMING ACCESSIBLE, DISCONNECT THE POWER SUPPLY CORD
IMMEDIATELY AND RETURN THIS UNIT TO YOUR DEALER.
DISCONNECT THE TELECOM CONNECTION BEFORE DISCONNECTING
THE POWER CONNECTION PRIOR TO RELOCATING THE EQUIPMENT, AND
RECONNECT THE POWER FIRST.
THIS UNIT IS EQUIPPED WITH AN EARTHING CONTACT PLUG. FOR
SAFETY REASONS THIS PLUG MUST ONLY BE CONNECTED TO AN
EARTHING CONTACT SOCKET WHICH HAS BEEN INSTALLED
ACCORDING TO REGULATIONS.
THE POWER SOCKET WALL OUTLET SHOULD BE LOCATED NEAR THIS
EQUIPMENT AND BE EASILY ACCESSIBLE.
THE POWER CARD/MAINS PLUG IS USED AS THE DISCONNECT DEVICE.
NOTE • This Installation Manual does not show complete model numbers that indicate
the country where your models should be used. The model number of your unit
is found on the label affixed to the unit.
MODEL NO. – – – – – – – –
(label)
73/23/EEC
89/336/EEC
92/31/EEC
93/68/EEC

Precaution
ii
FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT
CAREFULLY.
This appliance is supplied with a moulded three pin mains plug for your safety and convenience.
A 5 amp fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 5 amps and
that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement cover is obtained.
A replacement fuse cover can be purchased from your local Panasonic Dealer.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME
THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED
INTO ANY 13 AMP SOCKET.
If a new plug is to be fitted please observe the wiring code as shown below.
If in any doubt please consult a qualified electrician.
WARNING : THIS APPLIANCE MUST BE EARTHED.
IMPORTANT : The wires in this mains lead are coloured in accordance with the following code:
Green-and-Yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wire in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows.
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which
is marked with the letter E or by the Earth symbol or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with
the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with
the letter L or coloured RED.

Precaution
iii
How to replace the fuse : Open the-fuse compartment with a screwdriver and replace the fuse and fuse
cover.
FUSE
IMPORTANT INFORMATION
Do not connect KX-TVP100E to any AC outlet other than the standard AC 230–240V, 50Hz.
Ringer Equivalence Number (REN):
This relates to the performance of the apparatus when used in combination with other items of apparatus. It enables the
calculation of the maximum number of items of apparatus that may be connected simultaneously to the line by
summing the REN values of each items. A BT supplied instrument has a REN value of 1 unless otherwise marked. A
maximum REN value of 4 should not be exceeded. The REN value of this apparatus is 3.
Connection:
EThe apparatus is suitable for connection to a direct exchange line on the PSTN or via a compatible PBX.
EThe apparatus is not suitable as an extension to a payphone and should not be used on lines with shared
services.
EIt cannot be guaranteed that the apparatus will operate under all possible conditions of connection to compatible
PBX's.
This apparatus has been approved for the use of the following facilities:
1) Voice Mail Service
2) Auto-calling
3) Auto-answering
4) Auto-clearing
5) PBX timed break register recall
6) MF signalling
7) LD signalling
Any other usage will invalidate the approval of the apparatus if as a result, it then ceases to conform to the standards
against which approval was granted.
Any cases of difficulty should be referred in the first instance to the supplier of the apparatus.

iv
• Keep the unit away from heating appliances and electrical noise generating devices
such as fluorescent lamps, motors and television. These noise sources can interfere
with the performance of the Voice Processing System.
• This unit should be kept free of dust, moisture, high temperature (more than 40˚C /
104˚F) and vibration, and should not be exposed to direct sunlight.
• Never attempt to insert wires, pins, etc. into the vents or other holes of this unit.
• If there is any trouble, disconnect the unit from the telephone line. Plug the
telephone directly into the telephone line. If the telephone operates properly, do not
reconnect the unit to the line until the trouble has been repaired by an authorized
Panasonic Factory Service Center. If the telephone does not operate properly,
chances are that the trouble is in the telephone system, and not in the unit.
• Do not use benzine, thinner, or the like, or any abrasive powder to clean the
cabinet. Wipe it with a soft cloth.
• Do not drop this unit to avoid the damage to the hard disk.
DATE OF PURCHASE
NAME OF DEALER
DEALER’S ADDRESS
Attention
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR ANY TYPE OF MOISTURE.
The serial number of this product may be found on the label affixed to the bottom
of the unit. You should note the serial number of this unit in the space provided
and retain this book as a permanent record of your purchase to aid in identification
in the event of theft.
MODEL NO.:
SERIAL NO.:
For your future reference
