Panasonic Noise Filter Array User manual

Circuit Components Business Unit / Panasonic Electronic Devices
Circuit Components Business Unit / Panasonic Electronic Devices Co., Ltd. Co., Ltd.
1
10
100
1000
1 10 100 1000
Frequency (MHz)
Impedance (Ω)
EXC28CE121U
EXC28CE900U
EXC28CE900U
EXC28CE121U
EXC28CE201U
EXC28CE201U
JAppearance JDimension
Smallest Size Common Mode Noise Filter Array
Unit: mm
0.20
±
0.15
0.5
±
0.1
0.5±0.1
2.0
±
0.2
1.0±0.15
0.25
±
0.1
JApplications
JSpecification
IEEE1394
connector
IEEE
Ctrl
IC
TPA-
TPA+
TPB-
TPB+
•IEEE1394 Data-Line Common Mode
Noise Filter Array
•LVDS Data-Line
TTL →LVDS LVDS →TTL
Data LVDS
PLL PLL
CLK
JImpedance (Typical)
Z
Z
Differential Mode
Common Mode
IEEE1394
IEEE1394
Speed Signal
S400
EXC28CE201U Competitor (200 ohm)
1.0
1.5
2.0
2.5
0 100 200 300 400 500
Time (ns)
Voltage (V)
1.0
1.5
2.0
2.5
0 100 200 300 400 500
Time (ns)
Voltage (V)
•Bit Error countermeasure
•Radiation noise suppression
JEffect in IEEE1394
Common Mode Noise Filter Array
EXC28CE900U 90 typ. 15 max. 5 160 1.5
EXC28CE121U 120 typ. 18 max. 5 140 2.0
EXC28CE201U 200 typ. 20 max. 5 130 2.5
Rated Rated DCR
Voltage Current (ohm)
Common Differential (V DC) (mA) max.
at 100MHz
Impedance(ohm)
Part
Number
Common Mode
Differential Mode
