Paradox Digiplex Liberator DGP-319 Assembly instructions

DGP-319
Installer’s Guide
Wireless Bus Module V1.0
I319EI01.fm Page 1 Wednesday, September 29, 1999 10:56 AM

1.0 TABLE OF CONTENTS
INTRODUCTION ...........................................................................5
1.1 Technical Specifications ...................................................................... 5
1.2 System Features ................................................................................. 5
INSTALLATION ............................................................................6
2.1 Location ...............................................................................................6
2.2 Connections and Mounting ................................................................. 6
PROGRAMMING ...........................................................................8
3.1 Entering Module Programming Mode ................................................. 8
3.1.1 Feature Select Programming ...........................................................9
3.2 Low Battery Supervision ..................................................................... 9
3.3 Check-in Supervision ......................................................................... 10
3.4 Tamper Supervision on Receiver Module .......................................... 10
3.5 PGM Deactivation Mode .................................................................... 11
3.6 PGM Base Time ................................................................................. 11
3.7 PGM Timers ....................................................................................... 12
3.8 PGM Activation Event ........................................................................12
3.9 PGM Deactivation Event .................................................................... 13
3.10 PGM Override ...................................................................................14
3.11 System Reset .................................................................................... 14
3.12 Viewing Unknown Serial Numbers .................................................... 15
DETECTORS AND CONTACT SWITCHES ................................16
4.1 Assigning Detectors & Contact Switches to Receiver ........................ 16
4.2 Assigning Detectors & Contact Switches to Zones ............................ 18
4.3 Viewing Signal Strength of Detectors & Contact Switches ................ 18
I319EI01.fm Page 3 Wednesday, September 29, 1999 10:56 AM

4 Installer’s Guide
REMOTE CONTROLS .................................................................19
5.1 Assigning Remote Controls to Receiver Module ............................... 20
5.2 Assigning Remote Controls to User Access Codes ...........................21
5.3 Programming Remote Control Buttons .............................................. 21
5.4 Replacing the Remote Control’s Battery ............................................ 26
PROGRAMMING GUIDE .............................................................27
PGM PROGRAMMING TABLE ...................................................32
I319EI01.fm Page 4 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 5
1.0 INTRODUCTION
1.1 TECHNICALSPECIFICATIONS
Manchester Decoding
Diversity Antenna
Error Detection & Correction
Frequency Hopping: @ 902 MHz - 928 MHz or 868MHz
Range: Detectors & Contact Switches:
1000 m (3280’) or 300 m (984’) for 868 MHz
Remote Controls: 30 m (100‘)
Data Rate: 10 KB/s
Sensitivity: -105dBm
Current: 70 mA
Dimension (without antenna) 15 cm H x 16 cm L x 3 cm W
(6” H x 6.5” L x 1.1” W)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Operating Humidity: 85%
PGM Outputs: 1 (an additional PGM Output is available)
PGM Output current: 5A relay
1.2 SYSTEMFEATURES
Add 16 wireless detectors or contact switches to the Digiplex System
Add 16 remote controls to the Digiplex System
Reflow Design
No tuned Circuit
Tamper Switch
Low Battery, Check-in, and Tamper supervision through Digiplex Control Panel
Trouble Display through Digiplex Control Panel
Signal Strength Indicator
I319EI01.fm Page 5 Wednesday, September 29, 1999 10:56 AM

6 Installer’s Guide
2.0 INSTALLATION
2.1 LOCATION
Mount the Liberator Wireless Bus Module on a wall allowing at least 5 cm (2")
around the module to permit adequate ventilation and heat dissipation. Select a site
that is not susceptible to drastic temperature changes. Avoid installation near or in
the path of strong RF fields (i.e. neon lights, computers), on or near metal objects,
circuit breaker boxes, air conditioners, and heater ducts since they may cause
interference and reduce its sensitivity. We recommend installing it in a centralized
location on the main floor. Avoid installing it in the basement. Refer to the Digiplex
Control Panel's Reference & Installation Manual for maximum allowable distances
between the control panel and the Liberator Wireless Bus Module.
2.2 CONNECTIONSAND MOUNTING
Firmly screw the two antennae into the connectors marked "ANT" on the Receiver
Module (see Figure 2-1). Using a drill or screwdriver, punch out the four mounting
holes on the back of the plastic case. Align the six holes of the printed circuit board
with the six pins on the back plastic mounting case and snap into place. If placed
correctly, the antennae will lean directly over the grooves in the mounting case.
Do not cut, bend, or alter the antennae. Avoid mounting the Receiver
Module near or on metal as this may affect its sensitivity.
The Liberator Wireless Bus Module is connected to the control panel's DIGI-BUS in
a star and/or daisy chain configuration. The DIGI-BUS is a 4-wire communication
bus that provides power and two-way communication between the control panel and
all the modules connected to it. Connect the “GRN” and “YEL” terminals from the
Receiver Module to the corresponding “GRN” and “YEL” terminals of the control
panel. Connect the “RED” terminal to the “AUX+” of the control panel. Connect the
“BLK” terminal to the “AUX-” of the control panel.
Remove AC power and then remove the battery before adding a bus
module to the system or it may cause communication trouble.
I319EI01.fm Page 6 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 7
Figure 2-1: Connections for Receiver Module to Control Panel
I319EI01.fm Page 7 Wednesday, September 29, 1999 10:56 AM

8 Installer’s Guide
3.0 PROGRAMMING
3.1 ENTERINGMODULEPROGRAMMINGMODE
All programming is done through Module Programming Mode in the Digiplex Control
Panel from any keypad as shown in Figure 3-1. The sections referred to in Step 5
and the data referred to in Step 6 from Figure 3-1 are explored in the following
sections of the manual.
Figure 3-1: Module Programming Mode
I319EI01.fm Page 8 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 9
3.1.1 Feature Select Programming
Feature Select Programming is accomplished by enabling and/or disabling
options. Feature Select Programming is used to program sections [001] and [002]
and is also used in PGM Programming. Within the sections, numbers from 1 to 8
represent a specific option to enable or disable. Press the key corresponding to
the desired option and the digit should appear on the LCD screen or illuminate the
corresponding LED on the LED Keypad. This means that the option is enabled or
ON. For example, in Step 6 of Figure 3-1, options [1] and [4] are enabled and
show on the LCD screen. The 1 and 4 LEDs would illuminate on the LED Keypad.
Press the key again to remove or extiguish the digit, thereby disabling (turning
OFF) the option.
3.2 LOWBATTERYSUPERVISION
SECTION[001]: OPTION[1]
The wireless detectors and contact switches function on two 3.6V Lithium batteries.
When a detector or contact switch detects a battery voltage of 6.5V or less, its
yellow light (LED) will flash and it will transmit a signal to the Liberator Wireless Bus
Module indicating that the voltage is low. If this option is enabled, the Receiver
Module will transmit a signal to the control panel, which it will recognize as a Zone
Low Battery. If this option is disabled, the Receiver Module will not transmit the low
voltage signal to the control panel.
From Step 6 in Figure 3-1, page8, enable or disable the option:
Option [1] OFF = Low Battery Supervision disabled
Option [1] ON = Low Battery Supervision enabled (default)
I319EI01.fm Page 9 Wednesday, September 29, 1999 10:56 AM

10 Installer’s Guide
3.3 CHECK-INSUPERVISION
SECTION[001]: OPTIONS[2] AND[3]
The Liberator Wireless Bus Module waits for each of its assigned detectors and/or
contact switches to send a status signal within a specified time period to confirm
their presence and functionality. If a device has not sent a signal within the time
period, the Receiver Module will automatically transmit a signal to the control panel,
which it can recognize a supervision loss. Option [2] enables the Check-in
Supervision feature and option [3] specifies the time period required for the devices
to send their signal.
From Step 6 in Figure 3-1, page8, enable or disable the options:
Option [2] OFF = Check-in Supervision disabled
Option [2] ON = Check-in Supervision enabled (default)
Option [3] OFF = Check-in every 12 hours (default)
Option [3] ON = Check-in every 12 minutes
3.4 TAMPERSUPERVISIONONRECEIVERMODULE
SECTION[001]: OPTION[4]
If this option is enabled and the Receiver Module's cover is removed, the on-board
tamper switch will be triggered. The Receiver Module will send a signal to the control
panel, which it will recognize as a Module Tamper.
From Step 6 in Figure 3-1, page8, enable or disable the option:
Option [4] OFF = Receiver Module's Tamper Supervision disabled (default)
Option [4] ON = Receiver Module's Tamper Supervision enabled
I319EI01.fm Page 10 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 11
3.5 PGM DEACTIVATIONMODE
SECTION[002]: OPTION[1] AND[5]
The Liberator Wireless Bus Module has one or two on-board PGMs. Each PGM can
be in Follow Mode or in Timed Mode. If the PGM is in Follow Mode, it will deactivate
according to its PGM Deactivation Event. If the PGM is in Timed Mode, it will
deactivate according to its PGM Timer. However, if PGM Override is enabled,
Follow Mode and Timed Mode will be ignored.
From Step 6 in Figure 3-1, page8, enable or disable the options:
Option [1] OFF = PGM 1 in Follow Mode
Option [1] ON = PGM 1 in Timed Mode (default)
Option [5] OFF = PGM 2 in Follow Mode
Option [5] ON = PGM 2 in Timed Mode (default)
Ensure that both the PGM Activation Event and PGM Deactivation Event
are programmed for each PGM for Follow Mode to function properly.
3.6 PGM BASE TIME
SECTION[002]: OPTION[2] AND[6]
These options define the Base Time of the PGM Timers when the PGM is inTimed Mode.
From Step 6 in Figure 3-1, page8, enable or disable the options:
Option [2] OFF = PGM 1 Base Time is 1 second (default)
Option [2] ON = PGM 1 Base Time is 1 minute
Option [6] OFF = PGM 2 Base Time is 1 second (default)
Option [6] ON = PGM 2 Base Time is 1 minute
I319EI01.fm Page 11 Wednesday, September 29, 1999 10:56 AM

12 Installer’s Guide
3.7 PGM TIMERS
SECTIONS[003] AND[004]
When PGM(s) are in Timed Mode, the value programmed for PGM 1 in section [003]
and for PGM 2 in section [004] are multiplied by the PGM Base Time. This value can
be any decimal from 001 to 255. This defines the time period the PGM(s) will remain
activated unless the PGM Override is enabled. (Default 005)
From Step 5 in Figure 3-1, page8:
3.8 PGM ACTIVATIONEVENT
SECTIONS[005] AND[007]
The PGM Activation Events determine which events will activate the Liberator
Wireless Bus Module's one or two on-board PGMs. If other PGM(s) on other
modules or the control panel are programmed with the same PGM Activation Event
as the Receiver Module, those PGM(s) will also be activated when the event occurs.
For details on the available activation events, refer to the PGM Programming Table
(see section 7.0 of this manual).
Both the PGM Activation Event and PGM Deactivation Event must be
programmed for the PGM(s) in Follow Mode to function properly.
From Step 5 in Figure 3-1, page8:
PGM 1: enter section [005]
PGM 2: enter section [007]
Timer PGM 1: Timer PGM 2:
1) Enter section [003] 1) Enter section [004]
2) Enter value (001 to 255) 2) Enter value (001 to 255)
I319EI01.fm Page 12 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 13
Use the PGM Programming Table to program a PGM Activation Event by following
these steps:
1) In the selected section, enter the first digit where each digit is a hexadecimal
value from 8 to F that represents a specific event (0 = PGM Disabled).
2) Then enter the second digit, which can be any hexadecimal value from 0 to F
depending on the first digit chosen.
3) After entering the second digit, use Feature Select Programming to enable/
disable options [1] to [8]. Select up to eight specific events as detailed in the
PGM Programming Table.
These keys represent the hexadecimal values from A to F:
[STAY] = A [DISARM] = D
[FORCE] = B [BYP] = E
[ARM] = C [MEM] = F
For installations using the LED Keypads, the hexadecimal values will
illuminate the following LEDs:
(A) = [STAY] LED (D) = [A4] LED
(B) = [FORCE] LED (E) = [BYP] LED
(C) = [A1] LED (F) = [MEM] LED
3.9 PGM DEACTIVATIONEVENT
SECTIONS[006] AND[008]
When PGM Activation Events occur, the Liberator Wireless Bus Module's on-board
PGM(s) will deactivate when the events programmed in section [006] for PGM 1 or
in section [008] for PGM 2 occur unless it is in PGM Timed Mode. The PGM
Deactivation Event is programmed in the same manner as the PGM Activation
Event (see section 3.8 of this manual).
I319EI01.fm Page 13 Wednesday, September 29, 1999 10:56 AM

14 Installer’s Guide
3.10 PGM OVERRIDE
SECTION[002]: OPTIONS[3] AND[7], [4] AND[8]
When the PGM Override is enabled in options [3] and/or [7], the Liberator Wireless
Bus Module will ignore the PGM Mode, PGM Activation Events, PGM Deactivation
Events, and PGM Timers of the corresponding PGM(s). Enabling and disabling
options [4] and [8] controls whether each PGM is activated or deactivated once
PGM Override is enabled.
From Step 6 in Figure 3-1, page8, enable or disable the options:
Option [3] OFF = PGM 1 Override disabled (default)
Option [3] ON = PGM 1 Override enabled
Option [4] OFF = PGM 1 deactivated (default)
Option [4] ON = PGM 1 activated
Option [7] OFF = PGM 2 Override disabled (default)
Option [7] ON = PGM 2 Override enabled
Option [8] OFF = PGM 2 deactivated (default)
Option [8] ON = PGM 2 activated
3.11 SYSTEMRESET
Performing a system reset will erase all the sections in the Liberator Wireless Bus
Module's programming and set the following sections to their defaults:
Sections:
[001] = Options 1 and 2 ON; options 3 to 8 OFF
[002] = Options 1 and 5 ON; options 2, 3, 4, 6, 7, and 8 OFF
[003] = 005 (seconds)
[004] = 005 (seconds)
I319EI01.fm Page 14 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 15
To perform the system reset:
1) Disconnect the DIGI-BUS from the Receiver Module
2) Place the reset jumper on both reset pins on the Receiver Module.
3) Reconnect the DIGI-BUS to the Receiver Module
4) Wait until the "Locate" LED is off (takes about 4 seconds)
5) Remove the jumper
The module can also be reset using the Module Reset feature in the Digiplex Control
Panel (see Digiplex Control Panel's Reference & Installation Manual).
3.12 VIEWINGUNKNOWNSERIALNUMBERS
SECTION[025]
The serial number of a detector, contact switch, or remote control can be displayed.
From Step 5 in Figure 3-1, page8:
1) Enter section [025]
2) On LCD Screen: Press and hold the tamper switch on the detector or contact switch
or press and hold the remote's A and B buttons simultaneously until the keypad
squawks and the device's serial number appears on the LCD screen under the words
"View Data".
On LED Screen: Press and hold the tamper switch on the detector or contact switch
or press and hold the remote's A and B buttons simultaneously until the keypad
squawks. The first number of the device's serial number will illuminate (10 = zero).
Press the button to view each subsequent number. When you press the
button on the last number of the serial number, the control panel will exit the section.
I319EI01.fm Page 15 Wednesday, September 29, 1999 10:56 AM

16 Installer’s Guide
4.0 DETECTORS AND CONTACT SWITCHES
Programming for the wireless detectors and the contact switches is accomplished in
three steps:
1) Detectors and contact switches must be assigned to the Liberator Wireless Bus
Module.
2) The detectors and contact switches from the Liberator Wireless Bus Module must
be assigned to zones in the Digiplex Control Panel.
3) The zone parameters must be defined in the Digiplex Control Panel.
For more details concerning zones, refer to the Digiplex Control Panel's Reference
& Installation Manual.
Complete the Programming Guide (see section 6.0 of this manual) while
assigning the detectors and contact switches. The serial numbers and the
inputs that they are assigned to will be needed when programming the
zones in the control panel.
Sections [020], [021], [101] to [116],and [201] to [216] are all interrelated.
For example, when assigning a detector or contact switch to the Receiver Module:
1) The serial number and input number will be assigned in section [101]
2) The number of devices will automatically appear in section [020]
3) Its signal strength can be viewed in section [201]
4.1ASSIGNINGDETECTORS& CONTACTSWITCHES TORECEIVER
In these sections you will assign the detectors and contact switches to the Liberator
Wireless Bus Module. Up to 16 detectors or contact switches can be assigned to
each Receiver Module.
I319EI01.fm Page 16 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 17
SECTIONS[101] TO[116]
Enter the serial numbers of the detectors and contact switches in the sections [101]
to [116]. The serial numbers can be found inside the devices. Inputs 001 to 016 are
automatically assigned when the serial number is entered. For example, Section
[101] is assigned to input 001, Section [102] is assigned to input 002, etc,. When
one section is programmed, the keypad will automatically switch to the next section.
From Step 5 in Figure 3-1, page8:
1) Enter the desired section from [101] to [116]
2) Enter the serial number of the detector or contact switch
If you are unable to find the serial number, refer to section 3.12 of this
manual.
SECTIONS[020] AND[021]
The number of devices assigned to sections [101] to [108] can be viewed in section
[020]. The number of devices assigned to sections [109] to [116] can be viewed in
section [021].
In section [021] devices assigned to sections [109] to [116] appear as 1
through 8. For example, the device assigned to section [109] would appear
as 1 in section [021].
I319EI01.fm Page 17 Wednesday, September 29, 1999 10:56 AM

18 Installer’s Guide
4.2 ASSIGNINGDETECTORS& CONTACTSWITCHES TOZONES
Once the detectors and the contact switches have been assigned to the Liberator
Wireless Bus Module, they must be assigned to zones in the control panel. For
instructions how to assign the devices to the zones and then program the zones,
refer to the Digiplex Control Panel's Reference & Installation Manual.
Zones assigned to detectors or contact switches cannot be
programmed as Fire Zones.
4.3 VIEWINGSIGNALSTRENGTHOFDETECTORS& CONTACTSWITCHES
SECTIONS[201] TO[216]
Once the detectors and/or contact switches have been installed and assigned to the
Liberator Wireless Bus Module, the average signal strength of each device can be
verified in these sections. Each section represents the signal strength viewer for a
specific device. For example, section [201] is the viewer for the device in section
[101] and section [216] is the viewer for the device in section [116].
From Step 5 in Figure 3-1, page8, enter a section from [201] to [216] to view the
average strength of each device.
For installations using the LCD Keypads:
The signal strength is represented by one to ten characters that will appear on the
LCD screen below the words "Signal Strgh". The reading (number of characters) will
appear beside the characters.Three characters or less is a very weak signal and the
device should be moved. An average reading above four characters is acceptable.
For installation using the LED Keypads:
The signal strength is represented by the illumination of the numerical LEDs from
LED 1 to LED 10. A reading from LED 1 to LED 3 is a very weak signal and the
device should be moved. An average reading above LED 4 is acceptable.
I319EI01.fm Page 18 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 19
5.0 REMOTE CONTROLS
To program the remote controls:
1) Remote controls must be assigned to the Liberator Wireless Bus Module
2) The remote controls from the Liberator Wireless Bus Module must be assigned to
User Access Codes in the Digiplex Control Panel.
3) The buttons on the remote controls must be programmed
Complete the Programming Guide (see section 6.0 of this manual) while
assigning the remote controls. The serial numbers will be needed when
assigning the remote controls to User Access Codes. Also, knowing which
User Access Code was assigned to which remote control may affect how
the remote's buttons are programmed.
Sections [030],[031],[301] to [316],[401] to [416],and [501] to [516] are all
interrelated.
For example, when assigning a remote control to the Receiver Module:
1) The serial number will be entered in section [301]
2) It will automatically appear in section [030]
3) It is assigned to a User Access Code in section [401]
4) Its buttons are programmed in section [501]
When using the remote controls, users must press the button(s) until the red
LED on the remote control illuminates. This short delay (0.25 sec.) before
sending a signal is to avoid accidental transmissions. After pressing and
holding a button continuously for five seconds, the remote control will no
longer transmit any signals until the button is released and pressed again.
I319EI01.fm Page 19 Wednesday, September 29, 1999 10:56 AM

20 Installer’s Guide
5.1 ASSIGNINGREMOTECONTROLSTORECEIVERMODULE
In these sections you will assign the remote controls to the Receiver Module. Up to
16 remote controls can be assigned to each Receiver Module.
SECTION[301] TO[316]
Enter the serial numbers from the remote controls in the sections [301] to [316].
When one section is programmed, the keypad will automatically switch to the next
section.
If you are unable to find the serial number, refer to section 3.12 of this
manual.
From Step 5 in Figure 3-1, page8:
1) Enter a section from [301] to [316]
2) Enter the serial number of the remote control
SECTIONS[030] AND[031]
The number of remote controls assigned to the Receiver Module can be viewed in
sections [030] and [031]. The remotes assigned in [301] to [308] will appear in
section [030] and the remotes assigned in [309] to [316] will appear in section[031].
In section [031] remote controls assigned in [309] to [316] appear as 1
through 8. For example, the remote assigned in [309] would appear as 1 in
section [031].
I319EI01.fm Page 20 Wednesday, September 29, 1999 10:56 AM

Digiplex Liberator 21
5.2 ASSIGNINGREMOTECONTROLSTOUSERACCESS CODES
SECTIONS[401] TO[416]
Each remote control must be assigned to a User Access Code. All User Access
Codes are given a User Number from 01 to 64 (01 is the System Master Code).
Each section from [401] to [416] represents the remote control assigned to sections
[301] to [316] (see section 5.1 of this manual). For example, the remote assigned in
section [301] will be assigned to theUser Access Code designated in section [401].
From Step 5 in Figure 3-1, page8:
1) Enter a section from [401] to [416]
2) Enter the User Number (01 to 64) to be assigned to the remote control.
5.3 PROGRAMMINGREMOTECONTROLBUTTONS
SECTIONS[501] TO[516]
For each remote control, each button or a combination of the buttons pressed
simultaneously can be programmed to send a signal to the control panel to perform
certain actions as if users had gone to a keypad and entered their User Access
Codes. When a user arms or disarms using the remote, the control panel will arm or
disarm all the areas assigned to the User Access Code. For example, you arm with
a remote control whose User Access Code is assigned to areas 1 and 3, the control
panel will attempt to arm areas 1 and 3.
Each section from [501] to [516] represents the remote control assigned to the
sections [301] to [316] (see section 5.1 of this manual). For example, the buttons for
the remote control assigned in section [301] will be programmed in section [501].
I319EI01.fm Page 21 Wednesday, September 29, 1999 10:56 AM
