ZX82
8-Zone Input
Expansion Module
Installation Manual
V1.10 and higher
Introduction
The ZX82, 8-zone Expansion Module, provides 8 zones input expansion to
Paradox panels; connects on the keypad bus of EVO, Spectra, or MG
panels. The ZX82 comes with its own tamper-proof enclosure and provides
Zone Status LED indicators as well as Power and Data.
Compatibility
• All Paradox control panels v6.80 or higher
• BabyWare v5.1 and higher
• Infield v5.1 and higher
Connections
Connect the four bus terminals labeled + - GRN YEL of the module to the
corresponding terminals on the control panel as shown.
To enable anti-tamper switch input on EVO, use input terminal Z8 and enable
section
[001] option [1] .
To enable anti-tamper switch input on MG/SP, use input terminal Z1 and enable
section
[706] option [4] for panel +1, option [5] for panel +9 and option [6] for
panel +17.
Upgrading Firmware
The ZX82’s firmware can be upgraded in Infield via BabyWare using a
307USB Direct Connect Interface.
LED Indicators
*If control panel has an AC Loss all LEDs are turned off.
Technical Specifications
* Control Panel shall be certified to EN 50131-6 and used as the power supply
for the expansion module. If an external power supply is used, it must be
certified for EN 50131-6.
The security grade of the ZX82 is dependent on the security grade of the
system where it is installed. The maximum security grade is 3.
External Anti-Tamper
Switch (N.C.)
LED OFF ON
POWER OFF OK (10.5V to 16V)
RX / TX No clock or data
exchange
Clock and data OK
ZONE1 to ZONE8* Zone Closed Zone Opened /
Ta m p e r
ATZ Enabled on EVO
ZONE1 to ZONE8
Both zones connected
to this input are Closed
Any Zone connected
to this input is
Opened / Tamper
Input Voltage 10.5 to 16 Vdc
Current Consumption 100mA MAX all LEDs On
Number of Inputs 8 standard zone inputs
Operating Temperature -20 C to +50 C (-4 F to 122 F)
Humidity 95% maximum
Dimensions (H x W x D) 16.5 cm x 10.2 cm x 2.5 cm
(6.5 in x 4 in x 1 in)
Certification*
CE, EN 50131-3 Security Grade: 3
Environmental Class: II
Certification Body: Applica Test and
Certification AS
Display
Power
Lock
Data

ZX82-EI02 01/2019 PARADOX.COM
Programming EVO
1. Enter section [4003].
2. Enter the eight-digit module serial number.
3. Enter the three-digit module section number.
Module Tamper on Input-8
Section 001 - Bit 1, 0 = Disabled, 1 = Enabled
Note: If this option is enable the on-board tamper is disabled.
EOL/ATZ per Zone Input
Section 401 - Zone Input Options
Zone Input Options Individual Settings
EOL Resistor Value Selection
Section 402 - Zone Input Options
Zone Input Options Individual Settings
Programming MG/SP
1. Enter section [001] - [032].
2. Enter the two-digit zone definition.
3. Assign a partition.
4. Select or deselect zone options.
5. Press Enter.
6. Repeat steps 1 - 5 for remaining zones.
For more information on how to program zones, please refer to the MG/SP
Programming Guide.
Module Tamper on Input-1
Section 706 - Panel Programming
Note: If this option is enable the on-board tamper is disabled.
MG/SP Jumper Settings (Panel ATZ Off)
MG/SP Jumper Settings (Panel ATZ On)
Zone1 / Zone2 Zone3 / Zone4 Zone5 / Zone6 Zone7 / Zone8
_ / _
(0/0)
_ / _
(0/0)
_ / _
(0/0)
_ / _
(0/0)
OPTION DESCRIPTION
0System default; zone will follow global panel settings for EOL
1 EOL / ATZ disabled
2 EOL enabled / ATZ disabled
3 EOL disabled / ATZ enabled
4 EOL / ATZ enabled
Zone1 / Zone2 Zone 3 / Zone4 Zone5 / Zone6 Zone7 / Zone8
_ / _
(0/0)
_ / _
(0/0)
_ / _
(0/0)
_ / _
(0/0)
OPTION EOL Value Zone Value
01K 1K
12K2 1K5
23K3 3K3
34K7 4K7
44K7 6K8
52K2 4K7
68K2 8K2
72K2 2K2
Option Description Off ON
4ZX82 ID A (panel +1) Input 1 Zone input Tamper input
5ZX82 ID B (panel + 9) Input 1 Zone input Tamper input
6ZX82 ID C (panel + 17) Input 1 Zone input Tamper input
Module #
(Jumper) MG5000 MG5050 SP4000 SP5500 SP6000 SP65 SP7000
[phone]-16 10-17 17-24
[phone]-21 17-24 18-25 25-32
[phone]-29 25-32 26-32 N/A
Module #
(Jumper) MG5000 MG5050 SP4000 SP5500 SP6000 SP65 SP7000
[phone] 17-24 19-26 N/A
[phone]-26 25-32 27-32 N/A
[phone] 27-32 N/A N/A N/A
Warranty
For complete warranty information on this product, please refer to the Limited Warranty Statement
found on paradox.com/terms or contact your local distributor. Specifications may change without prior
notice.
