Paradox Digiplex DGP-641 User manual

DGP-641 LCD Keypad (V1.3)
DGP-641ACC Access Control LCD Keypad
(V1.1)
Reference and Installation Manual

Digiplex LCD Keypad 1n
TABLE OF CONTENTS
1.0 Introduction....................................................... 4
1.1 SPECIFICATIONS........................................................ 5
2.0 Installation......................................................... 6
2.1 CONNECTINGTHEKEYPAD ........................................ 6
2.2 CONNECTINGKEYPAD ZONES.................................... 6
2.3 PROGRAMMABLEOUTPUT......................................... 7
3.0 Programming ................................................. 11
3.1 ENTERMODULEPROGRAMMINGMODE.................... 11
3.2 PROGRAMMINGMETHODS....................................... 12
3.2.1 Feature Select Programming ................................... 12
3.2.2 Decimal Programming .............................................. 12
3.3 MODULEBROADCAST............................................. 12
4.0 System Options .............................................. 14
4.1 PARTITIONASSIGNMENT.......................................... 14
4.2 DISPLAYCODEENTRY............................................ 14
4.3 DISPLAYEXITDELAYTIMER.................................... 14
4.4 DISPLAYENTRYDELAYTIMER................................ 15
4.5 CONFIDENTIALMODE.............................................. 15
4.6 MUTING.................................................................. 16
4.7 BEEP ONEXITDELAY.............................................. 17
4.8 CHIMEONZONECLOSURE...................................... 17

2 Installer’s Guide
4.9 BEEP ONTROUBLE.................................................. 17
4.10 KEYPAD TAMPERENABLE..................................... 18
5.0 Features For DGP-641 Only........................... 19
5.1 CONFIDENTIALMODETIMER.................................... 19
5.2 PGM STATE............................................................ 19
5.3 PGM ACTIVATIONEVENT........................................ 20
5.4 PGM DEACTIVATIONEVENT.................................... 20
5.5 PGM TIMEDMODE.................................................. 21
5.6 PGM TIMER............................................................ 21
5.7 PGM BASE TIME..................................................... 21
5.8 PGM OVERRIDE...................................................... 22
6.0 Features For DGP-641ACC Only................... 23
6.1 BUSVOLTMETER..................................................... 23
6.2 ASSIGNINGDOORSTOPARTITIONS.......................... 23
6.3 READER’SOPTIONS................................................. 24
6.3.1 Reader’s LED To Follow Partition’s Status ............ 24
6.3.2 Reader’s Beep To Follow Partition's Status........... 24
6.3.3 Reader's LED Options Upon Access Granted........ 25
6.4 DOORLOCK OPTIONS.............................................. 25
6.4.1 Unlock on REX (Request For Exit) .......................... 25
6.4.2 Door Unlocked Period .............................................. 25
6.4.3 Door Unlocked Period Extension ............................ 26
6.4.4 Relock Interval........................................................... 26
6.4.5 Door Unlocked Schedule.......................................... 26
6.4.6 Card Activates Door Unlocked Schedule ............... 27

Digiplex LCD Keypad 3n
6.5 DOORLEFT OPENOPTIONS.................................... 28
6.5.1 Door Left Open Access Alarm ................................. 28
6.5.2 Door Left Open Interval Before Access Alarm....... 29
6.5.3 Door Left Open Pre-Alarm........................................ 29
6.5.4 Door Left Open Pre-Alarm Timer ............................. 29
6.5.5 Door Left Open Alarm Feedback ............................. 30
6.5.6 Beep Timer For Door Left Open Alarm ................... 31
6.6 DOORFORCEDOPENOPTIONS............................... 31
6.6.1 Door Forced Open Access Alarm ............................ 31
6.6.2 Door Forced Open Feedback................................... 32
6.6.3 Beep Timer For Door Forced Open Alarm .............. 32
7.0 Message Programming .................................. 33
8.0 Glossary .......................................................... 36

4 Installer’s Guide
1.0 INTRODUCTION
Thank you for choosing Paradox®Security Systems. The Digiplex™
Security System is an advanced technology security system that will
provide reliable security protection and powerful features that are
easy to use. The elegant and user-friendly Digiplex™ LCD Keypad
will allow easy access to the security system's functions and
information at the touch of a button. Since all programming is
accomplished through the keypad, please read this manual carefully.
As well as normal security system functions, the Digiplex Access
Control Keypad (DGP-641ACC) can also be used for access
control. Access Control is designed to monitor and control the
access for up to 32 designated doors without the need of an
additional control panel. The events that occur on an Access
Control door can be logged in the control panel’s Event Buffer,
but can only be viewed through an Access Control Keypad.
Each door to become an Access Control door requires an
Access Control Keypad (DGP-641ACC), a reader (suggestion:
Posiprox CR-R880), a REX device (suggestion: Paradoor 460), a
door contact, and a locking device.
If desired, door contacts can also be assigned to zones in the
control panel to link the doors to the Digiplex Alarm system. This
will allow you to use the same door for the Access Control
system and the alarm system. Only two of the Access Control
features require that the Access Control door's door contact be
assigned to a zone: Burglar Alarm on Forced Door in section
[537] option [5] and Access to Armed Access Control Doors in
sections [802] to [896], fourth screen, option [8].

Digiplex LCD Keypad 5n
1.1 SPECIFICATIONS
Power input: 9-16 VDC, 80mA maximum
PGM current limit: 50 mA
Number of inputs: 1 (DGP-641)
2 (DGP-641ACC)
Power indication: Yellow LED on
Locate indication: Green and yellow LEDs flash simultaneously
Bus fault indication: Red and yellow LEDs flash alternately
Tamper Switch: Yes (also used to deactivate locate)
LCD: Super Twisted Nematic display (STN), wide
viewing angle, 2 lines of 16 characters, backlight
and contrast adjustable
Compatibility:
DGP-641: Any Digiplex Control Panel
DGP-641ACC: DGP-48 Control Panel for Access Control
V2.20ACC and higher

6 Installer’s Guide
2.0 INSTALLATION
2.1 CONNECTINGTHEKEYPAD
The Digiplex™ LCD keypads (DGP-641 and DGP-641ACC) are
connected to the control panel's bus in a star and/or daisy chain
configuration. This 4-wire communication bus provides power
and two-way communication between the control panel and all
modules connected to it. Connect the four terminals labeled red,
black, green and yellow of each keypad to the corresponding
terminals on the control panel (refer to Figure 1on page8).
Refer to the Digiplex Control Panel's Reference & Installation
Manual for the maximum allowable installation distance from the
control panel.
See Figure 4on page10 for connection drawings for the REX
device, reader, locking device and door contact to the desired
DGP-641ACC keypad. A typical installation is shown in Figure
2on page9.
The door contact follows the control panel’s EOL
definition. When EOL is enabled and the door contact is
not used, place a 1k ΩΩ resistor across the keypad’s Z1
and BLK input terminals. If EOL is not enabled, use a
jumper. If the REX device is not used, place a jumper
across the keypad’s Z2 and BLK input terminals.
2.2 CONNECTINGKEYPAD ZONES
Each keypad has one traditional hardwired input terminal,
allowing you to connect one detector or door contact directly to

Digiplex LCD Keypad 7n
the keypad. For example, a door contact located at the entry
point of an establishment can be wired directly to the input
terminal of the entry point keypad instead of wiring the door
contact all the way to the control panel.
Connect the device to the keypad's input terminal as shown in
Figure 1on page8. In order to communicate its status to the
control panel, devices connected to the keypad's input terminal
must be assigned to a zone in the control panel and the zone's
parameters must be defined. For more information on zone
assignment, please refer to the Digiplex Control Panel's
Reference & Installation Manual. Please note that even with the
ATZ (zone doubling) feature enabled, the keypad supports only
one detection device.
2.3 PROGRAMMABLEOUTPUT
Each keypad has one on-board PGM. A PGM is a programmable
output that toggles to its opposite state (i.e. a normally open
PGM will close) when a specific event has occurred in the
system (see section 5.0 on page19). Upon activation, the PGM
can provide 50mA to any device connected to it. If the current
drawn is to exceed the current limit, a relay should be connected
to the PGM as shown in Figure 1. With the DGP-641ACC
keypad, the PGM is reserved for the door lock (refer to Figure
4on page10).

8 Installer’s Guide
Figure 1: Connecting the Keypad and Keypad Zone

Digiplex LCD Keypad 9n
Figure 2: Typical Access Control Installation (DGP-641ACC)
Figure 3: Access Control Overview (DGP-641ACC Only)

10 Installer’s Guide
Figure 4: Access Control Connections (DGP-641ACC Only)

Digiplex LCD Keypad 11n
3.0 PROGRAMMING
Programming the DGP-641 or DGP-641ACC LCD keypads is
simple. Enter the “Module Programming Mode”, enter the
desired section followed by the required data. When
programming the keypad, use the keypad’s Programming Guide
to keep track of which sections were programmed and how. We
strongly recommend you read this entire manual before you
begin programming.
The LCD keypad can also be programmed using the WinLoad
Security System Management Software. For more information,
refer to the WinLoad instructions or visit our web site at
www.paradox.ca.
3.1 ENTERMODULEPROGRAMMINGMODE
The keypad, like all other modules in the Digiplex system, is
programmed through the control panel. To do so, you must first
enter the “Module Programming Mode”:
Step 1: From Normal Mode press and hold the [0] key.
Step 2: Enter the [INSTALLERCODE](by default 000000)
Step 3: Enter section [953]
Step 4: Enter the keypad’s 8-digit [SERIALNUMBER].
Step 5: Enter the 3-digit [SECTION] you want to program.
Step 6: Enter the required [DATA].
The control panel will then redirect all programming to the
selected keypad. Every time the [CLEAR]key is pressed it will
revert to the preceding step, unless entering in data in which
case it will erase the current data entry. Please note that the

12 Installer’s Guide
serial number is located on the keypad's PC board or enter
section [000] in Step 3 to view the keypad’s serial number.
3.2 PROGRAMMINGMETHODS
3.2.1 Feature Select Programming
Program sections [001] to [005] by enabling or disabling options.
Within the sections, numbers from [1] to [8] represent a specific
keypad option. Press the key corresponding to the desired option
and the digit will appear in the display. This means the option is
enabled. Press the key again to remove the digit from the display
thereby disabling the option. Press [ENTER]when options are set.
3.2.2 Decimal Programming
Sections [006] and [007] are programmed using “Decimal
Programming”. In this method, any digit from 000 to 255 can be
entered.
3.3 MODULEBROADCAST
The Digiplex Control Panel’s Module Broadcast feature can be
used to copy the contents of one keypad to one or many other
keypads.
Step 1: From Normal Mode press and hold the [0] key.
Step 2: Enter [INSTALLERCODE].
Step 3: Enter section [954].
Step 4: Enter the [SERIAL#] of the source keypad. Thesource is the
programmed keypad whose data you want to copy to other
keypads.
Step 5: Enter the [SERIAL#] of the destination keypads. The
destination is the keypad(s) you want to program with the

Digiplex LCD Keypad 13n
source’s data. If you want to program more than one keypad
with the source’s data, enter the serial numbers of the
keypads one at a time.
Step 6: Once you have entered the serial numbers of the keypads
you want to program, press the[ACC] key.

14 Installer’s Guide
4.0 SYSTEM OPTIONS
4.1 PARTITIONASSIGNMENT
Section 001: Options [1] to [4]
Each keypad in the Digiplex system can be assigned to one or
more partitions. In section [001], options [1] to [4] represent
partitions 1 through 4 respectively. To assign the keypad to a
partition, simply enable the option that corresponds to the
desired partition. Therefore, the keypad would be assigned to
partitions 1 and 4 only. (By default, partition 1 to partition 4 are
enabled.)
4.2 DISPLAYCODEENTRY
Section 002: Option [1]
The digits of the User Access Codes can be displayed on the
LCD screen when they are entered.
Option[1] OFF= Digits are replaced by a *. (default)
Option[1] ON = Access Code digits will be displayed.
4.3 DISPLAYEXITDELAYTIMER
Section 002: Option [2]
Based on the user's needs, an Exit Delay Timer will be
programmed to provide the user time to exit the partition before
the system is armed. The Exit Delay Timer's countdown can be
displayed on the LCD screen.

Digiplex LCD Keypad 15n
Option [2] OFF= Will not display Exit Delay timer (default)
Option [2] ON = LCD screen will display Exit Delay timer
4.4 DISPLAYENTRYDELAYTIMER
Section 002: Option [3]
Based on the user's needs, an Entry Delay Timer will be
programmed to provide the user time to enter their User Access
Code before the alarm is triggered. The Entry Delay Timer's
countdown can be displayed on the LCD screen.
Option [3] OFF= Will not display the Entry Delay Timer (default)
Option [3] ON = LCD screen will display Entry Delay Timer
4.5 CONFIDENTIALMODE
Section 002: Option [4] and [5]
If the Confidential Mode is enabled and no actions are performed
on the keypad for a period of time, the LCD screen will appear as
shown in Figure 5 (page16) and the “AC” and “STATUS” LED will be
off until either a button is pressed or an access code is entered. For
the DGP-641 keypad, the period of time in which no action is
performed is defined by the Confidential Mode Timer (005-255
seconds; refer to section 5.1 on page19). For the DGP-641ACC
keypad, the period of time in which no action is performed is set at 2
minutes. Confidential Mode is activated by enabling option [4].
Option [5] regulates whether the LCD screen will be activated at the
touch of a button or only when an access code is entered.
Once the LCD screen is activated (by code or button), Normal
Mode will appear and display the date and time as shown in
Figure 5on page16. The status of the areas, the open zones for

16 Installer’s Guide
every area the keypad is assigned, the Alarm Memory Display if
necessary, and the Trouble Display if necessary (see Digiplex
User Manual) will also scroll on the LCD screen.
Section [002]:
Option[4] OFF= Normal Mode (default)
Option [4] ON = Confidential Mode
Option [5] OFF= LCD screen activated by entering an access code
(default)
Option [5] ON = LCD screen activated by pressing a button
Figure 5: LCD Screen
4.6 MUTING
Section 003: Option [1]
The keypad can be programmed not to emit audible sounds,
including Chimed zones. During Muting, the keypad will only
emit the Confirmation Beep, Rejection Beep, and beep when a
button is pressed.
Option[1] OFF= Audible sounds (default)
Option [1] ON = Mute

Digiplex LCD Keypad 17n
4.7 BEEP ONEXITDELAY
Section 003: Option [2]
The keypad can beep once every second during the Exit Delay
Timer. During the final 10 seconds, it will beep more rapidly to
provide a final warning before the area is armed.
Option [2] OFF= Exit Delay beep disabled
Option [2] ON = Exit Delay beep enabled (default)
4.8 CHIMEONZONECLOSURE
Section 003: Option [4]
During the Chime Zone Time Period that the user sets, the
keypad can emit an intermittent beep whenever a zone with the
Chime feature enabled closes (see Digiplex User Manual for
details on Chime Zones). If the user does not set the Chime
Zone Time Period and this option is enabled, the Chime Zones
will always beep upon closure.
Option [4] OFF= Chime on Zone Closure disabled (default)
Option [4] ON = Chime on Zone Closure enabled
4.9 BEEP ONTROUBLE
Section 004: Options [1] to [4]
Potential troubles have been sorted into groups. With these options
enabled, the keypad will emit an intermittent beep tone whenever a
trouble condition from the Trouble Groups occurs in the system. The
intermittent beep will remain activated until the user enters the
Trouble Display or if the trouble is resolved. For a list of the troubles,

18 Installer’s Guide
see the Digiplex Control Panel’s Reference and Installation Manual.
The intermittent beep will be re-initialized whenever the trouble
condition re-occurs.
Option [1] OFF= Beep disabled: System Troubles and Clock Loss
(default)
Option[1] ON = Beep enabled: System Troubles and Clock Loss
Option[2] OFF= Beep disabled: Communicator Troubles (default)
Option[2] ON = Beep enabled: Communicator Troubles
Option[3] OFF= Beep disabled: Module and Bus Troubles (default)
Option[3] ON = Beep enabled: Module and Bus Troubles
Option [4] OFF= Beep disabled: all Zone Troubles (default)
Option[4] ON = Beep enabled: all Zone Troubles
4.10 KEYPAD TAMPERENABLE
Section 005: Option [5]
When Tamper is enabled and the keypad's on-board tamper
switch is triggered, the keypad will send a Tamper report to the
control panel via the communication bus.
Option[5] OFF= Keypad's Tamper is disabled (default)
Option[5] ON = Keypad's Tamper is enabled
