Installation and Assembly
Desktop Swivel Mount
Model: HP432-002, HP432-002-S, HP432-002-GB
Max Load Capacity: 80 lbs (36.3 kg)

ISSUED: 8-29-07 SHEET #: 124-9102-3 08-13-08
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
2 of 5
Note: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List.................................................................................................................................................................. 3
InstallationtoDesktop .............................................................................................................................................. 4
InstallingTubeAssembly .......................................................................................................................................... 4
InstallingScreen ....................................................................................................................................................... 5
Forcustomerservicecall(800)865-2112 or(708)865-8870.
• Donot begin to install your Peerless product until you have read and understood the instructionsandwarnings
containedin this Installation Sheet. If you have any questions regarding any of theinstructionsor warnings, please
callPeerless customer careat 1-800-865-2112.
• Thisproduct should only be installed bya qualified professional.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardwareandcomponents.
• Neverexceedthe Maximum Load Capacity of 80 lbs (36.3 kg).
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly, but do notovertighten. Overtightening can damage theitems, greatly reducing their holding
power.
WARNING

ISSUED: 8-29-07 SHEET #: 124-9102-3 08-13-08
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
3 of 5
Parts List HP432-002 HP432-002-GB HP432-002-S
Description QTY. Part #
Aadapter plate 1 095-1322 095-P1322 095-4322
Badapter box 1 124-1794 124-P1794 124-4794
Cswivel tube 1 124-1792 124-P1792 124-4792
Dbase tube 1 124-1796 124-P1796 124-4796
Ebushing 2 590-1088 590-1088 590-1088
FM5 x 6 mm socket pin screw 4 520-1114 520-1114 520-2062
G1/4-20 x 1/2" socket pin screw 2 520-1054 520-1054 520-2069
HM8 x 25 mm socket pin screw 2 520-1101 520-1101 520-2184
IM4 x 10 mm socket pin screw 4 520-1060 520-1060 520-2060
JM4 x 20 mm socket pin screw 4 520-1061 520-1061 520-2163
KM6 x 12 mm socket pin screw 4 520-1050 520-1050 520-2050
LM6 x 20 mm socket pin screw 4 520-9554 520-9554 520-2554
MM6 x 30 mm socket pin screw 4 520-1067 520-1067 520-2067
N1/4-20 x 1" socket pin screw 4 520-1053 520-1053 520-2588
O1/4-20 T-nut 4 530-9301 530-9301 530-2301
P4 mm security allen wrench 1 560-9646 560-9646 560-9646
E
P
F
B
CD
GH
J
K
LMNO
A
Note: Read entire instruction sheet before you start installation and assembly.
I

ISSUED: 8-29-07 SHEET #: 124-9102-3 08-13-08
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
4 of 5
Determinemount position on desktop and using
the base tube (D) as a template, mark and drill
four5/16" diameter holes through desktop.
Place base tube on desktop and secure using
four 1/4-20 x 1" socket pin screws (N) and four
T-nuts(O).
Note: The holes on base tube (D) will face the back of
the desktop.
Insertswivel tube (C) into base tube (D), adjust
swiveltubeto desired height and secure using
two 1/4-20 x 1/2" socket pin screws (G).
Insert two bushings (E) into the two holes on
adapter box (B) as shown. Placeadapter box (B) onto swivel tube (C) and
secure using two M8 x 25 mm socket pin screws
(H). Be sure that screws (H) are positioned into
the slots in the swivel tube (C) and are fully
tightened.
Note: Narrowendofkeyhole slot faces toward bottom.
N
D
O
C
D
G
E
B
E
B
H
C
CAUTION
•Installations to desktops that have a gap between two supporting boards are not acceptable mounting surfaces for the HP line of
desktop swivel mounts.

ISSUED: 8-29-07 SHEET #: 124-9102-3 08-13-08
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
5 of 5
Identify hole pattern on back of screen.
Note: Desktop mount only supports screens with a VESA 100, VESA 200 and VESA 400 hole pattern.
FORVESA®100 MOUNTING PATTERN:
Threadfourscrews (I or J) into screen leaving 1/8" exposed thread as shown in figure 5.1.
Hook screen onto keyhole slots of adapter box (B), then fasten four screws (I or J) through the back of adapter box into
adapterplate as shown in figure 5.2.
FOR VESA®200 and VESA®400 MOUNTING PATTERN:
Attach adapter plate to screen using four screws (K, Lor M). Thread four M5 x 6 mm screws (F) into adapter plate
leaving1/8"exposed thread as shown in figure 5.3.
Hook screen onto keyhole slots of adapter box (B), then fasten four screws (F) through the back of adapter box into
adapterplate as shown in figure 5.4.
• If screws don't get three complete turns in the screen inserts or if screws bottom out and bracket is still not tightly
secured, damage may occur to screen or product may fail.
WARNING
fig. 5.1 fig. 5.2
fig. 5.3 fig. 5.4
1/8"SPACE
I or J
TIGHTEN
FASTENERS
THROUGH
BACK HOLES
1/8"SPACE
A
K, L or M
F
F
TIGHTEN
FASTENERS
THROUGH
BACK HOLES
B
I or J
