Perlesmith PSCM2 User manual

Installation Instruction
V1.0
PSCM2
Telephone：[phone] Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：[email protected] (US/CA/DE/UK/FR/IT/ES/JP/AU)
Thank you for choosing our product! We strive to provide the best
quality and services for our customers. Would you kindly share your
experience on Amazon if you are satisfied? Should you have any issues,
please don't hesitate to contact us.

IMPORTANT SAFETY INFORMATION
Tools Needed (Not lncluded)
Supplied Parts
Stud Finder Tape measure Pencil Drill
7/32 in.(5.5mm)
Wood Drill
25/64 in.(10mm)
Concrete Drill Screw Driver
Hammer
1 PC1 PC1 PC
1 PC
1 PC
2 PCS
1
[1] [2]
[4] [5]
[6]
1 PC
[7]
[3]
xx x x
PSCM2
ceiling mount
•Check package contents against Supplied Parts and Hardware Lists to assure that all
components were received undamaged. Do not use damaged or defective parts.lf you
require replacement parts, contact customer service at [email protected]
•Not all parts and hardware included will be used.
•Carefully read all instructions before attempting installation.If you do not understand
the instructions or have any concerns or questions, please contact customer service at
[email protected]
•This product may contain moving parts. Use with caution.
•Do not use this product for any purpose or in any configuration not explicitly specified
in this instruction. We hereby disclaims any liability for injury or damage arising from
incorrect assembly, incorrect mounting, or incorrect use of this product.
•DO NOT INSTALL INTO DRYWALL ALONE.
•Please check www.perlesmith.com for more products and company information.

M6x10mm M622x6.4x2 M6X55mm M6X60mm
Supplied Hardware
Hardware for Attaching TV Bracket to TV
Washers
M8
x4
A2
Spacers
L10mm
x8
Philips Screws
M6 x 15mm
M6 x 45mm
x4x4
D1 D2
Philips Screws
M8 x 15mm
M8 x 45mm
x4
x4
E1 E2
B2
Spacers
L5mm
x8
x2
x4
x7 x2 x1x2
C
Washers
M6
x11
B1
Hardware for Attaching Wall Plate to Wall
CAUTION!
M8X65
Lag Bolts
x4
A3
x4
A1
Wall
Anchor
Philips Screws
M4 x 30mm
F
x4
These anchors
are for concrete
or brickwalls
ONLY. DO NOT
use them in
drywall or wood
studs.
a
f
b c d e
2
Plastic Washer
16x6.4x1.5
x4
h
M6 Bolt
x1
g
Allen Wrench
5x5

STEP1
STEP 2A Wood Stud Option
WARNING:
WARNING:
Ensure the U Bracket [2] is securely fastened to the Ceiling
before continuing on to the next step.
Avoid potential personal injury or property damage! All lag
bolts [A1] MUST BE firmly tightened to prevent unwanted
movement of the
U Bracket [2] .X
STEP 2 Attach U Bracket [2] to the Ceiling
For wood stud installation, follow STEP 2A
For concrete installation, follow STEP 2B
3
Attach the U bracket [2] to Tube [5]
aba
b
ceg
B1
[5]
[2]

65mm
5.5mm
A1
A2
STEP 2A Wood Stud Option
WARNING:
Avoid potential personal injuries and property damage!
●
Anything covering the ceiling must not exceed 5/8 in. (16 mm)
● Nominal wood stud size: common 2 x 4 in. (51 x 102 mm) minimum
1½ x 3½ in. (38 x 89 mm)
● Stud center must be verified
4
[5]
[2]
7/32 in.(5.5mm)
Wood Drill
[7]

STEP 2B Solid Concrete or Concrete Block Option
Avoid potential personal injury or property damage! All lag bolts [A1]
MUST BE firmly tightened to prevent unwanted movement of the U
Bracket [2].
WARNING:
Wall
Anchor
A3
WARNING:
Ensure the U Bracket [2] is securely fastened to the
ceiling before continuing on to the next step.
WARNING:
● Anything covering the ceiling must not exceed 5/8 in. (16 mm)
● Mount the U Bracket [2] directly onto the concrete surface
● Minimum solid concrete thickness: 203 mm (8 in.)
● Minimum concrete block size: 203 x 203 x 406 mm (8 x 8 x 16 in.)
5
25/64 in.(10mm)
Concrete Drill
[7]

70mm
10mm
A1
A3
A2
STEP 4 Attach the connector [3] to the TV Plate [1]
6
[5]
[2]
A3
c
h
B1
f
[1]
[3]

Step 6 Before TV Bracket Installation
Manual Only!
Measure the distance between the holes located at the back of
your TV (these measures may form the shape of a square,or a
rectangle) and check that these taken measures are within the
VESA(*)range for this wall mount.
(*)VESA:International standard established by the TV
manufacturers used to determine if LCD/LED TVs are
compatible with wall mounts.
Hand thread screws into the threaded inserts
on the back of your TV to determine which
screw diameter (M4, M6, or M8) to use.
When attaching brackets [4] to the flat screen,be careful not to over tighten screws
and be sure that screws do not bottom out in the mounting holes.
Too Short Too Long Correct Correct
STEP 5
7
Attach the TV plate
assembly to the tube
[6],then connecet with U
bracket assembly
[1] [3]
[6]
c
B1 dg
200 mm ≈ 7 7/8 in
400 mm ≈ 15 3/4 in
100 mm ≈ 4 in
300 mm ≈ 11 3/4 in

Step 7 Attach Brackets [4] to TV
D1
B1
E1
or
F/D2
B1
B2/C
E2
B2/C
For TV with a curved back or obstruction
8
For TV with a flat back
[4]
[4]
or

locking
Step 8 HEAVY! You will Need Assistance with this Step
9
