Petsafe Drinkwell MINI-EU-45 User manual

MINI-EU-45
Lemmikin Mini –juomalähde - 1,2 litraa
Mini drickfontän för husdjur - 1,2 liter
Mini vannautomat til kjæledyr - 1,2 liter
Vandpost til mini-kæledyr - 1,2 Liter
Мини-поилка для домашних животных - 1,2 литра
Mini Pet Fountain - 1.2 Litres
.
Käyttöopas
Bruksanvisning
Bruksanvisning
Betjeningsvejledning
Пособие по эксплуатации
Operating Guide
Lue tämä opas kokonaan ennen kuin aloitat
Läs hela handboken innan du använder apparaten
Les hele bruksanvisningen før du starter
Læs hele denne vejledning for brug
Перед началом эксплуатации полностью прочтите данное пособие
Please read this entire guide before beginning

www.petsafe.net 32www.petsafe.net
FIDA SVRU NOEN
IMPORTANT SAFETY INFORMATION
Explanation of Attention Words and Symbols used in this guide
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION, used without the safety alert symbol, indicates a
hazardous situation which, if not avoided, could result in harm to
your pet.
NOTICE is used to address safe use practices not related to
personal injury.
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and/or injury to persons,
including the following:
• To reduce the risk of injury, close supervision is necessary when an appliance is used
by or near children.
• To protect against electric shock, do not place electrical Power Cord or plug in water
or other liquids.
• Do not use outdoors. FOR INDOOR HOUSEHOLD USE ONLY.
• Do not pull on the electrical Power Cord to remove the plug from the electrical outlet.
To unplug, grasp the plug, not the electrical Power Cord.
• Do not operate any appliance if it has a damaged electrical Power Cord or plug, or
if it is malfunctioning or has been damaged. Call Customer Care Centre immediately
for further instructions.
• For a portable appliance - To reduce the risk of electric shock, do not place or store
an appliance where it can fall or be pulled into a bath tub or sink.
• Always unplug any appliance when not in use, before putting on or taking off parts
and before cleaning.
• Do not use an appliance for anything other than its intended use.
• If the plug of this device gets wet, turn off the electricity to that electrical outlet. Do not
attempt to unplug.
• Examine this appliance after installation. Do not plug into electrical outlet if there is
water on the electrical Power Cord or plug.
.

www.petsafe.net 3
SV RUNO ENFI DA
• Do not allow pets to chew on or swallow any parts. If you are concerned about the
electrical Power Cord, purchase a cord conduit (a hard plastic protector) at any
hardware store.
• The plastic Pet Fountain parts are BPA-FREE. However, some animals have been
known to be sensitive to plastic food and water containers. If your animal shows signs
of an allergic reaction to the plastic, please discontinue use until you have consulted
with your veterinarian.
• The Pet Fountain is intended to run continuously (always plugged into an electrical
outlet), as long as the water level is maintained and the Pet Fountain is cleaned
regularly. Be sure to check the Pet Fountain regularly to help prevent damage to the
Pump, as the water may get consumed or evaporate causing the Pump to run dry.
• Do not attempt repairs on the Pump.
• To avoid the possibility of the plug or electrical outlet getting wet, the electrical outlet
should always be above the level of the Pet Fountain.
• If an extension cord is necessary, an extension cord with a proper rating should
beused.
• The electrical use of this appliance is 2 watts.
• The use of attachments not recommended or sold by the manufacturer may cause an
unsafe condition. Do not modify the appliance.
• Do not install or store appliance where it will be exposed to weather or temperatures
below 4.5° C.
• Read and observe all important notices listed on the appliance and in the packaging.
SAVE THESE INSTRUCTIONS
.

www.petsafe.net 54www.petsafe.net
FIDA SVRU NOEN
Thank you for choosing the PetSafe®brand. You and your pet deserve a companionship
that includes memorable moments and a shared understanding together. Our products
promote a lifestyle of protection, teaching and love; essentials that influence memories for
a lifetime. If you have any questions about our products, please visit our
website at www.petsafe.net or contact our Customer Care Centre.
To get the most protection out of your warranty, please register your product within 30
days at www.petsafe.net. By registering and keeping your receipt, you will enjoy the
product’s full warranty and should you ever need to call the Customer Care Centre,
we will be able to help you faster. Most importantly, your valuable information will
never be given or sold to anyone. Complete warranty information is available online at
www.petsafe.net.
Table of Contents
Components................................................................ 5
Features ................................................................... 5
Key Definitions .............................................................. 6
Operating Instructions ........................................................ 7
Pet Fountain Disassembly & Cleaning ........................................... 8
Pump Maintenance .......................................................... 9
Pet Fountain Reassembly..................................................... 10
The Pet Fountain and Your Environment ..........................................11
General Tips............................................................... 12
Warranty ................................................................. 12
Compliance ............................................................... 13
Important Recycling Advice .................................................. 14
Terms of Use and Limitation of Liability ......................................... 14
.

www.petsafe.net 5
SV RUNO ENFI DA
Components
Features
Housing
Bowl
Housing
Lid
Pump
with Flow
Control Knob
Charcoal Filter
Pre-Filter
In-line Plug/
Power Cord
Low-Voltage (12V) System
Adjustable flow control
Replaceable
Charcoal Filter
removes bad tastes
& odours
Free-falling water stream
encourages pets to drink
more water
1.2 L Water Capacity
Receiving ramp
reduces splash Submersible
pump for nearly
silent operation
Pre-Filter
.

www.petsafe.net 76www.petsafe.net
FIDA SVRU NOEN
Key Definitions
Housing: Water is pumped up through the Housing to cycle through the Charcoal Filter
and out the spout to create a waterfall into the Bowl.
Housing Lid: The Housing Lid snaps in place over the Housing, keeping pets out of the
Charcoal Filter.
Charcoal Filter: The 3-layer Charcoal Filter is made with granulated carbon derived
from coconut shells. The Charcoal Filter absorbs bad tastes and odours as the water
passes through and helps keep the water tasting fresh and more appealing to pets.
Bowl: The Bowl is the foundation of the Pet Fountain. It houses the Pump and has a Power
Cord “Pass-through” to hide the electrical Power Cord from view.
Pre-Filter: The small intake grate that catches large particles such as hair, debris and
kibble before they reach the Charcoal Filter. The Pre-Filter can be removed by pulling up
on the lip at the top. To replace, slide back into place over the Flow Control Knob and
push down until it clamps around the knob.
Flow Control Knob: The black knob attaches to the Faceplate and adjusts the rate of
water flow. The Pre-Filter will snap around the neck of the Flow Control Knob which will
lock it into place.
Pump: The small submersible aquarium Pump can be dismantled for cleaning. THE
PUMP IS NOT DISHWASHER SAFE! Remove Pump from Pet Fountain before cleaning
(see “Pump Maintenance” section for detailed instructions). The Pump also features a
removable In-Line Plug for easy attachment and removal.
.

www.petsafe.net 7
SV RUNO ENFI DA
Operating Instructions
Important: DO NOT RUN DRY - FOR INDOOR USE ONLY. Pet Fountain will come
fully assembled and ready for use.
1. As with any electrical device, check the electrical Power Cord for any tears or
damage before use.
2. Make sure the In-Line Plug is fully connected. When connected properly the silver tip
is not showing.
3. Remove the Housing Lid by placing your index fingers into the inset grooves on either
side of the Housing Lid. Lift up. Set the Housing Lid aside.
4. Insert the Charcoal Filter into the Housing. The Charcoal
Filter will fit into the two triangular slots located on the
right side of the Housing. The Charcoal Filter fits narrow
side down and the white side faces the front of the Pet
Fountain (Fig. 1). The Charcoal Filter will slide easily
into place, but make sure it is pushed all the way down.
Important: Rinse the Charcoal Filter thoroughly under
cool water before placing in the Pet Fountain. This will
remove any loose charcoal dust, which is harmless. A small
amount of charcoal dust may be released for the life of the
Charcoal Filter. This is normal and not harmful to your pet.
5. Fill the Pet Fountain with water. This includes the Bowl and the Housing. This will prime
the Pump.
6. Replace the Housing Lid and snap it into place.
7. Place Pet Fountain in desired location. Do not pick up a full Pet Fountain by the
Housing. Important: To protect your floor always use a protective mat such as a
towel or water-resistant placemat. This will help protect your floor from splashing or
spills caused by your pet.
8. Before you plug in the Pet Fountain, make sure the electrical Power Cord, the plug and
your hands are dry. Plug the Pet Fountain into a standard electrical wall outlet.
9. Set the desired flow rate with the Flow Control Knob, which is located to the right of
the receiving ramp. When the Flow Control Knob is in
the 10 o’clock position, flow is at its lowest. When the
Flow Control Knob is in the 2 o’clock position, flow is
at its highest (Fig. 2).
10. Add water as needed to the Bowl and Reservoir. Do
not let the water level fall lower than the Flow Control
Knob or you may risk Pump failure. Replacement
Pumps are sold separately by contacting the Customer
Care Centre. Visit www.petsafe.net for a telephone
listing of the Customer Care Centre near you.
Fig. 1
Fig. 2
MIN MAX
.

www.petsafe.net 98www.petsafe.net
FIDA SVRU NOEN
Pet Fountain Disassembly & Cleaning
Important: Pet Fountain must be cleaned to continue working normally.
CHARCOAL FILTER: The Charcoal Filter should be changed every two to four weeks.
1. Replace Charcoal Filter more frequently when using the Pet Fountain for multiple pets
or pets that produce a lot of saliva.
2. The Charcoal Filter is an added feature of the Pet Fountain. The use of a filter is not
required for normal operation, but using a filter will keep the Pet Fountain water
cleaner.
3. The Charcoal Filter may be rinsed out when the Pet Fountain is cleaned. Do not wash
with soapy water, as you will not be able to remove the soap residue.
PET FOUNTAIN Clean the Pet Fountain once a week.
1. Unplug the Pet Fountain and disconnect the In-Line Plug.
2. Remove Housing lid and the Charcoal Filter.
3. Empty the water out of the Pet Fountain.
4. Remove the Pre-Filter by gently pulling up on the top lip of the
Pre-Filter and wash with soap and water (Fig. 3).
5. Remove the Housing by gently pushing in on either side of the
Pet Fountain where the curve meets the seam. Gently lift up
(Fig. 4 & 5). You will notice the right side of the Housing will
offer some resistance as the water Intake Tube pulls away
from the Pump.
6. Remove the Pump from its cavity by placing your index finger behind Pump and
gripping the bottom with your thumb (Fig. 6).
Fig. 3
Fig. 5Fig. 4
Fig. 6
Pump
.

www.petsafe.net 9
SV RUNO ENFI DA
7. Lift the Pump straight up – this may require slight force until the suction cups release.
8. Pull the In-Line Plug up through the Cord Pass-Through located to the left of the
Pump(Fig. 7).
9. Once the Pet Fountain is completely
disassembled you will have 4 plastic parts.
10. Clean the Pet Fountain plastic parts with warm
water and soap. You can also put the Pet
Fountain in the top rack of the dishwasher.
Remove the pump before placing the Pet
Fountain in the dishwasher. NEVER PLACE
PUMP IN DISHWASHER! If possible, it is recommended that you turn down the
heat of the water inside the dishwasher. The Pet Fountain may also be cleaned with
a diluted vinegar solution (20% white vinegar and 80% water). Be sure to rinse
thouroughly with fresh water.
11 . If you have trouble reaching certain spots or getting hard-to-reach corners, try using a
cotton swab or puchase a Drinkwell®Cleaning Kit, a 3-piece Brush Kit. To purchase
a Cleaning Kit, visit our website at www.petsafe.net to locate a retailer near you or to
find a listing of Customer Care Centre telephone numbers for your area.
Pump Maintenance
Important: Cleaning the Pump is essential to the longevity of the Pet Fountain, as well
as the cleanliness of the water. Clean the Pump every two weeks. Warranty may be
voided if the Pump’s motor is not cleaned.
1. Remove the Pre-Filter and Housing from the Bowl.
2. Remove the Pump from the Pet Fountain as explained in the “Pet Fountain Disassembly
and Cleaning” section.
3. Once the Pump is out of the Pet
Fountain, with your thumb and
forefinger, gently squeeze on either
side of the Faceplate, and pull it
off. It may be necessary to insert
a fingernail into the seam of the
Faceplate to pry it off (Fig.8-9).
Cord
Pass-Through
Fig. 7
Pump Impeller Intake Plate Faceplate with
Flow Control Knob
Fig. 8 Fig. 9
.

www.petsafe.net 1110 www.petsafe.net
FIDA SVRU NOEN
4. Remove the Intake Plate by placing your fingernail underneath the small lip
located on the narrow side of the teardrop-shaped Intake Plate Pull-Tab and pull it
out(Fig.10-11).
5. Once the Intake Plate is removed, you can also
remove the Impeller (white, 3-bladed propeller)
which is held in place magnetically. To remove the
Impeller, use a fingernail to get underneath a blade
and lift out (Fig. 12).
6. Once the Pump is disassembled you can clean
the parts with warm water and soap. Use a cotton
swab or the “motor” brush from the Drinkwell®
Cleaning Kit to get into the Pump’s motor cavity
and remove any build-up (Fig. 13). For added
disinfecting and hard water removal, clean the
Pump witha diluted vinegar solution (20% white
vinegar and 80% water).
7. Once the parts are clean you can reassemble the
Pump for use.
a) Replace the Impeller.
b)Replace the Intake Plate.
c) Replace the Faceplate with the Flow Control Knob.
Pet Fountain Reassembly
1. R eplace the Pump into its location between the four posts on the right side of the Pet
Fountain Bowl. Gently push down on Pump to engage the suction
cups(Fig. 14 & 15).
Intake Plate
Pull-Tab
Fig. 10 Fig. 11
Fig. 12
Fig. 13
Fig. 14 Fig. 15
Pump
.
