PHD OPTIMAX OSW Series Manual

6441-701
1
NOTES:
1) ASSUMES USE OF AT LEAST 75% OF FULL THREAD DEPTH
2) ASSUMES USE OF HIGH STRENGTH STEEL SOCKET HEAD CAP SCREWS
3) PHD RECOMMENDS USE OF THREADLOCKER ON MOUNTING THREADS
SWITCH CIRCUIT TYPE
86727-0
SOLID STATE
SOURCE/PNP
86726-0
SOLID STATE
SINK/NPN
86725-0
REED SWITCH
BODY MOUNTING
2X THRU & C’BORE THIS SIDE
2X THREAD OPPOSITE
4X TABLE THREADS
EXTEND PORT
RETRACT PORT 2X TOOL
PLATE
THREADS
BLK
BRN
BLU
LOAD
SWITCH
DC
DC
REED DC 5-30V. 50mA
MODEL:
1 BRN
3 BLU
BRN
BLU
LOAD
SWITCH
DC
DC
86725 - 0
QUICK
CONNECT
BLK
BRN
BLU
LOAD
SWITCH
DC
DC
4
BLK
NPN SOLID STATE DC 5-30V. 50mA
MODEL:
1 BRN
3 BLU
86726 - 0
QUICK
CONNECT
4
BLK
PNP SOLID STATE DC 5-30V. 50mA
MODEL:
1 BRN
3 BLU
86727 - 0
QUICK
CONNECT
SERIES OSW SLIDE START-UP PROCEDURE
SWITCH BRACKET AND SWITCH INSTALLATION
1) Failure to connect switches per appropriate diagram may
result in permanent switch damage
2) Slide switch into top or bottom slots as shown
3) Adjust location until switch indicates proper tool plate location
4) Secure switch by tightening mounting screw - DO NOT OVER
TIGHTEN
WIRING SCHEMATIC
SLIDE START-UP PROCEDURES
1) Securely mount unit and attach tooling (see table below)
2) Install external flow controls
3) Provide adequate clearance for tool plate to extend from cylinder
4) Slowly apply pressure to the unit
PHD, Inc. makes no warranty as to the fitness of its products or as to the length of service life after being repaired or parts
replaced by anyone other than authorized employees of PHD, Inc. In no event shall PHD, Inc. be liable for loss of profits,
indirect, consequential, or incidental damages arising out of the use of PHD products.
Replacement Switches
Part Number Description
86725-0 Reed DC 5-30 V, 50mA, Quick Connect
86726-0 Sink Type (NPN), DC 5-30 V, 50mA, Quick Connect
86727-0 Source Type (PNP), DC 5-30 V, 50mA, Quick Connect
Includes one switch
!
Specifications Series OSW Slide
Operating Air Pressure 1.5 to 7 bar [21.7 to 101 psi]
Operating Temperature 5° to 60°C [41° to 140°F]
Velocity 50 to 500 mm/sec [2 to 20 in/sec]
Rated Life 3 million cycles
Lubrication Factory lubricated for rated life
Size
Recommended Mounting Torques
Body Thru & C’bore Body Threads Tool Plate Threads Table Threads
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
6 1.7 15 2.8 25 1.7 15 1.7 15
8 1.7 15 2.8 25 2.8 25 1.7 15
12 2.8 25 4.5 40 4.5 40 2.8 25
16 4.5 40 9 80 9 80 4.5 40
20 4.5 40 9 80 9 80 4.5 40
25 9 80 20 175 20 175 9 80

6441-701
2
C
B
D
A
D
K
K
GJ
H
SERIES OSW SLIDE START-UP PROCEDURE
SERIES OSW TRAVEL ADJUSTMENT KITS
PHD, Inc. makes no warranty as to the fitness of its products or as to the length of service life after being repaired or parts
replaced by anyone other than authorized employees of PHD, Inc. In no event shall PHD, Inc. be liable for loss of profits,
indirect, consequential, or incidental damages arising out of the use of PHD products.
Slide Bore SizeStroke Adjustment
Kit Base Part
Number
1687457 - 15-
06 = 6 mm
08 = 8 mm
12 = 12 mm
16 = 16 mm
20 = 20 mm
25 = 25 mm
Adjustment
Amount
Blank = 5 mm
15 = 15 mm
25 = 25 mm
5mm TRAVEL ADJUSTMENT
15mm TRAVEL ADJUSTMENT
25mm TRAVEL ADJUSTMENT
F
G
A
B
C
D
E
D15
D25
D15
D
D25
Size
Kit
part #
Replacement
Shock
Part #
Shock
Stroke
mm
Shock
barrel
Thread
Max energy
per cycle
Nm
Max energy
per hour
Nm
Max impact
speed
mm/s
8 87458-08 87460-01 6 M8 x 1 1.8 2400 800
12 87458-12 87460-01 6 M8 x 1 1.8 2400 800
16 87458-16 87460-02 8 M10 x 1 3.2 5760 800
20 87458-20 87460-03 12 M14 x 1.5 16 28800 800
25 87458-25 87460-03 12 M14 x 1.5 16 28800 800
Size
Dual Stop Block for
Travel Lengths Shown
8 50, 75
12 75,100
16 75,100
20 100, 125, 150
25 100, 125, 150
Size
A B C D
Fastener Torque Fastener Torque Fastener Torque Shock Torque
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
8 M3 x 0.5 x 12 1.7 15 M3 x 0.5 x 16 1.7 15 M3 x 0.5 x 16 1.7 15 1.7 15
12 M4 x 0.7 x 8 2.8 25 M4 x 0.7 x 12 2.8 25 M4 x 0.7 x 16 2.8 25 1.7 15
16 M5 x 0.8 x 10 4.5 40 M5 x 0.8 x 16 4.5 40 M5 x 0.8 x 16 4.5 40 3.1 27
20 M5 x 0.8 x 12 4.5 40 M6 x 1.0 x 25 7.9 70 M6 x 1.0 x 25 7.9 70 10.8 96
25 M6 x 1.0 x 16 7.9 70 M8 x 1.25 x 25 19.8 175 M8 x 1.25 x 25 19.8 175 10.8 96
Size
G H J K
Fastener Torque Fastener Torque Fastener Torque Adjuster Torque
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
6 M2.5 X 0.45 X 8 0.8 7 M2.5 X 0.45 X 8 0.8 7 M2.5 X 0.45 X 10 0.8 7 3 27
8 M3 x 0.5 x 12 1.7 15 M3 x 0.5 x 16 1.7 15 M3 x 0.5 x 16 1.7 15 5 44
12 M4 x 0.7 x 8 2.8 25 M4 x 0.7 x 12 2.8 25 M4 x 0.7 x 16 2.8 25 12.5 110
16 M5 x 0.8 x 10 4.5 40 M5 x 0.8 x 16 4.5 40 M5 x 0.8 x 16 4.5 40 25 220
20 M5 x 0.8 x 12 4.5 40 M6 x 1.0 x 25 7.9 70 M6 x 1.0 x 25 7.9 70 43 380
25 M6 x 1.0 x 16 7.9 70 M8 x 1.25 x 25 19.8 175 M8 x 1.25 x 25 19.8 175 69 610
