Philips HR2355/07 User manual

HR2355/07
Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
EN User manual 3
DA Brugervejledning 26
FI Käyttöopas 50
NO Brukerhåndbok 74
SV Bruksanvisning 98

2 English
Congratulations on your purchase, and welcome to Philips!
To fully benet from the support that Philips offers, register your product at
www.philips.com/welcome.
Read this user manual carefully before you install and use the unit. Save it for future
reference.
What's in the box
Shaping
discs Cleaning tools
Lasagna/
Dumpling
Penne
Fettuccine
Water cup
User manual Recipe book
Main unit
Flour cup
Flat cleaning tool
Use the at
cleaning tool
Use the at
cleaning tool
Spaghetti
Assembled
on the
appliance
upon
purchanse

English 3
Contents
What's in the box ����������� 2
Important �������������� 4
Overview �������������� 8
Disassembling and cleaning before
rst use �������������� 10
Assembling ������������ 12
Using the pasta maker �������� 14
Cleaning ������������� 20
Troubleshooting ���������� 23
Product information ��������� 25
Recycling ������������� 25
Guarantee and service �������� 25

4 English
Important
• Before you connect the appliance to the power, make
sure that the voltage indicated on the bottom of the
appliance corresponds to the local power voltage.
• Make sure that your hands are dry before you insert the
plug into the power outlet.
• Make sure that the plug is firmly inserted into the power
outlet.
• Never connect this appliance to a timer switch.
• Before you insert the plug into the power outlet, make
sure that the appliance is assembled correctly.
• If the power cord, the plug, or other parts are damaged,
do not use the appliance.
• If the power cord is damaged, you must have it replaced
by Philips, a service center authorized by Philips or
similarly qualified persons to avoid a hazard.
• Do not replace parts of the appliance yourself.
Warning
Safety
• Read this user manual carefully before you use the appliance,
and save it for future reference.

English 5
Warning
• This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
• This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved.
• For their safety, do not allow children to play with the
appliance.
• To prevent any accidents, do not use the appliance if it is
damaged for any reason.
• Always disconnect the appliance from the supply if it is
left unattended and before assembling, disassembling or
cleaning.
• Switch off the appliance and disconnect from supply
before changing accessories or approaching parts that
move in use.

6 English
• Before using the appliance for the first time, disassemble
and wash the accessories thoroughly (see “Disassemble
and cleaning before first use” section.)
• The appliance is intended for household use only.
• Do not use this appliance on an unstable or uneven
surface.
• Do not disconnect the power cord before processing is
complete. If you have to stop processing, disconnect the
power cord before you perform other operations.
• To better protect the lifetime of the appliance, we
recommend the continuous working time to be less
than 45 minutes.You can restart using the appliance after
15 minutes.
• If you intend to use the appliance continuously, clean the
shaping disc with the supplied cleaning tool each time
after use. For cleaning ease, do not soak the shaping disc
into the water directly.
• Do not bend the power cord forcibly, jerk, twist, bundle
nor put under heavy items.
• Do not put metal or flammable objects in the mixing
chamber.
• Unplug the appliance when not in use.
• Do not use the appliance near flammable objects such as
table cloth or drapes.
Caution

English 7
Caution
• Pull out the power plug immediately when you detect
smoke.
• When unplugging the power cord, do not pull the cable
but grab the plug part.
• Keep the power plug clean.
• Do not put heavy objects on the appliance.
• This appliance is designed as consumer kitchen appliance.
Do not use for any other purpose
• Do not move the appliance while it is operating.
• Disconnect the power and remove the power cord
before cleaning or disassembling this appliance.
• Do not immerse the main unit in water.
• Place the appliance in a dry and well ventilated place
after use.
• To prevent a short circuit or an electric shock, do not
pour water or any liquid into the safety switch.
• Do not use a dishwasher to clean the machine or the
accessories.
EMF
This Philips appliance complies with all applicable standards and regulations regarding
exposure to electromagnetic elds.

8 English
Overview
Mixing
chamber lid
Disc holder Front panel
Front panel
knobs
Shaping discsDisc holder
safety switch lever
Mixing
chamber
Mixing
paddle

English 9
Control panel
display
Power cord
Main unit
Disc holder safety switch
Shaping discs storage
Safety switch hole of
the mixing chamber lid
Power on/
off button
Program
button
Display
screen
Servings
button
Start/pause
button
Program button - select the extrusion-only program
or automatic program .
Servings button - select to make ~ 300g, 1-2
servings or to make ~ 600g, 3-4 servings of fresh
pasta.
Abbreviations
g = grams
~ = approximately
ml = milliliters
mm = millimeters
kg = kilogram
in = inch

10 English
Important
1 Remove the mixing chamber lid from the
appliance.
2 Loosen the front panel control knobs.
Note:
• The front panel is heavy.Take extra caution when
removing it.
Disassembling and
cleaning before
rst use
• Before using the appliance for the first time, remove and safely discard any
packaging material and /or promotional labels.
• Take out all the parts and accessories, wash and thoroughly dry all parts and
accessories (see "Cleaning" section).
• Do not use water to rinse or soak the main unit.
• Do not use a scourer or similar cleaners as these will scratch the plastic surface
and affect the lifetime of the pasta maker.
• This appliance is intended for household use only.

English 11
3 Disassemble the front panel, the shaping disc, the shaping disc holder, the mixing
paddle, and the mixing chamber in order.
4 Clean all detachable parts, and wipe them dry.
2
3
4
5
1

12 English
Important
Assembling Follow below assembling steps to install
the pasta maker.
1 Push the mixing chamber into the appliance.
2 Point the mixing paddle to the hole in the main
unit. Insert the mixing paddle all the way into the
main unit.
3 Attach the disc holder onto the appliance.
❶Disc holder safety switch
❷Disc holder safety switch lever
Note:
• Check that the safety switch ❶and safety
switch lever ❷are set as shown in the
illustration to the right.
1
2
• Make sure to tighten the front panel knobs during assembly.
• Make sure the appliance is not plugged in when assembling the appliance.

English 13
4 Put the shaping disc onto the disc holder ❶, and make sure it is rmly xed on the
disc holder ❷.
Note:
• Make sure the inner cavity
of the shaping disc and
disc holder is properly
tted.
5 Attach the front panel to the main unit.
❶Disc holder safety switch lever
Note:
• Make sure the front panel is completely fastened
before using the appliance.
• The front panel is heavy.Take extra caution when
assembling it.
6 Fasten the front panel control knobs.
Note:
• If the front panel or the shaping disc is not properly
assembled, the safety switch will prevent the
appliance from working.
7 Close the mixing chamber lid properly.
Note:
• If the mixing chamber lid is not properly installed,
the safety switch will prevent the appliance from
working.
12
1
1
2

14 English
Important
Using the pasta
maker
Preparing the ingredients
1 Measure one full cup of flour. Scrape off any
excessive flour from the cup edge with the
supplied flat cleaning tool. One full cup is
equivalent to 1-2 servings.
Note:
• Do not shake or hit the our cup to remove
excessive our. This will affect the our weight.
You can also use a kitchen scale to measure the
our. For instance, ~250g our makes
approximately 1-2 servings; ~500g our makes
approximately 3-4 servings of fresh pasta.
• Make sure to follow the right order to add flour and water into the mixing
chamber. Put the flour into the mixing chamber first, then place the chamber lid
onto the chamber. Start the pasta maker, and then slowly pour water along the
entire length of the opening in the lid.
• Never put excessive ingredients into the pasta maker. Otherwise, it will damage the
appliance.The maximum amount of flour used for each batch is 500g.
• Do not put any ingredients that are 60°C / 140°F or above into the pasta maker,
nor place the pasta maker in surroundings with high temperature (60°C / 140°F),
for instance in a high temperature sterilization.This will deform the appliance.
• Never pour water into the mixing chamber before you place the chamber lid onto
the chamber. Do not pour any liquids into the safety switch hole.
• Do not pour water into the mixing chamber before turning on the pasta maker.
Follow the instruction carefully to enjoy homemade pasta.

English 15
2 Remove the chamber lid.
3 Pour the our into the chamber. If you want to
make 3-4 servings, add a second cup of our as
you will need 2 cups (~500g) of our in total.
4 Close the chamber lid properly.
Note:
• Insert the two hooks into the appliance rst ❶, and
then push the lid against the main unit ❷.
• The appliance will not start working if the chamber
lid is not properly closed. During the pasta making
process, if the chamber lid becomes loose, the
appliance will automatically stop working.
5 Use the “Pasta making recipe table” and measure
the required amount of water.
Note:
• Do not pour water into the mixing chamber before
turning on the pasta maker.
• There are 2 sets of water markings on the supplied
water cup. One set is for normal pasta making, and
the other set is for egg pasta and other avor pasta
making.
1
2

16 English
Pasta making recipe table
For more information, you can visit www.philips.com/kitchen.
Flour/water ratio table
Flour
Normal pasta Egg pasta Processing
time Output
Water (marking) Water + egg
mixture (marking)
1 our cup
(~250g) Amount of water
needed for a cup
of our (~90ml)
Amount of water
+ egg mixture
needed for a cup
of our (~95ml)
10 minutes
~ 300g fresh
pasta.
This is sufcient
as a main meal
for 1-2 persons,
or as a side dish
for 4-6 persons.
2 our cups
(~500g) Amount of water
needed for 2 cups
of our (~180ml)
Amount of water
+ egg mixture
needed for 2 cups
of our (~190ml)
15 minutes
~ 600g fresh
pasta.
This is sufcient
as a main meal
for 3-4 people, or
as a side dish for
8-10 people.

English 17
Note:
• To ensure the quality of the pasta, use gluten our to make pasta. Follow the
recommended proportion to add the ingredients.
• Seasonal changes and using ingredients from different regions may affect the our/
water ratio.You may adjust based on the recommended proportion.
• When making the egg pasta or vegetable pasta, make sure you whisk the egg
mixture or vegetable juice evenly with the water before pouring into the chamber.
When adding ingredients, make sure the ingredient is in a liquid form.
• See the recipe book provided for additional pasta recipe variations and many
delicious new recipes to try.
Important
• The pasta recipes provided in the user manual and recipe book have been
tested for success. If you experiment with or use other pasta recipes, the flour
and water/egg ratios will need to be adjusted to the flour and water cup ratios
included with the pasta maker.The pasta maker will not operate successfully
without adjusting the new recipe accordingly.

18 English
Selecting the pasta making program
1 Connect the power plug to any 220-240V AC
outlet.The pasta maker will sound once, and all
indicators will flash once. Press the power on/off
button to switch on the pasta maker.
2 Based on the amount of our, press the servings
button to select to make ~ 300g or
to make ~ 600g of fresh pasta.
Important
• Do not select the extrusion-only program before the dough mixing is complete.
Otherwise, this will damage the pasta maker and its lifetime.
• Do not disconnect the power cord before processing is complete. If you have to
stop processing, press the on/off button to turn off the pasta maker and then
disconnect the power cord from outlet before performing other operations.
• To better protect the lifetime of the appliance, it is recommended the continuous
working time be less than 45 minutes.You can restart using the appliance after a
15 minute rest.
• If you intend to use the appliance continuously, clean the shaping disc with the
supplied cleaning tool each time after each pasta making session. For cleaning
ease, do not soak the shaping disc directly in water.

English 19
3 Press the start/pause button to start
processing, and the processing time starts to
count down.
Note:
• By default, the program is set as automatic. If this is
not the case, press the program button to re-
select.
4 After the kneading starts, slowly pour in the
water or water + egg mixture along the entire
length of the slot in the lid.
Note:
• During dough mixing, do not add other ingredients
after you have poured in the water. Otherwise, it will
affect the results of the pasta texture.
5 The pasta will start extruding out after a few
minutes. Place a container right under the outlet.
Cut the pasta into the desired length with the
supplied cleaning tool.
Note:
• If you notice the program is not set as automatic
while pasta is extruding, press the start/pause button
to stop the program.Then, press the power on/
off button and disconnect the plug from the
power socket.After cleaning the shaping discs, you
can restart the process.
• If the ratio of liquid and our is not correct, the extrusion will not succeed. In this
case, prepare the ingredients again.
• Move the cleaning tool downwards to cut the pasta.
6 After the pasta making is complete, if you notice there is some leftover dough inside
the chamber, you can press the extrusion-only button and press the start/pause
button for extra extrusion.
Note:
• The countdown timer of the extrusion-only program is 3 minutes.
• You may nd some ne pasta threads on the pasta surface. This is normal.
• The cooking time of the pasta varies depending on personal preferences, pasta
shapes, and number of servings.

20 English
Important
1 Press the power on/off button to turn off the
pasta maker, and then disconnect the plug from
the power outlet.
2 Remove the chamber lid from the appliance.
Cleaning
• Disconnect the power and remove the power cord before cleaning or
disassembling this appliance.
• Do not immerse the main unit in water.
• Do not use a scourer, caustic cleaners, or abrasive cleaners (for examples,
gasoline, alcohol, and propanol) to clean the appliance.
• Clean the appliance each time after use, or the appliance might not operate properly.
• Take extra caution when cleaning the appliance to avoid getting cut by any sharp
edges.
