Philips HR2355/09 User manual

HR2355/09
Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
EN User manual 2
CS Příručka pro uživatele 26
EL Εγχειρίδιο χρήσης 50
FR Mode d’emploi 74
HU Felhasználói kézikönyv 98
IT Manuale utente 122
NL Gebruiksaanwijzing 146
RU Руководство пользователя 170
SK Príručka užívateľa 196
TR Kullanım kılavuzu 220

2English
Congratulations on your purchase, and welcome to Philips!
To fully benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
Read this user manual carefully before you install and use the unit. Save it
for future reference.
What's in the box
Shaping
discs
Cleaning tools
Lasagna/
Dumpling
Penne
Fettuccine
Water cup
User manual Recipe book
Main unit
Flour cup
Flat cleaning tool
Use the flat
cleaning tool
Use the flat
cleaning tool
Spaghetti
Assembled
on the
appliance
upon
purchase

English 3
Contents
What's in the box ��������������� 2
Important ��������������������� 4
Overview ��������������������� 8
Disassembling and cleaning before
first use ��������������������� 10
Assembling ������������������ 12
Using the Pasta maker ����������� 14
Cleaning �������������������� 20
Troubleshooting ��������������� 23
Product information ������������ 25
Recycling �������������������� 25
Guarantee and service ���������� 25

4English
Important
• Before you connect the appliance to the power,
make sure that the voltage indicated on the
bottom of the appliance corresponds to the
local power voltage.
• Make sure that your hands are dry before you
insert the plug into the power outlet.
• Make sure that the plug is firmly inserted into
the power outlet.
• Never connect this appliance to a timer switch.
• Before you insert the plug into the power outlet,
make sure that the appliance is assembled
correctly.
• If the power cord, the plug, or other parts are
damaged, do not use the appliance.
• If the power cord is damaged, you must have it
replaced by Philips, a service center authorized
by Philips or similarly qualified persons to avoid
a hazard.
• Do not replace parts of the appliance yourself.
Warning
Safety
• Read this user manual carefully before you use the
appliance, and save it for future reference.

English 5
Warning
• This appliance shall not be used by children.
Keep the appliance and its cord out of reach of
children.
• This appliance can be used by persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and if they understand the hazards involved.
• For their safety, do not allow children to play
with the appliance.
• To prevent any accidents, do not use the
appliance if it is damaged for any reason.
• Always disconnect the appliance from the
supply if it is left unattended and before
assembling, disassembling or cleaning.
• Switch off the appliance and disconnect
from supply before changing accessories or
approaching parts that move in use.

6English
• Before using the appliance for the first time,
disassemble and wash the accessories
thoroughly (see “Disassemble and cleaning
before first use” section.)
• The appliance is intended for household use
only.
• Do not use this appliance on an unstable or
uneven surface.
• Do not disconnect the power cord before
processing is complete. If you have to stop
processing, disconnect the power cord before
you perform other operations.
• To better protect the lifetime of the appliance,
we recommend the continuous working time to
be less than 45 minutes. You can restart using
the appliance after 15 minutes.
• If you intend to use the appliance continuously,
clean the shaping disc with the supplied
cleaning tool each time after use. For cleaning
ease, do not soak the shaping disc into the
water directly.
• Do not bend the power cord forcibly, jerk, twist,
bundle nor put under heavy items.
• Do not put metal or flammable objects in the
mixing chamber.
• Unplug the appliance when not in use.
Caution

English 7
Caution
• Do not use the appliance near flammable
objects such as table cloth or drapes.
• Pull out the power plug immediately when you
detect smoke.
• When unplugging the power cord, do not pull
the cable but grab the plug part.
• Keep the power plug clean.
• Do not put heavy objects on the appliance.
• This appliance is designed as consumer kitchen
appliance. Do not use for any other purpose
• Do not move the appliance while it is operating.
• Disconnect the power and remove the power
cord before cleaning or disassembling this
appliance.
• Do not immerse the main unit in water.
• Place the appliance in a dry and well ventilated
place after use.
• To prevent a short circuit or an electric shock,
do not pour water or any liquid into the safety
switch.
• Do not use a dishwasher to clean the machine
or the accessories.
EMF
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.

8English
Overview
Mixing
chamber
lid
Disc holder Front panel
Front
panel
knobs
Shaping
discs
Disc holder
safety switch
lever
Mixing
chamber
Mixing
paddle

English 9
Control panel display
Power cord
Main unit
Disc holder safety switch
Shaping discs storage
Safety switch hole of
the mixing chamber lid
Power on/
off button
Program
button
Display
screen
Servings
button
Start/
pause
button
Program button - select the extrusion-only
program or automatic program .
Servings button - select to make ~300g, 1-2
servings or to make ~600g, 3-4 servings
of fresh pasta.
Abbreviations
g = grams
~= approximately
ml = milliliters
mm = millimeters
kg = kilogram
in = inch

10 English
Important
1 Remove the mixing chamber lid from the
appliance.
2 Loosen the front panel control knobs.
Note:
• The front panel is heavy. Take extra caution
when removing it.
Disassembling
and cleaning
before first use
• Before using the appliance for the first time, remove and safely
discard any packaging material and /or promotional labels.
• Take out all the parts and accessories, wash and thoroughly dry all
parts and accessories (see "Cleaning" section).
• Do not use water to rinse or soak the main unit.
• Do not use a scourer or similar cleaners as these will scratch the
plastic surface and affect the lifetime of the Pasta maker.
• This appliance is intended for household use only.

English 11
3 Disassemble the front panel, the shaping disc, the shaping disc holder,
the mixing paddle, and the mixing chamber in order.
4 Clean all detachable parts, and wipe them dry.
2
3
4
5
1

12 English
Important
Assembling Follow below assembling steps to
install the Pasta maker.
1 Push the mixing chamber into the
appliance.
2 Point the mixing paddle to the hole in
the main unit. Insert the mixing paddle
all the way into the main unit.
3 Attach the disc holder onto the
appliance.
❶Disc holder safety switch
❷Disc holder safety switch lever
Note:
• Check that the safety switch ❶and
safety switch lever ❷are set as shown
in the illustration to the right.
1
2
• Make sure to tighten the front panel knobs during assembly.
• Make sure the appliance is not plugged in when assembling the
appliance.

English 13
4 Put the shaping disc onto the disc holder ❶, and make sure it is firmly
fixed on the disc holder ❷.
Note:
• Make sure the inner
cavity of the shaping
disc and disc holder is
properly tted.
5 Attach the front panel to the main unit.
❶Disc holder safety switch lever
Note:
• Make sure the front panel is completely
fastened before using the appliance.
• The front panel is heavy. Take extra caution
when assembling it.
6 Fasten the front panel control knobs.
Note:
• If the front panel or the shaping disc is not
properly assembled, the safety switch will
prevent the appliance from working.
7 Close the mixing chamber lid properly.
Note:
• If the mixing chamber lid is not properly
installed, the safety switch will prevent the
appliance from working.
12
1
1
2

14 English
Important
Using the Pasta
maker
Preparing the ingredients
1 Measure one full cup of flour. Scrape off
any excessive flour from the cup edge
with the supplied flat cleaning tool. One
full cup is equivalent to 1-2 servings.
Note:
• Do not shake or hit the flour cup to remove
excessive flour. This will affect the flour
weight.
You can also use a kitchen scale to
measure the flour. For instance, ~250g
flour makes approximately 1-2 servings;
~500g flour makes approximately 3-4
servings of fresh pasta.
• Make sure to follow the right order to add flour and water into the
mixing chamber. Put the flour into the mixing chamber first, then place
the chamber lid onto the chamber. Start the Pasta maker, and then
slowly pour water along the entire length of the opening in the lid.
• Never put excessive ingredients into the Pasta maker. Otherwise, it will
damage the appliance. The maximum amount of flour used for each
batch is 500g.
• Do not put any ingredients that are 60°C / 140°F or above into the
Pasta maker, nor place the Pasta maker in surroundings with high
temperature (60°C / 140°F), for instance in a high temperature
sterilization. This will deform the appliance.
• Never pour water into the mixing chamber before you place the chamber
lid onto the chamber. Do not pour any liquids into the safety switch hole.
• Do not pour water into the mixing chamber before turning on the Pasta
maker. Follow the instruction carefully to enjoy homemade pasta.

English 15
2 Remove the chamber lid.
3 Pour the flour into the chamber. If you
want to make 3-4 servings, add a second
cup of flour as you will need 2 cups
(~500g) of flour in total.
4 Close the chamber lid properly.
Note:
• Insert the two hooks into the appliance first
❶, and then push the lid against the main
unit ❷.
• The appliance will not start working if the
chamber lid is not properly closed. During
the pasta making process, if the chamber
lid becomes loose, the appliance will
automatically stop working.
5 Use the “Pasta making recipe table” and
measure the required amount of water.
Note:
• Do not pour water into the mixing chamber
before turning on the Pasta maker.
• There are 2 sets of water markings on the
supplied water cup. One set is for normal
pasta making, and the other set is for egg
pasta and other flavor pasta making.
1
2

16 English
Pasta making recipe table
For more information, you can visit www.philips.com/kitchen.
Flour/water ratio table
Flour
Normal pasta Egg pasta
Processing
time Output
Water
(marking)
Water +
egg mixture
(marking)
1 flour cup
(~250g)
Amount of
water needed
for a cup of
flour (~90ml)
Amount
of water +
egg mixture
needed for a
cup of flour
(~95ml)
10 minutes
~300g fresh
pasta.
This is
sufficient as a
main meal for
1-2 persons,
or as a side
dish for 4-6
persons.
2 flour cups
(~500g)
Amount of
water needed
for 2 cups of
flour (~180ml)
Amount
of water +
egg mixture
needed for 2
cups of flour
(~190ml)
15 minutes
~600g fresh
pasta.
This is
sufficient as a
main meal for
3-4 people,
or as a side
dish for 8-10
people.

English 17
Note:
• To ensure the quality of the pasta, use gluten flour to make pasta.
Follow the recommended proportion to add the ingredients.
• Seasonal changes and using ingredients from different regions
may affect the flour/water ratio. You may adjust based on the
recommended proportion.
• When making the egg pasta or vegetable pasta, make sure you
whisk the egg mixture or vegetable juice evenly with the water before
pouring into the chamber through the slot in the lid. When adding
ingredients, make sure the ingredient is in a liquid form.
• See the recipe book provided for additional pasta recipe variations
and many delicious new recipes to try.
Important
• The pasta recipes provided in the user manual and recipe book have
been tested for success. If you experiment with or use other pasta
recipes, the flour and water/egg ratios will need to be adjusted to the
flour and water cup ratios included with the Pasta maker. The Pasta
maker will not operate successfully without adjusting the new recipe
accordingly.

18 English
Selecting the pasta making program
1 Connect the power plug to any 220-
240V AC outlet. The Pasta maker will
sound once, and all indicators will flash
once. Press the power on/off button
to switch on the Pasta maker.
2 Based on the amount of flour, press the
servings button to select to make
~300g or to make ~600g of fresh
pasta.
Important
• Do not select the extrusion-only program before the dough mixing
is complete. Otherwise, this will damage the Pasta maker and its
lifetime.
• Do not disconnect the power cord before processing is complete. If
you have to stop processing, press the on/off button to turn off
the Pasta maker and then disconnect the power cord from outlet
before performing other operations.
• To better protect the lifetime of the appliance, it is recommended
the continuous working time be less than 45 minutes. You can restart
using the appliance after a 15 minute rest.
• If you intend to use the appliance continuously, clean the shaping
disc with the supplied cleaning tool each time after each pasta
making session. For cleaning ease, do not soak the shaping disc
directly in water.

English 19
3 Press the start/pause button to start
processing, and the processing time
starts to count down.
Note:
• By default, the program is set as automatic. If
this is not the case, press the program button
to re-select.
4 After the kneading starts, slowly pour in
the water or water + egg mixture along
the entire length of the slot in the lid.
Note:
• During dough mixing, do not add other
ingredients after you have poured in the
water. Otherwise, it will affect the results of
the pasta texture.
5 The pasta will start extruding out after a
few minutes. Place a container right
under the outlet. Cut the pasta into the
desired length with the supplied cleaning
tool.
Note:
• You may find some fine pasta threads on the
pasta surface, especially at the beginning
and the end of the extrusion.
• If you notice the program is not set as automatic while pasta is
extruding, press the start/pause button to stop the program. Then,
press the power on/off button and disconnect the plug from the
power socket. After cleaning the shaping discs, you can restart the
process.
• If the ratio of liquid and flour is not correct, the extrusion will not
succeed. In this case, prepare the ingredients again.
• Move the cleaning tool downwards to cut the pasta.
6 After the pasta making is complete, if you notice there is some leftover
dough inside the chamber, you can press the extrusion-only button
❶and press the start/pause button ❷for extra extrusion.
Note:
• The countdown timer of the extrusion-only program is 3 minutes.
• The cooking time of the pasta varies depending on personal
preferences, pasta shapes, and number of servings.

20 English
Important
1 Press the power on/off button to turn
off the Pasta maker, and then disconnect
the plug from the power outlet.
2 Remove the chamber lid from the
appliance.
Cleaning
• Disconnect the power and remove the power cord before cleaning or
disassembling this appliance.
• Do not immerse the main unit in water.
• Do not use a scourer, caustic cleaners, or abrasive cleaners (for
examples, gasoline, alcohol, and propanol) to clean the appliance.
• Clean the appliance each time after use, or the appliance might not
operate properly.
• Take extra caution when cleaning the appliance to avoid getting cut
by any sharp edges.
