Pilz PNOZ m ES Profibus User manual

PNOZmESProfibus
OperatingManual1002698EN04
ConfigurableControlSystemPNOZmulti

Preface
Thisdocumentisatranslationoftheoriginaldocument.
AllrightstothisdocumentationarereservedbyPilzGmbH&Co.KG.Copiesmaybemade
forinternalpurposes.Suggestionsandcommentsforimprovingthisdocumentationwillbe
gratefullyreceived.
Pilz®,PIT®,PMI®,PNOZ®,Primo®,PSEN®,PSS®,PVIS®,SafetyBUSp®,
SafetyEYE®,SafetyNETp®,thespiritofsafety®areregisteredandprotectedtrademarks
ofPilzGmbH&Co.KGinsomecountries.
SDmeansSecureDigital

Content
OperatingManualPNOZmESProfibus
1002698EN04 3
Introduction 5
Validityofdocumentation 5
Retainingthedocumentation 5
Definitionofsymbols 5
Overview 6
Scopeofsupply 6
Unitfeatures 6
Frontview 7
Safety 7
Intendeduse 7
Systemrequirements 8
Safetyregulations 8
Useofqualifiedpersonnel 8
Warrantyandliability 8
Disposal 9
Foryoursafety 9
Functiondescription 9
Operation 9
Dataaccess 9
Assigningtheinputs/outputsinthePNOZmultiConfiguratortothePROFIBUSDPin
puts/outputs
10
Blockdiagram 11
Installation 11
Generalinstallationguidelines 11
Connectthebaseunitandexpansionmodules 11
Dimensions 12
Commissioning 12
Wiring 12
Generalwiringguidelines 12
Connectingthesupplyvoltage 12
PROFIBUSDPinterface 12
Preparingforoperation 14
Settingthestationaddress 14
DownloadmodifiedprojecttothecontrolsystemPNOZmulti 14
Connectionexample 15
Operation 15
Messages 15
Technicaldetails 16
Orderreference 18
Module 18

Content
OperatingManualPNOZmESProfibus
1002698EN04 4
Accessories 19

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 5
Introduction
Validityofdocumentation
ThisdocumentationisvalidfortheproductPNOZmESProfibus.Itisvaliduntilnewdocu
mentationispublished.
Thisoperatingmanualexplainsthefunctionandoperation,describestheinstallationand
providesguidelinesonhowtoconnecttheproduct.
Retainingthedocumentation
Thisdocumentationisintendedforinstructionandshouldberetainedforfuturereference.
Definitionofsymbols
Informationthatisparticularlyimportantisidentifiedasfollows:
DANGER!
Thiswarningmustbeheeded!Itwarnsofahazardoussituationthatposes
animmediatethreatofseriousinjuryanddeathandindicatespreventive
measuresthatcanbetaken.
WARNING!
Thiswarningmustbeheeded!Itwarnsofahazardoussituationthatcould
leadtoseriousinjuryanddeathandindicatespreventivemeasuresthatcan
betaken.
CAUTION!
Thisreferstoahazardthatcanleadtoalessseriousorminorinjuryplus
materialdamage,andalsoprovidesinformationonpreventivemeasures
thatcanbetaken.
NOTICE
Thisdescribesasituationinwhichtheproductordevicescouldbedam
agedandalsoprovidesinformationonpreventivemeasuresthatcanbe
taken.Italsohighlightsareaswithinthetextthatareofparticularimport
ance.

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 6
INFORMATION
Thisgivesadviceonapplicationsandprovidesinformationonspecialfea
tures.
Overview
Scopeofsupply
Unitfeatures
UsingtheproductPNOZmESProfibus:
Expansionmoduleforconnectiontoabaseunitfromtheconfigurablecontrolsystem
PNOZmulti2.
Theproducthasthefollowingfeatures:
}CanbeconfiguredinthePNOZmultiConfigurator
}ConnectionforPROFIBUSDP
}Stationaddressesfrom0...99,selectedviarotaryswitch
}StatusindicatorsforcommunicationwithPROFIBUSDPandforerrors
}InthePNOZmultiConfigurator,128virtualoutputsofthePNOZmulti2controlsystem
canbedefinedforcommunicationwiththefieldbusPROFIBUSDP.
}Max.1PNOZmESProfibuscanbeconnectedtothebaseunit
}Pluginconnectionterminals:
eitherspringloadedterminalorscrewterminalavailableasanaccessory(seeorder
reference)
}Pleaserefertothedocument"PNOZmultiSystemExpansion"fordetailsofthebase
unitsPNOZmulti2thatcanbeconnected.

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 7
Frontview
Legend
LED:
Power
Online
Offline
Fault
Rotaryswitch
x10=Tensdigitforthestationaddress
x1=Unitsdigitforthestationaddress
X1:PROFIBUSDPinterface(female9pinDSubconnector)
X4:0V,24V:
Supplyconnections
Functionalearth
Safety
Intendeduse
TheexpansionmodulePNOZmESProfibusisusedforcommunicationbetweenthecon
figurablecontrolsystemPNOZmulti2andPROFIBUSDP.
PROFIBUSDPisdesignedforfastdataexchangeatfieldlevel.Theexpansionmodule
PNOZmESProfibusisapassivesubscriber(Slave)ofPROFIBUSDP(DPV0).Thebasic
functionsofcommunicationwithPROFIBUSDPconformtoEN50170.Thecentralcontrol
ler(Master)readsinputinformationfromtheslavesandwritesoutputinformationtothe
slavesaspartofeachcycle.Aswellasthecyclicaltransferofusabledata,PROFIBUSDP
canalsobeusedfordiagnosticsandcommissioningfunctions.Datatrafficismonitoredon
theMaster/Slaveside.
Theexpansionmodulemayonlybeconnectedtoabaseunitfromtheconfigurablecontrol
systemPNOZmulti2(pleaserefertothedocument"PNOZmultiSystemExpansion"forde
tailsofthebaseunitsthatcanbeconnected).

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 8
TheconfigurablecontrolsystemPNOZmulti2isusedforthesafetyrelatedinterruptionof
safetycircuitsandisdesignedforusein:
}ESTOPequipment
}SafetycircuitsinaccordancewithVDE0113Part1andEN602041
Theexpansionmodulemaynotbeusedforsafetyrelatedfunctions.
IntendeduseincludesmakingtheelectricalinstallationEMCcompliant.Theproductisde
signedforuseinanindustrialenvironment.Itisnotsuitableforuseinadomesticenviron
ment,asthiscanleadtointerference.
Thefollowingisdeemedimproperuseinparticular:
}Anycomponent,technicalorelectricalmodificationtotheproduct
}Useoftheproductoutsidetheareasdescribedinthismanual
}Useoftheproductoutsidethetechnicaldetails(seechapterentitled“TechnicalDe
tails”)
Systemrequirements
Pleaserefertothe"ProductModifications"documentinthe"Versionoverview"sectionfor
detailsofwhichversionsofthebaseunitandPNOZmultiConfiguratorcanbeusedforthis
product.
Safetyregulations
Useofqualifiedpersonnel
Theproductsmayonlybeassembled,installed,programmed,commissioned,operated,
maintainedanddecommissionedbycompetentpersons.
Acompetentpersonissomeonewho,becauseoftheirtraining,experienceandcurrentpro
fessionalactivity,hasthespecialistknowledgerequiredtotest,assessandoperatethe
workequipment,devices,systems,plantandmachineryinaccordancewiththegeneral
standardsandguidelinesforsafetytechnology.
Itisthecompany’sresponsibilityonlytoemploypersonnelwho:
}Arefamiliarwiththebasicregulationsconcerninghealthandsafety/accidentpreven
tion
}Havereadandunderstoodtheinformationprovidedinthisdescriptionunder"Safety"
}Andhaveagoodknowledgeofthegenericandspecialiststandardsapplicabletothe
specificapplication.
Warrantyandliability
Allclaimstowarrantyandliabilitywillberenderedinvalidif
}Theproductwasusedcontrarytothepurposeforwhichitisintended
}Damagecanbeattributedtonothavingfollowedtheguidelinesinthemanual
}Operatingpersonnelarenotsuitablyqualified
}Anytypeofmodificationhasbeenmade(e.g.exchangingcomponentsonthePCB
boards,solderingworketc.).

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 9
Disposal
}Insafetyrelatedapplications,pleasecomplywiththemissiontimetMinthesafetyre
latedcharacteristicdata.
}Whendecommissioning,pleasecomplywithlocalregulationsregardingthedisposalof
electronicdevices(e.g.ElectricalandElectronicEquipmentAct).
Foryoursafety
Theunitmeetsallnecessaryconditionsforsafeoperation.However,youshouldalwaysen
surethatthefollowingsafetyrequirementsaremet:
}Thisoperatingmanualonlydescribesthebasicfunctionsoftheunit.Informationonthe
advancedfunctionscanbefoundintheonlinehelpforthePNOZmultiConfiguratorand
inthePNOZmultitechnicalcatalogue.Onlyusethesefunctionsafteryouhavereadand
understoodthedocumentation.Allnecessarydocumentationcanbefoundonthe
PNOZmultiConfiguratorCD.
}Donotopenthehousingormakeanyunauthorisedmodifications.
}Pleasemakesureyoushutdownthesupplyvoltagewhenperformingmaintenance
work(e.g.exchangingcontactors).
Functiondescription
Operation
ThevirtualinputsandoutputsthataretobetransferredviaPROFIBUSareselectedand
configuredinthePNOZmultiConfigurator.ThebaseunitandtheexpansionmodulePNOZ
mESProfibusareconnectedviaajumper.
Thestationaddressissetviarotaryswitches.Afterthesupplyvoltageisswitchedonorthe
controlsystemPNOZmulti2isreset,theexpansionmodulePNOZmESProfibusiscon
figuredandstartedautomatically.
LEDsindicatethestatusoftheexpansionmoduleonPROFIBUS.
TheconfigurationisdescribedindetailinthePNOZmultiConfigurator'sonlinehelp.
INFORMATION
TheGSDfileisavailableontheInternetatwww.pilz.de.
Dataaccess
Thedataisstructuredasfollows:
}Virtualdata
– InputrangePNOZmESProfibus
ThevaluesfortheinputsaresetasanoutputintheMasterandtransferredtothe
PNOZmulti2.
– OutputrangePNOZmESProfibus

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 10
TheoutputsareconfiguredinthePNOZmultiConfiguratorandtransferredtothe
Master.
}StatusofLEDs:
– Bits0…4:StatusofLEDsonthePNOZmulti2
Bit0:OFAULT
Bit1:IFAULT
Bit2:FAULT
Bit3:DIAG
Bit4:RUN
}DataexchangeisdisplayedinBit5.
}Pollingtheusabledata:2Byteswiththetablenumberandsegmentnumberaresentby
theMasterforaccesstotheusabledatatable(15BytesarereturnedtotheMaster).
Detailedinformationondataexchange(tables,segments)isavailableinthedocument
"CommunicationInterfaces"inthesectionentitled"Fieldbusmodules".
Assigningtheinputs/outputsinthePNOZmultiConfiguratortothePROFIBUSDP
inputs/outputs
Virtualinputsandoutputscanberequestedorsetdirectlyviathefollowingobjects.Each
elementcanbeselectedindividuallyinthemastercontrolsystem,e.g.virtualinputsi031.
Thedatawidthisalsoestablishedthisway.
Inputdata
TheMasterwritestothevirtualinputsofthePNOZmulti2.
Description InputdatafromPNOZmulti2
Virtualinputsi0–i31 4InputBytes
Virtualinputsi32–i63 4InputBytes
Virtualinputsi64–i95 4InputBytes
Virtualinputsi96–i127 4InputBytes
Outputdata
TheMasterreadsthevirtualoutputsofthePNOZmulti2.
Description OutputdatafromPNOZmulti2
Virtualoutputso0–o31 4OutputBytes
Virtualoutputso32–o63 4OutputBytes
Virtualoutputso64–o95 4OutputBytes
Virtualoutputso96–o127 4OutputBytes

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 11
Blockdiagram
Base unit
PROFIBUS DP
24 V 0 V
24 V 0 V
Installation
Generalinstallationguidelines
}Theunitshouldbeinstalledinasinglemountingareawithaprotectiontypeofatleast
IP54.
}Fitthesafetysystemtoahorizontalmountingrail.Theventingslotsmustfaceupwards
anddownwards.Othermountingpositionscoulddestroythesafetysystem.
}Usethelockingslideontherearoftheunittoattachittoamountingrail.
}Inenvironmentsexposedtoheavyvibration,theunitshouldbesecuredusingafixing
element(e.g.retainingbracketorendangle).
}Openthelockingslidebeforeliftingtheunitfromthemountingrail.
}TocomplywithEMCrequirements,themountingrailmusthavealowimpedancecon
nectiontothecontrolcabinethousing.
}TheambienttemperatureofthePNOZmultiunitsinthecontrolcabinetmustnotexceed
thefigurestatedinthetechnicaldetails,otherwiseairconditioningwillberequired.
NOTICE
Damageduetoelectrostaticdischarge!
Electrostaticdischargecandamagecomponents.Ensureagainstdischarge
beforetouchingtheproduct,e.g.bytouchinganearthed,conductivesur
faceorbywearinganearthedarmband.
Connectthebaseunitandexpansionmodules
Connectthebaseunitandtheexpansionmoduleasdescribedintheoperatinginstructions
forthebaseunits.
}Connecttheblack/yellowterminatortotheexpansionmodule.

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 12
}InstalltheexpansionmoduleinthepositioninwhichitisconfiguredinthePNOZmulti
Configurator.
Dimensions
101,4 (4,11“)
115,0 (4,53“)
22,5
(0,88“)
Commissioning
Wiring
Generalwiringguidelines
ThewiringisdefinedinthecircuitdiagramofthePNOZmultiConfigurator.
Pleasenote:
}Informationgiveninthe"Technicaldetails"mustbefollowed.
}Usecopperwirethatcanwithstand75°C.
}Externalmeasuresmustbeusedtoconnecttheterminal tothefunctionalearth,
whenthemountingrailisnotconnectedtothefunctionalearth.
}Alwaysconnectthemountingrailtotheprotectiveearthviaanearthingterminal.This
willbeusedtodissipatehazardousvoltagesinthecaseofafault.
}Thepowersupplymustmeettheregulationsforextralowvoltageswithprotectivesep
aration.
Connectingthesupplyvoltage
Connectthesupplyvoltagetothefieldbusmodule:
}Terminal24V:+24VDC
}Terminal0V:0V
PROFIBUSDPinterface
Itispossibletodefinewhichoutputsonthecontrolsystemwillcommunicatewith
PROFIBUSDP.TheconnectiontoPROFIBUSDPismadeviaafemale9pinDSubcon
nectorinaccordancewiththeguidelinesofthePROFIBUSUserGroup(PNO).

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 13
1
5
9
6
1: n.c.
2: n.c.
3: B (RxD/TxD-P)
4: CNTR-P
5: DGND
6: VP
7: n.c.
8: A (RxD/TxD-N)
9: n.c.
n.c.=notconnected
PleasenotethefollowingwhenconnectingtoPROFIBUSDP:
}Onlyusemetalplugsormetallisedplasticplugs
}Twistedpair,screenedcablemustbeusedtoconnecttheinterfaces

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 14
Preparingforoperation
Settingthestationaddress
ThestationaddressoftheexpansionmodulePNOZmESProfibusissetbetween0...99
(decimal)viatworotaryswitchesx1andx10.
1
2
3
4
9
8
7
6
0
5
x10
}Ontheupperrotaryswitchx10,useasmallscrewdrivertosetthetensdigitforthead
dress(“3”intheexample).
1
2
3
4
9
8
7
6
0
5
x1
}Onthelowerrotaryswitchx1,settheonesdigitfortheaddress(“6”intheexample).
Stationaddress36issetinthediagramsasanexample.
DownloadmodifiedprojecttothecontrolsystemPNOZmulti
Assoonasanadditionalexpansionmodulehasbeenconnectedtothesystem,theproject
mustbeamendedusingthePNOZmultiConfigurator.Proceedasdescribedintheoperat
inginstructionsforthebaseunit.
NOTICE
Forthecommissioningandaftereveryprogramchange,youmustcheck
whetherthesafetydevicesarefunctioningcorrectly.

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 15
Connectionexample
PROFIBUS-DP
Slave 3
PROFIBUS-DP
Slave 1
PROFIBUS-DP
Master
PROFIBUS-DP
Slave n
PNOZ m ES PROFIBUS
PROFIBUS-DP
Slave 2
Operation
Messages
Whenthesupplyvoltageisswitchedon,thePNOZmultisafetysystemcopiestheconfigur
ationfromthechipcard.
TheLEDs"POWER","DIAG","FAULT","IFAULT"and"OFAULT"lightuponthebaseunit.
TheexpansionmodulePNOZmESProfibusisconfiguredandstartedautomatically.The
"ONLINE"and"OFFLINE"LEDsindicatethestatusofthePNOZmESProfibuson
PROFIBUSDP.
IftheexpansionmodulePNOZmESProfibusdoesnotreceiveaconfigurationfromthe
baseunitforaperiodof30s,theexpansionmodulePNOZmESProfibusconnectsto
PROFIBUSDPand"ONLINE"statusisdisplayedonPROFIBUSDP.Theerrormessage
"NoConnectionwithBaseModule"issenttotheMaster.

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 16
Legend:
LEDon
LEDflashes
LEDoff
LED Meaning
POWER Supplyvoltageispresent
Supplyvoltageisnotpresent
ONLINE PNOZmESProfibusOnline,dataexchangeispossible
Masterhassentthetelegram"GlobalControlClear".Virtualinputbitsi0...
i127aresetto"0".
PNOZmESProfibusNotonline
OFFLINE PNOZmESProfibusOffline,dataexchangeisnotpossible
PNOZmESProfibusNotoffline
FAULT ApplicationWatchdogTimeout
1Hz Configurationerror,lengthofinputand/oroutputdataduringinitialisationofthe
PNOZmESProfibusdoesnotmatchtheconfiguration
Remedy:
EnsurethattherightGSDfilehasbeenused.
2Hz Configurationerror,length/contentoftheconfigurationdataduringinitialisation
ofthePNOZmESProfibusdoesnotmatchtheconfiguration
Remedy:
EnsurethattherightGSDfilehasbeenused.
4Hz ErrorwheninitialisingPROFIBUSDP
Noerror
Technicaldetails
General 772132
Approvals CCC,CE,EAC(Eurasian),cULusListed

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 17
Electricaldata 772132
Supplyvoltage
for Modulesupply
Voltage 24V
Kind DC
Voltagetolerance 20%/+25%
Supplyvoltage
Currentconsumption 35mA
Powerconsumption 0,9W
Max.powerdissipationofmodule 1,50W
Statusindicator LED
PROFIBUSDPinterface 772132
Number 1
Fieldbusinterface 772132
Fieldbusinterface PROFIBUSDP
Unittype SlaveDPV0
Stationaddress 099d
Transmissionrate 9,6kBit/s12MBit/s
Connection 9pinfemaleDSubconnector
Galvanicisolation Yes
Testvoltage 500VAC
Environmentaldata 772132
Ambienttemperature
Inaccordancewiththestandard EN60068214
Temperaturerange 060°C
Forcedconvectionincontrolcabinetoff 55°C
Storagetemperature
Inaccordancewiththestandard EN6006821/2
Temperaturerange 2570°C
Climaticsuitability
Inaccordancewiththestandard EN60068230,EN60068278
Condensationduringoperation Notpermitted
EMC EN611312
Vibration
Inaccordancewiththestandard EN6006826
Frequency 10,0150,0Hz
Acceleration 1g
Shockstress
Inaccordancewiththestandard EN60068227
Acceleration 15g
Duration 11ms
Max.operatingheightabovesealevel 2000m
Airgapcreepage
Inaccordancewiththestandard EN611312
Overvoltagecategory II
Pollutiondegree 2

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 18
Environmentaldata 772132
Ratedinsulationvoltage 30V
Protectiontype
Inaccordancewiththestandard EN60529
Mountingarea(e.g.controlcabinet) IP54
Housing IP20
Terminals IP20
Mechanicaldata 772132
Mountingposition Horizontalontophatrail
DINrail
Tophatrail 35x7,5EN50022
Recesswidth 27mm
Material
Bottom PC
Front PC
Top PC
Conductorcrosssectionwithscrewterminals
1coreflexible 0,252,50mm²,2412AWG
2corewiththesamecrosssection,flexiblewithout
crimpconnectorsorwithTWINcrimpconnectors 0,201,50mm²,2416AWG
Rigidsinglecore,flexiblemulticoreormulticore
withcrimpconnector 0,51,5mm²
Torquesettingwithscrewterminals 0,50Nm
Connectiontype Springloadedterminal,screwterminal
Conductorcrosssectionwithspringloadedterminals:
Flexiblewith/withoutcrimpconnector 0,202,50mm²,2412AWG
Springloadedterminals:Terminalpointsperconnec
tion 2
Strippinglength 9mm
Dimensions
Height 101,4mm
Width 22,5mm
Depth 115,0mm
Weight 95g
Thestandardscurrenton201210apply.
Orderreference
Module
Producttype Features Orderno.
PNOZmESProfibus Fieldbusmodule,PROFIBUSforPNOZmBx 772132

PNOZmESProfibus
OperatingManualPNOZmESProfibus
1002698EN04 19
Accessories
Terminator,jumper
Producttype Features Orderno.
PNOZmm0.xpconnector
left
Jumperyellow/blacktoconnectthemodules,1piece 779260
Connectionterminals
Producttype Features Orderno.
Springterminals
PNOZmmcxp1pc.
Springloadedterminals,1pieces 783542
Springterminals
PNOZmmcxp10pcs.
Springloadedterminals,10pieces 783543
Screwterminals
PNOZmmcxp1pc.
Screwterminals,1piece 793542
Screwterminals
PNOZmmcxp10pcs.
Screwterminals,10pieces 793543

The Best of
German
En gineering
Partner of:
Support
Technical support is available from Pilz round the clock.
Americas
Brazil
[phone]
Canada
+1 888-315-PILZ (315-7459)
Mexico
[phone]
USA (toll-free)
+1 877-PILZUSA (745-9872)
Asia
China
[phone]
Japan
[phone]
South Korea
[phone]
Australia
[phone]
Europe
Austria
[phone]
Belgium, Luxembourg
[phone]
France
[phone]
Germany
[phone]
Ireland
[phone]
Italy
[phone]
Scandinavia
[phone]
Spain
[phone]
Switzerland
[phone]
The Netherlands
[phone]
Turkey
[phone]
United Kingdom
[phone]
You can reach our
international hotline on:
[phone]
[e-mail]
CMSE ®, InduraNET p ®, PAS4000 ®, PAScal ®, PASconfig ®, Pilz ®, PIT ®, PLID ®, PMCprimo ®, PMCprotego ®, PMCtendo ®, PMD ®, PMI ®, PNOZ ®, Primo ®, PSEN ®, PSS ®, PVIS ®, SafetyBUS p ®,
SafetyEYE ®, SafetyNET p ®, the spirit of safety ®are registered and protected trademarks of Pilz GmbH & Co. KG in some countries. We would point out that product features may vary
from the details stated in this document, depending on the status at the time of publication and the scope of the equipment. We accept no responsibility for the validity, accuracy
and entirety of the text and graphics presented in this information. Please contact our Technical Support if you have any questions.
Pilz develops environmentally-friendly products using
ecological materials and energy-saving technologies.
products and environmentally-friendly solutions.
Pilz GmbH & Co. KG
Felix-Wankel-Straße 2
73760 Ostfildern, Germany
Tel.: [phone]
Fax: [phone]
[e-mail]
www.pilz.com
100XXXX-DE-0X
0-0-2-3-000, 2014-00 Printed in Germany
© Pilz GmbH & Co. KG, 2014
1002698EN04,201406PrintedinGermany ©PilzGmbH&Co.KG,2011
Frontcover
