Pioneer OSK102 User manual

USER MANUAL OF SMART AC
CS374U-APP(OSK102)
16122000002774
20160524
Company will notbe liable forany issues
and problems causedby Internet, Wi-Fi
Router and SmartDevices. Please contact
the original providerto get furtherhelp.
NOTE:
IMPORTANT NOTE:
Read the manualcarefully before installing or
connecting your Smartkit. Make sureto save
this manual forfuture reference.

CONTENTS
Model: OSK102
Standard:IEEE 802.11b/g/n
Antenna Type:Wxternal omnidirectionalAntenna
Frequency:WIFI 2.4G
Maximum Transmitted Power: 15dBm Max
OOO O
Operation Temperature:0 C~45 C/32 F~113 F.
Operation Humidity:10%~85%
Power Input:DC 5V/300mA
1
2
SPECIFICATION
PRECAUTIONS
1
SPECIFICATION...................................................1
PRECAUTIONS....................................................1
DOWNLOAD AND INSTALL APP...........................2
INSTALL THE SMART KIT .....................................3
USER REGISTRATION.........................................4
NETWORK CONFIGURATION...............................5
HOW TO USEAPP ..............................................13
SPECIAL FUNCTIONS ........................................15
2
3
4
5
6
7
8
1
Applicable system: IOS, Android.
(Suggest:IOS 7.0, Android 4.0)
Note:
APP can not support the lastest software version of
Android and IOS system.
Due to special situation may be occured, we explicitly
claims below: Not all of the Andriod and IOS system
are compatible with APP. We will not be responsible
for any issue as a result of the incompatibility.
Wireless safety strategy
Smart kit only support WPA-PSK/WPA2-PSK encryption
and none encryption . WPA-PSK/WPA2-PSK encryption
is recommended.
Caution
Please Check The Service Website For More Information.
Smart Phone camera needs to be 5 million pixels or
above to make sure scan QR code well.
Due to different network situation, sometimes, request
Hereby, wedeclare that this AC is in compliance
with the essentialrequirements and other relevant
provisions of Directive1999/5/EC. The declaration
of conformity maybe consulted with sales agent.
DECLARATION OF CONFORMITY

DOWNLOAD AND INSTALL APP
INSTALL THE SMART KIT
3
4
23
Remove the protectivecap of thesmart kit
Open the frontpanel and insertthe smart kitinto
the reserved interface.
Insert
Attach the QRcode packed withSMART KITto the
side panel ofthe machine, ensureit is convenience
to be scannedby the mobilephone. Alternatively,
user can takepicture of theQR Code andsave in
into their ownphone.
1
2
3
Due to differentnetwork situation, control process may
return time-out sometimes.If this situationoccurs, the
display between boardand Appmay not bethe same,
please do notfeel confused.
NOTE:Company will notbe liable forany issues and
problems caused byInternet, Wi-Fi Routerand Smart
Devices. Please contactthe original providerto get
further help.
Android Phone users: scan QR Code A or go to google
play, search 'Nethome Plus' app and download it.
Iphone Users: scan QR Code B or go to App Store,
search 'Nethome Plus' app and download it.
Caution: QR CodeA and QR CodeB is onlyavailable
for downloadingAPP.
QR Code A
QR Code B
WARNING:This interface is only compatible with
SMART KITprovided by the manufacturer.
time-out could happen,thus, it is necessary to do
network configuration again.

USER REGISTRATION NETWORK CONFIGURATION
56
45
,
,
,
,
12
1
2
2
3
4
Click CreateAccount Enter your emailaddress
and password, andthen
click Registration .
08:42 20:14
VI50828_a
Creat Accout
Forgot password?
[email protected]
Enter your E-mail address
Password
I have read and agree to the terms of service
65% 61%
Sign in
Registration
Sign up
Please ensure your mobile device is connected to Wifi
router. Also, the Wifi router has already connected to
Internet before doing user registration and network
configuration.
It is better to log in your email box and active your
registration account by clicking link in case you forget
the password.
Caution:
It is necessary to forget any other around network and
make sure the Android or IOS device just connect to
the WIFI network you want to configure.
Make sure the Android or IOS device WIFI function
works well and can be connected back to your original
WIFI network automatically.
Kindly reminder:
'
'
'
'
When ACenters into AP mode, theair-conditioning
remote controller can'tcontrol it. It is necessary to
finish network configuration or power the AC again
in order tocontrol it. Alternatively, youneed to wait
8 minutes tolet the AC quit AP mode automatically.
Using Android device to do network configuration
Make sure your mobile device has already been
connected to the wifi network which you want to use.
Also, you need to forget other irrelative wifi network in
case it influences your cofiguration process.
Disconnect the power supply of AC.
Connect the power supply of AC, and continuously
press the digital display button or do not disturb button
seven times in 3 minutes.
When the AC displays AP , it means that the AC WIFI
has already entered into AP Mode.
'
'
'
'
Some type ofAC donot need the step to bein AP
mode

6 7
5Press +Add Device,
,
67
8
9
Scan QR Codewhich
is packed withsmart kit
Select your ownWiFi
network, for example
My Home (thepicture
is only forreference)
Enter your ownWiFi
router password and
click OK;
Configuration Success,
you can seethe device
on the list.
Home
Nong Jun
User name
+
Add Device
20:14
Align the QR code within the frame to scan
The first press of restart
61%
QR Code Pictures
My Home
Password
Cisco
Belkin
20:14
Air conditioner want to use your WiFi
61%
Network OK Home
User
+
Oasis
Add Device

8 9
6Scan QR Codewhich
is packed withsmart kit
5Press +Add Device,
,
,
,
7Read the instruction
above and pressthe
Home button toreturn
to the deviceinterface.
Click settings toenter
the setting page,select
WLAN/WIFI.
8
Search and connection
Settings
Airplane Mode
WLAN
Bluetooth
Cellular
On
Off
Connect to WIFI AC hot spot:
Return to the setting page of IOS Device > Click
WLAN > Select net_ac_xxxx > Return to the
current page.
Password: 12345678
SSID: net_ac_xxxx
Using IOS deviceto do networkconfiguration
Mak sure your mobile device has already been
connected to the wifi network which you want to use.
Also, you need to forget other irrelative wifi network in
case it influences your cofiguration process.
Disconnect the power supply of AC(some units).
Connect the power supply of AC, and continuously
press the digital display button or do not disturb button
seven times in 3 minutes.
When the AC displays AP , it means that the AC WIFI
has already entered into AP Mode.
'
'
'
'
20:14 61%
Settings
Airplane Mode
WLAN Smart
Bluetooth Off
Cellular Off
VPN
Notifications
Control Center
Do Not Disturb
General
Home
Nong Jun
User name
+
Add Device
20:14
Align the QR code within the frame to scan
The first press of restart
61%
QR Code Pictures
1
2
3
4

Type defultpassword:
12345678 and click
"Join "
Return to APP and
click Next
Choose net_ac_XXXX
9
10
12
11
13
Select your ownWiFi
network, for example
My Home (thepicture
is only forreference)
Enter your ownWiFi
router password and
click OK;
Settings WLAN
CHOOSE ANET WORK.....
ASUS-5GX
ASUS-2.4GX
bdptest1
bdptest1-5G
HIWIFI-22EF60
Midea
midea_fc_6866
MideaACIOT
net_ac_0010
zztest
20:14 61%
10 11
Search and connection
Settings
Airplane Mode
WLAN
Bluetooth
Cellular
On
Off
Connect to WIFI AC hot spot:
Return to the setting page of IOS Device > Click
WLAN > Select net_ac_xxxx > Return to the
current page.
Password: 12345678
SSID: net_ac_xxxx
Joining "net_ac_0010"....
20:14 61%
Cancel Join
Enter Password
Password
My Home
Password
Cisco
Belkin
20:14
Air conditioner want to use your WiFi
61%
Network OK

12 13
14
Configuration Success,
you can seethe device
on the list.
HOW TO USE APP
7
Please ensure bothyour mobile deviceand air
conditioner are connectedto the Internetbefore
using app tocontrol the airconditioner via internet,
please follow thenext steps:
12
Type yourown account
and password, Click
"Sign in "
Select the targetair
conditioner to enter
into the maincontrol
interface.
NOTE:
User
Oasis
Premier
Add Device
Home
User
+
Oasis
Add Device
08:42
VI50828_a
Creat Accout
Forgot password?
[email protected]
65%
Sign in
When finishing networkconfiguration, APPwill
display success cuewords on thescreen.
Due to differentinternet environment, it is possible
that the devicestatus still display offline . Ifthis
situation occurs, itis necessary topull and refresh
the device liston theAPP and makesure the device
status become online . Alternatively, user can
turn off theAC power and turn on it again, the device
status will become online after fewminutes.
,
,
,
,
,
,
,
,
,
,
,
,

14 15
3Thus, user cancontrol
air conditioners on/off
status, operation mode,
temperature, fan speed
and so on.
SPECIAL FUNCTIONS
8
Timer on/ Timer off
Weekly, user can make an appointment toturn on or
off ACon specific time. User also can choose
circulation to keepthe ACunder schedule control
every week.
NOTE:
Not all thefunction of theAPP isavailable on air
conditioner. Forexample: ECO, Turbo, Left andRight
Swing, Up andDown swing function,please check
the user manualto find moreinformation.
O
Including: Timeron, Timeroff, 8 C Heat, Sleep,
Check.
NOTE: If the airconditioner do notsupport the above
function, the functionwill be hidedfrom the function
list.
Timer On
Mon. Tues.
18:00
Timer Off
Mon. Tues.
02:00
o
8 Heating
Sleep
Check
Timer On
Mon. Tues.
18:00
Timer Off
Mon. Tues.
02:00
o
8 Heating
Sleep
Check

16 17
O
8 CHeat
O
User can letthe ACrun under 8 C Heat by one-click.
When people gooutisde, this functioncan protect
your furniture fromfrost damage.
09
10
11
08 48
49
50
51
Repeat Mon,Tue
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Timer On
Mon. Tues.
18:00
Timer Off
Mon. Tues.
02:00
o
8 Heating
Sleep
Check

18 19
Sleep
User can customizetheir own comfortablesleep
by setting targettemperature.
Check
User can simplycheck theAC running statuswith
this function. Whenfinishing this procedure,it can
display the normalitems, abnormal items,and
detail information.
edit
young
Elder
Children
Timer On
Mon. Tues.
18:00
Timer Off
Mon. Tues.
02:00
o
8 Heating
Sleep
Check
Testing 97
97
Normal
0
Abonormal

20
CAUTIONS
This device complies with Part 15 of the FCC Rules
and RSS 210 of Industry & Science Canada. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Only operate the device in accordance with the
instructions supplied. This device complies with FCC
and IC radiation exposure limits set forth for an
uncontrolled environment. In order to avoid the
possibility of exceeding the FCC and IC radio frequency
exposure limits, human proximity to the antenna shall
not be less than 20cm (8 inches) during normal operation.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
Abnormal:0
Normal:97
Compressor frequency
Compressor current
Outdoor machine current
Evaporator temperature
Condenser temperature
Exhaust temperature
Outdoor temperature
21
