Pioneer N-30AE User manual

E
N
Before Start
What's in the box .................................................................... 2
Part Names
Front Panel ............................................................................. 3
Rear Panel .............................................................................. 4
Remote Controller .................................................................. 5
Display .................................................................................... 6
Install
Connections with an amplifier ................................................. 7
Connecting the power cord, etc. ............................................. 9
Initial Setup
Power On & Initial Setup ...................................................... 10
Playback
USB Storage Device/HDD .................................................... 12
Internet Radio ....................................................................... 14
Spotify ................................................................................... 15
AirPlay® ................................................................................ 16
Music Server ......................................................................... 17
Entering text ......................................................................... 19
Advanced Setup
Advanced Settings................................................................. 20
Firmware Update
Firmware Update .................................................................. 23
Others
Troubleshooting .................................................................... 25
General Specifications .......................................................... 27
License and Trademark Information ..................................... 28
> Before Start > Part Names > Install > Initial Setup > Playback
Advanced Setup | Firmware Update | Others
NETWORK AUDIO PLAYER
N-30AE
Instruction
Manual

2
> Before Start > Part Names > Install > Initial Setup > Playback
Advanced Setup |Firmware Update | Others
E
N
What's in the box
Before Start
0The power cord must be connected only after all other cable connections are completed.
0We will not accept responsibility for damage arising from the connection of equipment
manufactured by other companies.
0Functionality may be introduced by firmware updates and service providers may cease
services, meaning that some network services and content may become unavailable in
the future.
0Specifications and appearance are subject to change without prior notice.
Main unit (1)
Remote controller (RC-944E) (1), Batteries (AAA/R03) (2)
Analog audio cable (1)
Power cord (1)

> Before Start >PartNames > Install > Initial Setup > Playback
Advanced Setup |Firmware Update | Others
3
E
N
Front Panel
Part Names
1. ÍSTANDBY/ON button: Turns the unit on or to standby mode.
2. STANDBY/ON indicator: This lights red when this unit is on standby and blue when it is
on.
3. Display (P6)
4. SOURCE button: Switches the input to be played.
5. Play button:
∫ : This button stops playback.
1 /; : This button pauses the playback.
:6 : Move to the previous track.
59 : Move to the next track.
0Depending on the input, the operation may not start.
6. Remote control sensor
7. USB
port: Connect a USB storage device or HDD (hard disk drive) to play music files. You can
also supply power (maximum 5 V/0.5 A) to USB devices with a USB cable.
0When connecting a HDD that requires more than 5 V/0.5 A, connect to the USB port
(maximum 5 V/1 A) on the rear of the unit.


 


4
> Before Start >PartNames > Install > Initial Setup > Playback
Advanced Setup |Firmware Update | Others
E
N
Rear Panel
1. AC IN: Connect the supplied power cord.
2. Wireless antenna: Used for Wi-Fi connection. Adjust their angles according to the
connection status.
3. USB port: Connect a USB storage device or HDD (hard disk drive) to play music files. You
can also supply power (maximum 5 V/1 A) to USB devices with a USB cable.
4. NETWORK jack: Connect to the network with an ethernet cable.
5. CONTROL OUT jack: By connecting Pioneer brand amplifiers and CD players,
centralized control is possible, for example you can control the amplifiers and CD players
from the Pioneer Remote App.
6. ANALOG OUT jacks: Use the supplied analog audio cable to connect an integrated
amplifier, for example.
1
2

   


180°
90°

> Before Start >PartNames > Install > Initial Setup > Playback
Advanced Setup |Firmware Update | Others
5
E
N
Remote Controller
1. ÍSTANDBY/ON button: Turns the unit on or into standby mode.
2. DIMMER button: Switch the display off or adjust the brightness of the display in three
steps.
3. INPUT SELECTOR buttons: Switches the input to be played.
4. button: Input source played switches each time you press one of these buttons.
5. SHUFFLE button: Set shuffle play.
6. REPEAT button: Set repeat play.
7. TOP MENU button: Move to the top menu of the selected input.
8. Cursors, ENTER button: Select the item with the cursors and press ENTER to confirm.
9. SETUP button: Displays the Setup menu.
10. Play buttons:
:: Move to the track before the one being played.
/;: Play or pause play.
9: Move to the next track.
∫: Stop playback.
0Depending on the input, the operation may not start.
11. CLEAR button: Used when entering text, etc.
12. DISPLAY button: Press to turn off the display of this unit. Press again to turn the display
on.
13. NOW PLAYING button: When you have changed the display during play, for example, this
button returns the display to show information about the file being played.
14. RETURN button: Returns the display to the previous state.
15. NET RADIO MENU button:Use this when playing the internet radio.
0HOME MEDIA, OPTION, 22, and 11 are not used.















30° 30°
Approx.7 m

6
> Before Start >PartNames > Install > Initial Setup > Playback
Advanced Setup |Firmware Update | Others
E
N
Display
1. The input mode is displayed.
(USB Front / USB Rear / Music Server / Network)
2. The name of the file, artist, album, etc., is displayed.
3. Displays the play status.
4. Displays file format, sampling frequency, and quantization bit information.
5. The file play status is displayed. This may not be displayed depending on the input or file.
6. Lights in the following conditions.
:
When the connection setting on the unit is " Wired " and the unit is connected to the network.
: When the connection setting on the unit is " Wired " and the unit is not connected to the network.
: When the connection setting on the unit is " Wi-Fi " and the unit is connected to the network.
: When the connection setting on the unit is " Wi-Fi " and the unit is not connected to the network.
7. If an album jacket is recorded for the file being played, it is displayed here.
8. Lights in the following conditions.
: When all track repeat play is on
: When one track repeat play is on
: When shuffle play is on
0When DISPLAY on the remote controller is pressed to turn off the display, the unit may
appear the same as if you had unplugged the unit from the power outlet, but electricity is
still being supplied to the unit. To completely cut the unit off from the power supply, you
need to unplug the power plug (shutoff device) unit from the power outlet.
00:01:45 / 00:03:23
FLAC
44.1kHz/24bit
USB Front
Song
Artist
Album








1

7
E
N
> Before Start > Part Names >Install > Initial Setup > Playback
Advanced Setup | Firmware Update | Others
Connections with an amplifier
Install
a
1
2
a
a
N-30AE
1
2
a Analog audio cable
Integrated amplifier, AV receiver, etc.
Connection with an analog audio cable
You can play the audio from network features such as
internet radio through speaker systems connected to
integrated amplifiers or AV receivers. To connect, use the
supplied analog audio cable to connect from the ANALOG
OUT jack on this unit to the LINE IN input on an integrated
amplifier, AV receiver, etc.

8
> Before Start > Part Names >Install > Initial Setup > Playback
Advanced Setup | Firmware Update | Others
E
N
The control jack
By connecting Pioneer brand amplifiers or CD players, for
example, that have control jacks using monaural miniplug
cables (without resistors), you can centralize control of the
devices using the Pioneer Remote App.
Furthermore, even when the other devices are put in places
where the remote control signal is unable to reach, you can
enable operation of the other components through the
remote control sensor of this unit.
0Also make sure to connect with the analog audio cable.
Centralized control cannot work correctly with only the
control jack connection.
0With this connection, the remote control sensors on the
amplifier and CD player stop working. Point the remote
controller at remote control sensor of this unit.
a
a
CONTROL
IN
OUT
CONTROL
IN
OUT
CD player
Amplifier
N-30AE
a Monaural miniplug cables (without resistors)

9
> Before Start > Part Names >Install > Initial Setup > Playback
Advanced Setup |Firmware Update | Others
E
N
Connecting the power cord, etc.
a
a
1 2
Power cord connection
This model includes a removable power cord.
The power cord must be connected only after all other
connections are completed. Make sure you first connect the
power cord to AC IN terminal of the unit and then connect to
the outlet. Always disconnect the outlet side first when
disconnecting the power cord.
Ethernet cable connection
To connect to the network with an ethernet cable, use the
NETWORK jack. When using Wi-Fi connection, make
settings in initial settings (P10). You can enjoy features
such as internet radio and AirPlay by connecting to the
network.
a Power cord

10
> Before Start > Part Names > Install > Initial Setup >Playback
Advanced Setup |Firmware Update | Others
E
N
Power On & Initial Setup
Initial Setu p
1
3
2
BLUEBLINKING
Starting up: When you press ÍSTANDBY/ON, the power
indicator on the main unit slowly blinks blue, then "Hello" is
displayed on the display about 20 seconds later. After this,
the display goes blank, then after the Pioneer logo is
displayed, you can start operating the unit.
Wi-Fi connection settings
When you first turn the power on, the initial setup screen is
displayed automatically, allowing you to easily make Wi-Fi
connection settings.
To set, select the item with the cursors on the remote
controller and press ENTER to confirm. To return to the
previous display, press RETURN.
To make Wi-Fi settings, select "Wi-Fi". If you have
connected with an ethernet cable, select "Wired(Exit)" and
confirm. If you select "Wi-Fi", select the method for setting in
the next screen (for example "Scan Networks").
Initial Setup
Wired (Exit)
Wi-Fi
Selects the method of network
connection
