Precor CW-608 User manual

CW-608


CW-608 Assembly Guide
page 3
IMPORTANT SAFETY INSTRUCTIONS
Important Safety Instructions
Important Safety Guidelines
for Owners
Follow these guidelines to maintain proper working
condition of the equipment:
Important: Do not modify the equipment or any of
its parts, or permanently remove any part from the
equipment. Do not use accessory attachments that
are not recommended by Precor, as such attachments
might cause injuries.
• Qualiedtechniciansmustperformallregular
maintenance.
• Makesurethattrainers,facilitypersonnel,and
maintenance technicians understand how to use
theequipment,knowimportantsafetyguidelines,
and can recognize potential problems such as a
worn cable or cracked weld.
• Strengthtrainingrequiresasignicantfocusbythe
facilityanditsstafftomaintainthequalityofthe
tnessenvironment.Ifpossible,thefacilityshould
providedirectsupervisionofthetnessequipment
atalltimesbypeopleknowledgeableaboutthe
safe operation of the equipment and trained to
recognize potential problems.
• Ifanystaffmemberwitnessunsafeuseofthe
equipment,heorsheshouldaddresstheuser
directly,demonstratethepropertechnique,
andreviewtheImportant Safety Information for
Users. Precor recommends posting a copy of the
ImportantSafetyInformationforUsersnear the
equipment in a prominent location.
• Makesuretheequipmentisstableandplacedon
asolid,levelsurface.Theequipmentisdesignedto
befreestanding;however,equipmentcanbebolted
totheoorforextrastability.Consultaqualied
general contractor for proper fastening methods.
• Makesurethattheequipmentisinstalledwith
enough free space for safe operation. With most
equipment,thegeneralruleistoallowabouta
4-foot (1.2-meter) circle of space from the user’s
center.ForFunctionalTrainingequipment,make
sure that the operating space is large enough to
allowthecablestobefullyextendedinallpossible
directions.
• Checktheequipmentthoroughlybasedonthe
recommended inspection schedules outlined in
thismanual,includingdaily,weekly,monthlyand
annual checks.
• Placean“out-of-order”signontheequipment
during maintenance of the equipment or the
surroundingarea.Usersshouldneverbe
allowed to operate the equipment until it has
beeninspectedandworksproperly.Ifapieceof
equipmentneedsservice,keepitoutofuseuntil
repaired.
• Wheneveraweightcandropandhita
user,suchaswithanOlympicbench,
Precorhighlyrecommendsthata
helper or spotter be used.
• Donotplacetheequipmentoutdoorsor
on wet surfaces.
Obtaining Service
For information about product operation
orservice,refertothePrecorwebsite
atwww.precor.comwhereyoucanalso
ndcustomersupportnumbersoralistof
Precorauthorizedservicecenters.
Ifyoucallore-mailCustomerSupport,have
theserialnumberavailable.
Youcanndtheserialnumberprintedon
alabelafxedtotheequipment.Forfuture
reference,writetheserialnumberinthe
spaceprovidedbelow.
Serialnumber:
_______________________

CW-608 Assembly Guide
page 4
IMPORTANT SAFETY INSTRUCTIONS
Important Safety Instructions
Important Safety Information
for Users
Beforebeginninganytnessprogram,youshould
obtainacompletephysicalexaminationfromyour
physician.
French equivalent of the preceding paragraph, for the
Canadian market: Il est conseillé de subir un examen
médical complet avant d’entreprendre tout programme
d’exercise. Si vous avez des étourdissements ou des
faiblesses, arrêtez les exercices immédiatement.
Whenusingexerciseequipment,youshouldalways
takebasicprecautions,includingthefollowing:
• Ifyoudonotunderstandhowtooperateapieceof
equipment,asksomeonefromthefacilitysuchas
a trainer to demonstrate how to use it and explain
anysafetyinstructions.
• Donotallowchildrenonorneartheequipment.
Donotleavechildrenunsupervisedaroundthe
equipment.
• Usetheequipmentonlyforitsintendedpurpose.
Donotuseaccessoryattachmentsthatarenot
recommendedbythemanufacturer,assuch
attachmentsmaycauseinjuries.
• Wearproperexerciseclothingandshoesforyour
workout—no loose clothing.
• Do not overexert yourself or work to
exhaustion.Usereasonablejudgmentwhen
workingwithweights.Avoidusingexcessive
weight,whichmaycauseinjury.
• Ifyoufeelpain,faintness,dizziness,orabnormal
symptoms,stopexercisingimmediatelyand
consultyourphysician.
• Keephead,limbs,ngers,andhairclearofall
movingpartswhiletheequipmentisinuse.Keep
hands clear of racking pegs.
• Neverdroporinsertobjectsintoanyopeninginthe
equipment.
• Alwayschecktheequipmentbeforeusingit.If
youspotapotentialproblem,contactsomeonein
thefacilityimmediately.Donotusetheequipment
untilthefacilityhasveriedthattheequipmentis
workingproperly.Donotattempttoxabrokenor
jammedmachine.
• Donotusetheequipmentoutdoorsor
on wet surfaces.
• Donotdroporslamtheweightstack
while exercising.
• Donotusetheequipmentifan
“outoforder”signhasbeenplaced
on it.
• Readallpostedinstructions,including
allsafetyinstructionsandwarnings.

CW-608 Assembly Guide
page 5
Important Safety Guidelines for Owners ................................................................ 3
ObtainingService...................................................................................................................................... 3
Important Safety Information for Users................................................................... 4
Preparations............................................................................................................... 6
UnpackingtheEquipment ......................................................................................................................... 6
RequiredTools ......................................................................................................................................... 6
InstallationRequirements.......................................................................................................................... 6
Hardware Kit ............................................................................................................................................. 7
Assembly Instructions .............................................................................................. 9
OpentheBox ............................................................................................................................................ 9
AssembletheUnit ..................................................................................................................................... 10
CleantheUnit ........................................................................................................................................... 13
Specifications ............................................................................................................16
Table of Contents
1
2
Table of Contents

CW-608 Assembly Guide
page 6
1Preparations
Preparations
TheCW-608partsareinspectedbeforeshipment.
Eachunitcontainsseveralpiecesthatrequire
assembly.Youwillneedtoobtainadultassistance
duringtheassemblyprocess.
Unpacking the Equipment
Whenyouopenthebox,carefullyunpackthepieces
andlaythemontheoornearthelocationwhereyou
plan to use them.
CAUTION: Be careful when you remove the
packaging material with a utility knife. Do not
scratch the paint.
Ifanyitemsaremissing,contactthedealerfromwhom
youpurchasedtheunit.Formoreinformation,referto
Obtaining Service.
Required Tools
Toolsthatyouneedtoobtainbeforeassemblingthe
unit include:
❏ Wirecutterorutilityknife
❏¾-inch open-end wrench
Installation Requirements
Follow these installation requirements when
assembling the unit:
• Review the Important Safety Guidelines for
Owners.
• Assemble the unit where it will be used.
Provideamplespacearoundtheunit.
• Install components in the sequence shown.
•Insert all fasteners in the same direction.
Foraestheticpurposes,insertallthefasteners
inthesamedirectionunlessspecied(intextor
illustrations) to do otherwise.
• Leave room for adjustments.Tightenthe
fastenerstokeeptheunitstable,butleaveroom
foradjustments.Donotfullytightenfastenersuntil
instructed to do so.

CW-608 Assembly Guide
page 7
½x5-inchCarriagebolt(G) 14
½x¾-inchButtonheadscrew(E) 8
½x4¾-inchButtonheadscrew(D) 8
Fastener Qty Fastener Qty
Hardware Kit
Preparations, continued
½x5¼-inchButtonheadscrew(A) 8
½-inchLocknut(C) 30
½-inch Washer (B) 50
½-inchSplitwasher(F) 12
Hat washer (H) 30
Plasticcap(J) 30

CW-608 Assembly Guide
page8
Fastener Qty
Hardware Kit (continued)
Bumper(M) 8
Preparations, continued
½ x 1¼-inch Buttonhead screw (K) 4
Spacer(L) 4

CW-608 Assembly Guide
page 9
2Assembly
Instructions
Assembly Instructions
AssemblyoftheCW-608takesabout40minutesto
complete.Ifthisisthersttimeyouhaveassembled
thistypeofequipment,planonallowingmoretime.
Be careful to open boxes and assemble components in
the sequence presented in this manual.
Note:Withsomanyassembledparts,properalignment
andadjustmentiscritical.Whiletighteningthe
fasteners,besuretoleaveroomforadjustments. Do
not fully tighten fasteners until instructed to do so.
Open the Box
Usewirecutterstoopentheboxandremovethe
packing materials.
TheillustrationshowshowtheCW-608willlookwhen
youhavecompleteditsassembly.Thecalloutsidentify
specicpieces.
Cross Brace
Rear Upright
Rear Base
Front Upright
Weight Bar Plate
Safety Catch
Plate
Weight Plate
Holder

CW-608 Assembly Guide
page 10
Assemble the Unit
1. AttachtheRearBasetotheRearUprightswithtwo
longBackingPlatesusing
four 5¼-inch buttonhead screws (A)
eight ½-inch washers (B)
four ½-inch hat washers (H)
four½-inchlocknuts(C)
LooselytightenthefastenerssotheRearUprights
are stable.
2. AttachtheCrossBracetotheRearUprightswith
twoshortBackingPlatesusing
four 5¼-inch buttonhead screws (A)
eight ½-inch washers (B)
four ½-inch hat washers (H)
four½-inchlocknuts(C)
Wrench tighten both sets of fasteners using a
¾-inchopen-endwrenchandsnapaplasticcap(J)
overeachlocknut.
Note: You will need a ¾-inch open-end wrench to
tightenmostofthefastenersinthisassembly.
Assemble the Unit
4-5¼”buttonheadscrews
8-washers
4 - hat washers
4 - locknuts
4 - plastic caps
4-5¼”buttonheadscrews
8-washers
4 - hat washers
4 - locknuts
4 - plastic caps
Rear Upright
Rear Base
Cross Brace

CW-608 Assembly Guide
page 11
3. AttachtwoconnectorstotheRearUprightsusing
four4¾-inchbuttonheadscrews(D)
eight ½-inch washers (B)
four½-inchlocknuts(C)
Looselytightenthefasteners.
4. AttachthelowerFrontUprightstotheConnectors
using
four4¾-inchbuttonheadscrews(D)
eight ½-inch washers (B)
four½-inchlocknuts(C)
LooselytightenthefastenerssotheFrontUprights
are stable.
5. AttachtheupperFrontUprightstotheRear
Uprightsusing
eight¾-inchbuttonheadscrews(E)
eight ½-inch split washers (F)
Wrench tighten all three sets of fasteners.
Assemble the Unit, continued
8-¾”buttonheadscrews
8-splitwashers
4-4¾”buttonheadscrews
8-washers
4 - locknuts
Front Upright
Connector
4-4¾”buttonheadscrews
8-washers
4 - locknuts

CW-608 Assembly Guide
page 12
Important: Inthefollowingtwosteps,insertthe
bolts so that their heads face outward on both
sides.Iftheheadsoftheboltsfaceinward,their
threaded ends can protrude far enough to damage
thenishonbarbellweightplates.
6. Attachtheleft-handWeightBarPlatetotheoutside
oftheleft-handFrontUprightusing
ve5-inchcarriagebolts(G)
ve½-inchwashers(B)
ve½-inchhatwashers(H)
ve½-inchlocknuts(C)
WrenchtightenandsnapaPlasticCap(J)over
each locknut.
7. Repeat step 6 to attach the right-hand Weight Bar
Platetotheoutsideoftheright-handFrontUpright.
8. AttachaSafetyCatchPlatetotheoutsideofeach
FrontUprightusing
four5-inchcarriagebolts(G)
four ½-inch washers (B)
four ½-inch hat washers (H)
four½-inchlocknuts(C)
WrenchtightenandsnapaPlasticCap(J)over
each locknut.
4-5”carriagebolts
4 - washers
4 - hat washers
4 - locknuts
4 - plastic caps
Assemble the Unit, continued
10-5”carriagebolts
10 - washers
10 - hat washers
10 - locknuts
10 - plastic caps
Weight Bar
Plate
Safety Catch
Plate

CW-608 Assembly Guide
page 13
Assemble the Unit, continued
9. InsertthefourWeightPlateHoldersintotheRear
Uprights.TurntheWeightPlateHolderssothe
mounting holes align with the holes in the Rear
Uprights.
10. SecuretheWeightPlateHoldersusing
four 1¼-inch buttonhead screws (K)
four ½-inch split washers (F)
four ½-inch washers (B)
four spacers (L)
Wrench tighten.
Note: Foreaseofassembly,placeasplitwasher,
aatwasher,andaspacerontoeachscrewbefore
inserting the screw.
11. SlideaBumper(M)ontoeachendoftheWeight
PlateHolders,andpressrmlyagainsttheRear
Uprights.
Note: MakesurethesmallsideoftheBumper
facestheRearUprights.
ThiscompletestheassemblyoftheCW-608.
Clean the Unit
Tocleantheunit,moistenaclean,softclothinamild
solution of soap and water and wipe all the parts
thoroughly.
FrequentlyvacuumtheoorunderneaththeCW-608to
preventtheaccumulationofdustanddirt.
4-1¼”buttonheadscrews
4 - split washers
4 - washers
4 - spacers
Weight Plate
Holder

CW-608 Assembly Guide
page 14
Notes:

CW-608 Assembly Guide
page 15
Notes:

Precor,Icarian,andMoveBeyondareregisteredtrademarksofPrecorIncorporated.
Copyright2014PrecorIncorporated.
Specicationssubjecttochangewithoutnotice. 
www.precor.com
NOTICE:
Precoriswidelyrecognizedforitsinnovative,awardwinningdesignsofexerciseequipment.PrecoraggressivelyseeksU.S.and
foreignpatentsforboththemechanicalconstructionandthevisualaspectsofitsproductdesign.Anypartycontemplatingtheuseof
Precor’sproductdesignsisherebyforewarnedthatPrecorconsiderstheunauthorizedappropriationofitsproprietaryrightstobea
veryseriousmatter.Precorwillvigorouslypursueallunauthorizedappropriationofitsproprietaryrights.
PrecorIncorporated
20031142ndAvenueNE
P.O.Box7202
Woodinville,WAUSA98072-4002
1-800-347-4404
CW-608 Specifications
Length:73inches(184cm)
Height: 71 inches (179 cm)
Width:68inches(173cm)
Shippingweight:315lb(143kg)
CW-608 Assembly Guide CW33683-107 rev G
17 December 2014

General Safety &
Maintenance Manual
Precor Icarian Line
Commercial Strength Equipment

General Safety and Maintenance Manual: Important Safety Guidelines for Owners 1
IMPORTANT SAFETY GUIDELINES
Important Safety Guidelines for Owners
Follow these guidelines to maintain proper working condition of the
equipment:
Important: Do not modify the equipment or any of its parts, or
permanently remove any part from the equipment. Do not use
accessory attachments that are not recommended by Precor, as
such attachments might cause injuries.
• Qualified technicians must perform all regular maintenance.
• Check that all fasteners are securely tightened. Cables should be
secured at both end connections and properly threaded. Weight
stacks should be secure and functioning properly. Handle
attachments should be properly connected.
• Make sure that trainers, facility personnel, and maintenance
technicians understand how to use the equipment, know
important safety guidelines, and can recognize potential
problems such as a worn cable, loose hardware, or cracked
weld.
• Strength training requires a significant focus by the facility and its
staff to maintain the quality of the fitness environment. If possible,
the facility should provide direct supervision of the fitness
equipment at all times by people knowledgeable about the safe
operation of the equipment and trained to recognize potential
problems.

General Safety and Maintenance Manual: Important Safety Guidelines for Owners 2
IMPORTANT SAFETY GUIDELINES
• If any staff member witnesses unsafe use of the equipment, he or
she should address the user directly, demonstrate the proper
technique, and review the Important Safety Information for
Users. Precor recommends posting a copy of the Important
Safety Information for Users near the equipment in a prominent
location.
• Make sure the equipment is stable and placed on a solid, level
surface. The equipment is designed to be freestanding; however,
it can be bolted to the floor for extra stability. Precor highly
recommends that the equipment be bolted to the floor to reduce
the risk of toppling the equipment due to improper use. Since
floor construction varies, please consult a professional building
engineer for proper fastening.
• Locate the equipment at least 40 inches (1 meter) away from
walls or furniture on either side of the equipment, and 40 inches
(1 meter) away from objects behind the equipment. For
Functional Training equipment, make sure that the operating
space is large enough to allow the cables to be fully extended in
all possible directions.
• Check the equipment thoroughly based on the recommended
inspection schedules outlined in this manual, including daily,
weekly, monthly and annual checks. Ensure all bolt connections
are tight and that the threaded cables are properly and tightly
secured at both ends.
• Place an “out-of-order” sign on the equipment during
maintenance of the equipment or the surrounding area. Users
should never be allowed to operate the equipment until it has
been inspected and works properly. If a piece of equipment
needs service, keep it out of use until it is repaired.
