USERʼS MANUAL
CAUT ON
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
Model No. PFEVEX39832
Serial No.
QUEST ONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. f you
have questions, or if there are
missing parts, please call:
Or write:
CON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road ndustrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
08457 089 009
Class HC Fitness Product

2
TABLE OF CONTENTS
MPORTANTPRECAUTONS ................................................................3
BEFOREYOUBEGN ......................................................................4
ASSEMBLY ...............................................................................5
HOWTOOPERATETHEEXERCSECYCLE....................................................9
MANTENANCEANDTROUBLESHOOTNG ...................................................19
CONDTONNGGUDELNES...............................................................20
PARTLST ..............................................................................22
EXPLODEDDRAWNG ....................................................................23
ORDERNGREPLACEMENTPARTS ..................................................BackCover
PROFORM is a registered trademark of CON Health & Fitness, nc.

3
1. Read all instructions in this manual before
using the exercise cycle.
2. t is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions. Use the
exercise cycle only as described in this manual.
3. Use the exercise cycle indoors on a level sur-
face. Keep the exercise cycle away from
moisture and dust. Place a mat under the
exercise cycle to protect the floor.
4. nspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
6. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes for foot protection.
7. The exercise cycle should not be used by
persons weighing more than 115 kg (250 lbs.).
8. Always keep your back straight when using
the exercise cycle; do not arch your back.
9. f you feel pain or dizziness while exercising,
stop immediately and cool down.
10.The exercise cycle does not have a freewheel;
the pedals will continue to move until the fly-
wheel stops.
11. The pulse sensor is not a medical device.
Various factors, including the userʼs move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12.The exercise cycle is intended for home use
only. Do not use the exercise cycle in
a commercial, rental, or institutional setting.
13.A warning decal has been placed on the exer-
cise cycle in the location shown on page 4. f
the decal is missing, or if it is not legible,
please call our Customer Service Department
at 0345-089009 to order a free replacement
decal. Apply the decal in the location shown.
WARN NG: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. CON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
MPORTANT PRECAUT ONS
WARN NG: To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.

4
Congratulations for selecting the new PROFORM®745
EKG exercise cycle. Cycling is one of the most effec-
tive exercises for increasing cardiovascular fitness,
building endurance, and toning the entire body. The
PROFORM®745 EKG exercise cycle offers an impres-
sive array of features to let you enjoy this healthful
exercise in the convenience and privacy of your home.
For your benefit, read this manual carefully before
you use the exercise cycle. f you have questions
after reading this manual, please call our Customer
Service Department at 08457 089 009. To help us
assist you, please note the product model number
and serial number before calling. The model number
is PFEVEX39832. The serial number can be found on
a decal attached to the exercise cycle (see the front
cover of this manual).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Water Bottle Holder*
*No water bottle is included
Pulse Sensor
REAR
Seat
Adjustment Knob Pedal/Strap
Console
Fan
Wheel
Adjustment Handle
Handlebar
Adjustment Knob
R GHT S DE
BEFORE YOU BEG N

5
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable spanner and Phillips
screwdriver .
Use the part drawings below to identify the small parts used in assembly. The number in parenthesis below
each drawing refers to the key number of the part, from the PART L ST on page 22. The second number refers
to the quantity needed for assembly. Note: Some small parts may have been pre-attached for shipping. f a
part is not in the parts bag, check to see if it has been pre-attached.
M10 x 65mm Carriage Bolt (65)–4
M8 Nylon
Locknut (10)–4
M10 Black Nylon
Locknut (63)–4
M8 Split
Washer (64)–7
M8 Washer
(67)–1
M4 x 16mm
Screw (66)–4
M4 x 22mm
Screw (71)–2
M8 x 25mm Button
Screw (14)–3

6
1. dentify the Front Stabiliser (2). While another person
lifts the front of the Frame (1) slightly, attach the Front
Stabilizer to the Frame with two M10 x 65mm Carriage
Bolts (65) and two M10 Black Nylon Locknuts (63).
Make sure that the Front Stabiliser is turned so the
Wheels (50) are not touching the floor.
2
50
50
63
65
1
1
2. While another person lifts the back of the Frame (1)
slightly, attach the Rear Stabilizer (9) to the Frame with
two M10 x 65mm Carriage Bolts (65) and two M10
Black Nylon Locknuts (63).
65
9
1
3
13
1
36
73
64
14
14 14
71
70
64
2
63
63
4. The Console (16) requires four “D” batteries (not
included); alkaline batteries are recommended.
Remove the screw from the battery drawer. Pull the
battery drawer open and insert four batteries. Make
sure that the batteries are oriented as shown by
the markings inside the battery drawer. Close the
battery drawer and reattach the screw. Note: When the
batteries are installed correctly, the fan will turn on for a
moment.
16 Batteries
Battery
Drawer
4
Screw
3. Whilst another person holds the Upright (13) in the
position shown, connect the Upper Wire Harness (36)
to the Lower Wire Harness (73).
Slide the Upright (13) onto the Frame (1). Be careful to
avoid pinching the Wire Harnesses (36, 73). Attach
the Upright to the Frame with three M8 x 25mm Button
Screws (14) and three M8 Split Washers (64).
Attach the Water Bottle Holder (70) to the Upright (13)
with two M4 X 22mm Screws (71).

7
7. Turn the indicated Adjustment Knob (28) counterclock-
wise two or three turns to loosen it. Next, pull the Knob,
insert the Seat Post (5) into the Frame (1), and then
release the Knob. Move the Seat Post up and down
slightly until the pin on the Knob snaps into one of
the holes in the Seat Post. Then, turn the Knob clock-
wise until it is tight. 1
5
28
7
6. Hold the Console (16) near the Upright (13). Connect
the console wire to the Upper Wire Harness (36).
nsert the excess wire into the Upright.
Attach the Console (16) to the Upright (13) with four
M4 x 16mm Screws (66). Be careful to avoid pinch-
ing the wires.
5. Slide the two slots in the Handlebar Clamp (49) onto the
two indicated tabs on the Upright (13). Lift the bottom of
the Handlebar Clamp away from the Upright, and insert
the Handlebar (15) between the Handlebar Clamp and
the Upright. Centre the Handlebar and rotate it to the
desired position.
Slide an M8 Washer (67) onto the Adjustment Handle
(53). nsert the Adjustment Handle into the Handlebar
Clamp (49) and tighten the Adjustment Handle into the
Upright (13). Note: The Adjustment Handle works like a
spanner. Turn the Handle clockwise, pull it away from
the Upright, turn it counterclockwise, push it toward the
upright, and then turn it clockwise again.
53
49
15
67
13
5
Tabs
6
16
36
13
Console
Wire
66
66
8. Attach the Seat (12) to the Seat Bracket (6) with four
M8 Nylon Locknuts (10) and four M8 Split Washers
(64). Note: The Nylon Locknuts and the Split Washers
may be pre-attached to the underside of the Seat.
Turn the Adjustment Knob (28 counterclockwise two or
three turns to loosen it. Next, pull the Knob, slide the
Seat Bracket (6) into the top of the Seat Post (5), and
then release the Knob. Move the Seat Bracket for-
ward and backward slightly until the pin on the
Knob snaps into one of the holes in the Seat
Bracket. Then, turn the Knob clockwise until it is tight.
Note: f desired, you can attach your own seat to the
exercise cycle using the Adapter Bracket (not shown) in
place of the Seat (12) and the Seat Bracket.
5
10
64
6
12
64
10
28
8

8
10. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
9. dentify the Left Pedal (24), which is marked with an
“L.” Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the Left Crank Arm
(42). Tighten the Right Pedal (not shown) clockwise
into the Right Crank Arm. mportant: Tighten both
Pedals as firmly as possible. After using the
exercise cycle for one week, retighten the Pedals.
For best performance, the Pedals must be kept
tightened.
Adjust the Left Pedal Strap (25) to the desired posi-
tion, and press the end of the Pedal Strap onto the
tab on the Left Pedal (24). Adjust the Right Pedal
Strap (not shown) in the same way.
9
24
42
25
Tab

9
HOW TO OPERATE THE EXERC SE CYCLE
HOW TO ADJUST THE SEAT POST
For effective exer-
cise, the seat
should be at the
proper height. As
you pedal, there
should be a slight
bend in your knees
when the pedals
are in the lowest
position. To adjust
the height of the
seat, first turn the
indicated knob
counterclockwise two or three turns to loosen it (if the
knob is not loosened enough, it may scratch the seat
post). Next, pull the knob, slide the seat post to the
desired height, and then release the knob. Move the
seat post up and down slightly until the pin on the
knob snaps into one of the holes in the seat post.
Then, turn the knob clockwise until it is tight.
HOW TO ADJUST THE SEAT
The seat can be
adjusted to the
position that is the
most comfortable
for you. Before
adjusting the seat,
dismount the
exercise cycle; do
not adjust the
seat while you are
sitting on it. To
adjust the seat, first
turn the indicated knob counterclockwise two or three
turns to loosen it (if the knob is not loosened enough, it
may scratch the seat bracket). Next, pull the knob,
slide the seat to the desired position, and then release
the knob. Move the seat bracket forward and back-
ward slightly until the pin on the knob snaps into
one of the holes in the seat bracket. Then, turn the
knob clockwise until it is tight.
HOW TO ADJUST THE HANDLEBAR
The handlebar can
be adjusted to the
position that is the
most comfortable for
you. To adjust the
handlebar, first turn
the indicated handle
counterclockwise to
loosen it. Note: The
adjustment handle
works like a span-
ner. Turn the handle
counterclockwise,
pull it away from the handlebar, turn it clockwise, push
it toward the handlebar, and then turn it counterclock-
wise again. Repeat this procedure until the handlebar
is loose. Move the handlebar up or down to the desired
position, and then turn the handle clockwise until it is
tight.
HOW TO ADJUST THE PEDAL STRAPS
See assembly step 9 on page 8 to adjust the pedal
straps.
HOW TO LEVEL THE EXERC SE CYCLE
f the exercise cycle
does not sit flat on
the floor, turn one or
both of the leveling
pads until the exer-
cise cycle is level.
Seat
Post
Knob
Seat
Seat
Bracket
Seat
Knob
Handle
Pads

10
FEATURES OF THE CONSOLE
The advanced console offers a selection of features
designed to make your workouts more enjoyable and
effective. When the manual mode of the console is
selected, the resistance of the pedals can be changed
with the touch of a button. As you pedal, the console
will provide continuous exercise feedback. You can
even measure your heart rate using the built-in hand-
grip pulse sensor.
n addition, the console offers six Smart programs. Each
program automatically changes the resistance of the
pedals and prompts you to increase or decrease your
pace as it guides you through an effective workout.
The console also features iF T.com interactive technol-
ogy. Having iF T.com interactive technology is like hav-
ing a personal trainer in your home. Using the included
audio cable, you can connect the exercise cycle to your
home stereo, portable stereo, computer, or VCR and
play special iF T.com CD and video programs (iF T.com
CDs and videocassettes are available separately).
iF T.com CD and video programs automatically control
the resistance of the pedals and prompt you to vary
your pace as a personal trainer coaches you through
every step of your workout. High-energy music pro-
vides added motivation. To purchase iF T.com CDs
and videocassettes, visit our Web site at
www.iF T.com.
With the exercise cycle connected to your computer,
you can also go to our Web site at www.iF T.com and
access programs directly from the internet. Explore
www.iF T.com for more information.
To use the manual mode of the console, see page
11. To use a Smart program, see page 13. To use
an iF T.com CD or videocassette, see page 17. To
use a program directly from our Web site, see page
18.
Display Buttons
Fan Button
On/Reset Button
Resistance Buttons
