PROAIM JB-VG12-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
12' Vega Video Camera Jib Crane for Video makers
& Filmmakers (JB-VG12-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Vega Jib Front Secon
Assemb ly Manua l
Vega Jib Middle Secon
Vega Jib End Secon
Handle
3/16mm
Allen Key
1/4 to 3/8
Converter
2 x Allen Bolts
With Washers

2
• Aer opening the end secon, loosen the
boom and side knobs of the Central Fork.
• The end secon is properly open, now.
Feature: Central Fork mechanism facilitates
ultra-smooth pan-lt movements while
absorbing unwanted vibraons for cleaner
shots.
• Mount the end secon of the Vega Jib on
the Jib Stand (Not Included).
End Secon Assembly
Vega Jib Setup
• Completely stretch and open the end
secon of Vega Jib, as shown in the image.
• Aer mounng the end secon, ghten the
knob while aligning the holes with each
other.
• Loosen and remove the top knob of the end
secon.

3
• The central part has connecng bars
aached at both the ends, slide the middle
secon into the slots of the end secon.
• Aer sliding the middle secon into the slot
of the end secon, insert the locking knob
in the threads present on top and boom of
the secon.
• Tighten the knobs to completely secure the
secon.
Middle Secon Assembly
• Loose and remove the Center knob of end
secon.
• Now, loosen and remove the top knob of
middle secon.
• The front secon has connecng bars
aached at both ends, slide the front
secon into the slots of the middle secon.
Front Secon Assembly

4
• To detach the handles from one another,
loosen them by turning them in circular mo-
on
Feature: The Camera Crane can be controlled
and moved with the help of a handle.
• Remove the washer from the handle.
• Insert the handle into the hole at the end
secon of the Vega Jib, as shown in the im-
age.
• Aer inserng the handle, aach the han-
dle to the jib from the other side.
Handle Assembly
• Tighten the locking knobs to secure the Jib
secons.
• Aach the handle with each other.
• Mount the Quick Release Plate
(Not Included) on the Camera mounng
plate of the Vega Jib.
• Aer mounng the Quick Release Plate
(Not Included), insert the bolts from the
boom side of the Camera mounng plate.

5
• Now, the Gimbal (Not Included) is complete-
ly secured, as shown in the image.
Camera Mounng Plate
• Insert a 1/4" bolt from the boom of the
extension Camera plate to secure the Quick
Release Plate (Not Included) and ghten
with the Allen key.
• Unlock the lever lock of the quick release
plate.
• Insert the weight (Not Included) inside the
weight Rod.
NOTE: Use the weights according to your cam-
era weight set up requirements.
• Slide the Gimbal (Not Included) onto the
Quick Release Plate and lock it using the
locking lever.
• Monitor (Not Included) each frame by
aaching a monitor to the Jib using the
oponal Universal Clamp with
13"arculang double arms and 3/8"-16
Threaded Stud.

6
YOUR PROAIM 12' VEGA VIDEO CAMERA JIB CRANE
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
