PROAIM P-OHCP-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manual
What’s In The Box
2 x Side bar
3 Overhead Plaorm for Camera & Studio Lights (P-OHCP-01)
2 x L Bracket
1 x Camera Mount
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
1 x Cross Bar
2 x Ground Foot
9 x Foot Thumb Screw &
8 x M5 Short Thumb Screw
4 x Support bar
2 x Plasc Clips

2
 Side Bar is properly aached to the ground
foot.
 Aach the support bar on the side bar
using the long M5 Short knob.
 Repeat these steps for the other support bar
assembly, as shown in the image.
 Then to aach the support bar on the foot,
use short M5 short knob.
3 Overhead Plaorm Setup
 Slide the camera holder on the cross bar.
 Slide and place the side bar on the ground
foot. Lock the assembly using 1/4-20 foot
thumbscrew.

3
 Adjust the cross bar height by sliding it along
the side bar.
NOTE: Camera Plaorm slide on crossbar as
per your requirement.
NOTE: The Overhead Plaorm's crossbar is up/
down adjustable & easily mounts through
rosee knobs. The Camera Holder with a ¼"-20
screw can be locked into any posion on the
crossbar.
 Then lock it into posion using the two height
adjustment thumb screws.
 To secure the cross bar, insert pin on the side.
 Secure it from the other side too.
 You can adjust the height of the crossbar
according to your shoong setup.

4
YOUR PROAIM 3FT OVERHEAD PLATFORM FOR CAMERA & STUDIO LIGHTS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
 Aach two L-brackets using the thumb screws
on the cross bar.
 Both the L-brackets are properly aached
now.
 Clamp your backdrop to the brackets using
two clips.
NOTE: The backdrop & other related
accessories are not included with the Overhead
Camera Plaorm.

5
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
