PROAIM P-OHCP-02 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
4 Versale Overhead Camera Plaorm System (P-OHCP-02)
Assembly Manua l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
2 x Pole Stands
What’s In The Box
2 x Telescopic Poles
6 x 300mm Male Rods
2 x 300mm Female Rods
2 x Accessory Clamps
2 x Pole Connectors
2 x Female Caps
Center Bar with adjustable
camera mount
2 x Knobs

2
2 x Backdrop Brackets
iPhone Adapter
2 x Plasc Clips BS100 1 x 3/16” L-Type Allen key
1 x 4mm T-Type Allen key

3
INDEX
Sr. No Particulars Page No.
1. 4 Versale Overhead Camera Setup 4
2. Telescopic Poles & Pole Stand Assembly 4
3. Height Adjustment 4-5
4. Pole Connector Assembly 5
5. Male & Female Rods Assembly 5
6. Center Bar Assembly 6
7. Accessory Clamps Assembly 6-7
8. Backdrop Brackets Assembly 7-8
9. Center Bar Posioning 8
10. Center Bar Height Adjustment 8
11. Camera Setup 9
12. iPhone Adapter Assembly 9-10
13. BS100 Mounng 10
14. Final Setup 11

4
4 Versale Overhead Camera Setup
• Insert the telescopic pole into the pole stand.
• Aer inserng the pole stand, ghten the
knob on the boom side of the telescopic
pole.
• Repeat the same process for inserng the
second telescopic pole into the pole stand.
• Loosen the knob on the pole stand and adjust
the height per your requirement and
re-ghten the knob.
Telescopic Poles & Pole Stand Assembly
Height Adjustment
• Aer adjusng the height, use the 3/16” Allen
Key to ghten the knob securely.
• Repeat the same process for height
adjustment of the second pole.
• To adjust the pole stand, you can loosen or
ghten its knobs.

5
• Loosen the bolt of the pole connector using a
4mm T-Type Allen key and mount it on the
pole stand.
• Aer mounng the pole connector, re-ghten
the bolt.
• Repeat the same process for the second pole
connector.
• Adjust the posion of the pole stand per your
requirement.
Pole Connector Assembly
• Insert the two 300mm male rods into the
300mm female rods and ghten them
securely.
• Repeat the same process for inserng the
remaining rods.
NOTE: Add or remove the rods per your
requirement.
Male & Female Rods Assembly

6
• Loosen the side knob of the Center Bar and
insert the rod.
• Insert both side knobs into the Center Bar.
• Aer inserng the rod, securely ghten the
knob.
Center Bar Assembly
• Loosen the knob of the Accessory Clamp and
insert the rods into it.
• Repeat the same process for inserng the
second rod.
Accessory Clamps Assembly

7
• Aer inserng the rods, ghten the knob
securely.
• Loosen both knobs of the pole connector and
insert both rods with clamp accessory into the
pole connector, as shown in the image.
• Aer inserng the rods, re-ghten the pole
connector knobs.
• Repeat the same process for inserng the
other end of the rods into the pole connector.
• Insert female caps onto the ends of male rods
and ghten them securely.
• Similarly, insert female caps to the other side
of the rods.
• Remove the top knob from the accessory
clamp.
Backdrop Brackets Assembly
• Insert backdrop brackets into the accessory
clamp, ensuring the threads match. Insert and
ghten the knob.

8
Feature: The knob can be loosened or ghtened
for adjusng the backdrop brackets.
• To adjust the posion of the Center Bar,
loosen its knobs and adjust the Center Bar
per your requirement.
Center Bar Posioning
• To adjust the height of the center bar, loosen
its knobs.
Center Bar Height Adjustment
Dierent Posioning of Center Bar
• Aer posioning it per your requirement,
re-ghten its knob.

9
• Loosen the knob on the camera mounng
plaorm and posion it per your
requirement.
Camera Setup
• Your Camera is securely mounted.
• Use the two plasc clips to clamp your
backdrop to the brackets.
NOTE: The Overhead Camera Plaorm does not
include the backdrop and other Related
Accessories.
• Aach the Camera (Not Included) to the
camera mounng plaorm and lock it
securely.
iPhone Adapter Assembly
• Securely aach the iPhone Adapter to the
camera mounng plaorm on the center bar.

10
• Slide the iPhone Adapter and mount your
iPhone (Not Included) on it.
• Aach the BS100 to the Camera Mount on
the Center Bar.
NOTE: The Centre Bar, with an adjustable
Camera Mount featuring a 1/4"-20 knob, is
compable with most Cameras. We include a
conversion adapter for 3/8″-16 mounng for
added exibility, oering wide compability.
BS100 Mounng
Height Adjustable Telescopic Pole

11
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR PROAIM 4FT VERSATILE OVERHEAD CAMERA PLATFORM SYSTEM
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
