PRONAR T663/4 User manual

PRONAR Sp. z o.o.
17-210 NAREW, UL. MICKIEWICZA 101A, WOJ. PODLASKIE, POLAND
Phone.: [phone] [phone]
[phone] [phone]
Fax: [phone] [phone]
www.pronar.pl
OPERATOR'S MANUAL
TRAILER
PRONAR T663/4
PRONAR 663/4 SILO
TRANSLATION OF THE ORIGINAL DOCUMENT
ISSUE 1B-11-2011 PUBLICATION NO. 177N-00000000-UM
EN

INTRODUCTION
Information contained herein is current as of the date of its publication. As a result of
improvements, some numerical values and illustrations contained in this publication may not
correspond to the factual specification of the machine delivered to the user. The manufacturer
reserves the right to introduce design changes in manufactured machines that facilitate
operation and improve the quality of their work, without making amendments to this Operator's
Manual.
This Operator's Manual is an integral part of the machine. Before using the machine, the user
must carefully read this Operator's Manual and observe all recommendations. This guarantees
safe operation and ensures malfunction-free work of the machine. The machine is designed to
meet obligatory standards, documents and legal regulations currently in force.
The manual describes the basic safety and operation rules of Pronar T663/4, T663/4 SILO
trailer.
If the information contained in the Operator's Manual needs clarification, the user should refer
for assistance to the sale point where the machine was purchased or to the manufacturer.
MANUFACTURER'S ADDRESS
PRONAR Sp. z o.o.
ul. Mickiewicza 101A
17-210 Narew, Poland
PHONE NUMBERS
[phone] [phone]
[phone] [phone]

SYMBOLS USED IN THIS MANUAL
Information, descriptions of danger, precautions, recommendations and orders associated with
user safety instructions are indicated as follows:
and preceded by the word "DANGER". Failure to observe the instructions may endanger the
machine operator's or other person's health or life.
Particularly important information and instructions, the observance of which is essential, are
indicated with the sign:
and preceded by the word "ATTENTION". Failure to observe the instructions may lead to
damage to the machine as a result of improper operation, adjustment or use.
In order to focus the user's attention on the need to perform periodical maintenance, the
relevant section of the Operator's Manual is indicated with the sign:
Additional tips contained in this document refer to helpful information on the machine operation
and are indicated as follows:
and preceded by the word "TIP".

DETERMINING THE DIRECTIONS FOR THE MANUAL'S NEEDS
Left side — a left hand side of the person facing the machine's forward travel direction.
Right side — a right hand side of the person facing the machine's forward travel direction.
SCOPE OF OPERATION STEPS
Operation steps are indicated with the following sign: 
The result of an operation/adjustment task or any notes on execution of the tasks performed is
indicated with the sign 

TABLE OF CONTENTS
1 BASIC INFORMATION 1.1
1.1 IDENTIFICATION 1.2
1.1.1 TRAILER IDENTIFICATION 1.2
1.1.2 AXLE IDENTIFICATION 1.3
1.1.3 LIST OF FACTORY NUMBERS 1.4
1.2 PROPER USE 1.4
1.3 EQUIPMENT 1.8
1.4 WARRANTY TERMS 1.9
1.5 TRANSPORT 1.10
1.5.1 TRANSPORT ON VEHICLE. 1.11
1.5.2 INDEPENDENT TRANSPORT BY THE USER. 1.13
1.6 ENVIRONMENTAL HAZARDS 1.13
1.7 WITHDRAWAL FROM USE 1.14
2 SAFETY ADVICE 2.1
2.1 BASIC SAFETY RULES 2.2
2.1.1 USE OF TRAILER 2.2
2.1.2 HITCHING AND DISCONNECTING FROM TRACTOR 2.3
2.1.3 HITCHING AND UNHITCHING THE SECOND TRAILER 2.3
2.1.4 HYDRAULIC AND PNEUMATIC SYSTEMS 2.4
2.1.5 LOADING AND UNLOADING 2.5
2.1.6 TRANSPORTING THE MACHINE 2.7
2.1.7 TYRES 2.10
2.1.8 MAINTENANCE 2.11
2.2 RESIDUAL RISK 2.13
2.3 INFORMATION AND WARNING DECALS 2.14

3 DESIGN AND OPERATION 3.1
3.1 TECHNICAL SPECIFICATION 3.2
3.2 TRAILER CONSTRUCTION 3.3
3.2.1 CHASSIS 3.3
3.2.2 LOAD BOX 3.5
3.2.3 MAIN BRAKE 3.9
3.2.4 HYDRAULIC TIPPER SYSTEM 3.14
3.2.5 SUPPORT HYDRAULIC SYSTEM 3.16
3.2.6 HYDRAULIC SYSTEM OF SILO ATTACHMENT 3.18
3.2.7 PARKING BRAKE 3.19
3.2.8 LIGHTING SYSTEM 3.20
4 CORRECT USE 4.1
4.1 PREPARING FOR WORK BEFORE THE FIRST USE 4.2
4.1.1 CHECKING THE TRAILER AFTER DELIVERY 4.2
4.1.2 PREPARING THE TRAILER FOR THE FIRST HITCHING TO TRACTOR 4.3
4.2 HITCHING AND UNHITCHING THE TRAILER FROM TRACTOR 4.5
4.3 HITCHING AND UNHITCHING THE SECOND TRAILER 4.9
4.4 LOADING AND SECURING LOAD 4.11
4.4.1 GENERAL INFORMATION ABOUT LOADING 4.11
4.5 TRANSPORTING LOAD 4.19
4.6 UNLOADING 4.20
4.7 PROPER USE AND MAINTENANCE OF TYRES 4.26
5 MAINTENANCE 5.1
5.1 PRELIMINARY INFORMATION 5.2
5.2 MAINTENANCE OF BRAKES AND AXLES 5.2
5.2.1 PRELIMINARY INFORMATION 5.2
5.2.2 INITIAL INSPECTION OF AXLE BRAKES, 5.3

5.2.3 CHECK WHEEL AXLE BEARINGS FOR SLACKNESS 5.4
5.2.4 ADJUSTMENT OF AXLE BEARING SLACKNESS 5.6
5.2.5 MOUNTING AND DISMOUNTING WHEEL, INSPECTION OF WHEEL
NUT TIGHTENING 5.7
5.2.6 CHECKING AIR PRESSURE IN TYRES, EVALUATING TECHNICAL
CONDITION OF TYRES AND STEEL WHEELS 5.9
5.2.7 ADJUSTMENT OF MECHANICAL BRAKES 5.10
5.2.8 CHANGE OF PARKING BRAKE CABLES AND ADJUSTMENT OF CABLE
TENSION. 5.12
5.3 PNEUMATIC SYSTEM MAINTENANCE 5.15
5.3.1 PRELIMINARY INFORMATION 5.15
5.3.2 CHECKING AIR TIGHTNESS AND VISUAL INSPECTION OF
PNEUMATIC SYSTEM 5.15
5.3.3 CLEANING THE AIR FILTERS 5.17
5.3.4 DRAINING WATER FROM AIR TANK 5.18
5.3.5 CLEANING THE DRAIN VALVE 5.19
5.3.6 CLEANING AND MAINTAINING PNEUMATIC CONDUIT CONNECTIONS
AND PNEUMATIC SOCKETS 5.20
5.3.7 REPLACEMENT OF PNEUMATIC CONDUIT 5.21
5.4 HYDRAULIC SYSTEM MAINTENANCE 5.22
5.4.1 PRELIMINARY INFORMATION 5.22
5.4.2 CHECKING HYDRAULIC SYSTEM TIGHTNESS 5.22
5.4.3 CHECKING TECHNICAL CONDITION OF HYDRAULIC COUPLERS AND
SOCKETS. 5.23
5.4.4 REPLACEMENT OF HYDRAULIC CONDUITS 5.23
5.5 MAINTENANCE OF ELECTRICAL SYSTEM AND WARNING
ELEMENTS 5.24
5.5.1 PRELIMINARY INFORMATION 5.24
5.5.2 REPLACEMENT OF BULBS 5.25
5.6 TRAILER LUBRICATION 5.25
5.7 CONSUMABLES 5.31

5.7.1 HYDRAULIC OIL 5.31
5.7.2 LUBRICANTS 5.32
5.8 CLEANING THE TRAILER 5.33
5.9 STORAGE 5.35
5.10 TIGHTENING TORQUE FOR NUT AND BOLT CONNECTIONS 5.35
5.11 INSTALLATION AND DISMOUNTING OF WALL EXTENSIONS 5.37
5.12 ADJUSTMENT OF DRAWBAR POSITION 5.37
5.13 TROUBLESHOOTING 5.39

SECTION
1
BASIC INFORMATION

Pronar T663/4 T663/4 SILO SECTION 1
1.2
1.1 IDENTIFICATION
1.1.1 TRAILER IDENTIFICATION
FIGURE 1.1 Location of the data plate and serial number
(1) data plate, (2) serial number
The trailer is marked with the data plate (1), and the factory number (2) located on a gold
painted rectangle. The data plate is located on the front beam of the main frame and the
serial number is stamped into the front beam of the chassis frame – figure (1.1). When
buying the trailer check that the serial numbers on the machine agree with the number written
in the WARRANTY BOOK, in the sales documents and in the OPERATOR'S MANUAL. The
meanings of the individual fields found on the data plate are presented in the table below:

SECTION 1 Pronar T663/4 T663/4 SILO
1.3
TABLE 1.1 Markings on data plate
ITEM
MARKING
A General description and purpose
B Symbol / type of trailer
C Trailer year of manufacture
D Seventeen digit vehicle identification number (VIN)
E Official certificate number
F Tare weight
G Maximum gross weight
H Carrying capacity
I Permissible hitching system loading
J Permissible axle 1 load
K Permissible axle 2 load
1.1.2 AXLE IDENTIFICATION
FIGURE 1.2 Location of the axle data plate
(1) axle, (2) data plate
The factory number of the axle shaft and its type are stamped onto the data plate (2) secured
to the axle shaft beam (1) – figure (1.2).

Pronar T663/4 T663/4 SILO SECTION 1
1.4
1.1.3 LIST OF FACTORY NUMBERS
VIN
S Z B 6 6 3 4 X X X
FRONT AXLE FACTORY NUMBER
REAR AXLE FACTORY NUMBER
TIP
In the event of ordering a replacement part or in the case of the appearance of problems
it is often essential to give the factory n mbers of parts or the VIN n mber of the trailer,
therefore it is recommended that these n mbers are inscribed in the spaces above.
1.2 PROPER USE
The trailer is designed for transport of harvested crops and agricultural products as well as
loose, bulk and long load materials at the farm and on public roads. It is acceptable to
transport construction materials, mineral fertilisers and other loads, if fulfilling conditions
indicated in section 4. Non-compliance with the recommendations concerning the carriage
and loading of goods described by the Manufacturer and the road transport regulations in
force in the country in which the trailer is used shall void the warranty and is regarded as the
use of the machine contrary to its intended purpose.
The trailer is not intended or designed for transporting people, animals or goods classified as
dangerous materials.
The trailer is constructed according to current safety requirements and engineering
standards. The brake system and the light and indicator system meet the requirements of
road traffic regulations. The maximum speed of the trailer on public roads in Poland is 30
km/h (pursuant to Traffic Law Act of June 20th 1997, article 20). In the countries where the
trailer is used, the limits stipulated by the road traffic legislation in force in a given country
must be observed. The trailer speed must not, however, be greater than the maximum design
speed of 30 km/h.

SECTION 1 Pronar T663/4 T663/4 SILO
1.5
ATTENTION
The trailer m st not be sed for p rposes other than those for which it is intended. The
ser MUST NOT:
•transport people, animals, hazardo s materials, chemically aggressive loads
that will corrode the constr ction elements of the trailer (ca sing corrosion of
steel, destr ction of paint coat, dissolving plastic elements and destr ction of
r bber elements etc.),
•transport incorrectly sec red load, which d ring travel may ca se
contamination of the road and nat ral environment,
•transport incorrectly sec red load, which d ring travel may change position
in load box or fall o t of the load box,
•transport loads, whose centre of gravity may destabilise the trailer,
•transport loads, which have neven load distrib tion and/or overload axles
and s spension elements.
Using it as intended also involves all actions connected with the safe and proper operation
and maintenance of the machine. Due to the above, the user is obliged to:
•carefully read the OPERATOR'S MANUALof the trailer and the WARRANTY
BOOKand conform with the recommendations contained in these documents,
•understand the trailer's operating principle and how to operate it safely and
correctly,
•adhere to the established maintenance and adjustment plans,
•comply with general safety regulations while working,
•prevent accidents,
•comply with the road traffic regulations and transport regulations in force in a
given country, in which the trailer is used,
•carefully read the Operator's Manual and comply with its recommendations,
•only hitch the trailer to an agricultural tractor, which fulfils all the requirements
made by the trailer's Manufacturer.

Pronar T663/4 T663/4 SILO SECTION 1
1.6
The trailer may only be used by persons, who:
•are familiar with the contents of this publication and with the contents of the
agricultural tractor Operator's Manual,
•have been trained in trailer operation and safe operation,
•have the required authorisation to drive and are familiar with the road traffic
regulations and transport regulations.
TABLE 1.2 Agricultural tractor's requirements
CONTENTS UNIT REQUIREMENTS
Brake system - sockets
Pneumatic system 1 conduit
Double conduit pneumatic system
Hydraulic system
Maximum system pressure
Single conduit pneumatic system
Double conduit pneumatic system
Hydraulic system
-
-
-
bar / kPa
bar / kPa
bar / MPa
according to ISO 1728
according to ISO 1728
according to ISO 7421-1
5.8 / 580
8 / 800
150 / 15
Hydraulic tipper system
Hydraulic oil
Maximum system pressure
Oil demand:
-
bar / MPa
l
L HL 32 Lotos
(1)
160 / 16
15
Electrical system
Electrical system voltage
Connection socket
V
-
12
7 polar compliant with ISO 1724
Required tractor hitch
Type of hitch -
-
Hitch for single axle trailer
Upper transport hitch
Other requirements
Min. tractor power kW /
Horsepower
49.7 / 67.6
(1)
– use of other oil is permitted, on condition that it may be mixed with the oil in the trailer. Detailed
information can be found on the product information card.

SECTION 1 Pronar T663/4 T663/4 SILO
1.7
TIP
Tractor req irements depend on trailer accessories.
In the event that the trailer shall be hitched to a second trailer it must fulfil the requirements
stipulated in table (1.3).
TABLE 1.3 Requirements for second trailer
CONTENTS UNIT REQUIREMENTS
Maximum gross weight
T663/4
T663/4 SILO
kg
kg
14 000
14 000
Brake system - connectors
Pneumatic system 1 conduit
Double conduit pneumatic system
Hydraulic system
Maximum system pressure
Single conduit pneumatic system
Double conduit pneumatic system
Hydraulic system
-
-
-
bar / kPa
bar / kPa
bar / MPa
connector compliant with ISO 1728
connector compliant with ISO 1728
connector compliant with ISO 7421-1
5.8 / 580
8 / 800
150 / 15
Hydraulic tipper system
Hydraulic oil
Maximum system pressure
-
bar / MPa
L HL 32 Lotos
(1)
160 / 16
Electrical system
Electrical system voltage
Connection socket
V
-
12
7 polar compliant with ISO 1724
Drawbar of trailer
Diameter of drawbar eye mm 40
(1)
– use of other oil is permitted, on condition that it may be mixed with the oil in the trailer. Detailed
information can be found on the product information card.

Pronar T663/4 T663/4 SILO SECTION 1
1.8
1.3 EQUIPMENT
TABLE 1.4 Trailer optional equipment
EQUIPMENT
STANDARD
ADDITIONAL
OPTIONS
Operator`s Manual •
Warranty book •
Connection lead for the electrical system •
Double conduit pneumatic system for the trailer with the maximum
design speed of 40km/h •
Single conduit pneumatic system for the trailer with the maximum
design speed of 25 km/h •
2-line pneumatic system with automatic regulator •
Hand brake •
Mudguards set •
Hydraulic shear type support •
Hydraulic brake system •
Rotating drawbar eye ∅50 mm •
Drawbar eye ∅40 mm •
Wheel chocks •
Rear hitch •
Slow-moving vehicle warning sign •
Warning reflective triangle •
Complete set of wall extensions (600 mm) (T663/4 only) •
Complete set of additional wall extensions (600 mm) (T663/4 only) •

SECTION 1 Pronar T663/4 T663/4 SILO
1.9
EQUIPMENT
STANDARD
ADDITIONAL
OPTIONS
Hydraulically raised rear wall (663/4 SILO only) •
Frame with tarpaulin cover and fenced platform •
Clamping cable with cable extraction mechanism •
Chute •
Spare wheel holder •
Spare wheel •
Some standard equipment elements, which were listed in table (1.4), may not be present in
the delivered trailer. This allows the possibility of ordering new machines with a different set
of optional equipment, replacing standard equipment.
Information concerning tires is provided at the end of this publication inANNEX A.
1.4 WARRANTY TERMS
PRONAR Sp. z o.o. Narew guarantees the reliable operation of the machine when it is used
according to its intended purpose as described in the OPERATOR'S MANUAL. The repair
period is specified in the WARRANTY BOOK.
The guarantee does not apply to those parts and sub-assemblies of the machine, which are
subject to wear in normal usage conditions, regardless of the warranty period. Consumables
include the following parts/sub-assemblies:
•drawbar hitching eye,
•pneumatic system connector filters,
•tyres,
•brake shoes,
•bulbs and LED lamps,

Pronar T663/4 T663/4 SILO SECTION 1
1.10
•seals,
•bearings.
The warranty service only applies to such cases as: mechanical damage which is not the
user's fault, factory defects of parts, etc.
In the event of damage arising from:
•mechanical damage which is the user's fault, road accidents,
•by inappropriate use, adjustment or maintenance, use of the trailer for purposes
other than those for which it is intended,
•use of damaged machine,
•repairs carried out by unauthorised persons, improperly carried out repairs,
•making unauthorised alterations to machine design,
the user will lose the right to warranty service.
TIP
Demand that the seller caref lly and precisely fills o t the Warranty Book and g arantee
repair co pons. A missing date of p rchase or sale point stamp, may make the ser
ineligible for any warranty repair or ref nd.
The user is obliged to report immediately on noticing any wear in the paint coating or traces
of corrosion, and to have the faults rectified whether they are covered by the guarantee or
not. For detailed Terms & Conditions of Warranty, please refer to the WARRANTY BOOK
attached to each newly purchased machine.
Modification of the trailer without the written consent of the Manufacturer is prohibited. In
particular, do NOT weld, drill holes in, cut or heat the main structural elements of the
machine, which have a direct impact on the machine operation safety.
1.5 TRANSPORT
The trailer is ready for sale completely assembled and does not require packing. Packing is
only required for the machine's technical documentation and any extra equipment. The trailer
