OPERATOR`S MANUAL
AGRICULTURAL TRAILER
PRONAR T701HP
TRANSLATION OF THE ORIGINAL COPY OF THE MANUAL

INTRODUCTION

Introduction
2PRONAR T701HP
INTRODUCTION
Information contained herein is current
at date of publication. As a result of im-
provements, some numerical values and
illustrations contained in this publication
may not correspond to the factual spec-
ication of the machine supplied to the
user. The manufacturer reserves the right
to introduce design changes in machines
produced that facilitate operation and im-
prove the quality of their work, without
making minor amendments to this Opera-
tor's Manual.
This Operator's Manual is an integral part
of the machine's documentation. Before
using the machine, the user must carefully
read this Operator's Manual and observe
all recommendations. This guarantees
safe operation and ensures failure-free
work of the machine. The machine is de-
signed to meet obligatory standards, doc-
uments and legal regulations currently in
force.
If the information contained in the Oper-
ator's Manual needs clarication then the
user should refer for assistance to the sale
point where the machine was purchased
or to the Manufacturer.
It is recommended that the serial number
of the machine is inscribed in the spaces
below after purchase of the machine.
U.10.1.EN
Machine serial number

3PRONAR T701HP
Introduction
SYMBOLS APPEARING IN THIS OPERATOR'S MANUAL
DANGER
Information, descriptions of danger and
precautions as well as recommendations
and prohibitions associated with the safety
of use are marked in the text with the sign
DANGER. Failure to observe the instructions
may endanger the machine operator's or
other person's health or life.
ATTENTION
Particularly important information and in-
structions, the observance of which is
essential, are distinguished in the text by
the sign ATTENTION. Failure to observe the
instructions may lead to damage to the
machine as a result of improper operation,
adjustment or use.
TIP
Additional tips included in the Operator's
Manual describe useful advice for the ma-
chine operation and are marked with the
sign TIP.
U.02.1.EN
DANGER
ATTENTION
TIP

Introduction
4PRONAR T701HP
DIRECTIONS USED IN THIS OPERATOR'S MANUAL
Left side – side to the left hand of the op-
erator facing in the direction of machine's
forward travel.
Right side – side to the right hand of the
operator facing in the direction of ma-
chine's forward travel.
Rotation to the right – clockwise rotation
of a mechanism (the operator is facing the
mechanism).
Rotation to the left – counterclockwise
rotation of a mechanism (the operator is
facing the mechanism).
U.03.1.EN

5PRONAR T701HP
Introduction
CHECKING THE TRAILER AFTER DELIVERY
The manufacturer guarantees that the
trailer is fully operational and has been
checked according to quality control pro-
cedures and is ready for use. This does
not release the user from an obligation to
check the trailer's condition after delivery
and before the rst use. The trailer is de-
livered to the user completely assembled.
After delivery of the machine to the buyer,
the user is obliged to check technical con-
dition of the trailer. While buying the ma-
chine, the user must be informed by the
seller about the method of use of the ma-
chine, risks resulting from the use for pur-
poses other than intended, the method of
the machine hitching and the principles of
the machine construction and design. De-
tailed information concerning the machine
hand-over are included in the WARRANTY
BOOK.
SCOPE OF ACTIVITIES
• Check completeness of the machine
according to order (standard and op-
tional equipment).
• Check technical condition of shields
and protection devices.
• Check condition of paint coating;
check the machine for traces of
corrosion.
• Inspect the trailer's individual
components for mechanical damage
resulting from, among others, in-
correct transport (dents, piercing,
bent or broken components).
• Check technical condition of tyres
and tyre pressure.
• Check if the nuts and bolts xing the
wheels are properly tightened.
• Check technical condition of drawbar
eye and if correctly installed.
• Check technical condition of pneu-
matic conduits.
• Check technical condition of elastic
hydraulic conduits.
• Check that there are no hydraulic oil
leaks.
• Check tipping cylinder, tailgate cyl-
inders and support cylinder for hy-
draulic oil leaks.
• Check electrical system and lighting
system of the trailer.
If non-conformities are found, do not hitch
and start using the trailer. Discovered
TIP
Hand-over of the trailer to the buyer involves a de-
tailed visual inspection and verification of the trailer
operation, as well as instructing the buyer on the
basic usage rules. The trailer is operated for the
first time in the presence of the Seller.

Introduction
6PRONAR T701HP
defects should be notied directly to the seller in order to remove them.
U.29.1.EN

7PRONAR T701HP
Introduction
FIRST USE OF THE TRAILER
SCOPE OF ACTIVITIES
• The user must read this OPERA-
TOR'S MANUAL and observe all the
recommendations contained in it.
• Adjust the height of the drawbar eye
to the tractor hitch
• Check all the trailer's lubrication
points, lubricate the machine as
needed according to recommenda-
tions provided in SECTION 5.17.
• Check if the nuts and bolts xing the
wheels are properly tightened.
• Visually inspect the trailer before
driving off according to the guidelines
presented in SECTION 5.8.
• Drain the air tank in the braking
system (SECTION 5.5).
• Ensure that pneumatic, hydraulic and
electrical connections in agricultural
tractor are according to the require-
ments, if not the trailer should not be
hitched to the tractor.
If all the above checks have been per-
formed and there is no doubt as to the
trailer's good technical condition, it can
be connected to tractor. Start the tractor,
check all systems and conduct test run of
trailer without load (no load in load box).
It is recommended that the inspection is
conducted by two people, one of which
should always remain in the tractor cab.
Test start should be conducted according
to the sequence shown below.
• Connect the trailer to appropriate
hitch on agricultural tractor.
• Connect conduits of braking, elec-
trical and hydraulic systems.
• Switch on individual lights, check
correct operation of electrical system.
• Conduct test tipping of load box.
• Actuate and check if tailgate control
system operates correctly.
• When moving off check if the main
brakes operate correctly.
• Perform test drive.
ATTENTION
During the first use, the trailer is checked in the
presence of the Seller.
The Seller is obliged to conduct the training in safe
and correct operation of the trailer.
The user trained by the seller is not released from
the obligation to carefully read this Operator's Man-
ual and adhere to the recommendations contained
in it.
TIP
Operating activities: hitching to/unhitching from
tractor, adjustment of draw bar position, tipping of
load box etc. are described in detail in further parts
of the Operator's Manual in SECTION 4.

Introduction
8PRONAR T701HP
If during test run worrying symptoms occur
such as:
• noise and abnormal sounds origi-
nating from the abrasion of moving
elements of the trailer structure,
• brake system leak,
• hydraulic oil leak,
• incorrect operation of hydraulic and/
or pneumatic cylinders,
or other faults, nd the cause of the
problem. If a fault cannot be rectied or
the repair could void the guarantee, please
contact retailer for additional clarications
or to make a repair.
After completion of test drive check
tightness of wheel nuts.
U.30.1.EN
