PRONAR RC2100-2 User manual

PRONAR Sp. z o.o.
17-210 NAREW, UL. MICKIEWICZA 101A, PODLASKIE PROVINCE
phone: [phone] [phone]
[phone] [phone]
fax: [phone] [phone]
www.pronar.pl
OPERATOR'S MANUAL
AGRICULTURAL TRAILER
PRONAR RC2100-2
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
ISSUE 2A-09-2017 PUBLICATION NO 437N-00000000-UM

INTRODUCTION
Information contained herein is current at date of publication. As a result of improvements,
some numerical values and illustrations contained in this publication may not correspond to the
factual specification of the machine supplied to the user. The manufacturer reserves the right to
introduce design changes in machines produced that facilitate operation and improve the quality
of their work, without making minor amendments to this Operator's Manual.
This Operator's Manual is an integral part of the machine's documentation. Before using the
machine, the user must carefully read this Operator's Manual and observe all
recommendations. This guarantees safe operation and ensures malfunction free work of the
machine. The machine is designed to meet obligatory standards, documents and legal
regulations currently in force.
The manual describes the basic safety rules and operation of trailer Pronar RC2100-2.
If the information stated in the Operator's Manual needs clarification then the user should refer
for assistance to the sale point where the machine was purchased or to the Manufacturer.
MANUFACTURER'S ADDRESS:
PRONAR Sp. z o.o.
ul. Mickiewicza 101A
17-210 Narew
CONTACT TELEPHONES
[phone] [phone]
[phone] [phone]

SYMBOLS APPEARING IN THIS OPERATOR'S MANUAL
Information, descriptions of danger and precautions and also recommendations and prohibitions
associated with user safety instructions are marked:
and also preceded by the word "DANGER”. Failure to observe the instructions may endanger
the machine operator's or other person's health or life.
Particularly important information and instructions, the observance of which is essential, are
distinguished in the text by the sign:
and also preceded by the word "ATTENTION". Failure to observe the instructions may lead to
damage to the machine as a result of improper operation, adjustment or use.
In order to focus the user's attention on the need to perform maintenance, the relevant section
of the Operator's Manual is marked with the pictogram:
Additional tips and advice for machine operation are marked:
and also preceded by the word "TIP".

DIRECTIONS USED IN THIS OPERATOR'S MANUAL
Left side – side to the left hand of the operator facing in the direction of machine's forward
travel.
Right side – side to the right hand of the operator facing in the direction of machine's forward
travel.
REQUIRED SERVICE ACTIONS
Service actions described in the manual are marked: 
Result of service/adjustment actions or comments concerning the performance of actions are
marked: 

CONTENTS
1 BASIC INFORMATION 1.1
1.1 IDENTIFICATION 1.2
1.1.1 TRAILER IDENTIFICATION 1.2
1.1.2 AXLE IDENTIFICATION 1.3
1.1.3 LIST OF FACTORY NUMBERS 1.4
1.2 PROPER USE 1.4
1.3 EQUIPMENT 1.7
1.4 TERMS & CONDITIONS OF WARRANTY 1.7
1.5 TRANSPORT 1.9
1.5.1 TRANSPORT ON VEHICLE 1.9
1.5.2 INDEPENDENT TRANSPORT BY THE USER 1.11
1.6 ENVIRONMENTAL HAZARDS 1.11
1.7 WITHDRAWAL FROM USE 1.13
2 SAFETY ADVICE 2.1
2.1 BASIC SAFETY RULES 2.2
2.1.1 USE OF TRAILER 2.2
2.1.2 HITCHING AND DISCONNECTING FROM TRACTOR 2.3
2.1.3 HYDRAULIC SYSTEM 2.4
2.1.4 LOADING AND UNLOADING 2.4
2.1.5 TRANSPORTING THE MACHINE 2.6
2.1.6 TYRES 2.9
2.1.7 MAINTENANCE 2.9
2.2 DESCRIPTION OF RESIDUAL RISK 2.12
2.3 INFORMATION AND WARNING DECALS 2.13

3 DESIGN AND OPERATION 3.1
3.1 TECHNICAL SPECIFICATION 3.2
3.2 TRAILER CONSTRUCTION 3.3
3.2.1 CHASSIS AND LOAD PLATFORM 3.3
3.2.2 DRAWBAR OF TRAILER 3.5
3.2.3 SUSPENSION 3.5
3.2.4 MAIN BRAKE 3.6
3.2.5 PARKING BRAKE 3.8
3.2.6 LIGHTING SYSTEM 3.9
4 CORRECT USE 4.1
4.1 PREPARING FOR WORK BEFORE FIRST USE 4.2
4.1.1 CHECKING THE TRAILER AFTER DELIVERY 4.2
4.1.2 PREPARE A TRAILER FOR FIRST HITCHING TO TRACTOR 4.2
4.2 HITCHING AND DISCONNECTING FROM TRACTOR 4.4
4.3 TRAILER SUPPORT OPERATION 4.6
4.4 LOADING AND UNLOADING THE TRAILER 4.8
4.4.1 STANDARD SIZE LOADS 4.8
4.4.2 OVERSIZE LOADS 4.10
4.4.3 UNLOADING THE TRAILER 4.10
4.5 RAMPS' PROTECTIONS 4.11
4.6 SECURING LOAD 4.12
4.7 TRANSPORTING THE MACHINE 4.14
4.8 PROPER USE AND MAINTENANCE OF TYRES 4.15
5 MAINTENANCE 5.1
5.1 PRELIMINARY INFORMATION 5.2
5.2 SERVICING BRAKES AND AXLES 5.2
5.2.1 PRELIMINARY INFORMATION 5.2

5.2.2 INITIAL INSPECTION OF AXLE BRAKES 5.3
5.2.3 CHECK BRAKE SHOE LININGS FOR WEAR 5.3
5.2.4 CHECK WHEEL AXLE BEARINGS FOR LOOSENESS 5.5
5.2.5 ADJUSTMENT OF PLAY OF WHEEL AXLE BEARINGS 5.7
5.2.6 MOUNTING AND DISMOUNTING WHEELS, INSPECTION OF
WHEEL NUT TIGHTENING. 5.8
5.2.7 CHECK AIR PRESSURE, EVALUATE TECHNICAL CONDITION
OF WHEELS AND TYRES 5.12
5.2.8 MECHANICAL BRAKES ADJUSTMENT 5.13
5.2.9 CHANGE OF PARKING BRAKE CABLE AND ADJUSTMENT OF
CABLE TENSION 5.15
5.3 HYDRAULIC SYSTEM OPERATION 5.17
5.3.1 PRELIMINARY INFORMATION 5.17
5.3.2 CHECKING HYDRAULIC SYSTEM TIGHTNESS 5.18
5.3.3 CHECKING TECHNICAL CONDITION OF HYDRAULIC
CONNECTIONS AND SOCKETS. 5.18
5.3.4 REPLACEMENT OF HYDRAULIC CONDUITS 5.19
5.4 CHECKING DRAWBAR EYE TIGHTNESS 5.19
5.5 OPERATION OF ELECTRICAL SYSTEM AND WARNING
ELEMENTS 5.20
5.5.1 PRELIMINARY INFORMATION 5.20
5.5.2 CHANGING BULBS 5.21
5.6 TRAILER LUBRICATION 5.21
5.7 CONSUMABLES 5.26
5.7.1 HYDRAULIC OIL 5.26
5.7.2 LUBRICANTS 5.27
5.8 CLEANING TRAILER 5.28
5.9 STORAGE 5.29
5.10 TIGHTENING TORQUE FOR NUT AND BOLT
CONNECTIONS 5.30

5.11 TROUBLESHOOTING 5.31

SECTION
1
BASIC INFORMATION

PRONAR RC2100-2 SECTION 1
1.2
1.1 IDENTIFICATION
1.1.1 TRAILER IDENTIFICATION
FIGURE 1.1 Location of the data plate and serial number
(1) data plate, (2) example of serial number, (3) right longitudinal member of lower frame
The trailer is marked with data plate (1), located on the trailer's front wall and with serial
number (2) located on a gold painted rectangle. The serial number is stamped on the right
longitudinal member of the frame. When buying the trailer check that the serial numbers on
the machine agree with the number written in the WARRANTY BOOK, in the sales
documents and in the OPERATOR'S MANUAL.

SECTION 1 PRONAR RC2100-2
1.3
TABLE 1.1 Markings on data plate
ITEM
MARKING
A General description and purpose
B Symbol / type of trailer
C Trailer's year of manufacture
D Seventeen digit serial number (VIN)
E Official certificate number
F Tare weight
G Maximum gross weight
H Carrying capacity
I Permissible hitching system loading
J Permissible front axle load
K Permissible rear axle load
1.1.2 AXLE IDENTIFICATION
FIGURE 1.2 Location of the axle data plate
(1) data plate, (2) wheel axle
The factory number of the axle shaft and its type are stamped onto the data plate (2) secured
to the axle shaft beam (1) – figure (1.2).

PRONAR RC2100-2 SECTION 1
1.4
1.1.3 LIST OF SERIAL NUMBERS
TIP
If spare parts have to be ordered or if problems occur, it is very ofte ecessary to give
the factory umbers of parts or the VIN umber of the trailer. Therefore, it is
recomme ded that these umbers are i scribed i the table (1.2).
TABLE 1.2 List of factory numbers
VIN
S Z B R C 2 1 0 2 X
AXLE FACTORY NUMBER
1.2 INTENDED USE
The trailer is designed for transporting agricultural and construction machines and the loads
which can be properly secured against moving during travel (loads placed in boxes,
containers, on pallets etc.). Transporting people, animals, bulk and hazardous materials is
prohibited and regarded as contrary to the intended purpose of the trailer. During the use of
the machine comply with all road traffic regulations and transport regulations in force in the
given country, and any breach of these regulations is regarded by the Manufacturer as use
contrary to its intended purpose.

SECTION 1 PRONAR RC2100-2
1.5
ATTENTION
The trailer must ot be used for purposes other tha those for which it is i te ded. The
user MUST NOT:
•tra sport people, a imals, hazardous materials, chemically aggressive loads
that will corrode the structural eleme ts of the trailer (causi g corrosio of
steel, destructio of pai t coat, dissolvi g plastic eleme ts a d destructio of
rubber eleme ts etc.),
•tra sport i correctly secured load, which duri g travel may cause
co tami atio of the road a d atural e viro me t,
•tra sport i correctly secured load, which duri g travel may cha ge its
positio o the load platform or fall out of the load platform,
•tra sport load whose ce tre of gravity may destabilise the trailer a d threate
safety duri g travel,
•tra sport loads, which have u eve load distributio a d/or overload axles
a d suspe sio eleme ts.
The trailer is designed according to current safety requirements and engineering standards.
The brake system and the light and indicator system meet the requirements of road traffic
regulations. The maximum speed of the trailer on public roads in Poland is 30 km/h (pursuant
to Traffic Law Act of June 20th 1997, article 20). In the countries where the trailer is used, the
limits stipulated by the road traffic legislation in force in a given country must be observed.
The trailer speed must not, however, be greater than the maximum design speed of 60 km/h.
Using it as intended also involves all actions connected with the safe and proper operation
and maintenance of the machine. Due to the above, the user is obliged to:
•carefully read the OPERATOR'S MANUAL of the trailer, WARRANTY BOOK and
comply with the recommendations contained in these documents,
•understand the trailer's operating principle and how to operate it safely and
correctly,
•adhere to the established maintenance and adjustment plans,
•comply with general safety regulations while working,
•prevent accidents,

PRONAR RC2100-2 SECTION 1
1.6
•comply with the road traffic regulations in force in a given country, in which the
trailer is used,
•carefully read the Operator's Manual and comply with its recommendations,
•only hitch the trailer to an agricultural tractor which fulfils all the requirements
specified by the trailer's Manufacturer.
The trailer may only be used by persons, who:
•are familiar with the contents of this publication and with the contents of the
agricultural tractor Operator's Manual,
•have been trained in trailer operation and work safety,
•have the required authorisation to drive carrying vehicles and are familiar with the
road traffic regulations and transport regulations.
TABLE 1.3 Requirements for agricultural tractor
CONTENTS UNIT REQUIREMENTS
Brake system - sockets
Hydraulic system
Double conduit pneumatic system
Nominal pressure of the system
Hydraulic system
Double conduit pneumatic system
bar / MPa
bar / KPa
sockets compliant with ISO 7421-1
according to PN-ISO 1728
150 / 15
6.5/ 650
Electrical system
Electrical system voltage
Connection socket
V
-
12
7-pole compliant with ISO 1724
Hydraulic system
Hydraulic oil
Maximum system pressure
-
bar / MPa
L HL 32 Lotos
160 / 16
Tractor hitches
Type
Minimum lift capacity (vertical load) of the
hitching system
-
kg
Transport hitch
3,000

SECTION 1 PRONAR RC2100-2
1.7
CONTENTS UNIT REQUIREMENTS
Other requirements
Minimum tractor power demand kW(hp) 76.4 (104)
ATTENTION
Use of other oil is permitted o co ditio that it may be mixed with the oil used i the
trailer. Detailed i formatio ca be fou d o the product i formatio card.
1.3 EQUIPMENT
TABLE 1.4 RC2100-2 trailer equipment
EQUIPMENT
STANDARD
ADDITIONAL
OPTION
THE OPERATOR'S MANUAL •
WARRANTY BOOK •
Connection lead for the electrical system •
Floor planks (coniferous wood planks) •
Single conduit hydraulic braking system •
Double conduit pneumatic braking system with ALB regulator •
Drawbar set with rotating drawbar eye ∅50 •
Drawbar set with ball drawbar eye ∅80 •
Drawbar set with fixed drawbar eye ∅50 •
Drawbar set with fixed drawbar eye ∅40 •
Ramp folding mechanism •
Hydraulic system of the ramps •

PRONAR RC2100-2 SECTION 1
1.8
EQUIPMENT
STANDARD
ADDITIONAL
OPTION
Widened ramps •
Lateral protections (shields) •
Fixing lugs •
Mechanical support foot •
Support leg, hydraulic •
Water tank •
Toolbox •
Slow-moving vehicle warning sign •
Reflective warning triangle •
Spare wheel (1 or 2 pcs) •
Ramp floor insert •
1.4 TERMS & CONDITIONS OF WARRANTY
PRONAR Sp. z o.o. Narew guarantees the reliable operation of the machine when it is used
according to its intended purpose as described in the OPERATOR'S MANUAL. The repair
period is specified in the WARRANTY BOOK.
The warranty does not cover those parts and sub-assemblies of the machine which are
subject to wear in normal usage conditions, regardless of the warranty period. Consumables
include the following parts/sub-assemblies:
•drawbar hitching eye,
•tyres,
•brake shoes,
•bulbs and LED lamps,

SECTION 1 PRONAR RC2100-2
1.9
•seals,
•bearings,
•floor planks.
The warranty service only applies to such cases as: mechanical damage which is not the
user's fault, factory defects of parts, etc.
In the event of damage arising from:
•mechanical damage which is the user's fault, damage caused by road accidents,
•incorrect use, adjustment or maintenance, use of the trailer for purposes other
than those for which it is intended,
•use of damaged machine,
•repairs carried out by unauthorised persons, repairs carried out improperly,
•making unauthorised alterations to machine design,
the user will lose the right to warranty service.
TIP
Dema d that the seller carefully a d precisely fills out the Warra ty Book a d guara tee
repair coupo s. A missi g date of purchase or sale poi t stamp may make the user
i eligible for a y warra ty repair or refu d.
The user is obliged to report immediately on noticing any wear in the paint coating or traces
of corrosion, and to have the faults rectified whether they are covered by the warranty or not.
For detailed Terms & Conditions of Warranty, please refer to the WARRANTY BOOK
attached to each newly purchased machine.
Modification of the trailer without the written consent of the Manufacturer is prohibited. In
particular, do NOT weld, drill holes in, cut or heat the main structural elements of the
machine, which have a direct impact on the machine operation safety.

PRONAR RC2100-2 SECTION 1
1.10
1.5 TRANSPORT
The trailer is ready for sale completely assembled and does not require packing. Packing is
only required for the machine's technical documentation and any extra equipment. The trailer
is delivered to the user either transported on a vehicle or, after being attached to a tractor,
independently (trailer towed with a tractor).
1.5.1 TRANSPORT ON VEHICLE
Loading and unloading of trailer from vehicle shall be conducted using loading ramp with the
aid of an agricultural tractor. During work, adhere to the general principles of occupational
health and safety (OHS) applicable to reloading work. Persons operating reloading
equipment must have the qualifications required to operate these machines. The trailer must
be properly connected with the tractor according to the requirements in this Operators
Manual. The trailer braking system must be started and checked before driving off or onto
ramp.
ATTENTION
Whe bei g road tra sported o a motor vehicle the trailer must be mou ted o the
vehicle's platform i accorda ce with the tra sport safety requireme ts a d the
regulatio s.
Driver of the vehicle should be particularly careful duri g travel. This is due to the
vehicle's ce tre of gravity shifti g upwards whe loaded with the machi e.
Use o ly certified a d tech ically reliable securi g measures. Carefully read the
i formatio co tai ed i the Operator's Ma uals for the give securi g measures.
The trailer should be attached firmly to the platform of the vehicle using straps or chains fitted
with a tightening mechanism. Securing elements should be attached to the transport catches
designed for this purpose (1) – figure (1.3), or permanent structural elements of the trailer
(longitudinal members, crossbars etc.) Transport catches (hooks and eyes) are welded to
upper longitudinal frame (2), with one pair on each side of the trailer. Use certified and
technically reliable securing measures. Worn straps, cracked securing catches, bent or
corroded hooks as well as elements damaged in a different way may be unsuitable for use.
Carefully read the information contained in the Operator's Manual for the given securing
measure. Chocks, wooden blocks or other objects without sharp edges should be placed
under the wheels of the trailer to prevent it from rolling. Trailer wheel blocks must be nailed to
the low platform planks of the vehicle or secured in another manner preventing their
