OPERATOR'S MANUAL
AGRICULTURAL TRAILER
PRONAR RC2100
TRANSLATION OF THE ORIGINAL COPY OF THE MANUAL
ISSUE 2A-09-2010 PUBLICATION NO 208N-00000000-UM

INTRODUCTION
Information contained herein is current at date of publication. As a result of improvements,
some numerical values and illustrations contained in this publication may not correspond to the
factual specification of the machine supplied to the user. The manufacturer reserves the right to
introduce design changes in machines produced that facilitate operation and improve the quality
of their work, without making minor amendments to this Operator's Manual.
This Operator's Manual is an integral part of the machine's documentation. Before using the
machine, the user must carefully read this Operator's Manual and observe all
recommendations. This guarantees safe operation and ensures malfunction free work of the
machine. The machine is designed to meet obligatory standards, documents and legal
regulations currently in force.
The manual describes the basic safety rules and operation of agricultural trailer Pronar RC2100.
If the information contained in the Operator's Manual needs clarification then the user should
refer for assistance to the sale point where the machine was purchased or to the Manufacturer.
MANUFACTURER'S ADDRESS:
PRONAR Sp. z o.o.
ul. Mickiewicza 101A
17-210 Narew
CONTACT TELEPHONES
[phone] [phone]
[phone] [phone]

SYMBOLS APPEARING IN THIS OPERATOR'S MANUAL
Information, descriptions of danger and precautions and also recommendations and prohibitions
associated with user safety instructions are marked:
and also preceded by the word "DANGER”. Failure to observe the instructions may endanger
the machine operator's or other person's health or life.
Particularly important information and instructions, the observance of which is essential, are
distinguished in the text by the sign:
and also preceded by the word "ATTENTION". Failure to observe the instructions may lead to
damage to the machine as a result of improper operation, adjustment or use.
In order to focus the user's attention on the need to perform maintenance, the relevant section
of the Operator's Manual is marked with the pictogram:
Additional tips and advice for machine operation are marked:
and also preceded by the word „TIP”.

DIRECTIONS USED IN THIS OPERATOR'S MANUAL
Left side – side to the left hand of the operator facing in the direction of machine's forward
travel.
Right side – side to the right hand of the operator facing in the direction of machine's forward
travel.
REQUIRED SERVICE ACTIONS
Service actions described in the manual are marked: 
Result of service/adjustment actions or comments concerning the performance of actions are
marked: 

TABLE OF CONTENTS
1 BASIC INFORMATION 1.1
1.1 IDENTIFICATION 1.2
1.1.1 TRAILER IDENTIFICATION 1.2
1.1.2 AXLE IDENTIFICATION 1.3
1.1.3 LIST OF FACTORY NUMBERS 1.4
1.2 PROPER USE 1.4
1.3 OPTIONAL EQUIPMENT 1.7
1.4 WARRANTY TERMS 1.8
1.5 TRANSPORT 1.9
1.5.1 TRANSPORT ON VEHICLE. 1.10
1.5.2 INDEPENDENT TRANSPORT BY THE USER. 1.12
1.6 ENVIRONMENTAL HAZARDS 1.12
1.7 WITHDRAWAL FROM USE 1.13
2 SAFETY ADVICE 2.1
2.1 BASIC SAFETY RULES 2.2
2.1.1 USE OF TRAILER 2.2
2.1.2 HITCHING AND DISCONNECTING FROM TRACTOR 2.3
2.1.3 HYDRAULIC AND PNEUMATIC SYSTEMS 2.4
2.1.4 LOADING AND UNLOADING 2.4
2.1.5 TRANSPORTING THE MACHINE 2.6
2.1.6 TYRES 2.9
2.1.7 MAINTENANCE 2.10
2.2 DESCRIPTION OF MINIMAL RISK 2.12
2.3 INFORMATION AND WARNING DECALS 2.13

3 DESIGN AND OPERATION 3.1
3.1 TECHNICAL SPECIFICATION 3.2
3.2 TRAILER CONSTRUCTION 3.3
3.2.1 CHASSIS AND LOAD PLATFORM 3.3
3.2.2 DRAWBAR OF TRAILER 3.5
3.2.3 SUSPENSION 3.6
3.2.4 MAIN BRAKE 3.7
3.2.5 PARKING BRAKE 3.9
3.2.6 HYDRAULIC SYSTEM OF THE RAMPS 3.10
3.2.7 SUPPORT HYDRAULIC SYSTEM 3.12
3.2.8 LIGHTING SYSTEM 3.13
3.2.9 HYDRAULIC WINCH 3.14
4 CORRECT USE 4.1
4.1 PREPARING FOR WORK BEFORE FIRST USE 4.2
4.1.1 CHECKING THE TRAILER AFTER DELIVERY 4.2
4.1.2 PREPARE A TRAILER FOR FIRST HITCHING TO TRACTOR 4.3
4.2 HITCHING AND DISCONNECTING FROM TRACTOR 4.4
4.3 TRAILER SUPPORT OPERATION 4.7
4.4 LOADING AND UNLOADING THE TRAILER 4.10
4.4.1 STANDARD SIZE LOADS 4.10
4.4.2 OVERSIZE LOADS 4.11
4.4.3 UNLOADING THE TRAILER 4.15
4.5 RAMPS' PROTECTIONS 4.15
4.5.1 RAMPS' INTERLOCK 4.15
4.5.2 SPRING CATCH 4.17
4.6 OPERATION OF HYDRAULIC WINCH 4.18
4.6.1 USE OF HYDRAULIC WINCH 4.18
4.6.2 GENERAL PRINCIPLES OF SAFE OPERATION OF THE WINCH 4.18

4.7 SECURING LOAD 4.19
4.8 TRANSPORTING THE MACHINE 4.21
4.9 PROPER USE AND MAINTENANCE OF TYRES 4.23
5 MAINTENANCE 5.1
5.1 PRELIMINARY INFORMATION 5.2
5.2 SERVICING BRAKES AND AXLES 5.2
5.2.1 PRELIMINARY INFORMATION 5.2
5.2.2 INITIAL INSPECTION OF AXLE BRAKES 5.3
5.2.3 CHECK WHEEL AXLE BEARINGS FOR LOOSENESS 5.4
5.2.4 ADJUSTMENT OF WHEEL AXLE BEARINGS LOOSENESS 5.6
5.2.5 MOUNTING AND DISMOUNTING WHEELS, INSPECTION OF
WHEEL NUT TIGHTENING. 5.7
5.2.6 CHECK AIR PRESSURE, EVALUATE TECHNICAL CONDITION
OF WHEELS AND TYRES, 5.10
5.2.7 ADJUSTMENT OF MECHANICAL BRAKES 5.11
5.2.8 CHANGE OF PARKING BRAKE CABLE AND ADJUSTMENT OF
CABLE TENSION. 5.13
5.3 PNEUMATIC SYSTEM MAINTENANCE 5.16
5.3.1 PRELIMINARY INFORMATION 5.16
5.3.2 INSPECTING AND CHECKING AIR TIGHTNESS OF
PNEUMATIC SYSTEM. 5.17
5.3.3 CLEANING THE AIR FILTERS 5.18
5.3.4 DRAINING WATER FROM AIR TANK 5.19
5.3.5 CLEANING DRAIN VALVE 5.20
5.3.6 CLEANING AND MAINTAINING PNEUMATIC LINE
CONNECTIONS AND PNEUMATIC SOCKETS 5.21
5.3.7 REPLACEMENT OF THE PNEUMATIC LINE 5.22
5.4 HYDRAULIC SYSTEM MAINTENANCE 5.23
5.4.1 PRELIMINARY INFORMATION 5.23
5.4.2 CHECKING HYDRAULIC SYSTEM TIGHTNESS 5.24

5.4.3 CHECKING TECHNICAL CONDITION OF HYDRAULIC
CONNECTIONS AND SOCKETS. 5.24
5.4.4 CHANGE OF HYDRAULIC LINES 5.25
5.5 ADJUSTMENT OF DRAWBAR EYE POSITION 5.25
5.6 OPERATION OF ELECTRICAL SYSTEM AND WARNING
ELEMENTS 5.27
5.6.1 PRELIMINARY INFORMATION 5.27
5.6.2 CHANGE BULBS 5.28
5.7 TRAILER LUBRICATION 5.29
5.8 CONSUMABLES 5.33
5.8.1 HYDRAULIC OIL 5.33
5.8.2 LUBRICANTS 5.34
5.9 CLEANING TRAILER 5.35
5.10 STORAGE 5.37
5.11 TIGHTENING TORQUE FOR NUT AND BOLT
CONNECTIONS 5.37
5.12 TROUBLESHOOTING 5.39

SECTION
1
BASIC INFORMATION

Pronar RC2100 SECTION 1
1.2
1.1 IDENTIFICATION
1.1.1 TRAILER IDENTIFICATION
FIG. 1.1 Location of the data plate and serial number
(1) data plate, (2) example of serial number, (3) right longitudinal member of lower frame
The trailer is marked with data plate (1), located on the trailer's front wall and with serial
number (2) located on a gold painted rectangle. The serial number is stamped on the right
longitudinal member of the frame. When buying the trailer check that the serial numbers on
the machine agree with the number written in the WARRANTY BOOK, in the sales
documents and in the OPERATOR'S MANUAL.

SECTION 1 Pronar RC2100
1.3
TAB. 1.1 Markings on data plate
ITEM
MARKING
A General description and purpose
B Symbol /Type
C Year of manufacture
D Seventeen digit serial number (VIN)
E Official certificate number
F Tare weight
G Maximum gross weight
H Carrying capacity
I Permissible hitching system loading
J Permissible front axle load
K Permissible rear axle load
1.1.2 AXLE IDENTIFICATION
FIG. 1.2 Location of the axle data plate
(1) data plate, (2) wheel axle,
The factory number of the axle shaft and its type are stamped onto the data plate (2) secured
to the axle shaft beam (1) – figure (1.2).

Pronar RC2100 SECTION 1
1.4
1.1.3 LIST OF FACTORY NUMBERS
TIP
If spare parts have to be ordered or if problems occur, it is very ofte ecessary to give
the factory umbers of parts or the VIN umber of the trailer. Therefore, it is
recomme ded that these umbers are i scribed i the table (1.2).
TAB. 1.2 List of factory numbers
VIN
S Z B R C 2 1 0 0 X
FRONT AXLE FACTORY NUMBER
REAR AXLE FACTORY NUMBER
1.2 PROPER USE
The trailer is designed for transporting agricultural and construction machines and the loads
which can be properly secured against moving during travel (loads placed in boxes,
containers, on pallets etc.). Transporting people, animals, bulk and hazardous materials is
forbidden and regarded as contrary to the intended purpose of the trailer. During the use of
the machine comply with all road traffic regulations and transport regulations in force in the
given country, and any breach of these regulations is regarded by the Manufacturer as use
contrary to its intended purpose.
The trailer is constructed according to current safety requirements and engineering
standards. The brake system and the light and indicator system meet the requirements of
road traffic regulations. The maximum speed of the trailer on public roads is 30 km/h in
Poland (pursuant to Road Traffic Act of June 20th 1997, article 20). In the countries where
the trailer is used, the limits stipulated by the road traffic legislation in force in a given country
must be observed. The trailer speed must not, however, be greater than the maximum design
speed of 40 km/h.

SECTION 1 Pronar RC2100
1.5
IMPORTANT!
The trailer must ot be used for purposes other tha those for which it is i te ded. The
user MUST NOT:
•tra sport people, a imals, hazardous materials, chemically aggressive loads
that will corrode the co structio eleme ts of the trailer (causi g corrosio of
steel, destructio of pai t coat, dissolvi g plastic eleme ts a d destructio of
rubber eleme ts etc.),
•tra sport i correctly secured load, which duri g travel may cause
co tami atio of the road a d atural e viro me t,
•tra sport i correctly secured load, which duri g travel may cha ge its
positio o the load platform or fall out of the load platform,
•tra sport load whose ce tre of gravity may destabilise the trailer a d threate
safety duri g travel,
•tra sport loads, which have u eve load distributio a d/or overload axles
a d suspe sio eleme ts.
Using it as intended also involves all actions connected with the safe and proper operation
and maintenance of the machine. In connection with this the user is obliged to:
•carefully read the OPERATOR'S MANUAL of the trailer, WARRANTY BOOK and
comply with the recommendations contained in these documents,
•understand the trailer's operating principle and how to operate it safely and
correctly,
•adhere to the established maintenance and adjustment plans,
•comply with general safety regulations while working,
•prevent accidents,
•comply with the road traffic regulations in force in a given country, in which the
trailer is used,
•carefully read the Operator's Manual and comply with its recommendations,
•only hitch the trailer to an agricultural tractor which fulfils all the requirements
specified by the trailer's Manufacturer.

Pronar RC2100 SECTION 1
1.6
The trailer may only be used by persons, who:
•are familiar with the contents of this publication and with the contents of the
agricultural tractor Operator's Manual,
•have been trained in trailer operation and safe operation,
•have the required authorisation to drive and are familiar with the road traffic
regulations and transport regulations.
TAB. 1.3 Agricultural tractor's requirements
CONTENTS UNIT REQUIREMENTS
Pneumatic brake system
Pneumatic system 2 - line
Nominal pressure of the system
Hydraulic brake system
Hydraulic system
Nominal pressure of the system
-
bar
-
bar
sockets compliant with PN-
ISO 1728:2007
8
sockets compliant with ISO 7421-1
150
Hydraulic system
Hydraulic oil
Pressure rating of the system
Oil demand:
-
MPa
l
L HL 32 Lotos
16
14
Electrical system
Electrical system voltage
Attachment socket
V
-
12
7 polar compliant with ISO 1724
Tractor hitches
Minimum lift capacity (vertical load) of the
hitching system kg 3,000
Other requirements
Minimum tractor power demand kW(KM) 74.6(104)
IMPORTANT!
Use of other oil is permitted o co ditio that it may be mixed with the oil used i the
trailer. Detailed i formatio may be fou d o the product i formatio card.

SECTION 1 Pronar RC2100
1.7
1.3 OPTIONAL EQUIPMENT
TAB. 1.4 Trailer optional equipment
EQUIPMENT
STANDARD
ADDITIONAL
OPTION
OPERATOR'S MANUAL •
WARRANTY BOOK •
2-line pneumatic system with ALB regulator •
2-line pneumatic system with ALB Knorr Bremse regulator •
Hydraulic system •
Drawbar set with ball joint towing attachment ∅80 •
Drawbar set with fixed eye ∅50 •
Drawbar set with fixed eye ∅40 •
Drawbar set with rotating drawbar eye ∅50 •
Ramp folding mechanism •
Hydraulic system for ramp folding •
Wheel chocks •
Slow-moving vehicle warning sign •
Warning reflective triangle •
Mudguards •
Water tank •
Side Barriers •
Fixing lugs •
Toolbox •

Pronar RC2100 SECTION 1
1.8
EQUIPMENT
STANDARD
ADDITIONAL
OPTION
Spare wheel (1 or 2 pcs) •
Floor extensions + plank holder •
Connection lead for the electrical system •
Hydraulic winch •
Floor planks (coniferous wood planks) •
Floor planks (oak wood planks) •
Information concerning tyres is provided at the end of this publication in ANNEX A.
1.4 WARRANTY TERMS
PRONAR Sp. z o.o., Narew guarantees the reliable operation of the machine when it is used
according to its intended purpose as described in the OPERATOR'S MANUAL. The repair
period is specified in the WARRANTY BOOK.
The guarantee does not apply to those parts and sub-assemblies of the machine, which are
subject to wear in normal usage conditions, regardless of the warranty period. Consumables
include the following parts/sub-assemblies:
•drawbar hitching eye,
•pneumatic system connector filters,
•tyres,
•brake shoes,
•bulbs and LED lamps,
•seals,
•bearings,
•floor planks.

SECTION 1 Pronar RC2100
1.9
The warranty service only applies to such cases as: mechanical damage, which is not the
user's fault, factory defects of parts, etc.
In the event of damage arising from:
•mechanical damage which is the user's fault, caused by road accidents,
•by inappropriate use, adjustment or maintenance, use of the trailer for purposes
other than those for which it is intended,
•use of damaged machine,
•repairs carried out by unauthorised persons, improperly carried out repairs,
•making unauthorised alterations to machine design,
the user will lose the right to warranty service.
TIP
Dema d that the seller carefully a d precisely fills out the Warra ty Book a d guara tee
repair coupo s. A missi g date of purchase or sale poi t stamp, may make the user
i eligible for a y warra ty repair or refu d.
The user is obliged to report immediately on noticing any wear in the paint coating or traces
of corrosion, and to have the faults rectified whether they are covered by the guarantee or
not. Detailed guarantee regulations are contained in the WARRANTY BOOK attached to
each machine.
Modification of the trailer without the written consent of the Manufacturer is forbidden. In
particular, do NOT weld, drill holes in, cut or heat the main structural elements of the
machine, which have a direct impact on the machine operation safety.
1.5 TRANSPORT
The trailer is ready for sale completely assembled and does not require packing. Packing is
only required for the machine's technical documentation and any extra fittings. The trailer is
delivered to the user either transported on a vehicle or, after being attached to a tractor,
independently (trailer towed with a tractor).

Pronar RC2100 SECTION 1
1.10
1.5.1 TRANSPORT ON VEHICLE.
Loading and unloading of trailer from vehicle shall be conducted using loading ramp with the
aid of an agricultural tractor. During work adhere to the general principles of Health and
Safety at Work applicable to reloading work. Persons operating reloading equipment must
have the qualifications required to operate these machines. The trailer must be properly
connected with the tractor according to the requirements in this Operators Manual. The trailer
brake system must be started in checked before driving off or onto ramp.
The trailer should be attached firmly to the platform of the vehicle using straps or chains fitted
with a tightening mechanism. Securing elements should be attached to the transport catches
designed for this purpose (1) Figure (1.3) or to permanent structural elements of the trailer
(longitudinal members, crossbars etc.). Transport catches (hooks and eyes) are welded to
upper longitudinal frame (2), with one pair on each side of the trailer. Use certified and
technically reliable securing measures. Worn straps, cracked securing catches, bent or
corroded as well as other damage may disqualify use of the given element from use.
Carefully read the information contained in the Operator's Manual for the given securing
measure. Chocks, wooden blocks or other objects without sharp edges should be placed
under the wheels of the trailer to prevent it from rolling. Trailer wheel blocks must be nailed to
the low platform planks of the vehicle or secured in another manner preventing their
movement. The number of securing elements (cables, straps, chains and stay etc.) and the
force necessary for their tensioning depends on a number of things, including weight of the
trailer, the construction of vehicle carrying trailer, speed of travel and other conditions. For
this reason it is impossible to define the securing plan precisely. A correctly secured trailer
does not change its position with regard to the transport in vehicle. The securing elements
must be selected according to the guidelines of the Manufacturer of these elements. In case
of doubt apply a greater number of securing straps in order to immobilise the trailer. If
necessary, sharp edges of trailer should be protected at the same time protecting the
securing straps from breaking during transport.
During reloading work, particular care should be taken not to damage parts of the machine's
fittings or the lacquer coating. The tare weight of the trailer in condition ready for travel is
given in table (3.1).
