PulseTech SP-12-OBD-T User manual

Installation Manual
For Model
SP-12-OBD-T
GETTING STARTED
What SolarPulse Can Do For You
SolarPulse is one of the most effective methods available for charging your 12-volt lead-acid batteries. Besides
charging, it also uses our patented Pulse Technology®to remove and prevent the buildup of lead-sulfate deposits
on your battery plates. By keeping the plates clean, your battery recharges faster, accepts a full charge and releases
all its stored energy.
The SP-12-OBD-T 12-Watt SolarPulse unit has three components:
• Solar Panel with quick disconnect for easier installation
• Circuit Box housing our exclusive Pulse Technology
• OBD connector
Installation is quick and easy. Just follow the steps inside.
WARNING: Because of the possibility of personal injury, always use extreme caution when working with batteries.
SPECIFICATIONS
Max Charge Current: 750 mA Maximum Output Voltage: 16.5 V
Solar Panel Dimensions: 12.41" L x 9.85" W x 0.2" H Circuit Box Dimensions: 3.4" L x 2.4" W x 1.5" H
Main Cable Length: 17' Lug Cable Length: 3'
Quick Disconnect Between Solar Panel & Circuit Box LED Pulse/Charge Indicator
High-Quality Weatherproof Suction Cups
WARRANTY AND WARNINGS
10-Year Limited Warranty
What Does This Warranty Cover? The warranty covers any defects in workmanship or materials in the
circuit board in the SolarPulse™ product under normal use and service. How Long Does The Coverage
Last? This warranty runs for ten (10) years from the date of purchase. What Will PulseTech Do? PulseTech
will, at its option, replace or repair any defective circuit board with a new or rebuilt circuit board at no charge.
What Does This Warranty Not Cover? This warranty does not cover any parts other than the circuit board.
In addition, PulseTech will not be responsible under this warranty if PulseTech determines that (1) upon
examination that the circuit board failure was (A) caused by misuse, neglect, accident, alteration, or abnormal
condition of operating or handling (including the failure to install the product in accordance with PulseTech’s
instructions and observe the warnings on the product and the instruction manual), or other conditions beyond
the control of PulseTech or (B) damaged in transit to PulseTech, or (2) the owner is not the original purchaser
that purchased the product through an authorized PulseTech dealer or distributer. IN NO EVENT SHALL
PULSETECH BE LIABLE FOR ANY DIRECT, SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL, PUNITIVE OR
EXEMPLARY DAMAGES, EXPENSES, LOST SAVINGS OR LOST PROFITS OR ANY OTHER DAMAGES OF ANY
KIND FROM ANY BREECH OF THIS WARRANTY OR OTHERWISE. Some states, provinces or countries do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply
to you. How To Get Service? Send the product postage prepaid with proof of purchase (sales receipt) within
the warranty period to the authorized reseller where the product was purchased or contact PulseTech directly
by calling [phone]. How Does State, Province or Country Law Apply? This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state, province to province or country
to country.
THIS WARRANTY IS THE SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
FOR FITNESS FOR A PARTICULAR PURPOSE.
WARNING
The pulsating DC current produced by
this product may interfere with the correct
operation of some electronic devices when
the unit is placed near the antenna. In order
to ensure no interference, the circuit box
should be placed away from the antenna.
BASIC CLEANING & MAINTENANCE
• Be sure to keep the solar panel clean of
dirt and dust so that it has optimum access
to sunlight.
• The circuit box has no moving parts so
maintenance is unnecessary.
• Periodically check to make sure the positive
and negative wires are securely fastened to
the battery terminals.
Circuit Box
Quick Disconnect
OBD Connector
Solar Panel
Suction Cups

4
WARNING: Always remove temporary solar
panel(s) before moving the vehicle.
NOTE: For the most effective results, we suggest you install a
SP-12 permanently. However, if your vehicle does not allow for a
permanent install, temporary placement of the SP-12-OBD-T will
not affect performance.
[phone]www.pulsetech.com
998MX360 08/23
Remove the suction cups and solar panel from
the box. Screw a suction cup into each of the four
corners of the solar panel.
Let the solar panel cable hang down to the vehicle’s
OBD port.
Connect the quick-disconnect plugs on the solar
panel and circuit box cables.
Push the OBD connector into the OBD port and
ensure it’s secure.
Make sure the circuit box’s LED lights up indicating
the solar panel is working at an optimum level. The
LED dims when solar panel is in partial sunlight and
you may need to move the solar panel into direct
sunlight for maximum effectiveness.
Lay the circuit box on the floor.
Make sure the suction cups are securely attached
to the solar panel, and the bottom of the suction
cups are clean. Mount the solar panel on the inside
of the vehicle windshield where it will have direct
access to sunlight.
WARNING: Any solvents that may be
harmful to plastic should not be used on
or near the unit.
Installation Instructions For Model SP-12-OBD-T
