Puretec Basic HD Series User manual

User Guide
For correct operation & installation, it is essential to observe these instructions.
AUG2020
Water Filtration Housings
HD / HD-B / LD Series
DO NOT OVERTIGHTEN.
DO NOT USE
LIQUID SEALANTS.
SURGE PROTECTION
REQUIRED /
NO EXTENSION CORDS.
SURGE PROTECTION
REQUIRED /
NO EXTENSION CORDS.

2 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Puretec Customer Service
Thank you for purchasing a Puretec water lter housing. Your housing is a proven
performer manufactured from only quality materials and components and will give
years of ‘spring fresh’ water free of impurities if maintained properly.
The housing can be used in a wide variety of applications and is compatible with a
wide range water lter cartridges (sold separately). Select a cartridge that best suits
your situation/water source. For cartridge selection advice contact your local Puretec
dealer or call our Puretec Customer Service Helpline.
With a sediment lter some features include:
• Supply clean water to kitchen, bathroom and laundry.
• Extends the life of appliances by removing silt, rust etc protecting hot water
systems, washing machines, dishwashers, solenoid garden valves, tap washers,
ceramic disc mixer taps and thermostatic valves.
• Minimises build-up in pipework and reduces repair costs.
With a taste and odour removal lter you will:
• Provide healthy, clean and pure water for all household drinking, cooking and
showering needs.
• Have better tasting beverages, tea, coee, drinking water and ice.
• Safe water to drink, free from harmful chemicals - also safe for baby formulas.
• Chemicals absorbed by the skin can be removed for use in the shower.
What's Inside
Introduction................................................................................................................................. 2
Guidelines and Warnings ..................................................................................................... 3
Positioning Your Filter............................................................................................................ 4
Installation Procedure ........................................................................................................... 4
Typical Installation.................................................................................................................. 4
Replacement Guide................................................................................................................. 5
Cartridge Installation / Replacement ............................................................................ 6
Replacement Parts List......................................................................................................... 7
Warranty ....................................................................................................................................... 8
What's Inside

3
HD / HD-B / LD Series Water Filtration Housings
Guidelines & Warnings
The Puretec lter housing cartridges need replacing regularly to maintain optimum
performance. Replace cartridges when water ow is reduced, taste or odour returns
to water (carbon cartridges only) or every 6 to 12 months. For cartridge replacements
contact your nearest Puretec stockist.
Customer Service Helpline 1300 140 140 (Australia) 0800 130 140 (New Zealand).
Guidelines and Warnings
• Where line pressure exceeds 350 kPa for HD1020-BC and 520 kPa for all other
housings, a pressure limiting valve must be tted prior to inlet. Protect the housing
from water hammer.
• Use on cold water line only (with water up to 52°C). For installation over 52°C
please enquire as to a suitable housing. Protect the housing from freezing.
• Do not install in direct sunlight.
• Clear housings must not be installed externally as housings must be
protected from direct sunlight to prevent bacterial growth.
• Use PTFE thread seal tape on all connections. Use of liquid pipe sealants/
dope will void warranty.
• Do not overtighten. Too much tape or over tightening may cause head to split.
• For point of entry installations an approved dual check backow prevention device
must be tted in accordance with national plumbing product codes.
• Do not use with water that is microbiologically unsafe or with water of unknown
quality without adequate disinfection.
• This product must be installed in accordance with local plumbing regulations by a
licensed plumber.
Installation Note: A water lter system/tap, like any product, has a limited life
and may eventually fail. Also sometimes failure happens early due to unforeseen
circumstances. To avoid possible property damage, this product should be regularly
examined for leakage and/or deterioration and replaced when necessary. A drain pan,
plumbed to an appropriate drain or outtted with a leak detector, should be used in
those applications where any leakage could cause property damage, and/or the water
supply should be turned o if no one is home/present.
INSTALLATION MUST BE COMPLETED BY A LICENCED PLUMBER. FAULTY
OPERATION DUE TO UNQUALIFIED PERSONS WILL RESULT IN VOIDED
WARRANTY COVERAGE.

4 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Connecting
Pipework
Isolation
Valve
Pressure
Limiting Valve Isolation
Valve (recommended)
OutletInlet
Positioning Your Filter
Positioning Your Filter
Choose a location where any water spillage will not cause damage. If a cupboard
is chosen care needs to be taken in case of water spillage or ooding. Make sure
mounting position is solid so that the lter housing stays in position when changing
lters. An isolation valve may be installed immediately prior to the lter to isolate the
lter for changing the cartridge.
Installation Procedure
1. Isolate water supply and relieve pressure by opening a downstream tap.
2. Cut pipe to suit length of required valve and housing installation.
3. Use approved brass, galv/poly plumbing ttings to suit existing pipework. The
female threads on the housing will receive tapered male threads. Thread into
housing head carefully as too much tape or overtightening may cause it to split
WARNING: Use PTFE thread seal tape on all connections. Use of liquid pipe
sealant/dope will void warranty.
4. If using sweated ttings, allow enough time to cool before connecting to the
housing.
5. Securely x wall mount bracket and pipework with suitable clips. Allow 50mm
clearance under the housing bowl for lter changes.
6. Flush debris from pipework.
7. Install lter cartridge as per cartridge replacement instructions.
Typical Installation

5
HD / HD-B / LD Series Water Filtration Housings
Replacement Guide
You can obtain replacements from your local Puretec dealer. To maintain performance,
warranty and standards use genuine Puretec replacements.
To maintain the high quality of the puried water the cartridge need changing every
6 - 12 months, dependent on water quality and usage. You can obtain replacement
cartridges from your local Puretec stockist. To maintain performance and warranty use
genuine Puretec replacements.
The following tables provide a guide to what lter cartridge can be used in your housing:
Replacement Guide
Model Code Dirt, Rust, Sediment
(Mains Water)
Taste, Odour Removal
(Mains Water)
Dirt, Rust, Sediment
(Rainwater)
Taste, Odour Removal
(Rainwater)
LD1025
LD1025K
LD1040
LD1040K
MB05LD1 EC10LD1 PP05LD1 ML10LD1-DP
LD2025
LD2025K
LD2040
LD2040K
MB05LD2 EC10LD2 PP05LD2 ML10LD2-DP
Model Code Dirt, Rust, Sediment
(Mains Water)
Taste, Odour Removal
(Mains Water)
Dirt, Rust, Sediment
(Rainwater)
Taste, Odour Removal
(Rainwater)
HD1020-B
HD1020-BC MB051 GA051 PP051 ML101-DP
HD2020-B
HD2020K MB052 GA202 PP052 ML102-DP
HD-B Housings
LD Housings
Model Code Dirt, Rust, Sediment
(Mains Water)
Taste, Odour Removal
(Mains Water)
Dirt, Rust, Sediment
(Rainwater)
Taste, Odour Removal
(Rainwater)
HD10006-S
HD1020-S
HD1020-K MB051 GA051 PP051 ML101-DP
HD Housings

6 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Cartridge Installation
Cartridge Installation / Replacement
To change the lter cartridge please adhere to the following procedure:
1 Turn water supply o and relieve pressure by opening a downstream tap or
pressing the red pressure relief button on the housing(s) (if tted).
2 Unscrew the lter bowl anti-clockwise. If dicult to undo, use the wrench provided.
Remove old cartridge. We recommend replacing O-rings every 3 - 5 years to
ensure a water tight seal, preventing any leaks.
3 Clean bowl with soap and warm water and rinse thoroughly. Check O-ring for
damage and if there is any, replace.
4 Check O-ring lubrication and if necessary apply a light coating of food grade
silicone lubricant (or similar).
5 Remove all packaging from new lter cartridge and insert into housing bowl
making sure cartridge is properly seated over spigot in base of bowl. Remember to
record the model no. of the cartridge you use.
6 Hold the bowl upright while screwing onto head. Make certain that the spigot in
the housing head is located centrally to the cartridge to make a good seal. Hand
tighten bowl until rm. DO NOT OVER TIGHTEN.
7 Open downstream tap to allow air to be released and gently open water supply
allowing all air to be purged.
8 Allow water to run for 2 minutes to ush the system.
9 Close down stream tap and check for leaks. Flush system for 10 minutes aer any
period of non-use more than 2 days. For a period of non-use of 2 weeks or more,
it may be necessary to replace the cartridge.

7
HD / HD-B / LD Series Water Filtration Housings
Replacement Parts List
Sold separately
(included in housing
kits only).
Wall Mount Bracket
HD Housings HDBK
HD-B Housings HDBK-B
LD Housings LDBK
O-ring
HD Housings HDOR
HD-B Housings HDOR-B
LD Housings LD0R
Filter Housing Bowl
(housing model code)
Filter Housing Head
(housing model code)
Housing Spanner
HD Housings HDW10
HD-B Housings HDW10-B
FP Housings FPSP
Notes
Puretec water care products are designed, manufactured and supported by Puretec Pty Ltd the name you can
trust for viable and proven water solutions. The complete range of Puretec products are developed, rened, made
to meet and exceed stringent specications for the worldwide market.
Important: Sales of products are subject to our Terms and Conditions which are available upon request. All
specications, information and photos are a guide only and are subject to change without notice. Please ring
to conrm details. Warning: For correct operation of this appliance it is essential to observe manufacturer’s
instructions.
Replacement Parts List

Warranty
Any claim under this warranty must be made within 1 year of the date of purchase of the product. This product is
warranted to be free of defect of material and workmanship for 1 years from date of purchase. 1 year warranty
is 1 year parts and labour.
To make a claim under the warranty, take the product and proof of purchase to place where you purchased the
product, and they will lodge a Warranty Request with Puretec.
Puretec will pay your reasonable, direct expenses of claiming under this warranty. You may submit details and
proof of your expense claim to place of purchase for consideration.
The warranty only applies if the product was used and/or installed in accordance with the user guide and/or
installation instructions. This warranty is given in lieu of all other express or implied warranties and manufacturer
shall in no circumstance be held liable for damages consequential or otherwise or delays caused or faulty
manufacturing except as excluded by law.
Applicable to all above, is that the Warranties need to be approved by Puretec to ensure product was not
incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including
chargeable inspection and labour costs incurred.
All installation and service work should be completed by qualied tradespeople. Faulty operation due to
unqualied persons will result in voided warranty coverage.
Use PTFE thread seal tape on all connections. Use of liquid pipe sealant/dope will void warranty.
Warranty/Australia
This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road, Lonsdale SA 5160, telephone
no. 1300 140 140 and email at [email protected].
This warranty is provided in addition to other rights and remedies you have under law: Our goods come with
guarantees which cannot be excluded under the Australian Consumer Law. You are entitled to replacement or
refund for a major failure and to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Warranty/New Zealand
This warranty is given by Puretec Ltd, Reg. No 4464398, PO Box 875 Cambridge 3450 NZ, telephone no. 0800
130 140 and email at [email protected].
This warranty is provided in addition to other rights and remedies you have under law: Our goods come with
guarantees which cannot be excluded under the Consumer Guarantees Act. You are entitled to replacement or
refund for a major failure and to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Warranty
