Puretec CR-Z2 User manual

User Guide
Caravan / RV Quick Twist Undersink Water Filter System
CR-Z2
For correct operation & installation, it is essential to observe these instructions.NOV2020

2Installation & Operation Manual Copyright © Puretec Ltd 2020
Puretec Customer Service
Thank you for purchasing a Puretec Caravan / RV Quick Twist Undersink Water Filter System.
Your system is a proven performer manufactured from only quality materials and components
and will give years of ‘spring fresh’ water free of impurities if maintained properly.
The Puretec CR-Z2 system cartridges need replacing regularly to maintain optimum
performance. This is a simple procedure when following instructions. For cartridge
replacements contact your nearest Puretec stockist.
Customer Service Helpline 1300 140 140 (Australia) 0800 130 140 (New Zealand).
Caution: Do not use with water that is microbiologically unsafe or with water of unknown

What's Inside
Operation ............................................................................................................................................... 3
Cartridge Replacement................................................................................................................... 3
Installation Requirements and Procedure ........................................................................... 3
Cartridge Changeout ....................................................................................................................... 4
Use Guidelines .................................................................................................................................... 5
Assembly................................................................................................................................................ 6
Faucet Connections.......................................................................................................................... 7
Battery Installation................................................................................................................................8
Warranty....................................................................................................................................................... 9
What's Inside
This product contains a button battery. Accidental ingestion may
occur and can be fatal. Please keep out of reach from infants. If you
suspect an accidental ingestion please contact emergency services.

3
Compact Caravan / RV Inline Undersink Water Filter System with LED Faucet
Operation
The Puretec CR-Z2 systems are designed to run economically for many years dependent on
the initial installation and periodical maintenance.

non-use of 2 weeks or more, it may be necessary to replace cartridge.
Cartridge Replacement

months (dependent on water quality and usage).
When replacing the cartridge, ensure you reset the LED reminder light by removing/replacing
the battery from the rubber seat. Please refer to page 6 for a detailed diagram.
Order Z2-R for a replacement cartridge to suit your CR-Z2 system.
Installation
This system comes complete with an installation kit enabling it to be connected to 12 mm
tubing.
Installation Note
eventually fail. Also sometimes failure happens early due to unforeseen circumstances. To
avoid possible property damage, this product should be regularly examined for leakage and/or
deterioration and replaced when necessary. A drain pan, plumbed to an appropriate drain or


Installation requirements
1 12 mm tubing.
2 Supply pressure: 200 - 520 kPa.
3 Supply temperature 0° - 38 °C (protect from freezing).
4 Suitable location for faucet.
 
tube. No electrical or drainage requirements needed.

4Installation & Operation Manual Copyright © Puretec Ltd 2020
Installation Procedure
 

spillage will not cause damage. Location should not be in direct sunlight.
2. Isolate water supply. Uninstall the connections on the cold water line and connect the

supplied thread seal tape on each of the threads. Reinstall the previous connection to
the Tee
3. Choose the best position for the faucet, taking into consideration height of jugs etc.

as in the instructions for your model in step 5.
4. To install the faucet, connect spout to the base of the faucet, ensuring that the white

then tighten by hand. Once connected, place the escutcheon and O-ring supplied onto
the base of the tap. Insert into the counter top or sink and place the plastic washer,
lock washer and locking nut onto the thread and tighten, ensuring the tap is in the


thread.
Note: 

5. Reset LED indicator by following instructions on page 8.
 



 
in the tubing.
 
Tubing on the inlet side.

tap adaptor.
9. Restore the water supply and check for leaks.
 

Installation

5
Compact Caravan / RV Inline Undersink Water Filter System with LED Faucet
Installation
Cartridge Installation/Changeout
1. Rotate the old cartridge counterclockwise 1/4 turn, pull it out and dispose of it.
2. Remove all packaging from the new cartridge, including any wraps or caps (if
applicable).
Replacement cartridge Z2-R
 
4. Reset LED indicator by following instructions on Page 7 & 10.
5. Turn on the water and check for leaks. If leaks occur, repeat step 3. If leaks persist,
discontinue use and call your supporting dealer.
 
Use Guidelines
• Minimum operating pressure 200 kPa.
• Maximum operating pressure 520 kPa.
• Do not allow exposure to temperatures below 0 °C, protect from freezing.
• Maximum operating temperature 38 °C (protect from freezing).
 
• Replacement Cartridge: Z2-R
 

replacement frequency.
 


Caution: Do not use with water that is microbiologically unsafe or of unknown quality


6Installation & Operation Manual Copyright © Puretec Ltd 2020
Assembly
Figure 1
1
No. DESCRIPTION
1 Tee Connector
2
3
4 Mounting Bracket & Head
5 Z2-R Filter Cartridge
6 White Tubing
2 3
5
6
7
8
9
10 11
12
4
77/16
8 Faucet Lock Nut and Washer
9 Black Plastic Washer
10 Black Rubber Washer
11 Escutcheon
12 DFU180 High Loop Faucet

7
Compact Caravan / RV Inline Undersink Water Filter System with LED Faucet
1. Cut the tube square and push in to
the tube stop. For metal tube remove
burrs and chamfer tube end to prevent
O-Ring seal being damaged.
DISCONNECTION PROCEDURE
 
2. Fitting grips before it seals. Ensure
tube is pushed in to tube stop.
HOW TO USE QUICK CONNECT FITTINGS
3. Tube is secured in position.
Figure 2
Assembly
Figure 3
Note: Parts packet also contains


tube connection and are not needed

Gasket
Cone Washer/Olive

Faucet
LED Display
Battery Seat
Circuit Board
Battery
(CR2032)
Escutcheon
12.5mm Hole
Counter Top
Faucet Tap Adaptor
Locking Nut
Plastic Washer

Lock Washer
Large Rubber Washer

8Installation & Operation Manual Copyright © Puretec Ltd 2020
Battery Installation - LED Reminder Light
1. Remove the black
battery seat
from the faucet
lever handle (see
Figure 3).
2. Install battery
into the battery
seat, positive
side up.

twice and then followed
by the blue light.
3. Reinstall battery
seat assembly
into the faucet
lever.
Important Note: Battery must be replaced when changing cartridges.
 
are due to be changed (usage has
exceeded 3,000 minutes or 12 months).
Please change the battery when
changing the cartridges.
Positive
side up
Negative on
the PCB
 
during normal
operation.
LED Reminder Light

Notes
Puretec water care products are designed, manufactured and supported by Puretec Pty Ltd
the name you can trust for viable and proven water solutions. The complete range of Puretec

worldwide market.
Important: Sales of products are subject to our Terms and Conditions which are available


appliance it is essential to observe manufacturer’s instructions.
Warranty
Any claim under this warranty must be made within 10 years of the date of purchase of the
product. This product is warranted to be free of defect of material and workmanship for 10
years from date of purchase. 10 year warranty is 1 year parts and lanour plus 9 years parts
only. Excludes cartridges.
To make a claim under the warranty, take the product and proof of purchase to place where
you purchased the product, and they will lodge a Warranty Request with Puretec.
Puretec will pay your reasonable, direct expenses of claiming under this warranty. You may
submit details and proof of your expense claim to place of purchase for consideration.
The warranty only applies if the product was used and/or installed in accordance with the
user guide and/or installation instructions. This warranty is given in lieu of all other express
or implied warranties and manufacturer shall in no circumstance be held liable for damages
consequential or otherwise or delays caused or faulty manufacturing except as excluded by
law.
Applicable to all above, is that the warranties need to be approved by Puretec to ensure
product was not incorrectly used, installed or claimed. False and incorrect claims will be
pursued at Puretec’s discretion, including chargeable inspection and labour costs incurred.
