QDI P5I865PE User manual

Notice
The information inthisdocumentissubjectto
change inordertoimprovereliability,design,or
function withoutpriornoticeand doesnotrepre-
sentacommitmenton the partofthiscompany.
Inno eventwill webe liablefordirect, indirect,
special,incidental,orconsequentialdamages
arising outofthe useorthe possibilityofsuch
damages.
All trademarks arethe propertyoftheirrespec-
tiveowners.
If you need anyfurtherinformation,pleasevisit
ourweb-site:“www.qdigrp.com”.
Thisitemchecklistisonlyavailableforretail
market. Completelycheck yourpackage,If you
discoverdamaged ormissing items,contact
yourretailer.
ItemChecklist
P5I865PEseriesmainboard
QDIUtilityCD
1HDribboncable
1FDDcable
User’smanual
I/Oshield(option)
USB cable(option)

CertificateofCompliance
The followingproductshavebeen tested byuswiththe listedstandardsandfound in
compliancewiththe council EMCdirective89/336/EEC.It isdemonstrativeforthe
compliancewiththisEMCDirective.
Submittor:QDITechnologyLimited
23Floor,LincolnHouse,Taikoo Place 979 King’s
Road,QuarryBay,HONGKONG
Product: MotherBoard
M/N:P5I865PE
þEN55022/A1:2000 Limitsand methodsofmeasurementsofradio
disturbancecharacteristics ofinformation technology
equipment
þEN61000-3-2/A14:2000 Electromagneticcompatibility(EMC)
Part3:Limits
Section 2:Limitsforharmoniccurrentemissions
(equipmentinputcurrent<=16Aperphase)
þEN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)
Part3:Limits
Section 3:Limitsofvoltage fluctuationsand flickerin
low-voltage supplysystemsforequipmentwith
rated current<=16A
þEN55024/A1:2001 Information technologyequipment-Immunitycharac-
teristics limitsand methodsofmeasurement
Signature:Date:2004.02.01
Printed Name:Wang Dayong Position:GeneralManager
Thestatementisbasedon asingleevaluation ofonesampleofabovementionedproducts.Itdoesnotimply
anassessmentofthewholeproduction and doesnotpermit theuseofthetestlab.logo.

Declaration ofconformity
TradeName:QDIComputer(U.S.A.)Inc.
ModelName:P5I865PE
ResponsibleParty:QDIComputer(U.S.A.)Inc.
Address:41456 ChristyStreet
Fremont,CA94538
Telephone:[phone]
Facsimile:[phone]
EquipmentClassification:FCC Class BSubassembly
TypeofProduct: Mainboard
Manufacturer:QDITECHNOLOGY(HK)Inc.
Address:23Floor,LincolnHouse,Taikoo Place
979 King’sRoad,QuarryBay,HONG
KONG
SupplementaryInformation:
Thisdevice complieswithPart15 oftheFCC Rules.Operation issubjectto
thefollowing twoconditions:(1)thisdevice maynotcauseharmfulinterfer-
ence,and (2)thisdevice mustacceptany interference received,including
interference thatmaycauseundesiredoperation.
TestedtocomplywithFCC standards.
Signature:Date:2004

CONTENTS
Chapter1
Introduction.....................................................................1
KeyFeatures..................................................................2
Chapter2
InstallationInstructions.........................................................4
ExternalConnectors............................................................5
PS/2Keyboard/MouseConnector...................................5
USB1,USB2,USB3,USB4andLANConnectors................5
ParallelPort,SerialPortandSPDIFConnectors................5
Line-injack,Mic-injack andSpeaker-outjack ..................6
6-ChannelAudio.............................................................6
ATX12VPowerSupplyConnectors&PowerSwitch......7
HardDiskLEDConnector(HD_LED)...............................7
ResetSwitch(RESET)..................................................7
PowerLEDConnector(PWR_LED).................................8
FanConnectors(CPU_FAN,SYS_FAN).........................8
F_USB1;F_USB2Connector..........................................9
InfraredHeader(IrDA)...................................................9
AudioConnector(CD_IN)................................................10
SPEAKERConnector(optional).........................................10
DiagnosisLED.................................................................11
FrontAudioInterface(F_AUDIO)......................................12
OnboardSATA................................................................12
SPDIF_OUTConnector(optional).....................................13
SPDIF_INConnector(optional).........................................13
ChassisSecuritySwitch(CHSSEC)..................................13
SerialPortConnector(COM2)(optional)............................14
Wake_upOnInternalModem(WOM).................................14
JumperSettings..................................................................15
BIOS-ProtectionJumper(BIOS_WP)...................................15
Enablekeyboardpasswordpower-on function(JKB).........16
ClearCMOS(CLR_CMOS).....................................................17

CONTENTS
Chapter3
BIOSDescription................................................................18
AWDFLASH.EXE...............................................................19
AWARD BIOSDescription.................................................20
Appendix
QDIUtilityCD.......................................................................22
Using4-/6-ChannelAudio...................................................25
Layout

Caution
Caution
Besuretoadd someSiliconeGrease betweentheCPUand the
heatsinktokeepthemfullycontactedtomeettheheatsinkrequire-
ment.
Besuretounplug theAC powersupplybeforeadding or
removing expansion cards,RAMorothersystemperipherals,
otherwise yourmainboardand RAMmightbeseriouslydamaged.
Note:
ThismanualissuitableforP5I865PE series ofmainboards.Each
mainboardiscarefullydesignedforthePCuserwho wantsdifferent
features.
-6A:with6channelAudio
-L:withonboard10/100MLAN
-K:withonboardG-bitLAN

P5I865PE
1
Chapter1
Chapter1
P5I865PE seriesofmainboardsutilizeIntel®865PE +ICH5
chipset, providing afullycompatible,high performanceand
cost-effectiveATXplatform.The newintegrated
technologies,togetherwithAC’97 audio(2/6-channel),8
USB,2SATA,and ATA100/66/33,givecustomersan
advanced,multimediasolution atreasonableprice.It pro-
vides533/800MHzhostbusspeed tosupportIntel®LGA775
processorsand the DDR266/333/400 memory.It alsopro-
videsadvanced featuressuchasACPIfunction.Suspend-
ing toRAM,the optimalimplementation ofthe Advanced
Configuration and PowerInterface(ACPI)specification,
makesthe PC’spowerconsumption drop tothe lowestpos-
sibleleveland enablequick wakeup.
Introduction

Introduction
P5I865PE
2
Key Features
Formfactor
ATXformfactorof295mm x220mm
Microprocessor
SupportsIntel®LGAprocessors
Supports533/800MHzhostbusspeed
Systemmemory
Providesthree 184-pinDDR SDRAMinterfaces
SupportsDDR266/333/400 SDRAM
Supports128/256/512Mbtechnologyup to3GB
Graphics Interface
The AGPinterfaceSupports1.5Vsignaling with8Xdatatransfer
OnboardIDE
SupportsIndependenttiming ofup to4drives
SupportsUltraATA33/66/100
TwofastIDEinterfacessupporting fourIDEdevices
OnboardLAN(optional)
10/100(availableon -Lmainboard)/1000(availableon -Kmainboard)Mbit/sec
Ethernetsupport
10/100/1000M(availableon -Kmainboard)LANinterfacebuilt-inon board
USB2.0
USB 2.0compliant, operatesat480Mbps,about40Xtimesfasterthan USB 1.1
Provides8USB 2.0ports
OnboardI/O
One floppyportsupporting up totwo3.5″floppydriveswith1.44Mformat
Twohigh speed 16550 compatibleCOMwith16 bytesend/receiveFIFO
One parallelportsupportsSPP/EPP/ECP/ECP+EPP mode
SupportsPS/2mouseand PS/2keyboard
Providesone IrDAconnector
All I/Oportscan be enabled/disabled inthe BIOSsetup
OnboardAudio
AC’97 2.3Specification Compliant
ProvidesonboardLine-inJack,Microphone-inJack and Speaker-outJack
6-channelOnboardAudio
ProvidesFrontleft&right, Rearleft&right/Line-inJack and Center&Woofer/Micro
phone-inJack,whichcan be specified bysoftware
Advancedfeatures
PCI2.2Specification Compliant
SupportsWindows98/2000/ME/XP soft-off
OnboardSATA
TwoSATAdevicesincluding SATAHDD and CDROM/DVDROMdevices
Supports150Mbpstransferrate.

P5I865PE
3
Chapter1
BIOS
Licensed advanced AWARD(Phoenix)BIOS,supportsflashROM,plug and play
ready
SupportsIDECDROM/USB bootup.
Greenfunction
SupportsACPI(Advanced Configuration and PowerInterface)and ODPM(OS
Directed PowerManagement)
SupportsACPIpowerstatus:S0(full-on),S1(poweron suspend),S3(suspend to
RAM),S4(suspend toDisk,dependson OS)and S5(soft-off)
MainExpansion Slotsand Connectors
Slot/Port(Quantity)Description
PCI(5)PCIslots
IDE(2)IDEports
FLOPPY(1)FloppyDriveport
DDR(3)DIMM socket
USB(8)USB connectors
AGP(1)AGPslot
LAN(1)(optional)LANconnector
COM(2)(optional)COMconnectors
PARALLEL(1)Parallelconnector
IrDA(1)IrDAconnector

Installation Instructions
P5I865PE
4
Installation Instructions
Chapter2
Thissection coversExternalConnectorsand Jumper
Settings.Refertothe mainboardlayoutchartforlocations
ofall jumpers,externalconnectors,slotsand I/Oports.Fur-
thermore,thissection listsall necessaryconnectorpinas-
signmentsforyourreference.The particularstateofthe
jumpers,connectorsand portsareillustrated inthe follow-
ing figures.Beforesetting the jumpersorinserting these
connectors,pleasepayattention tothe direction.

Chapter2
P5I865PE
5
ExternalConnectors
PS/2Keyboard/Mouse Connector
PS/2keyboardconnectorisforthe usage ofPS/2keyboard.If using astandardATsize
keyboard,an adaptershouldbe used tofitthisconnector.PS/2mouseconnectorisfor
the usage ofPS/2mouse.
USB1,USB2,USB3,USB4and LAN Connectors(optional)
FourUSB portsareforconnecting USB devices.The RJ-45 connectorisforonboard
LAN.
PS/2Mouseconnector
PS/2Keyboardconnector
ParallelPort,SerialPortConnectors(COM1)and SPDIFConnector
The parallelportconnectorcan be connected toaparalleldevicesuchasaprinter.The
serialportCOM1connectorcan be connected toaserialportdevicesuchasaserialport
mouse.You can enable/disablethemand choosethe IRQorI/Oaddress in“Integrated
Peripherals”fromAWARD BIOSSETUP.The S/PDIF(Sony/PhilipsDigitalInterface)
inputallowyourdigitalaudioinputfromdigitalaudiodevices(optional).The S/PDIF
outputiscapableofproviding digitalaudiodataorcompressedAC3datatoan external
Dolbydigitaldecoder.
Besuretounplug the ACpowersupplybeforeadding orremov-
ing expansion cardsorothersystemperipherals,otherwiseyour
mainboardand expansion cardsmightbe seriouslydamaged.
MWarning:
USB1
USB2
LAN(optional)
USB3
USB4
ParallelPort
COM1
SPDIF

Installation Instructions
P5I865PE
6
Line-injack,Microphone-injack and Speaker-outjack
The Line-injack can be connected todevicessuchasacassetteorminidisc playerto
playback orrecord.
The Microphone-injack can be connected toamicrophone forvoiceinput.
The Speaker-outjack allowsyou toconnectspeakersorheadphonesforaudiooutput
fromthe internalamplifier.
6-ChannelAudio
ThismainboardutilizesALC655 chipproviding 6-channelAudio,whichconsistsofFront
Left,FrontRight, RearLeft, RearRight, CenterandWooferforacompletesurroundsound
effect. When 6-Channelaudioisavailable,the frontLeft&Rightjack can be connected to
the Frontspeskers,the Back Left&Rightjack can be connected tothe rearspeakersand
the Center&Wooferjack can be connected tothe centerspeakerand woofer.
Microphone function isoffered byF_AUDIOConnectoron the mainboardnow.
If set2-ChannelAudiomode on -6Amainboard,you can connecttwospeakerstothe
FrontLeft&Rightjack,atthe sametimeusethe RearLeft&Rightjack asLine injack,and
usethe Center&Wooferjack asMicrophone injack.
SpeakerOut
Line In
Microphone In
Speakerout/Frontleft&right
Line in/RearLeft&Right
Microphone in/Center&Woofer

Chapter2
P5I865PE
7
HardDisk LEDConnector(HD_LED)
The connectorconnectstothe case’sIDEindicatorLEDindicating the activitystatusof
IDEharddisk.The connectorhasan orientation.If one waydoesn’twork,trythe other
way.
ResetSwitch(RESET)
The connectorconnectstothe case’sresetswitch.Press the switchonce,the system
resets.
ATX12VPowerSupplyConnector&PowerSwitch(POWERSW)
The powerswitch(POWERSW)shouldbe connected toamomentaryswitch.When
powering up yoursystem,firstturnon the mechanicalswitchofthe powersupply(ifone
isprovided),then pushoncethe powerswitch.When powering off the system,you
needn’tturnoff the mechanicalswitch,justpushoncethe powerswitch.
Ifyou change “Soft-off byPWR-BTTN”fromdefault“Instant-off”
to“Delay4Sec”inthe “POWERMANAGEMENTSETUP”sec-
tion ofthe BIOS,the powerswitchshouldbe pressed formorethan
4secondsbeforethe systempowersdown.
ANote:
POWERSW
1
12V
12V
GND
GND
+12VPowerSupplyConnector
1
ATXPowerSupplyConnector
20
1
12V
5VSB
5V
GND 3.3V GND 5V GND PS-OK 3.3V
5V
5V
-5V GND PS-ON -12V 3.3V GND GND GND

Installation Instructions
P5I865PE
8
PowerLEDConnector(PWR_LED)
When the systemisinS0status,the LEDison.When the systemisinS1status,the
LEDisoff; When the systemisinS3,S4,S5status,the LEDisoff. The connectorhas
an orientation.
FanConnectors(SYS_FAN,CPU_FAN)
The fan speed ofthesethree fanscan be detected and viewed in“PCHealth”section
ofthe CMOSSETUP.
SYS_FAN
CPU_FAN
+12V
Sensor
GND
HDD LED
POWER
LED Power
SW
RESET
SW
Reserved
POWER LED
HDD LED
HDD LED(+)
HDD LED(-)
GND
RESET
EMPTY
RESERVED
GND
POWER
PWRLED(+)
RESET SW
PWRLED(-)
POWER SW
+12V
Sensor
GND
Control

Chapter2
P5I865PE
9
F_USB1;F_USB2Connentor
BesidesUSB1,2,3,4on the back panel,P5I865PE seriesofmainboardsalsohavetwo
headerson boardwhichmayconnecttofrontpanelUSB cable(optional)toprovide
additionalfourUSB ports.
InfraredHeader(IrDA)
Thisconnectorsupportswireless transmitting and receiving device.Beforeusing this
function,configurethe settingsforIRAddress,IRMode and IRIRQfromthe “INTE-
GRATEDPERIPHERALS”section ofthe CMOSSETUP.
F_USB1
F_USB2
IrDA
１
VCC IRRX
GND
IRTX
NC
１
+5V
USB0+
USB0-
GND
CUT
USB1-
USB1+
+5V
GND
GND
１
+5V
USB0+
USB0-
GND
CUT
USB1-
USB1+
+5V
GND
GND

Installation Instructions
P5I865PE
10
AudioConnectors(CD_IN)
CD_INisSonystandardCD audioconnector,itcan be connected toaCD-ROMdrive
through aCD audiocable.
CD_INCD RightChannel
GND
CD Left Channel
SPEAKERConnector(optional)
SPK_DATA
GND
NC
SPK_VCC
1

Chapter2
P5I865PE
11
DiagnosisLED(Optional)
During the POST,the LED1~LED5representing POSTstepswill lightup inturn.
During the POST,If usethe CPUofHyper-Threading and Hyper-Threading isen-
ableinthe BIOS,the LEDswill lightup inturn,then blinktogether.pleaserefertothe
following tabletolearnthe POSTstatus:
LED1LED2LED3LED4LED5status
blinkoff off off off CPUdamaged ,BIOSchipabsentordamaged
on off off off off systemdetectCPUand initializechipset
off on off off off systemdetectmemory
off off on off off systeminitializePCI
off off off on off systeminitializeclockgen
off off off off on systemdetectVideo and invokeVideo BIOS
on on on on on Hyper-Threading OK
LED1
LED5
LED3 LED4
LED2

Installation Instructions
P5I865PE
12
FrontAudioInterface(F_AUDIO)
The audiointerfaceprovidestwokindsofaudiooutputchoices:the FrontAudio,the
RearAudio.Theirprioritylevelisassequence.When the FrontAudioisavailable,the
RearAudiowill be cutoff. Anonboardamplifierisprovided forthe earphone.When
the FrontAudioisabsent, Pin5 and Pin6,Pin9 and Pin10 mustbe shortconnected.
OnboardSATA
The mainboardprovidestwoSerialATAconnectors,SATAisastorage interfacethat
iscompliantwithSATA1.0Specification.Withspeed ofup to150Mbps.you can con-
nectSerialATAcabletoSerialATAharddisk.
RX-
Pin No. Symbol Pin No. Symbol
1AUD_MIC 2AUD_GND
3AUD_MIC_BIAS 4ADU_VCC
5AUD_FPOUT_R 6AUD_RET_R
7NC 8(Cut away)
9AUD_FPOUT_L 10 AUD_RET_L
2
4
6
10
1
3
5
7
98
F_AUDIO
SATA1/SATA2
GND
GND
GND RX+
TX+
TX-

Chapter2
P5I865PE
13
ChassisSecuritySwitch(CHSSEC)
The connectorconnectstothe chassissecurityswitchon the case.The systemcan
detectthe chassisintrusion through the statusofthisconnector.If the connectorhas
been closed once,the systemwill recordthe statusand indicatethe chassishasbeen
opened.You can monitororcheck thisinformation fromsomesoftware.
CHSSEC
1
GND
Indicatesignal
SPDIF_OUTConnector
The SPDIFoutputallowyourdigitalaudioinputfromdigitalaudiodevices.
SPDIFout
GND
Cutaway
SPDIF_OUT
SPDIF_INConnector
SPDIF_IN
SPDIFIN
GND
Cutaway
1
1

Installation Instructions
P5I865PE
14
Wake-UpOnInternalModem(WOM)
Through thisfunction,the systemwhichisinthe suspend orsoft-off statuscan be
waked up byaring signalreceived fromthe internalmodem.When thisfunction is
used,be surean internalmodemcardwhichsupportsthisfunction isused.Then
connectthisheadertothe relevantconnectoron the modemcard,set“Poweron by
Ring/LAN”asEnabled inthe “PowerManagementSetup”section ofthe CMOS
SETUP.Saveand exit, then bootthe operating systemoncetomakesurethisfunc-
tion takeseffect.
WOMSignalforwaking up(activelow)
+5Vstandby
GND
1
SerialPortConnector(COM2)(optional)
The serialportCOM2isnotavailableon the back panel.Therefore,weprovide a9-pin
header.
COM2(optional)DCD
GND
SOUT-
RTS
RI
SIN
NC
DSR
CTS
DTR
