QDI Legend-III P6I440LX/AV User manual

PENTIUMII
P6I440LX/AV
Legend-III

Notice
The information in this document is subject to change in order to improve
reliability, design, or function without prior notice and does not represent a
commitment on the part of this company. In no event will we be liable for direct,
indirect, special, incidental, or consequential damages arising out of the use or
the possibility of such damages.
All trademarks are the property of their respective owners.
If you need any further information, please visit our web-site:
“www.qdigrp.com”.

Declaration of conformity
QUANTUM DESIGNS(HK) LTD.
5/F Somerset House, TaiKoo Place 979 Kings Road,
Quarry Bay, Hong Kong
declare that the product
Pentium® II Motherboard
P6I440LX/AV Legend-III
is in conformity with
(reference to the specification under which conformity is declared in accordance with
89/336 EEC-EMC Directive)
þEN 55022 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
þEN 50081-1 Generic emission standard part 1:
Residual, commercial and light industry
þEN 50082-1 Genetic immunity standard Part 1:
Residual, commercial and light industry
European Representative:
QDI COMPUTER ( UK ) LTD QDI COMPUTER ( SCANDINAVIA ) A/S
QDI SYSTEM HANDEL GMBHQDI COMPUTER ( NETHERLANDS) B. V.
QDI COMPUTER (FRANCE) SARL QDI COMPUTER HANDELS GMBH
QDI COMPUTER (ESPANA) S.A. QDI COMPUTER (SWEDEN) AB
Signature : Place / Date : HONG KONG /1997
Printed Name : Anders Cheung Position/ Title : President
Declaration of conformity
(EC conformity marking)

Trade Name: QDI Computer ( U. S . A. ) Inc.
Model Name: P6I440LX/AV Legend-III
Responsible Party: QDI Computer ( U. S. A.) Inc.
Address: 41456 Christy Street
Fremont, CA 94538
Telephone: [phone]
Facsimile: [phone]
Equipment Classification: FCC Class B Subassembly
Type of Product: PCI Pentium Motherboard
Manufacturer:Quantum Designs (HK) Inc.
Address: 5/F, Somerset House, TaiKoo Place 979 Kings
Road, Quarry Bay, HONG KONG
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Signature : Date : 1997

Contents
I
SpeedEasy Quick Setup(English)----------------------------------------1
SpeadEasy Schnell-Installation(Deutsch)------------------------------3
Fácil Y Veloz Rápida Instalación(Español)----------------------------5
Facilité de vitesse Initialisation(Francais)-----------------------------7
Setup Della Scheda Speedeasy(Italiano)-------------------------------9
SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ(ÖÐÎÄ·±Ìå ) ----------------------------------11
SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ(ÖÐÎļòÌå )---------------------------------13
1. Introduction ----------------------------------------------1-1
Overview ------------------------------------------------------------------ 1-1
Key Features-------------------------------------------------------------- 1-1
2. Connector Configuration-------------------------------2-1
Green LED Connector -------------------------------------------------- 2-1
Power Switch Connector------------------------------------------------ 2-1
Hard Disk LED Connector --------------------------------------------- 2-2
Speaker Connector------------------------------------------------------- 2-2
LED Connector----------------------------------------------------------- 2-2
Reset Switch -------------------------------------------------------------- 2-2
Hardware Green Connector-------------------------------------------- 2-2
Keylock Connector ------------------------------------------------------ 2-3
Infrared Header---------------------------------------------------------- 2-3
FAN Connectors --------------------------------------------------------- 2-3
LAN Wake-up Header--------------------------------------------------- 2-4
Chassis Security Header------------------------------------------------ 2-4
USB Connector----------------------------------------------------------- 2-4
I/O Port Description----------------------------------------------------- 2-4
Memory Configuration-------------------------------------------------- 2-5
Clear CMOS-------------------------------------------------------------- 2-5

Contents
II
3. AWARD BIOS Description-----------------------------3-1
Entering Setup------------------------------------------------------------ 3-1
Load Setup Defaults ---------------------------------------------------- 3-2
Standard CMOS Setup -------------------------------------------------- 3-2
SpeedEasy CPU Setup -------------------------------------------------- 3-5
BIOS Features Setup ---------------------------------------------------- 3-6
Chipset Features Setup-------------------------------------------------- 3-8
Power Management Setup ---------------------------------------------- 3-11
PNP/PCI Configuration Setup ---------------------------------------- 3-14
Integrated Peripherals -------------------------------------------------- 3-16
System Monitor Setup --------------------------------------------------- 3-18
Supervisor/User Password Setting------------------------------------- 3-19
IDE HDD Auto Detection ---------------------------------------------- 3-20
Boot with BIOS defaults------------------------------------------------ 3-22
4. VGA and TV-out Description--------------------------4-1
Preparing your computer----------------------------------------------- 4-1
Install Enhanced Driver for Windows 95----------------------------- 4-2
Install Enhanced Driver for Windows NT 4.0------------------------ 4-5
5. Crystal Audio Description------------------------------5-1
Features ------------------------------------------------------------------- 5-1
Layout of Audio System ------------------------------------------------- 5-2
Software Drivers Installation------------------------------------------- 5-2
I. Installation of Windows 95 driver ---------------------------- 5-2
II. Installation of Windows NT driver---------------------------- 5-3
III. How to take effect of 3D sound ------------------------------- 5-4
IV. Install AudioStation--------------------------------------------- 5-4
V. Software Wavetable Synthesis--------------------------------- 5-7

Contents
III
Appendix. About Utility Diskette -------------------------------------A-1
Processor Installation Procedures---------------------- A-2
Boot logo --------------------------------------------------- A-5

P6I440LX/AV Legend - III
1
SpeedEasy Quick Setup
Procedures :
1. Insert the PentiumII correctly.
2. Plug in other configurations and restore the system.
3. Press <Del> key and switch on power to the system to enter BIOS
Setup.
4. Enter “SpeedEasy CPU Setup” menu to set up CPU speed.
Note: If you do not set CPU speed, your system will run at
the default setting (233MHZfor PentiumII).
5. Save and exit BIOS Setup, your system can now boot successfully
SpeedEasy CPU Setup Menu

SpeedEasy Type Introduction
2
Select <SpeedEasy CPU Setup> item from the main menu and enter the sub-
menu:
ROM PCI/ISA BIOS (2A69JQ1B)
SpeedEasy CPU SETUP
QDI Innovative Technology
CPU Model : Pentium(R)II
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right .CPU over speed will
be dangerous!
ESC:Quit ↑↓→←Select
Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figure -1 SpeedEasy CPU Setup Menu
BIOS will provide you with a set of basic values for your PentiumII selection
instead of the jumper setting. You can manually select PentiumII speed on
“SpeedEasy CPU Setup” menu screen.
Note: If your system does not boot up again because of wrong CPU
setting, you can hold down the hot-key <Del>at startup/restart (i.e.
power on). The system will reboot and run at basic values.
MM Warning:
Do not set CPU frequency higher than its working frequency. If
you do, we will not be responsible for any damage caused.

P6I440LX/AV Legend - III
3
Schnell-Installation durch SpeadEasy
Vorgehensweise der Installation:
1. Legen sie die Pentium® II im Slot 1 mit Hilfe der mitgelieferten
halterung.
2. Vervollständigen Sie das System mit den weiteren erforderlichen
Coputerkomponenten
3. Drücken Sie die Taste <Entf >und schalten Sie das System an um
das BIOS-setup zu gelangen.
4. Steigen Sie in das Menü “SpeedEasy CPU Setup” ein, um die
Geschwindigkeit einzustellen.
ACHTUNG:Falls Sie die Taktfrequenz der CPU nicht setzen,
arbeitet Ihr System mit den Standardwerten für die
CPU. Bei der Pentium® II sind das 233MHz).
5. Speichern Sie die Einstellungen und verlassen Sie das BIOS, um die
auvor eingestellte Taktfrequenz zu aktivieren.

SpeedEasy Einführung
4
SpeedEasy CPU Installationsmenü
Wählen Sie <SpeedEasy CPU Setting>aus dem Hauptmenü und öffnen Sie
das untergeordnete Menü
ROM PCI/ISA BIOS (2A69JQ1B)
SpeedEasy CPU SETUP
QDI Innovative Technology
CPU Model : Pentium(R)II
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right .CPU over speed will
be dangerous!
ESC:Quit ↑↓→←Select
Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Abb.1 SpeedEasy CPU Installationsmenü
Das BIOS stellt lhnen eine Reihe von Grundeinstellungen fur lhren Pentium®
II zur Verfügung, anstelle von “Jumper Setting”. Sie können manuell die
Geschwindigkeit der Pentium® II innerhalb des “SpeedEasy CPU
Installationmenus ” einstellen.
Achtung : Sollte sich lhr System wegen falscher CPU Einstellung nicht
starten lassen, drüken, Sie die Taste <Del> und gleichzeitig die
Power On Taste. Das System startet neu und läuft mit den
vorgegebenen Grundeinstellungen.
MM Warnung:
Bitte setzen Sie die Taktfrequenz der CPU nicht höher als die
tatsächliche freigegebene Taktfrequenz, ansonten kann QDI für
rechtliche Anspruche nicht herangezogen werden.

P6I440LX/AV Legend - III
5
SpeedEasy Instalación rápida
Procedimiento:
1. Introduzca correctamente el Pentium® II.
2. Finalize el proceso de ensamblaje de su equipo.
3. Presione la tecla <Supr> y encienda el sistema para entrar en BIOS.
4. Entre al menu “SpeedEasy CPU setup” para establecer la velocidad
de su CPU.
Nota: Si no establece la velocidad del CPU, su sistema funcionará
a la velocidad minima por defecto (233MHzpara Pentium®II)
5. Salve y salga de BIOS, luego su sistema arrancará a la velocidad por
Ud. seleccionada.

Introducción de Instalación SpeedEasy
6
Menu del SpeedEasy CPU
Seleccione el item <SpeedEasy CPU setup> desde el menu principal y entre
en el submenu:
ROM PCI/ISA BIOS (2A69JQ1B)
SpeedEasy CPU SETUP
QDI Innovative Technology
CPU Model : Pentium(R)II
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right .CPU over speed will
be dangerous!
ESC:Quit ↑↓→←Select
Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figura-1 Menu del CPU SpeedEasy
BIOS le proporcionará unos valores básicos para la elección de su
Pentium®II, en vez de tener que cofigurar jumpers. Ud. puede seleccionar
manulmente la velocidad de Pentium®II en el Menu “SpeedEasy CPU
Setup”.
Nota: adicionalmente, si su sistema no puede arrancar debido a un error
en la configuración de la velocidad de su CPU, Ud. siempre tiene
la opción de arrancar manteniendo presionada la tecla<Supr>, con
lo que el sistema le arrancará nuevamente a la velocidad mínima
por defecto.
MM Aviso
NO es recommendable selecclonar una frecuencia de trabajo
superìor a la cual esta diseñada su CPU. De otra manera, no
seremos responsables de los daños que esto pudiera ocasionar.

P6I440LX/AV Legend - III
7
Facilité de vitesse Initialisation
Procédure:
1. Insérez le Pentium® II correctement.
2. Connectez les autres configurations et restaurez le système.
3. Appuyez sur la touche <Del> et mettez le système sous tension
pour entrer dans l’initialisation BIOS.
4. Entrez le menu “SpeedEasy CPU Setup” (=initialisation de la
facilitéde vitesse dans l’unitécentrale) pour déterminer la vitesse
de l’unite centrale.
Note: Si vous ne déterminez pas la vitesse de votre unité
centrale, votre système fonctionnera par défaut
(233MHz pour Pentium ® II).
5. Sauvegardez et sortez de la position BIOS. Le système pourra alors
démarrer avec le succès auquel vous vous attendez.

Introduction Du Type Facilité de vitesse
8
Menu d’initialisation de “SpeedEasy” dans l’unité centrale.
Sélectionnez la rubrique <SpeedEasy CPU Setup> dans le menu principal et
entrez le sous-menu:
ROM PCI/ISA BIOS (2A69JQ1B)
SpeedEasy CPU SETUP
QDI Innovative Technology
CPU Model : Pentium(R)II
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right .CPU over speed will
be dangerous!
ESC:Quit ↑↓→←Select
Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figure-1 Menu d’initialisation de “SpeedEasy” dans l’unité centrale
BIOS fournira un jeu de valeurs de base pour votre sélection de Pentium ®II
au lieu de positions cavaliers. Vous pouvez sélectionner manuellement la
vitesse de Pentium® II dans l’affichage du menu “SpeedEasy CPU Setup”.
Note: De plus, si votre système ne peut pas redémarrer àcause
d’une mise à “1” erronée, vous pouvez maintenir la pression
sur la touche à grande activité <Del> tout en mettant le
système sous tension. Ce dernier alors redémarrera et
fonctionnera sur des valeurs de base.
MMAvertissement:
Ne vous laissez pas aller à installer une fréquence à l’unité
centrale supérieure à sa fréquence de travail. Sinon nous
déclinerons toutes responsabilités en ce qui concerne les dégâts qui
en résulteraient.

P6I440LX/AV Legend - III
9
SETUP DELLA SCHEDA
SPEEDEASY
Procedura di installazione:
1. Inserite il microprocessore Pentium®II come da istruzioni.
2. Modificate la configurazione del computer e ripristinate il sistema.
3. Premete il tasto <Del> e accendete il computer per entrare nel setup
BIOS.
4. Entrate nel menu “SpeedEasy CPU* Setup” per regolare la velocità
del microprocessore. 1
Nota: se non regolate la velocità del microprocessore, il sistema
funzionerà con le regolazioni standard (233MHz per il
Pentium® II).
5. Salvate e uscite dal Setup BIOS, e fate ripartire il computer.
*CPU= microprocessore

Spiegazioni tecniche sul microprocesore SpeedEasy
10
Menu del Setup del Microprocessore
SpeedEasy
Selezionare <SpeedEasy CPU Setup> dal menu principale ed entrare nel
seguente sottomenu:
ROM PCI/ISA BIOS (2A69JQ1B)
SpeedEasy CPU SETUP
QDI Innovative Technology
CPU Model : Pentium(R)II
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right .CPU over speed will
be dangerous!
ESC:Quit ↑↓→←Select
Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figure -1 Menu del Setup del Microprocessore SpeedEasy
I1 sistema BIOS Vi forniràuna serie di valori base per la selezione del
microprocessore Pentium®II al posto della regolazione jumper
(dell’accoppiamento). Potete selezionare manualmente la velocitàdel
Pentium® II sulla schermata “SpeedEasy CPU Setup”.
Nota: se il sistema non dovesse ripartire dopo aver effettuato tutte le
regolazioni del microprocessore, potete tenere premuto il tasto
<Del> mentre accendete la macchina, ed il sistema ripartirà e
funzionerà con le regolazioni originali.
Avvertenza:
non dovete regolare la frequenza del microprocessore più alta
di quella predisposta, altrimenti la casa produttrice non si
farà carico di eventuali danni al micorprocessore.

P6I440LX/AV Legend - III
11
SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ
³ÌÐò£º
1¡¢ÕýÈ·µØ²åÈë Pentium® II¡£
2¡¢²åÈëÆäËûÅäÖã¬×é×°³ÉÍêÕûµÄϵͳ¡£
3¡¢¿ª¶¯ÏµÍ³µçÔ´£¬²¢ÇÒ°´ <Del>¼ü£¬½øÈëBIOSÉ趨¡£
4¡¢½øÈë “SpeedEasy ÖÐÑë´¦ÀíÆ÷É趨”
ÏîÄ¿µ¥£¬ÒÔµ÷½ÚÖÐÑë´¦Àí Æ÷µÄËٶȡ£
×¢Ò⣺Èô²»µ÷½ÚÖÐÑë´¦ÀíÆ÷µÄËٶȣ¬ÏµÍ³½«ÒÔÔ¤
ÖÃÉ趨µÄËٶȽøÐУ¨Pentium®IIΪ233Õ׺ա³
5¡¢ÏÈ´¢´æÈ»ááÀ뿪BIOSÉ趨¡£ÄãµÄϵͳ½«°´ÕÕÄãµÄÉ趨³É¹¦Æô
¶¯¡£

SpeedEasy ·½Ê½½éÉÜ
12
SpeedEasy ÖÐÑë´¦ÀíÆ÷É趨ÏîÄ¿µ¥
´ÓÖ÷ÏîÄ¿µ¥ÖÐÑ¡Ôñ<SpeedEasy CPU Setup>ÏîÄ¿£¬È»áá½øÈë´ÎÏîÄ¿µ¥£º
ROM PCI/ISA BIOS (2A69JQ1B)
SpeedEasy CPU SETUP
QDI Innovative Technology
CPU Model : Pentium(R)II
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right .CPU over speed will
be dangerous!
ESC:Quit ↑↓→←Select
Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
ͼ£-1 SpeedEasyÖÐÑë´¦ÀíÆ÷É趨ÏîÄ¿µ¥
BIOSΪÄãµÄPentium®IIÌṩһ×é»ù±¾É趨ѡÏÒÔ´úÌ洫ͳµÄ
ÌøÏßñ(Jumper)·½Ê½£¬
´Ó¶øʹÄã¿ÉÒÔÔÚ(SpeedEasyÖÐÑë´¦ÀíÆ÷É趨) ÏîÄ¿µ¥µÄÓ«
Ä»ÉÏ£¬×ÔÐÐÑ¡Ôñ Pentium®II µÄËٶȡ£
×¢Ò⣺´ËÍ⣬ÖÐÑë´¦ÀíÆ÷É趨Èô²»ÕýÈ·£¬ÏµÍ³±ã²»ÄÜÖØпªÆô¡
£Ö»ÒªÔÚϵͳ¿ª¶¯µçÔ´áᣬ¼´°´ <Del>¼ü£¬ÏµÍ³½«»á°´»ù±¾µ
ÄÉ趨ѡÏîÖØпª¶¯¡£
MM ¾¯¸æ£º
ÇëÎð½«ÖÐÑë´¦ÀíÆ÷µÄƵÂʵ÷½ÚÖÁ¸ßì¶ÆäÕý³£¹¤×÷ƵÂÊ£¬·ñÔò±¾
¹«Ë¾½«²»»á
¸ºÔðËùµ¼ÖµÄÈκÎËð»Ù¡£
