SCOPIA Elite 5000 Series MCU
Version 7.5
User Guide

RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
© 2000-2010 RADVISION Ltd. All intellectual property rights in this publication are owned by RADVISION Ltd and are
protected by United States copyright laws, other applicable copyright laws and international treaty provisions.
RADVISION Ltd retains all rights not expressly granted.
This publication is RADVISION confidential. No part of this publication may be reproduced in any form whatsoever or used
to make any derivative work without prior written approval by RADVISION Ltd.
Norepresentationofwarrantiesfor fitness for any purpose other than whatisspecificallymentioned in this guide is made
either by RADVISION Ltd or its agents.
RADVISION Ltd reserves the right to revise this publication and make changes without obligation to notify any person of
such revisions or changes. RADVISION Ltd may make improvements or changes in the product(s) and/or the program(s)
described in this documentation at any time.
If there is any software on removable media described in this publication, it is furnished under a license agreement
included with the product as a separate document. If you are unable to locate a copy, please contact RADVISION Ltd and
a copy will be provided to you.
Unless otherwise indicated, RADVISION registered trademarks are registered in the United States and other territories.
All registered trademarks recognized.
For further information contact RADVISION or your local distributor or reseller.
User Guide for SCOPIA Elite 5000 Series MCU Version 7.5, August 2010
http://www.radvision.com

Table of Contents| iRADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
Table of Contents
1About SCOPIA Elite MCU
2Starting or Joining a Conference from an Endpoint
Starting or Joining a Conference Using an Auto Attendant Number.................................4
Starting or Joining a Conference with H.323 Endpoints by Dialing Directly into the SCOPIA Elite
MCU ............................................................................................................4
Starting or Joining a Conference with SIP Endpoints by Dialing Directly
into the SCOPIA Elite MCU..................................................................................5
3Moderating Conferences
4Controlling Personal Video Layouts with DTMF

1
About SCOPIA Elite MCU | 1
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
About SCOPIA Elite MCU
SCOPIA Elite MCU (Multipoint Conferencing Unit) is a device that provides multipoint
videoconferencing services supporting audio, data and video. Participants, using various
videoconferencing devices that support different protocols, can take part in the same conference
hosted on SCOPIA Elite MCU. For example, a SIP-based IP phone user can create a conference and
invite other parties using a H.323-based IP phone, a 3G phone, standard definition or high
definition room systems and even a Telepresence system.
Figure 1-1 Various Devices Are Used in the Same Conference

About SCOPIA Elite MCU | 2
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
Upon joining a conference, a participant can see the video of the virtual conference room. The
video layout, depending of the configuration performed by an administrator, can be different,
showing conference participants in frames.
Figure 1-2 MCU Virtual Conference Room Window
Using video menus, participants can moderate the conference as well as to change the way the
virtual conference room is presented to them.

2
Starting or Joining a Conference from an Endpoint | 3
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
Starting or Joining a Conference from an Endpoint
You can start or join a conference either by using an auto attendant number or by dialing directly
into the SCOPIA Elite MCU. The auto attendant number is a prefix defined by your video network
administrator. You can use the auto attendant number for both H.323 and SIP endpoints.
•Starting or Joining a Conference Using an Auto Attendant Number.................... page 4
•Starting or Joining a Conference with H.323 Endpoints by Dialing Directly into the SCOPIA Elite
MCU page 4
•Starting or Joining a Conference with SIP Endpoints by Dialing Directly into the SCOPIA Elite
MCU page 5

Starting or Joining a Conference from an Endpoint | 4
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
Starting or Joining a Conference Using an Auto Attendant Number
You can start or join a conference using an auto attendant number with both H.323 and SIP
endpoints.
Procedure
Step 1 Contact an administrator and verify the auto attendant number. By default, the auto attendant
number is set to 1800.
Step 2 From the endpoint, dial the auto attendant number, then perform one of these actions:
•Select 0 to create a new meeting.
Figure 2-1 MCU Menu
-or-
•Select a meeting to join from the list of existing meetings.
Starting or Joining a Conference with H.323 Endpoints by Dialing Directly into the SCOPIA
Elite MCU
Perform this procedure to start or join an ad hoc conference with H.323 endpoints.
Procedure
Step 1 Contact an administrator and verify the meeting ID number.
The meeting ID number is composed of a service prefix number and a unique number (or numbers)
identifying the meeting.
For example, the meeting ID number of 711234 consists of these elements:
•71 is the service prefix.
•1234 is the unique meeting number.

Starting or Joining a Conference from an Endpoint | 5
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
Step 2 Dial in to the meeting using the meeting ID number.
As soon as the MCU accepts the call, you are either connected to the existing meeting.
-or-
If the meeting does not exist, the MCU creates a new meeting with this meeting identifier.
Starting or Joining a Conference with SIP Endpoints by Dialing Directly into the SCOPIA Elite
MCU
Perform this procedure to create or join ad hoc conferences with SIP endpoints.
Procedure
Step 1 Verify the meeting ID number.
The meeting ID number is composed of a service prefix number and a unique number (or numbers)
identifying the meeting.
For example, the meeting ID number of 711234 consists of these elements:
•71 is the service prefix.
•1234 is the unique meeting number.
Step 2 Verify the MCU domain name.
Step 3 Dial in to the meeting using the meeting ID number and the MCU domain name in this format:
<meeting ID number> @ <mcu.domain.com>
-or-
<meeting ID number> @ <mcu.IP address>
As soon as the MCU accepts the call, you are either connected to the existing meeting.
-or-
If the meeting does not exist, the MCU creates a new meeting with this meeting identifier.

3
Moderating Conferences | 6
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
Moderating Conferences
You can control MCU meetings using Dual Tone Multi-Frequency (DTMF) signals from yourendpoint
remote control or key pad. You may need to enable touch tone mode for DTMF entry on some
endpoint remote controls.
Figure 3-1 Moderator Menu
Table 3-1 DTMF Controls
During a meeting press *
followed by:
* Listen to available options and display video menu
1 Become Moderator/stop moderating
2 Mute/unmute your line
3Controlyourvolume
4 Show/hide participant names (Moderator only)
5 Terminate the meeting (Moderator only)

Moderating Conferences | 7
RADVISION | User Guide for SCOPIA Elite 5000 Series MCU Version 7.5
6 Change the main video layout for the meeting
(Moderator only)
7 Block/allow admission to meeting (Moderator only)
8 Invite a new participant (Moderator only)
9 Mute/unmute all participants besides yourself (Moderator
only)
# Return to the meeting
During a meeting press *
followed by:
