FITTING INSTRUCTIONS FOR YTI0011 YOKE TOP INSERT
DUCATI PANIGALE V4, V4S, SPECIALE ‘18-
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
Please note that the way the kit is packed does not necessarily represent the way of mounting to the bike.
THE PARTS SHOWN MAY BE REPRESENTATIVE ONLY (FOR CLARITY OF INSTRUCTIONS ONLY).
KIT CONTENTS
•Yoke top insert (FI0140) (x1)
•M6 x 20mm long countersunk head bolt (x1)
•M6 well nut (x1)
TOOLS REQUIRED
•4mm Allen Key
Picture 1
Picture 2

R&G
Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: [phone] Fax: [phone] www.rg-racing.com Email: [e-mail]
Page | 2
Picture 3
FITTING INSTRUCTIONS
•Place the top flange of the well nut into the recess in the back of the insert as shown in picture 1.
•Bolt through the well nut and insert assembly and tighten the bolt until the rubber of the well nut begins to
expand as shown in picture 2.
•Place this assembly into the yoke top as shown in picture 3 and while pressing the insert against the yoke top
tighten the bolt until the insert tightens itself into position.
•Regularly check to ensure frame insert remains tight.
ISSUE 1 20/02/2018 (HB)
Digital copies of these instructions are available to download from www.rg-racing.com
CONSUMER NOTICE
The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not
diminish their performance or visual appeal and supplying them in such state shall conform to the order. The Buyer acknowledges no representation or
warranty (other than as to title) has been given or will apply to the Products other than those in R&G’s order or confirmation and the Buyer confirms it
has chosen the Products as being of merchantable quality and suitable for its particular purposes. Where R&G fits the Products or undertakes other
services it shall exercise reasonable skill and care and rectify any fault free of charge unless the workmanship has been disturbed. The Buyer is
responsible for ensuring that the warranty on the motorcycle is not affected by the fitting of the Products. On return of any defective Products R&G
shall at its option either supply a replacement or refund the purchase money but shall not be liable if the Products have been modified or used or
maintained otherwise than in accordance with R&G’s or manufacturer’s instructions and good engineering practice or if the defect arises from accident
or neglect. Other than identified above and subject to R&G not limiting its liability for causing death and personal injury, it shall not be liable for
indirect or consequential loss and otherwise its liability shall be limited to the amounts paid by the Buyer for the Products or the fitting or service
concerned. These terms do not affect the Buyer’s statutory rights.
R&G RETURNS POLICY (NON-FAULTY GOODS)
Returns must be pre-authorised (if not pre-authorised the return will be rejected). Goods may only be returned direct to us if they were purchased direct
from us (customer must prove if necessary). Otherwise to be returned to original vendor. Goods must be in re-sellable condition, in the opinion of
R&G. All returns are subject to a 25% restocking and handling fee (25% of the gross value exc. P&P –at the prevailing price at time of purchase). The
customer must pay any and all carriage charges. No returns of discontinued products, unless within 14 days of purchase. This policy does not affect your
statutory rights and does not refer to faulty goods.

R&G
Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: [phone] Fax: [phone] www.rg-racing.com Email: [e-mail]
Page | 3
NOTICE DE MONTAGE POUR YTI0011 INSERT DE JOUG
DUCATI PANIGALE V4, V4S, SPECIALE ‘18-
Le kit contient les articles exposés ci-dessous, vérifier que toutes les pièces soient présentes
