Rauch AXENT 90.1 User manual

AXENT 90.1
Operator's manual
Please read carefully
before using the
machine!
Keep for future use
This operator's and assembly manual is
an integral part of the machine. Suppliers
of new and second-hand machines are
required to document in writing that the
operator's and assembly manual was
delivered with the machine and handed
over to the customer.
5903360-b-en-1122
Original instructions

Foreword
Dear customer,
By purchasing the large area spreader of the series AXENT, you have shown confidence in our
product. Thank you very much! We want to justify this confidence. You have purchased a powerful
and reliable machine.
However, in case unexpected problems arise, our customer service department is always there for
you.
Please read this operator’s manual carefully before commissioning the large area spreader
and follow the advice given.
This operator’s manual gives detailed instructions on the operation of the machine, as well as
valuable information on assembly, maintenance, and care.
This manual may also describe equipment that is not included in your machine.
Please note that damage caused by incorrect operation or improper use cannot be covered by
warranty claims.
Please enter your model type and serial number, together with the year of
manufacture of your machine here.
These data are provided on the machine nameplate or on the frame.
Please state this information when ordering spare parts or optional equipment,
and in case of complaints.
Type: Serial number: Year of manufacture:
Technical improvements
We continuously strive to improve our products. For this reason, we reserve the right to make any
improvements and changes to our machine that we consider necessary without notice. We do not
accept any obligation to make such improvements or changes on machines that have already been
sold.
We will be pleased to answer any other questions that you might have.
Yours sincerely
RAUCH Landmaschinenfabrik GmbH

Table of contents
1 Intended use 7
2 User instructions 8
2.1 About this operator’s manual 8
2.2 Structure of the operator’s manual 8
2.3 Notes on text descriptions 9
2.3.1 Instructions and procedures 9
2.3.2 Lists 9
2.3.3 References 9
3 Safety 10
3.1 General information 10
3.2 Meaning of warnings 10
3.3 General information on the safety of the machine 11
3.4 Instructions for the operator 11
3.4.1 Qualifications of personnel 11
3.4.2 Instruction 12
3.4.3 Accident prevention 12
3.5 Information on operational safety 12
3.5.1 Parking the machine 12
3.5.2 Filling the machine 13
3.5.3 Checks before commissioning the machine 13
3.5.4 Hazard zone 13
3.5.5 Running operation 14
3.5.6 Wheels and brakes 15
3.6 Use of fertilizer and slug pellets 16
3.7 Hydraulics system 16
3.8 Maintenance and service 17
3.8.1 Qualifications of maintenance personnel 17
3.8.2 Wear parts 17
3.8.3 Maintenance and service tasks 18
3.9 Safety in traffic 18
3.9.1 Checks before driving 18
3.9.2 Road travel with the machine 19
3.10 Safety equipment, warnings and instructions 19
3.10.1 Position of safety equipment as well as warning and instruction stickers 19
3.10.2 Function of safety equipment 23
3.11 Warning and instruction stickers 23
3.11.1 Warning stickers 24
3.11.2 Instruction stickers 25
3.12 Name plate and machine marking 27
3.13 Lighting system, front, side, and rear reflectors 29
4 Machine data 30
4.1 Manufacturer 30
4.2 Description of the machine 30
Table of contents
AXENT 90.1 5903360 3

4.2.1 Assembly overview 31
4.3 Technical data 35
4.3.1 Technical data for the basic equipment 35
4.3.2 Technical data of fertilizer spreading unit 37
4.3.3 Wheels and tires 38
4.4 Special equipment 40
4.4.1 Optional equipment for the large area spreader 41
4.4.2 Optional equipment for the fertilizer spreading unit 41
5 Transport without tractor 43
5.1 General safety instructions 43
5.2 Loading and unloading, parking 43
6 Commissioning 44
6.1 Accepting the machine 44
6.2 Type approval 44
6.3 Tractor requirements 45
6.4 Mounting the universal drive shaft on the machine 45
6.5 Installing the machine at the tractor 48
6.5.1 Preconditions 48
6.5.2 Ball coupling 52
6.5.3 Hitch coupling 52
6.5.4 Folding away the support stand 53
6.5.5 Fitting the universal drive shaft at the tractor 53
6.5.6 Braking 54
6.5.7 Disengaging the parking brake 56
6.5.8 Establishing other connections 57
6.6 Filling the machine 57
6.7 Checking the filling level 59
7 Spreading operation 61
7.1 General information 61
7.2 Conveyor belt speed adjustment 62
7.3 Adjusting the opening of the pre-metering slide 62
7.4 Fertilizer spreading 63
7.4.1 Spreading operation sequence 63
7.4.2 Information on the fertilizer chart 63
7.4.3 Setting the machine via ISOBUS terminal 64
7.4.4 Setting the working width 66
7.4.5 Adjusting the drop point 69
7.4.6 Setting the application rate 71
7.4.7 Spreading at the headlands 71
7.5 Discharging residual material 74
7.5.1 Safety instructions 74
7.5.2 Emptying the machine 74
7.6 Parking and unhitching the machine 75
8 Faults and possible causes 79
9 Maintenance and service 81
Table of contents
45903360 AXENT 90.1

9.1 Safety 81
9.2 Cleaning the machine 84
9.2.1 Cleaning the bearings of the guide rollers 84
9.2.2 Draining of cleaning water 85
9.2.3 Clean mud guards and wheels 86
9.3 Wear parts and screw connections 86
9.3.1 Checking wear parts 86
9.3.2 Checking the screw connections 87
9.4 Covers 87
9.4.1 Front cover 88
9.4.2 Spreading unit cover 88
9.5 Electrics, electronic system 89
9.6 Hydraulics system 90
9.6.1 Checking the hydraulic hoses 91
9.6.2 Replacing hydraulic hoses 91
9.6.3 Hydraulic cylinders for adjustment functions 92
9.6.4 Checking the conveyor belt drive 93
9.7 Setting of the towing bar suspension 93
9.8 Hitch 95
9.9 Setting the conveyor belt 95
9.9.1 Adjusting the conveyor belt position 95
9.9.2 Setting the conveyor belt tension 97
9.10 Adjusting the belt cleaner 98
9.11 Chassis and brakes 100
9.11.1 Checking the condition and function of the braking system 100
9.11.2 Checking the free travel of the slack adjuster 101
9.11.3 Draining the air tank 102
9.11.4 Checking the brake pad 102
9.12 Wheels and tires 102
9.12.1 Checking the tires 103
9.12.2 Checking the condition of the wheels 103
9.12.3 Checking the bearing clearance of the wheel hub 103
9.12.4 Changing wheels 103
9.12.5 Checking the brake lever length 105
9.13 Recovery of the machine 106
9.14 Lubrication plan 106
9.14.1 Basic machine lubrication points 107
9.14.2 Drive shaft lubrication 109
9.15 Maintenance of the fertilizer spreading unit 109
9.15.1 Checking the position of the spreading disc hub 109
9.15.2 Checking the agitator drive 110
9.15.3 Metering slide adjustment 113
10 Winterization and preservation 116
10.1 Safety 116
10.2 Washing the machine 116
10.3 Preserving the machine 117
Table of contents
AXENT 90.1 5903360 5

11 Disposal 118
11.1 Safety 118
11.2 Disposal of the machine 118
12 Appendix 119
12.1 Tire table 120
12.2 Torque value 121
13 Guarantee and warranty 125
Table of contents
65903360 AXENT 90.1

1 Intended use
The large area spreaders of the series AXENT may only be used in accordance with the stipulations of
the present operator’s manual.
The large area spreaders of the series AXENT are constructed in accordance with their intended use
and may be exclusively used for the application of dry, granular and crystalline fertilizers, seeds and
slug pellets.
The machine is intended to be used by one person and be attached to a tractor that meets the
requirements of this operator’s manual.
In the following chapters, the large area spreader is referred to as “machine.”
Any use beyond these specifications is considered as contrary to the intended use. The manufacturer
shall not assume any liability for any damages resulting from this. The risk is solely carried by the
operator.
The intended use also comprises the compliance with the operating, maintenance, and repair
conditions prescribed by the manufacturer. Only genuine spare parts from RAUCH may be used as
replacements.
The machine may only be used, maintained and repaired by people who are familiar with the
characteristics of the machine and who are aware of the risks.
The instructions regarding the operation, service, and safe handling of the machine as described in
this operator's manual and declared by the manufacturer in the form of warning signs and symbols on
the machine must be strictly followed during operation. The relevant accident prevention regulations
and other generally recognized safety-related, occupational health and road traffic regulations must be
observed when using the machine.
Unauthorized modifications to the machine are not permitted. Such modifications exclude any liability
of the manufacturer for any resulting damages.
nForeseeable misuse
The manufacturer provides warning notes and signs on the mineral fertilizer spreader relating to
foreseeable misuse. These warnings and warning symbols must always be observed. This way,
application of the machine against the intentions of the operator’s manual is prevented.
1. Intended use
AXENT 90.1 5903360 7

2 User instructions
2.1 About this operator’s manual
This operator’s manual is an integral part of the machine.
The operator’s manual contains important instructions for safe, proper, and economic use and
maintenance of the machine. Compliance with its stipulations helps to avoid risks, reduce repair
costs and downtime, and to increase the reliability and service life of the machine controlled with it.
The complete documentation, comprising this operator’s manual and any other documents provided,
must be kept in an easily accessible location close to where the machine is used (e.g., in the tractor).
If the machine is sold, the operator’s manual must also be passed to the new owner.
The operator’s manual is intended for the operator of the machine and anyone involved in operating
and maintaining it. It must be read, understood, and applied by every person who is entrusted with the
following work on the machine:
• Operation,
• Maintenance and cleaning,
• Troubleshooting.
In particular, the following is to be observed:
• The chapter on safety,
• The warnings in the text of the individual chapters.
The operator's manual does not replace your own responsibility as operator and operational staff of
the machine control unit.
2.2 Structure of the operator’s manual
The operator’s manual is divided into six key areas in terms of content
• User instructions
• Safety instructions
• Machine data
• Instructions on operating the machine
• Instructions for finding and correcting faults
• Maintenance and service instructions
2. User instructions
85903360 AXENT 90.1

2.3 Notes on text descriptions
2.3.1 Instructions and procedures
Steps that the operator must carry out are shown as follows.
uInstruction for action step 1
uInstruction for action step 2
2.3.2 Lists
Lists without a specific sequence are shown as lists with bullet points:
• Property A
• Property B
2.3.3 References
References to other sections in the document are shown with paragraph number, header text and/or
page number:
•Example: Please also note 3 Safety
References to other documents are shown as information or instructions without the exact chapter or
page number:
•Example: Follow the instructions in the operator’s manual of the universal drive shaft
manufacturer.
2. User instructions
AXENT 90.1 5903360 9

3 Safety
3.1 General information
The chapter Safety contains basic warning notes as well as working and traffic safety instructions for
the usage of the installed machine.
The adherence to the instructions in this chapter is a prerequisite for the safe handling and trouble-
free operation of the machine.
There are additional warnings in the other chapters of this operator’s manual, which must also be
observed. The warning instructions are given before the text for the relevant actions.
Warning notes on the supplier components can be found in the respective supplier documentation.
These warning instructions must also be observed.
3.2 Meaning of warnings
The warnings in the operator’s manual are classified according to the severeness of the risk and the
probability of its occurrence.
The warning symbols draw attention to the unavoidable residual risks inherent in the design to which
users of the machine are exposed. The warnings used are structured as follows:
Symbol + signal word
Explanation
Level of danger of warnings
The level of danger is indicated in the signal word. The levels of danger are classified as follows:
DANGER!
Type and source of danger
This warning warns of a danger posing an immediate threat to the health and life of people.
Ignoring these warnings will result in severe injury or death.
uAlways observe the measures described to prevent this danger.
WARNING!
Type and source of danger
This warning warns of a potentially dangerous situation for personal health.
Ignoring these warnings leads to severe injury.
uAlways observe the measures described to prevent this danger.
3. Safety
10 5903360 AXENT 90.1

CAUTION!
Type and source of danger
This warning warns of a potentially dangerous situation for personal health.
Ignoring these warnings leads to injury.
uAlways observe the measures described to prevent this danger.
NOTICE!
Type and source of danger
This warning warns of material and environmental damage.
Ignoring these warnings will result in damage to the machine and to the environment.
uAlways observe the measures described to prevent this danger.
This is a note:
General information containing application tips and particularly useful information, but which
constitutes neither warnings nor hazards.
3.3 General information on the safety of the machine
The machine is constructed in accordance with the state of the art and the recognized technical
regulations. However, its usage and maintenance may cause danger to the health and life of the
operator or third parties and/or the impairment of the machine and other material assets.
For this reason, the machine may only be operated
• when it is in a proper and roadworthy condition,
• in awareness of safety and dangers.
Therefore, it is imperative that you have read and understood the contents of the operator’s manual.
You must be familiar with the applicable accident protection regulations and the generally accepted
regulations for safety, occupational health, and road traffic, and apply these rules as required.
3.4 Instructions for the operator
The owner is responsible for the intended use of the machine.
3.4.1 Qualifications of personnel
Before starting any work on or with the machine, all persons who are involved in operation,
maintenance or service must have read and understood this operator’s manual.
3. Safety
AXENT 90.1 5903360 11

• The machine may only be operated by instructed personnel authorized by the owner.
• Persons who are apprentices, in training or under instruction may only work on the machine under
the supervision of an experienced person.
• Maintenance and service may only be carried out by qualified maintenance personnel.
3.4.2 Instruction
Distribution partners, works representatives or employees of the manufacturer will instruct the operator
regarding the operation and maintenance of the machine.
The owner must ensure that newly recruited operating and maintenance personnel are instructed to
the same extent and with the same care with regard to the operation and repair of the machine in
compliance with this operator’s manual.
3.4.3 Accident prevention
Safety and accident prevention regulations are legally specified in every country. The owner of the
machine is responsible for observing the regulations applicable in the country of operation.
The following instructions must also be observed:
• Never let the machine run without supervision.
• Do not ride on the machine while it is working or being transported (no passengers).
•Do not use machine parts as steps.
• Always wear tight fitting clothes. Do not wear work clothes with belts, loose threads or other items
that could get caught.
• Follow the manufacturer's warnings when handling chemicals. You may have to wear personal
protective equipment (PPE).
3.5 Information on operational safety
Only use the machine in safe operating condition. Avoid hazardous situations.
3.5.1 Parking the machine
Only park the machine with an empty hopper on level, firm ground.
Prior to decoupling, check that the machine is secured against tilting and rolling.
• Is the parking brake engaged?
• Is the support stand folded down?
• Are the wheels secured with wheel chocks?
For further information, refer to chapter 7.6 Parking and unhitching the machine
3. Safety
12 5903360 AXENT 90.1

3.5.2 Filling the machine
• Only fill the machine when the machine is mounted or attached to the tractor (depending on the
machine)
• Only fill the machine when the engine of the tractor is shut off. Remove the ignition key in order to
prevent the engine from being started.
• Make sure that there is adequate space on the filling side.
• Use suitable auxiliary equipment for filling the machine (e.g., front-end loader, screw conveyor).
• Fill the machine no higher than the top-edge. Check the filling level.
• Only fill the machine with the protective grid closed. This way, faults during spreading caused by
lumps in the spreading material or other foreign bodies are prevented.
3.5.3 Checks before commissioning the machine
Check the operating safety of the machine before the first and every subsequent commissioning.
• Is all safety equipment at the machine installed and functioning?
• Are all fasteners and load-bearing connections tightly installed and in good condition?
• Are all locking mechanisms securely engaged?
• Are there no persons in the danger zone of the machine?
• Is the universal drive shaft cover in good condition?
3.5.4 Hazard zone
Ejected spreading material may cause serious injury (e.g., to the eyes).
When persons are present between the tractor and the machine, there is a great hazard by the tractor
rolling away of machine movements When persons are present between the tractor and the machine
which may have fatal consequences.
The following figure displays the hazard zones of the machine.
3. Safety
AXENT 90.1 5903360 13

Fig. 1: Hazard zone when devices are pulled
A Hazard zone in spreading operation B Hazard zone when coupling/decoupling the
machine
• Ensure that no persons are present in the spreading range [A] of the machine.
• Immediately stop the machine and the tractor if persons are present in the hazard zone of the
machine.
• When coupling/decoupling the machine at the tractor, make sure that no one is present in the
hazard zones [B].
3.5.5 Running operation
• In the event of malfunctions, the machine is to be shut down and secured immediately against
reactivation. Have the fault repaired immediately by qualified technicians.
• Do not climb on the machine while the spreader unit is running.
• Only operate the machine with the protective grids in the hopper closed. During operation, the
protective grid must neither be opened nor removed.
• Rotating machine components can cause serious injury. Make sure that body parts or clothing
never come close to rotating components.
• Do not deposit any parts (such as screws, nuts) in the hopper.
• Ejected spreading material may cause serious injury (e.g., to the eyes). For this reason, ensure
that nobody is present in the spreading range of the machine.
• If the wind speed becomes too high, spreading has to be stopped as the specified spreading
range cannot be guaranteed under such conditions.
• Do not climb on the machine or the tractor when it is situated beneath high-voltage electrical
power lines.
• Do not open or close the hopper cover when the machine is situated under high-voltage electrical
power lines.
3. Safety
14 5903360 AXENT 90.1

nMeasures in case of contact with overhead lines
• Operations such as opening and closing the hopper cover can change the dimensions of the
machine. Check the area to make sure that the machine can be operated safely.
• Do not leave the vehicle if it is standing under hazardous voltage (discharge voltage pattern).
• In case of contact with power lines, remain in the vehicle if possible.
• Keep all persons away from the machine (at least 10 m) and contact emergency services to ask
them to switch off power.
• Drive away from the power line if the machine is operational.
If you have to leave the cabin, park the machine, turn off the engine, and jump away from the
machine as far as possible. Do not touch the ground and the machine at the same time as this
may result in electric shock.
• Maintain a safe distance from the machine as the ground near the machine can be live.
• Do not return to the machine until the operator of the power line has confirmed that it is safe to do
so.
3.5.6 Wheels and brakes
Due to the high overall weight and the terrain, the chassis of the towed machine is subject to extreme
loads. To ensure operational safety, the following points are to be considered:
• All wheels and tires must comply with the technical requirements specified by the manufacturer.
• Wheels must not be bent or have inadmissible bumps.
• Check the wheels at their sides on the inside and outside. In case of damage (bumps, scratches),
replace them immediately.
• Prior to every use, check the tire pressure and the function of the brakes.
• Have the brake pads replaced in time. All brake pads must comply with the technical
requirements specified by the manufacturer.
• To prevent contamination of the wheel bearings, they must always be covered by dust covers.
• Only use wheels approved in the certificate of conformity. Always observe the specification of the
approved wheels (load bearing capacity, tire pressure).
• Check the brake pads when changing the tires and when using tires other than those approved by
the manufacturer. See 9.12.4 Changing wheels
•Do not use the tractor joystick for braking This way, trailers with pneumatic brakes cannot be
stopped.
3. Safety
AXENT 90.1 5903360 15

3.6 Use of fertilizer and slug pellets
Improper selection or use of fertilizer and slug pellets may cause serious injury or environmental
damage.
• When selecting the fertilizer, inform yourself of its effects on humans, the environment and the
machine. When using slug pellets, observe the specific national plant protection directives.
• When selecting the fertilizer, inform yourself of its effects on humans, the environment and the
machine.
• Always follow the instructions of the fertilizer manufacturer.
3.7 Hydraulics system
The hydraulic system is under high pressure.
Fluid escaping under high pressure may cause serious injury and environmental damage. The
following instructions must be observed to prevent danger:
• Always operate the machine below the permissible maximum operating pressure.
•Release the pressure from the hydraulic system before carrying out any maintenance. Switch off
the engine of the tractor. Secure it against reactivation.
• When searching for leaks, always wear safety glasses and safety gloves.
• In case of injury in connection with hydraulic oil, consult a physician immediately as severe
infections may occur.
• When connecting the hydraulic hoses to the tractor, ensure that the hydraulic system is
depressurized, both on the tractor and the machine side.
• Attach the hydraulic hoses of the tractor and the spreader hydraulic systems only with the
prescribed connections.
• Prevent any contamination of the hydraulic circuit. Always suspend the couplings in the brackets
provided. Use the dust caps. Clean the connections before coupling them.
• Regularly check the hydraulic components and hydraulic hose lines for mechanical defects, e.g.,
cuts and abrasions, contusions, bends, tears, porosity, etc.
• Even when stored correctly and used within approved load limits, hoses and hose couplings are
subject to a natural aging process. This limits their storage and service life.
The hydraulic hoses are designed for a maximum service life of 6 years, including storage for a
maximum of 2 years.
The month and year of manufacture of the hydraulic hoses is stamped on the hose fitting.
• Have the hydraulic hoses replaced if they are damaged and after the specified service life has
been reached.
• Replacement hydraulic hoses must meet the technical requirements of the equipment
manufacturer. Make sure the replacement hydraulic hoses meet the maximum pressure
specifications.
3. Safety
16 5903360 AXENT 90.1

3.8 Maintenance and service
Maintenance and service involve additional hazards that do not occur during operation of the machine.
For this reason, take particular care when carrying out maintenance and service work. Work
particularly thoroughly and cautiously.
3.8.1 Qualifications of maintenance personnel
• Only specialist workshops or approved brake repair service providers may perform adjustment or
repair work on the brake system.
• Only qualified personnel may perform repair work on wheels and tires. They must use appropriate
mounting tools for this.
• Welding and work on the electrical and hydraulic systems is to be carried out by qualified
technicians only.
3.8.2 Wear parts
• The maintenance and service intervals described in the present operator’s manual are to be
strictly adhered to at all times.
• Also observe the maintenance and service intervals for the supplied components. See the
supplier documentation for the relevant intervals.
• We recommend having your dealer check the condition of the machine, particularly fastening
components, safety-relevant plastic components, the hydraulic system, metering components and
spreader vanes, after every working season.
• Spare parts must at least comply with the technical standards specified by the manufacturer.
Compliance with technical requirements is ensured using original spare parts.
• Self-locking nuts are designed to be used only once. Always use new self-locking nuts to fasten
components (e.g., when replacing spreading vanes).
3. Safety
AXENT 90.1 5903360 17

3.8.3 Maintenance and service tasks
•Always switch off the tractor engine before any cleaning, maintenance, service, and
troubleshooting. Wait until all rotating parts of the machine have come to a standstill.
• Make sure that no unauthorized person can start the machine. Remove the ignition key of the
tractor.
• Disconnect the power supply between the tractor and the machine before performing any
maintenance and service tasks or before working on the electrical system.
• Check that the tractor with the machine is correctly parked. Park the spreader with an empty
hopper on level, solid ground and secure it to prevent it from moving.
• Release the pressure from the hydraulic system before any maintenance and repair work.
• If work is to be carried out while the PTO shaft is rotating, make sure that nobody is near the PTO
or the universal drive shaft.
• Never clear blockages in the spreader hopper by hand or with the foot: always use a suitable tool.
• Before cleaning the machine with water, steam jet, or other cleaning agents, cover all components
that must not get wet (e.g., bearings, electrical connections).
• Regularly check nuts and screws for tightness. Retighten loose connections.
• After driving the first 5 km, check the tightening torque of each individual wheel nut. See 9.12.4
Changing wheels
3.9 Safety in traffic
Driving on public roads with the towed machine without attached spreading unit is prohibited
(underride protection).
When traveling on public roads and tracks, the tractor with the towed machine and attached spreading
unit must comply with the traffic regulations of the country in which it is operating. The owner and
driver are responsible for compliance with these regulations.
3.9.1 Checks before driving
The check before departure is an important contribution to road safety. Before every trip, check
compliance with the operating conditions, traffic safety, and the regulations of the country of operation.
3. Safety
18 5903360 AXENT 90.1

• Is the admissible overall weight complied with? Observe the admissible towing load and static
load of the trailer unit as well as the admissible axle load.
• Note the permitted brake load, the permitted tire load capacity load, and the permitted tire
pressure.
• Is the machine coupled correctly?
• Can fertilizer be lost while traveling?
○ Observe the filling level of the fertilizer in the hopper.
○ The metering slides must be closed.
○ Switch off the electronic control unit.
• Check the tire pressures and the function of the machine brake system. Observe the admissible
brake load and tire payload.
• Does the brake system setting correspond to the machine's load? See 6.5.6.1 Setting the manual
brake force regulator.
• Is the hopper cover closed and secured against accidental opening?
• Do the lighting and labeling on the machine comply with the national regulations for operation on
public roads? Make sure that warning signs, rear reflectors, and auxiliary lights are correctly
placed.
3.9.2 Road travel with the machine
Handling, steering, and braking performance of the tractor are affected by the towed machine. For
example, an excessive support load of the machine will reduce the weight on the front axle of the
tractor and affect the steering.
• Adapt your driving to the modified driving characteristics.
• When driving, always ensure that there is sufficient visibility. If vision is restricted (e.g., when
reversing), another person is required to direct the driver.
• Observe the admissible maximum speed.
• Avoid sudden turns when driving uphill or downhill or across a slope. The change in the center of
gravity may increase the danger of tipping. Special care is to be particularly applied when driving
on uneven, soft ground (e.g., when entering fields, curbs).
• Passengers are prohibited on the machine during transport and operation.
• If necessary, attach a front weight at the tractor. For further information, please refer to the
operator’s manual of the tractor.
3.10 Safety equipment, warnings and instructions
3.10.1 Position of safety equipment as well as warning and instruction stickers
The safety equipment is not available in all countries and depends on the regulations that apply
where the machine is used.
3. Safety
AXENT 90.1 5903360 19

Fig. 2: Safety equipment, warning and instruction stickers, front
[1] Warning: passenger transport prohibited
Warning: high-voltage electrical power lines
[2] Cleaning flap cover
Warning: moving parts
[3] Homologation sign
Serial number
[4] Warning: read operator’s manual
Warning: remove ignition key
[5] White reflectors
[6] Trailer unit nameplate
[7] Yellow side reflectors
[8] Wheel chock
Warning: wheel chocks
[9] Front lighting with warning sign and white
reflector
[10] Side cover for guide rollers and conveyor
belt
3. Safety
20 5903360 AXENT 90.1
