Rauch AXIS-M 20.2 EMC User manual

INSTRUCTION MANUAL
AXIS 20.2/30.2/40.2/50.2
Please read carefully
before using the ma-
chine.
Keep for future reference.
This instruction manual/assembly in-
struction is to be considered as part of
the machine. Suppliers of new and se-
cond-hand machines are required to
document in writing that the instructi-
on manual/assembly instruction was
delivered with the machine and han-
ded over to the customer.
Original instructions
5901540-a-en-0815

Preface
Dear Customer,
By purchasing the mineral fertiliser spreader of the AXIS series you have shown confidence in our
product. Thank you very much! We want to justify this confidence. You have purchased a powerful
and reliable machine.
However, in case unexpected problems arise: Our customer service is always there for you.
Please read this operator’s manual carefully before commissioning the mineral fertiliser
spreader and follow the advice given.
This operator’s manual gives detailed instructions on how to operate the machine, as well as val-
uable information on assembly, maintenance, and care.
This manual may also describe equipment that is not included in your machine.
You should be aware that damage caused by incorrect operation or improper use can not be cov-
ered by warranty claims.
Technical improvements
We are continuously improving our products. Therefore, we reserve the right to make any
improvements and changes to our machine that we consider necessary without notice.
This constitutes no obligation to make such improvements or changes on machines that
have already been sold.
We will be pleased to answer any other questions that you might have.
Yours sincerely
RAUCH
Landmaschinenfabrik GmbH
NOTICE
We kindly ask you to enter the type and serial number as well as the year of construction of your
mineral fertiliser spreader here.
These data are provided on the machine nameplate or on the frame.
Please state this information when ordering spare parts or accessories, and in case of com-
plaints.
Type: Serial number: Year of manufacture:

AXIS
AXIS 20.1
AXIS 20.2
AXIS 30.2, AXIS 40.2
AXIS 50.2
AXIS
The chapter AXIS-General deals with general instructions regarding the operation of the entire
AXIS model range. Please read this chapter carefully and follow the advice given before taking the
mineral fertiliser spreader into service.
In particular, the chapter Safety contains general safety instructions as well as occupational and
traffic safety regulations associated with the handling and operation of the mineral fertiliser
spreader AXIS. The consideration of and adherence to the instructions in this chapter is the basic
requirement for the safe handling and trouble-free operation of the mineral fertiliser spreader.
At the end of the operator’s manual, you will find the chapters dealing with disposal of the product
and terms/conditions of warranty for all models.
The section AXIS 50.2 contains specific information on the mineral fertiliser spreaders
AXIS 50.2 and AXIS 50.2 W.
The chapter AXIS-Maintenance describes the general maintenance and repair work,
to be executed for all types of the mineral fertiliser spreaders of the AXIS series.
The section AXIS 20.2 contains specific information on the mineral fertiliser spreaders AXIS 20.2,
AXIS-M 20.2 EMC, AXIS 20.2 W and AXIS-M 20.2 EMC + W.
The section AXIS 30.2/AXIS 40.2 contains specific information on the mineral fertiliser spreaders
AXIS 30.2, AXIS 40.2, AXIS-M 30.2 EMC, AXIS-M 40.2 EMC,AXIS 30.2 W, AXIS 40.2 W,
AXIS-M 30.2 EMC + W, AXIS-M 40.2 EMC + W
