mn100 Dual Digital Display
EMC Conformance
All Raymarine equipment is designed to the best industry standards for
use in the recreational marine environment. The design and
manufacture of Raymarine equipment conforms to the appropriate
Electromagnetic Compatibility (EMC) standards. Correct installation is
required to ensure that performance is not compromised.

Contents
1
1 Information Page
1.1 Introduction - 2
1.2 Specifications 2
1.3 Power Management and Battery Life - 2
1.4 Safety and Disposal - 4
2 Operation
2.1 Display Information - 5
2.2 Switching the System On and Off - 6
2.3 Backlighting - 6
2.4 Audible Signals and Alarms - 6
2.5 Utilities - 8
2.6 Chapter and Page Operation - 9
2.7 Chapter and Page Description - 11
3 Setup and Calibration
3.1 Entering Setup and Calibration Mode - 18
3.2 Chapter and Page Setup and Calibration - 18
3.3 Editing Values - 18
3.4 Setup Page Description - 20
3.5 Calibration Page Description - 23
4 Seatrial and Calibration
4.1 Depth Offset - 29
4.2 Speed Calibration - 30
4.3 Wind Calibration - 31
4.4 Compass Calibration and Alignment - 32
5 Installation
5.1 Tools List & Parts- 33
5.2 Precautions and Positioning Advise - 33
5.3 Bracket Mounting - 34
5.4 Surface Mounting - 35
5.5 External Power Connections - 36
6 Maintenance and Fault Finding
6.1 Care and Maintenance - 37
6.2 Fault Finding and Technical Support - 37

1 Information
1.1 Introduction
Your Micronet display is powered for life by the environment. Although
feature packed and highly visible in all conditions, current demand is so
low, and the supply so efficient, that the solar-powered display is self
sufficient. Combined with other displays in the Micronet range this
display becomes part of a complete navigational system.
1.2 Specifications
Height of digits: 20mm (0.8”)
Backlighting: 3 levels with daylight shutoff
System-wide or local control
Power: Solar Powered
300 hrs autonomy by day, 7 nights at brightest
backlighting,
20 nights at economy backlighting without charge
Units of display: Boat Speed (knots, km per hour, statute miles per hour)
Distance (nautical miles, statute miles, kilometres)
Depth (metres, feet, fathoms)
Wind Speed (knots, metres per second, Beaufort)
Alarm: Audible Alarm for Depth, Wind and MOB
Weight: 285g (0.63lbs)
Operating Temp.: 10oto +60oC (14oto 14oF)
Frequency: 868 MHz or 916 MHz
This unit can be controlled using the T113 Remote Display
1.3 Power Management and Battery Life
What makes your mn100 display possible is Raymarine’s revolutionary
approach to power management. By reducing the amount of power
being used by the electronics and maximizing the potential of the sun to
provide power, a mn100 display becomes a virtually perpetual device.
Power status is indicated by two icons on the display:
Battery Level and Charge Rate
Used together these icons will show the condition of the power supply.
mn100 Dual Digital Display
2

Information
3
If using the displays at night, power usage can be reduced dramatically
by switching the Backlighting to level 1 or Off. If Backlighting is not
required on displays located below decks it is best to set them to “Local”
Backlighting control (see page 27 -s37) so that power is not being
wasted in displays which may not be visible from the one being viewed.
If the internal battery is fully charged then it does not matter how
much the display is subjected to bright sunlight no further charging
is required and the Charge Rate Indicator will remain low.
If the displays are to be stored for a long period of time before next
use (Over Winter) ensure that the batteries are fully charged before
storage. If necessary connect to a 9-30V DC power supply for 24
hrs prior to storage.
Bright Sunny Day
Overcast Day
Night
Battery is charged and being
topped up by the sun. (see Note)
Battery is low and being charged
by the sun.
Battery is charged and requires no
further charging.
Battery is low but maintaining it’s
level.
Battery is charged but is not
charging.
Battery is low with no charging.
It is recommended that the
instrument be left in daylight for
some time for the battery to
recover, or charge from an external
9-30V power source. A fully
discharged battery will recharge in
approximately 12 hours of direct
bright sunlight.
LOW Power

Sleep Mode
If there is no boat speed or change in heading registered on the system
for a period of 12 hours your Micronet display will switch off to conserve
power. A "POWER SAVE" alarm will sound before the system switches
off. Pressing any button within 10 seconds of the alarm sounding will
allow the system to remain switched on.
Backlighting will automatically shut down/off when operated in daylight.
AArrttiiffiicciiaalllliigghhttWWIILLLLNNOOTTrreecchhaarrggeetthheebbaatttteerryy..Placing your Micronet
display close to an artificial light will seriously damage the display.
Only recharge in natural daylight.
Applying External Power
In cases where displays are mounted permanently below decks it will be
necessary to apply an external power source to prevent complete
discharge of the built in battery.
Connections on the rear of the display allow a 9V to 30V DC power
source to be connected. Connections can be made to the vessels DC
system or a 9V battery pack may be connected. It is recommended that
permanent connection is only made when the displays are permanently
fixed to the vessel and not when the clip brackets are used.
Connection to a 9V (PP3) battery will fully recharge the internal battery
over a period of 24 hours.
1.4 Safety and Disposal
Your Micronet display contains Manganese Lithium Dioxide batteries
which should be disposed of correctly. Do not dispose of any instrument
in domestic waste. Refer to regulations in force in your country.
If in doubt return the instrument to Raymarine Ltd. for correct disposal.
mn100 Dual Digital Display
4

Operation
5
Chapter Button
Hold
down for
on/off
Set-up
Button
Prompt
Alarm
Indicator
(Flashes)
Battery
Level
Set Button Page and Adjust Buttons
Hold down
for
Backlighting
Descriptive
Text
Charge
Rate
2 Operation
Important:
Ensure that the "Auto Network" procedure described on the yellow
instruction sheet and full Setup and Calibration has been performed
correctly before attempting to use your Micronet system.
2.1 Display Information
Display Icons
The following icons are used to display information on the screen:
KKTTSS, KKPPHH, MMPPHHto display speed units
KKTTSS, MMto display wind speed units
TTRRUUEE, AAPPPPto indicate True or Apparent wind
TTRRUUEE, MMAAGGto indicate True or Magnetic bearings and headings
LLAATT, LLOONNto indicate Latitiude or Longitude
LLOOGG, TTRRIIPPto indicate a Total Logged or Trip distance
ooto indicate degrees of angle or temperature

2.2 Switching the System On and Off
To switch your Micronet system on or off select any display and press
the button for 2 seconds.
2.3 Backlighting
At any stage of the display’s operation press and hold for 2
seconds the button to access the lighting control.
Pressing the and buttons will scroll through setting
OFF, 1, 2 and 3 whilst changing the Backlighting.
Depending on the display setup (see page 27 -s37),
Backlighting on the whole system or just the single display will be
altered.
Backlighting is automatically switched off in daylight as part of the
display’s power saving feature and will not operate in daylight.
2.4 Audible Signals and Alarms
At stages during its operation your Micronet display will beep to indicate
alarms or moments of importance.
Power-up Once operating as part of a network the display will issue a single
beep as it is switched on by pressing the button for 2
second.
Button Press A single beep is issued each time a button is pressed. A second
beep is issued after a 2 second hold down of the button.
Timer A single beep will be issued at each minute of the countdown.
With 1 minute left to go a beep will sound every 10 seconds. With
10 seconds to go a beep will sound every second.
Countdown complete will be indicated by a single burst of three
beeps.
mn100 Dual Digital Display
6
Switch on Switch off

Alarm Continuous bursts of three beeps will indicate an alarm. The
alarm activated will be indicated on the digital display,
accompanied by the flashing symbol. Pressing any button will
silence the alarm. See fault finding section on p37.
Depth Shallow Alarm
The water depth has fallen below the preset alarm level.
The depth value that triggers the alarm is affected by any
keel or waterline offsets that have been added.
See page 22 s11 to set the alarm function.
This alarm does not sound as the depth increases above the
preset alarm level.
Depth Deep Alarm
The water depth has increased above or fallen below the
preset alarm level.
The depth value that triggers the alarm is affected by any
keel or waterline offsets that have been added.
See page 22 s12 to set the alarm function.
Off Course Alarm
The heading has deviated from its locked value by more than
the preset alarm level
See page 22 -S13 to set the alarm function
See page 17 -P33 to lock a heading
Wind High Alarm
The wind speed has increased beyond the preset alarm
level.
See page 22 s14 to set the alarm function.
This alarm does not sound as the wind speed decreases
below the preset alarm level.
Cross Track Error Large Alarm
A large cross track error has been alerted by the GPS.
See page 23 s15 to set the alarm function.
Waypoint Arrival Alarm
A waypoint arrival signal has been received from the GPS.
The waypoint name is shown on the top line of the display.
See page 23 s16 to set the alarm function
Operation
7

mn100 Dual Digital Display
8
2.5 Utilities
Keylock The Keylock feature protects from accidental key presses and is
intended for use in high activity applications such as crewed race
yachts. If your display is mounted in a position where keys may
be pressed accidentally (eg the companionway of a race yacht),
then you can enable keylock as follows:
Press and hold to enter set up
Press repeatedly to reach the OPTS chapter
Press repeatedly to reach the Key Lock page
Press to activate keylock
Press and hold to exit setup.
Once keylock is activated, pressing a key causes the unit to
give the unlock key prompt. Press followed by to
unlock the keys (this will allow the keys to function for one minute,
after which the keys will automatically relock).
Page Hiding To hide unwanted pages and configure an instrument to your
needs:
Press and hold to enter set up
Press repeatedly to reach the OPTS chapter
Press repeatedly to reach the Page Hiding page
Press to activate page hiding for 5 minutes
Press and hold to exit setup.
Once page hiding is activated, press for 2 seconds to
hide a top page or press for 2 seconds to hide a bottom
page. A period of 5 minutes is allowed during which you can
select pages to hide.
Page Unhide To clear Page Hiding and return to all pages visible:
Press and hold to enter set up
Press repeatedly to reach the OPTS chapter
Press repeatedly to reach the Pages Hidden page
Press to clear page hiding
Press and hold to exit setup.

Operation
9
2.6 Chapter and Page Operation
Information is displayed in a “Chapter and Page” format using the
(Chapter) button to scroll through the Chapters which are displayed in
the upper part of the window and the and (Page) buttons to
move between Pages within a Chapter which are displayed in the lower
part of the window.
Chapter Sequence Shown in Upper Window
(for a full description of each Chapter see page 11 - c1 to c8)

It is possible to select any Page (lower window) within any Chapter
(upper window) giving you a chance to display any two pieces of
information available at any time.
Once a Page display has been selected within a Chapter the same Page
will be displayed every rollover of the Chapter sequence ensuring that
you return to your choice of display within a maximum of 8 presses of
the (Chapter) button.
To move through the pages in chapter groups, press and hold . To
then move individually page by page, let go of and step forward
and back with a single press of and buttons.
mn100 Dual Digital Display
10
TIME
SPEED P1
VMG P2
VMG WP P3
LOG P4
TRIP P5
MAX SPD P6
AVG SPD P7
DEPTH P8
MIN DEPTH P9
MAX DEPTH P10
A SPDWIND P11
A ANG WIND
P12
TRU SPD WIND
P13
TRU ANGWIND P14
MAG TWDIR P15
BEAUF P16
LIFT P17
MAG HDG
P18
TACK
P19
SOG
P20
COG
P21
LAT
P22
LON
P23
BTW
P24
DTW
P25
XTE
P26
TTG
P27
SEA
P28
TIMER
P29
P30
DATE
P31
LOCK
P33
VOLTS
P32
Full Page Selection List Shown in Lower Window
(for a full description of each Page see page 12 -p1 to p33)

2.7 Chapter and Page Descriptions
Chapters
C1 Depth
The Actual Depth beneath the vessel as measured by the
Depth Transducer. The displayed value will be affected by
any keel or waterline offset added (see page 29).
C2 Apparent Wind Speed
The actual Wind Speed with respect to the vessel as
measured by the Wind Transmitter.
C3 Boat Speed
The vessels actual speed through the water as measured by
the Speed Transducer.
C4 Heading
Current Compass Heading of the vessel as measured by the
Compass Transducer. The value displayed will be affected by
the calibration routine for the compass (see page 32).
C5 True Wind Speed
The True Wind Speed with respect to the vessel, calculated
by the display taking into account the vessels speed through
the water. Both Apparent Wind Speed, Angle and Boat
Speed must be available for this calculation.
C6 Course Over the Ground
Course Over the Ground as calculated by the GPS Antenna.
C7 Bearing to Waypoint
Bearing To (active) Waypoint. The active Waypoint being the
one to which the GPS is currently navigating.
C8 PROG (Custom Chapter)
A Custom Chapter which allows you to select from a full list the
information you wish to display in the Chapter (upper) window (see page
26 -s35 for selection). This chapter is not displayed if no Custom
Chapter has been defined in Setup.
Operation
11

Pages
P1 Boat Speed
The vessels Actual Speed through the water as measured by
the Speed Transducer.
P2 Velocity Made Good to windward
The vessels calculated Speed Directly Upwind. This value is
calculated by the display from the Boat Speed and True Wind
Angle.
P3 Velocity Made Good to waypoint
The vessels calculated Speed directly towards the active
Waypoint. This value is calculated by the GPS Antenna.
P4 Log distance
The total distance travelled by the vessel since installation of
the display or since a Factory Reset.
P5 Trip distance
The distance travelled since the last Trip Reset.
To Reset see page 20 -s1.
P6 Maximum Speed (Identified by displayed KKTTSS/KKPPHH/MMPPHHicon)
The Maximum Speed attained since the last reset.
To Reset see page 20 -s4.
P7 Average Speed (Identified by displayed KKTTSS/KKPPHH/MMPPHHicon)
The Average Speed attained since the last reset.
To Reset see page 20 -s5.
P8 Depth
The Actual Depth beneath the vessel as measured by the
Depth Transducer. The displayed value will be affected by
any keel or waterline offset added (see page 29).
P9 Minimum Depth (identified by displayed FFTT/MM/FFTTMMicon)
The Minimum Depth encountered since switch on or since
the last Minimum Depth Reset. To Reset see page 20 -s2.
mn100 Dual Digital Display
12

P10 Maximum Depth (identified by displayed FFTT/MM/FFTTMMicon)
The Maximum Depth encountered since switch on or since
the last Maximum Depth Reset. To Reset see page 20 -s3.
P11 Apparent Wind Speed (identified by displayed KKTTSS/MMicon)
The Actual Wind Speed with respect to the vessel as
measured by the Wind Transmitter.
P12 Apparent Wind Angle
The actual Wind Angle with respect to the vessel as
measured by the Wind Transmitter.
P13 True Wind Speed (identified by displayed KKTTSS/MMicon)
The True Wind Speed with respect to the vessel, calculated
by the display taking into account the vessels speed through
the water. Both Apparent Wind Speed, Angle and Boat
Speed must be available on the network for this calculation.
P14 True Wind Angle
The True Wind Angle with respect to the vessel, calculated by
the display taking into account the vessels speed through
the water. Both Apparent Wind Speed, Angle and Boat
Speed must be available on the network for this calculation.
P15 True Wind Direction
The Actual Wind Direction over the water, calculated by the
display taking into account the vessels speed through the
water and compass heading. Apparent Wind Speed,
Direction and Compass Heading must be available on the
network for this calculation.
P16 Beaufort Wind Strength
The Actual Wind Speed over the water displayed using the
Beaufort scale, calculated by the display taking into account
the vessels speed through the water and compass heading.
Apparent Wind Speed, Direction and Compass Heading
must be available on the network for this calculation.
Operation
13

P17 Wind Shift, Head or Lift
Indicates changes in the wind against a compass heading.
Spotting these wind changes is the key to fast sailing upwind.
The system automatically detects the mean wind direction by
averaging over a time period of 2 minutes to 60 minutes (this
time period can be changed in setup). However, to manually overide this
automatic calculation and set the mean wind direction:
1. If a Wind Transmitter is included in your Micronet system then simply
press the button; (the current wind direction is stored as the
mean wind direction and displayed for 5 seconds during which time
the and buttons may be used to adjust the value.)
If the mean wind direction changes, press again.
2. If you do not have a Wind Transmitter included, sail close hauled and
press the button then tack and, once close hauled, press the
button again.
If the mean wind direction changes then the instrument may be
updated press and holding the button while sailing on port tack,
the button while sailing on starboard tack or the button
while head to wind.
See Raymarine’s “Using wind shifts to your advantage” sheet for further
information.
P18 Heading
Current Compass Heading of the vessel as measured by the
Compass Transducer. The value displayed will be affected by
the calibration routine for the compass (see page 32).
P19 Heading on opposite tack
Compass heading which the vessel will follow should it tack
through the wind, calculated by the display. Apparent Wind
Angle and Magnetic Heading must be available on the
network for this calculation to be made.
P20 Speed Over the Ground
Vessels Speed Over the Ground as calculated by the GPS
Antenna.
P21 Course Over the Ground
Vessels Course Over the Ground as calculated by the GPS
Antenna.
mn100 Dual Digital Display
14

P22 Latitude
Vessels current Latitude as calculated by the GPS Antenna.
P23 Longitude
Vessels current Longitude as calculated by the GPS
Antenna.
P24 Bearing to Waypoint
Bearing To (active) Waypoint. The active Waypoint being the
one to which the GPS is currently navigating.
P25 Distance to Waypoint
Distance To (active) Waypoint. The active Waypoint being the
one to which the GPS is currently navigating. When the
Waypoint has been named in the GPS the name will be
displayed (first five digits only).
P26 Cross Track Error
Cross Track Error as defined by the GPS Antenna.
P27 Time to Go to Waypoint
The time remaining before you will arrive at the (active)
waypoint as calculated by a GPS receiver or plotter.
P28 Sea Temperature
Current Sea Temperature as measured by the sensor in the
Speed Transducer.
Operation
15

P29 Timer
Countdown or elapsed time stopwatch.
Press and hold for 1 second the button and use the and
buttons to set the required countdown time in minutes.
Press the button quicklyto prepare to start the countdown.
Press the button quickly to start the countdown.
The display will sound a single beep each 60 seconds until 1 minute
remains when a beep will sound at 10 second intervals. The final 10
seconds will count down with a beep each second with “START” being
indicated by a triple quick beep at 0. The timer will automatically start to
count the elapsed time and this will continue until the button is
pressed and held for one second.
At any stage a quick press of the button will resynchronise the timer
to the nearest full minute and then carry on the count down.
Example: Press at 3mins 24secs the timer will reset to 3mins 0 secs
Press at 7mins 52secs the timer will reset to 8mins 0 secs
mn100 Dual Digital Display
16
Press and hold for 1
second to enter the
timer setup
Select the desired
countdown time
Press and hold for 1
second to store the
countdown time
Press to start Countdown time in
progress
Press to
resynchronise
to nearest full minute
(8:00)

Operation
17
P30 Time
Current Time as received from the GPS Antenna corrected to
local time if an offset has been added (see page 26 -s36).
P31 Date
Current date as received by the GPS Antenna.
P32 Volts
The voltage connected to the PWR input of the hull
transmitter or the Wireless (NMEA) Interface.
P33 Lock
Produces a “Trim” indication showing an increase or decrease in value
from a set point.
Select the appropriate chapter in the upper display using the
button.
Select “Lock” in the lower display using the or buttons.
Press the button to lock the upper display value, the
lower display will now indicate increase or decrease from the
set value.
Values displayed as units will show a percentage (%) increase or
decrease whereas values displayed as degrees will show the difference
in degrees.
Heading locked at 269onow
showing +008 change
meaning current heading is
277o
Speed locked at 8.69 kts
now showing +10% change
meaning current speed is
9.56 kts)

3 Setup and Calibration
3.1 Entering Setup and Calibration Mode
To enter the Setup and Calibration menu press and hold for 2 seconds
the button.
This will not work when in the Race Timer page.
3.2 Chapter and Page Setup and Calibration
Setup and Calibration is displayed in a “Chapter and Page” format using
the button to scroll through the Chapters and the and
buttons to move between Pages. The diagram below shows the
information format.
Unlike normal operation you must scroll to the Chapter heading
page before moving to another chapter.
3.3 Editing Values
To adjust any settings press the button. The setting will start to flash
and the and buttons will change the value. Then press the
button again to save the new setting.
mn100 Dual Digital Display
18
