RDMOTO Y36S Assembly instructions

RDMOTO CZECH REPUBLIC
[e-mail]
www.rdmoto.eu
1
Y36S
Yamaha R1 2015
Kit for left side: Kit for right side:
Instruction to assembly:
1. The first do assembly left side.
2. Take off Orignal bolt.
3. Leave all spacer´s/bushes in place.
4. Take the alu. spacer ID.1 for left side, insert bolt ID.2 into the spacer ID.1.
5. This kit gripping on the frame and tighten.
6. Place slide and tighten it by bolts ID.3, place alu. cover into the slider use bolts ID.4.
7. Mounting instruction for right side.
8. Take off Orignal bolt.
9. Please leave all spacer´s/bushes in place.
10. Take the alu. spacer ID.1 for right side insert bolt ID.2 into this kit.
11. This kit gripping on the frame and tighten.
12. Place slide and tighten it by bolts ID.3, place alu. cover into the slider use bolts ID.4.
Warning: We recommend use the glue of all threads. Medium strong.
ID
Description
Cat.N
QTY
1
Alu. spacer for SL
348
1
2
Bolt 12x95x1,25
900
1
3
Bolt M6x25
877
3
4
Bolt M4x16
876
2
ID
Description
Cat.N
QTY
1
Alu. spacer for SL
1137
1
2
Bolt M12x60x1,25
916
1
3
Bolt M6x25
877
3
4
Bolt M4x16
876
2
5
Alu. Roller d=5mm
1260
1
1
3
2
1
4
3
5
4
