RDMOTO CF79Y User manual

RDMOTO CZECH REPUBLIC
[e-mail]
www.rdmoto.eu
1
CF79Y
Yamaha MT07
LEFT SIDE KIT
RIGHT SIDE KIT
ID
Desription
Cat.no.
Pcs
ID
Description
Cat.No.
Pcs
1
Frame
1
1
Frame
1
2
Bolt M12x130x1.25
1027
1
2
Bolt M12x130x1.25
1027
1
3
Slider
SL01
1
3
Slider
SL01
1
4
SL adapter
1137
1
4
SL adapter
1137
1
5
Bolt M6x25
877
3
5
Bolt M6x25
877
3
6
Bolt M4x16
876
2
6
Bolt M4x16
876
2
7
Slider cover
CAPSL-Y
1
7
Bolt M10x40x1.25
941
1
8
Dural. roller d=45mm
1303
1
8
Dural. roller d=45mm
1303
1
9
Washer M10 flat
804
1
10
Slider cover
CAPSL-Y
1
We recommend to use safety glue on all threads(medium strong).
INSTRUCTIONS
1.) Unbolt original bolt from the frame of motorcycle.
2.) Fit upper part of frame with adapter ID4 and dural. roller ID8 using bolt M12.
3.) Unbolt original bolt from the the lower part of motorcycles frame.
4.) Fit left side using original bolt and right side using bolt M10x40.
5.) Fit slider using three bolts ID5 on the slider adapter.
6.) Fit cover using two bolts ID6.
Original bolt on the left,
bolt M10x40 on the right
+ washer M10
ID2
M12x130x1.25
ID8
