Rear view safety Go Vue RVS-020770 User manual

1
TM



  

LSTY
   2017 A Safe Fleet Brand

What’s in the Box?
• 1 Color CCD Infrared Weatherproof Camera
• Transmitter with power cable
• 3M sticker
2REAR VIEW SAFETY

3
Table of Contents
Introduction...................................................................................................4
Features...........................................................................................................5
Specifications............................................................................................67
Installation.....................................................................................................8
Operations ...............................................................................................914
Reverse With Confidence™

REAR VIEW SAFETY
4
Introduction
Thank you for purchasing our WiFi backup camera! The user man
ual has a detailed description on how to correctly use the WiFi
backup camera and provides detailed product information,
including operation, installation precautions and technical
specifications. Please read the manual carefully before using. We
hope you enjoy this system.
Please read all of the installation instructions
carefully before installing the product. Improper
installation will void manufacturer’s warranty.

5
Reverse With Confidence™
Features
Produc Fea ures
• WiFi Transmitter
• Wide View Camera with adjustable mounting bracket
• Weatherproof Camera
• Full night vision
• Easy installation
• DC 12V car power supply
• Unobstructed transmission distance is 100 feet
• Connects to iPhone, iPad and Android devices

REAR VIEW SAFETY
6
Specifications
Camera Specifica ions
ITEM SPECIFICATION
Camera 1/4 Sharp Color CCD
Picture Elements 250,000 pixels
amma Correction r=0.45 to 1.0
Image Sensor 480TV lines PAL:500(H)*582(V),
NTSC:510(H)*492(V)
Lens 2.1mm
View Angle 130°
Sync System Internal Synchronization
Infrared distance 50 Feet (18 Infrared)
Usable Illumination 0 Lux (IR On)
Power Source DC 12V24V (+/ 10%)
S/N Ratio More than 48dB
Electronic Iris 1/50, 1601/100,000sec
Video Output 1Vp.p 75ohm
IR Switch Control ACDS Automatic Control
Vibration and Shock Rating 20 / 100
Operating Temperature 30°C  80°C / RH 95% Max
Storage Temperature 30°C  60°C / RH 95% Max

7
Reverse With Confidence™
Specifications
Transmi er Specifica ions
ITEM SPECIFICATION
Transmitting frequency 2400MHz2483.5MH
Modem mode 802.11b: DSSS(CCK,DQPSK,DBPSK)
Transmission distance with no obstacle Max 100 feet
Frame rate 30fps
Video resolutions V A 640x480
Video compression H.264
Wireless protocols IEEE 802.11b, IEEE 802.11g
IEEE 802.n(1T1RModes)
Power supply DC 12V
Consumption current 150mA (Max)
Encryption mode WPA2
Rainproof Yes
Weight 60+5g
Tx Dimensions 45x75x18mm (excluding antenna)
Operation temperature 10°C~+50°C
Operation humidity 150%~85% RH

Installation instructions for the camera:
REAR VIEW SAFETY
8
Installation
No ice:
• The positive and negative pole of the power cable of the
transmitter box are connected to the positive and negative pole of
the rear lamp of the car.
• Never reverse the positive and negative pole. Otherwise the
transmitter box and the camera can be damaged and cannot be
used.
• Camera can also be connected to ignition power to view as long as
the vehicle is turned on.
1. Attach camera bracket close to rear marker lights, centered on
vehicle.
2. Attach camera to bracket using screws provided and adjust the
angle.

9
Reverse With Confidence™
Operations
Opera ions for Android sys em clien
• Ins alla ion of he APP sof ware:
1. Turn on the intelligent mobile device and enter the
OO LE PLAY store.
2. Search ” OVUE”™, and download.
3. Install the APP software, with the following interface:
• WiFi Connec ion:
1. Open your devices WiFi setting and locate the oVue Wifi.
2. Connect to the oVue WiFi™ (Default password: 12345678).
3. With the WiFi connected, open the oVue app.

10
• View he video:
Open the app , if the connection between the wifi of the
camera and the intelligent mobile device is successful, the icon
will be highlighted and you will be able to see the camera view as
shown.
REAR VIEW SAFETY
Operations
When the connection is bad, the icon will not be illuminated.

11
Operations
Reverse With Confidence™
Please exit the app and check power to the camera and WiFi
connection.
• Se ings:
Press this icon to enter into the settings menu. In this menu
you will be able to change the default factory SSID and password
of the WiFi camera.
When you see this image upon opening app

Notice
• User could press the RESET button on the transmitter to renew the
default factory SSID and password.
Opera ions for iOS Apple sys em clien
• Installation of the APP software:
1. Turn on the intelligent mobile device and enter the iPhone App
Store.
2. Search “ oVue”™, and download.
3. Install the APP software with the following interface:
REAR VIEW SAFETY
12
Operations

13
Reverse With Confidence™
Operations
• WiFi Connec ion:
1. Open your devices WiFi setting and locate the oVue™ Wifi.
2. Connect to the oVue™ WiFi (Default password: 12345678).
3. With the WiFi connected, open the oVue™ app.
• View the video:
Open the app and if the connection between the WiFi of the
camera and the intelligent mobile device is successful, you will be
able to see the camera view as shown in the figure.

REAR VIEW SAFETY
14
Operations
No ice:
When you see this image upon opening app
Please exit the app and check power to the camera and WiFi
connection.
• Se ings:
Press this icon to enter into the settings menu. In this menu you
will be able to change the default factory SSID and password of the
WiFi camera..
No ice:
• User could press the RESET buton of the transmitter to renew the
default factory SSID and password.
